CHIEF Hospitality Solutions User manual

HOSPITALITY SOLUTIONS

professional av mounts

Why Chief?

Chief mounts appear in the

ﬁnest hotels and casinos around

the world, providing end users

the ultimate guest experience

and comforts of home. An

industry leader for more than

30 years, Chief’s innovative AV mounting solutions

are ideal for guest rooms, hanging quietly in

lobbies and common areas, or securely supporting

technology in the outdoors.

Chief is not just a mount provider, but also an

industry partner providing valuable resources to

ensure a complete state-of-the-art solution – from

placement and aesthetics to full integration.

Largest line of mounting solutions worldwide

Chief offers the broadest line of solutions and

supporting accessories worldwide. We aggressively

evolve our products with changing technology, to

ensure that we are at the forefront of the industry.

Top quality products, fast installation

Chief builds unique features into every mount,

focusing on speed of installation while providing

end users with the best in form and function. Our

mounts are shipped fully assembled, and backed by

an expert Technical and Customer Service Team.

year

Multiple levels of assistance

Chief is fully staffed to handle projects of

varying complexity, in a wide range of

applications. Dedicated technical and

design resources work with you to create

the perfect solution on time and within

budget. From custom mounts to fully-

integrated audio visual solutions, we can

assist with as much or as little as you like.

State-of-art standard product mix,

including custom and universal

interfaces, and UL Listed designs

A Display Solutions Team that is

capable of generating completely

unique mounting solutions

Skilled, on-site consulting services

for larger projects

Custom kitting to assist with

sourcing of all aspects of your

installation through Chief - from ﬂat

panel TVs and projectors to cables

and power conditioners

Hospitality Solutions for:

nGuest Rooms

nBathrooms

nLobbies

nConference Rooms

nBars and Restaurants

nOutdoor Patios

nGaming/Casinos

Flat Panel Wall Mounts FSR™nFixed Wall Mount

nLow-proﬁle solution, only 0.75”

(19 mm) deep

n0.5” (13 mm) left/right lateral shift

nVESA 75 x 75 mm and 100 x 100 mm

nAvailable in black

26”

45 lbs

MSR™nFixed Wall Mount

nLow-proﬁle solution, 1.25”

(32 mm) deep*

n1.5” (38 mm) left/right lateral shift

nRapid Level™System for fast,

hands-free leveling on wall

nAvailable in black

50”

125 lbs

PST™nFixed Wall Mount

nLow-proﬁle solution, 1.21”

(31 mm) deep*

n4” (102 mm) left/right lateral shift

nRapid Level™System for fast,

hands-free leveling on wall

nAvailable in black

65”

200 lbs

*Depth does not include interface bracket

Common Applications

Guest Room

Bathroom

Common Area

Lobby

Restaurant/Bar

(20.4 kg)

(56.7 kg)

(90.7 kg)

FTR™nTilt Wall Mount FWS™nSingle Swing Arm

n+5/-15˚ smooth ﬁngertip tilt

nLow-proﬁle solution, 1.95”

(50 mm) deep

n0.5” (13 mm) left/right lateral shift

nVESA 75 x 75 mm and 100 x 100 mm

nAvailable in black

nExtends 9.44” (240 mm) and pivots

up to 180˚ for broad range of motion

n+/-15˚ Centris™Fingertip Tilt

nIn-arm cable channels conceal and

protect cables

nAvailable in black and silver

26”

45 lbs

26”

40 lbs

MTR™nTilt Wall Mount MPW™nDual Swing Arm

n15˚ tilt adjustment

n1.5” (38 mm) left/right lateral shift

nRapid Level™System for fast,

hands-free leveling on wall

nAvailable in black

nExtends 8.75” (222 mm) and swivels

up to 45˚ for broad range of motion

nLow-proﬁle solution, only 1.5”

(38 mm) deep in home position*

nIntegrated lateral shift

nAvailable in black and silver

50”

125 lbs

50”

100 lbs

PLP™nPull-N-Tilt™Wall Mount PDR™nDual Swing Arm

n15˚ smooth ﬁngertip tilt

nLow-proﬁle solution, 1.8”

(46 mm) deep*

nBottom pulls out 3” (76 mm) for

easy cable access and routing

nAvailable in black

nExtends 37.38” (949 mm) and swivels

up to 90˚ for broad range of motion

n+5/-15˚ Centris™Fingertip Tilt

nIn-arm cable channels conceal and

protect cables

nAvailable in black and silver

65”

200 lbs

65”

200 lbs

(20.4 kg)

(56.7 kg)

(90.7 kg)

(18.1 kg)

(45.4 kg)

(90.7 kg)

Table Stands MTS™nBolt-Down Table Stand

nSecure bolt-down design

nKeyed locking options

nSwivel of +/- 10˚, 20˚, 30˚, 40˚or 270˚

nQuick-connect/disconnect for fast

installation and service

nAvailable in black and silver

45”

100 lbs

MSS™nSwivel Table Stand

n+/-45˚ swivel with optional stops at

+/-15˚, 25˚ or 35˚

n5” (127 mm) height adjustment for

screen heights up to 32” (813 mm)

nTwo cable management options

nAvailable in black and silver

50”

125 lbs

MPO™nPull-Out Swivel Mount

nFor new or retroﬁt cabinet and

armoire installations

n5.5” (140 mm) SmoothGlide™

extension for better viewing angle

n15˚ yaw left and right of center

nAvailable in black

40”

130 lbs

Also Available: PSS™Swivel Table Stand for large ﬂat

panel TVs up to 50” and 175 lbs (79.4 kg)

Common Applications

Guest Room

Common Area

Conference Room

(45.4 kg)

(56.7 kg)

(59 kg)

MF1™nDisplay Stand

n4’ - 7’ (1.2 m - 2.1 m) telescoping

height adjustment

n+/-15˚ Centris™Fingertip Tilt

nClickConnect™Technology conﬁrms

ﬂat panel is secure - no tools or levers

nAvailable in black and silver

50”

125 lbs

MFC™nMobile Cart

n4’ - 6’ (1.2 m - 1.8 m) telescoping

height adjustment

n+/-15˚ Centris™Fingertip Tilt

nClickConnect™Technology conﬁrms

ﬂat panel is secure - no tools or levers

nAvailable in black and silver

Also Available: PF1™Display Stand for extra-large ﬂat

panel TVs up to 65” and 200 lbs (90.7 kg)

Also Available: PFC™Mobile Cart for extra-large ﬂat

panel TVs up to 65” and 200 lbs (90.7 kg)

Display Carts & Stands

Common Applications

Common Area

Lobby

Conference Room

(56.7 kg)

50”

125 lbs

(56.7 kg)

Automated Mounts CM1W18™nSwing Arm Mount

nExtends 18” (457 mm) and swivels up

to 50˚ for a broad range of motion

nCollapses to 4.25” (108 mm) with a

recessed installation

n3 progammable viewing positions

nAvailable in black

61”

170 lbs

CM7W12™nSwing Arm Mount

nExtends 12” (305 mm) and swivels up

to 28˚ for a broad range of motion

n2 programmable viewing positions

nEasy on-wall installation with

decorative cover for a ﬁnished look

nAvailable in black

63”

180 lbs

Common Applications

Guest Room

Common Area

Lobby

Conference Room

(77.1 kg)

(81.6 kg)

CM2L40™nPop-Up Lift CM3T45™nSwivel Table Stand

nTravels up to 40” (102 cm) with a

stored height of only 31” (787 mm)

nProvides quick, quiet travel at over 2”

(51 mm) per second

nIntegrated cable management

nAvailable in black

n+/-45˚ automated swivel with optional

stops at 15˚, 25˚ and 35˚

n5” (127 mm) height adjustment

nFree standing base with bolt-down

capability for increased security

nAvailable in black and silver

61”

190 lbs

50”

125 lbs

CM2C40™nCeiling Lift

nTravels up to 40” (102 cm) with a

stored height of only 31” (787 mm)

nProvides quick, quiet travel at over 2”

(51 mm) per second

nIntegrated cable management

nAvailable in black

61”

190 lbs

(86.2 kg)

(56.7 kg)

Furniture JFA36e™nAV Cabinet

nVersatile 5-shelf design

nAdjustable shelves accommodate

any size AV system

nConvection cooling system keeps AV

components at proper temperature

nAvailable in Espresso

32”

JFV65e™nLowboy Cabinet

nVersatile 3-shelf design

nAdjustable, tempered glass shelves

accommodate any size AV system

nSliding glass doors provide easy

access to AV components

nAvailable in Espresso

80”

275 lbs

JFBD1e™nBackdrop

nMounts directly to back of JFV65e

Lowboy; supports large and

extra-large ﬂat panel wall mounts

nGrade A hardwood veneers and solid

frame provide stability and style

nAvailable in Espresso

63”

100 lbs

Common Applications

Guest Room

Common Area

(45.4 kg)

(124.7 kg)
