7.Counterfeit Detection
number can be increased 10 by 10 every time>. While press the
"FUNC./-1" button, it will decrease 1 by 1.the batch number can be
set in amounts between 1 and 999 by pressing“RESET/+10”or
“FUNC/-1”button.
To clear this function, press the“ADD/BATCH”button until the
indicator is off.
--Under the batch counting mode, once the hopper is loaded, the
machine will start counting and stop when the counted quantity
reaches the preset batch quantity.
--To repeat the batch counting operation under the same preset batch
quantity, just remove the counted bill from the stacker.
The unit will batch the next group of bills under the same settings.
--If you wish to keep batching without removing the preset number,
press the“RESET/+10”button.
--If the counted number does not tally with the preset batch number,
the counter display will show the quantity with blinking number.
--When counting with MG and/or UV detection on, the machine will
stop automatically when detecting counterfeit currency. This
function can be resumed by removing the dubious bill from the
stacker and pressing “RESET/+10” button.
Figure 1 Figure 2 Figure 3
--Bills should be correct placed as indicated in the following steps:
Place the bills between the counting guides as shown in the figure1
and figure2. Swiftly, push the bills with a figure <see figure3> to make
them rest on the top of the hopper plate, in the correct counting
position.
2>Addition Function
--Addition can be performed by pressing the“ADD/BATCH”button
(Press this button one time, the ADD indicator will light on the function
display).In this case, removing the counted bills from the stack will not
clear the quantity counted and shown on the counter display. The next
bills placed in the hopper will be counted and added to the preceding
quantity. The total amount of added bills will be shown on the counter
screen. Press the “ADD/BATCH”button to close the function and
clear the count.
3>Batch Function
--The preset batch function can be performed by pressing the “ADD/
BATCH
” bu
tto
n<P
res
s two ti
mes
, the BATC
H ind
ica
tor w
ill li
ght o
n
the function display>. By default, when pressing the“RESET/+10”
button, the batch number is set to 10. By pressing it again, the batch
<UV(Ultraviolet) detection function <avail able for the model with UV
detection or the model with b oth UV and MG detections>
---used to check all kinds of banknotes which contains UV features.
--Press "FUNC./-1"one time to turn on the UV ( the UV indicator will
be light on the function display) .
--If the machine detects a counterfeit note when counting, it will stop
5.Power up
6.Counting function
c.I f the unit has been expo sed to rain or wa ter.
d.I f the mach ine has been dropped or the case has been damaged.
e.If the produ ct shows a noticeable change in pe rformanc e.
--To reduc e the risk of electric shock, do no t di sasse mble this pro duct.
Ta ke it to quali fied serv ice perso nnel when service or re pair work is
re quire d. Openin g or removing covers ma y ex pose you to da ngero us
vo ltage s or other risks . Incorrect reass embly can cause electric shock
wh en the appli ance is su bsequently used.
--Do not use the unit if the power cord is damaged or if the plug socket
contact is loose. Not following these instructions may result in electric
shock , fire or other hazards.
--When unplugging the power plug, do not pull it by the cord but rather
grip the plug and pull it out, not following those instruction may result
in electric shock, fire or damage to the unit.
Connect the power cord to the machine (power outlet), then plug it to
power source and turn the switch on; the unit will conduct a self-check
by spanning the feeding roller while the MG and/or UV functions will be
automatically turned on by default. The counts display will show “0”
when the unit is ready <the machine is in its normal working condition>.
1>Counting Function
--Once the bills are correctly placed in the hopper, the machine will start
counting automatically. The number of counted bill will be shown on the
counter display. Moreover, once the bills are removed from the stacker,
the counter display will clear and the batch display in turn will show the
number of counted bills instead.
and emit beeping sound, while the display screen will show the
message "EE1" and the UV indicator will blink (alerting the user the
presence of a dubious bill). The dubious bill will always be the last
one on the stacker. Remove the dubious bill, press "RESET/+10"
button to continue.
<MG (Magnetic) detection function<available for the the models with
both UV and MG detections>
---used to check all kinds of banknotes which contains MG features.
--Press "'FUNC./-1" two times to turn on the MG( the MG indicator
will be light on the function display).
--If the machine detects a counterfeit note when counting, it will stop
and emit beeping sound, while the batch display will show the
message EE2? and the MG indicator will blink (alerting the user the
presence of a dubious bill). The dubious bill will always be the last
one on the stacker. Remove the dubious bill, press "RESET/+10"
button to continue.
<Double-notes Detection Function <available for the models with
UV detection or the model with both UV and MG detection>
---used to check a double-note
--By default, serving as a supplementary function, this detection can
be activated when the unit is powered up.
--If the machine detects a double-note when counting, it will stop and
emit beeping sound, while the display screen will show the message
“EE4” (alerting the user the presence of a double-note). The double-
note will always be the last one on the stacker. Remove the dubious
bill, press “RESET/+10” button to continue.
