Cisco Catalyst IW9167E Manual

Cisco Catalyst IW9167E Heavy Duty Access Point Hardware Installation

Guide

First Published: 2023-02-23

Last Modified: 2023-02-23

Americas Headquarters

Cisco Systems, Inc.

170 West Tasman Drive

San Jose, CA 95134-1706

USA

http://www.cisco.com

Tel: 408 526-4000

800 553-NETS (6387)

Fax: 408 527-0883

CONTENTS

Preface vii

PREFACE

About this Guide vii

Conventions vii

Related Documentation viii

Communications, Services, and Additional Information viii

Cisco Bug Search Tool viii

Documentation Feedback viii

About Cisco Catalyst IW9167E Heavy Duty Access Point 1

CHAPTER 1

Introduction to Cisco Catalyst IW9167E Heavy Duty Access Point 1

Cisco Catalyst IW9167E Heavy Duty Access Point Features 1

Connectors and Ports 2

4-Pin Micro-Fit Connector for DC Power 4

M12-RJ45 Adapter 4

M12-PWR Adapter 5

Power Sources 6

Power Adapters 6

Power Injectors 7

Ethernet (PoE) Ports 7

SFP Option 7

Antennas and Radios 8

Supported External Antennas 8

Unpacking Your Access Point 13

CHAPTER 2

Package Contents 13

Unpacking the Access Point 13

Cisco Catalyst IW9167E Heavy Duty Access Point Hardware Installation Guide

iii

Cisco Orderable Accessories 13

Installation Overview 17

CHAPTER 3

Performing a Preinstallation Configuration (Optional) 17

Preinstallation Checks and Installation Guidelines 19

Mounting the Access Point 20

Mounting Hardware 20

Mounting Bracket Part Numbers 20

Using the Integrated Flange Mounts 20

Using the DIN Rail Mounting Bracket 22

Using the Pole Mounting Bracket 24

Using the Mounting Bracket AIR-ACCPMK3700= 24

Using the Mounting Bracket AIR-ACCPMK3700-2= 25

Attaching a Power Adapter 30

Attaching a Power Adapter Using the Mounting Bracket AIR-ACCPMK3700= 30

Attaching a Power Adapter Using the Mounting Bracket AIR-ACCPMK3700-2= 31

Installing a Lightning Arrestor 33

Lightning Arrestor Installation Notes 33

Grounding the Access Point 34

Powering the Access Point 36

Power Feature Matrix 36

Connecting a Power Injector 37

Connecting to the DC Power Port Using Cable Gland 37

Connecting DC Power Port Using M12 Adapter 39

Connecting Data Cables 41

Connecting an Ethernet Cable to the Access Point 41

Connecting to the RJ-45 Port Using Cable Gland 41

Connecting to the RJ-45 Port Using M12 Adapter 42

Connecting to the SFP Port of the Access Point 44

Connecting to SFP Port Using Cable Gland 44

Using M12 Adapter on SFP Port 46

Configuring and Deploying the Access Point 49

CHAPTER 4

Controller Discovery Process 49

Cisco Catalyst IW9167E Heavy Duty Access Point Hardware Installation Guide

Contents

Deploying the Access Point in a Wireless Network 50

Checking the Access Point LEDs 50

Troubleshooting 53

CHAPTER 5

Using the Reset Button 53

Troubleshooting the Access Point to Controller Join Process 54

Important Information for Controller-based Deployments 54

Configuring DHCP Option 43 54

Safety Guidelines and Warnings 57

CHAPTER 6

Safety Instructions 57

FCC Safety Compliance Statement 58

Safety Precautions 58

Safety Precautions when Installing Antennas 59

Avoiding Damage to Radios in a Testing Environment 59

Performing Site Surveys 60

Declarations of Conformity and Regulatory Information 63

CHAPTER 7

Manufacturers Federal Communication Commission Declaration of Conformity Statement 63

Operation of Cisco Catalyst Access Points in México 64

VCCI Statement for Japan 64

Statement 191—Voluntary Control Council for Interference (VCCI) Class A Warning for Japan 64

ステートメント 191—日本向けVCCI クラス Aに関する警告 65

Guidelines for Operating Cisco Catalyst Access Points in Japan 65

Compliance Statement for Canada 66

Industry Canada 66

European Community, Switzerland, Norway, Iceland, and Liechtenstein 67

Declaration of Conformity for RF Exposure 67

Generic Discussion on RF Exposure 67

This Device Meets International Guidelines for Exposure to Radio Waves 68

This Device Meets FCC Guidelines for Exposure to Radio Waves 68

This Device Meets the Industry Canada Guidelines for Exposure to Radio Waves 68

Cet appareil est conforme aux directives internationales en matière d'exposition aux fréquences

radioélectriques 69

Cisco Catalyst IW9167E Heavy Duty Access Point Hardware Installation Guide

Contents

Additional Information on RF Exposure 69

Declaration of Conformity Statements 70

Cisco Catalyst IW9167E Heavy Duty Access Point Hardware Installation Guide

Contents

Preface

This preface describes this guide and provides information about the conventions used in this guide, and

Related Documentation

CHAPTER 1

About Cisco Catalyst IW9167E Heavy Duty Access

Point

•Introduction to Cisco Catalyst IW9167E Heavy Duty Access Point, on page 1

•Cisco Catalyst IW9167E Heavy Duty Access Point Features, on page 1

•Connectors and Ports, on page 2

•Power Sources, on page 6

•SFP Option, on page 7

•Antennas and Radios, on page 8

Introduction to Cisco Catalyst IW9167E Heavy Duty Access Point

The Cisco Catalyst IW9167E Heavy Duty Access Point is a tri-band 802.11ax (Wi-Fi 6) AP that provides

reliable wireless connectivity for mission-critical applications as organizations automate processes and

operations. It can operate as Wi-Fi 6 or Cisco Ultra-Reliable Wireless Backhaul (Cisco URWB). Wi-Fi 6

technology brings higher density, higher throughput, more channels, power efficiency, and improved security

in industrial or outdoor locations. Cisco URWB provides ultra-reliable wireless connectivity for moving assets

or to extend the network where running fiber isn’t feasible or is too costly.

The Cisco Catalyst IW9167E Heavy Duty Access Point comes with three 4x4 radios, in a heavy-duty design

that is IP67 rated, and packed with advanced features.

A full listing of the AP's features and specifications is provided in the Cisco Catalyst IW9167E Heavy Duty

Access Point Data Sheet.

Cisco Catalyst IW9167E Heavy Duty Access Point Features

Cisco Catalyst IW9167E Heavy Duty Access Point is supported on Cisco Catalyst 9800 wireless

controller-based products, and have the following features:

• 2 GB DDR4 memory, 1 GB NAND Flash

• Tri-radio, dual band support: 2.4 GHz Slot 0, 5 GHz Slot 1, and 5 GHz Slot 2

• 4 x 4 MIMO with up to 4 spatial streams

Cisco Catalyst IW9167E Heavy Duty Access Point Hardware Installation Guide

• 8 x N-type female connectors for Wi-Fi, 1x TNC female for GNSS, multi-protocol loT radio, Aux radio,

Barometer

• Bluetooth Low Energy (BLE) radio enables IoT use cases such as location tracking and wayfinding

• Client or AP mode – Cisco URWB, WGB, or AP

• 1 x multi-Gigabit (mGig) copper Ethernet port (supporting PoE, including IEEE 802.3at/bt, Cisco UPoE,

100 Mbps/1 Gbps/2.5 Gbps/5 Gbps)

• 1 x SFP interface – supports up to 10 Gbps

For 10G SFP fiber module, Cisco PID SFP-10G-LR10-I has guaranteed

performance with IW9167EH access point.

Note

• Optional M12 adapter for network and power interfaces

• Dual power input options – PoE-in and 24 - 48VDC

• Water and dust resistance – IP 66/67

• Hardened for shock, vibration, and extreme temperatures

• Operating temperature: -40°C to 70°C without solar loading. Support cold start at -40°C and extend

working at -50°C.

Connectors and Ports

The following figures show the available ports on the AP.

Cisco Catalyst IW9167E Heavy Duty Access Point Hardware Installation Guide

About Cisco Catalyst IW9167E Heavy Duty Access Point

Connectors and Ports
