DRIVER INFORMATION

Instrument Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2

Instrument Panel Cluster . . . . . . . . . . . . . . . . . . . . . .3

Driver Information Center . . . . . . . . . . . . . . . . . . . . .4

SAFETY & SECURITY

Programmable Automatic Door Locks . . . . . . . . . . .5

Remote Lock/Unlock Feedback . . . . . . . . . . . . . . . . .6

OnStar

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7

Remote Keyless Entry System . . . . . . . . . . . . . . . . .7

Content Theft-Deterrent System . . . . . . . . . . . . . . . .8

COMFORT

Manual Dual-Zone Climate Controls . . . . . . . . . . . . .8

Automatic Dual-Zone Climate Controls . . . . . . . . . .9

Electric Adjustable Pedals . . . . . . . . . . . . . . . . . . . .10

Heated Seats . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10

Memory Seats . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10

ENTERTAINMENT

AM/FM Stereo with CD and RDS . . . . . . . . . . . . . . .11

AM/FM Stereo with Six-Disc CD . . . . . . . . . . . . . . .12

Touch Screen Navigation

Entertainment System . . . . . . . . . . . . . . . . . . . . . . .13

CONVENIENCE

Headlamp Controls . . . . . . . . . . . . . . . . . . . . . . . . . .13

Automatic Lamp Control . . . . . . . . . . . . . . . . . . . . .14

Dome Lamp Override . . . . . . . . . . . . . . . . . . . . . . . .14

Outside Rearview Mirrors . . . . . . . . . . . . . . . . . . . .15

Universal Home Remote . . . . . . . . . . . . . . . . . . . . .15

Sun Visors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15

Sunroof . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16

Luggage Carrier . . . . . . . . . . . . . . . . . . . . . . . . . . . .16

PERFORMANCE & MAINTENANCE

Malfunction Indicator Lamp . . . . . . . . . . . . . . . . . . .17

Four-Wheel Drive . . . . . . . . . . . . . . . . . . . . . . . . . . .17

StabiliTrak

– Stability Control System . . . . . . . . .17

Tire Pressure Monitor . . . . . . . . . . . . . . . . . . . . . . . .18

OWNER INFORMATION

Roadside Assistance . . . . . . . . . . . . . . . . . . . . . . . .20

My GMLink . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20

Congratulations on your purchase of a Chevrolet TrailBlazer. Please read this information and your Owner

Manual to ensure an outstanding ownership experience. Note that your vehicle may not include all the

features described in this booklet. Keep this booklet with your Owner Manual for easy reference.

A. Exterior Lamp Controls

B. Air Outlets

C. Turn Signal/Multifunction Lever

D. Instrument Panel Cluster

E. Ignition Switch

F. Transfer Case Controls or Traction

Control Button (if equipped)

G. Rear Window Washer/Wiper

H. Audio System

I. Climate Controls

J. Hood Release

K. Ashtray (if equipped)

L. Shift Lever

M.Lighter (if equipped)

N. Accessory Power Outlet

O. Rear Window Defogger

(if equipped)

P. Glove Box

Getting to Know Your TrailBlazer

See Section 3 of your Owner Manual.

Instrument Panel

DRIVER INFORMATION

See Section 3 of your Owner Manual.

BCD

Instrument Panel Cluster

Your vehicle’s instrument panel is

equipped with this cluster or one very

similar to it. The instrument panel

cluster includes these key features:

A. Tachometer

B. Speedometer

C. Engine Oil Pressure Gauge

D. Fuel Gauge

E. Voltmeter

F. Engine Coolant Temperature

Gauge

Note: The instrument panel cluster is

designed to inform you about many

important aspects of your vehicle’s

operation. It is important to read your

Owner Manual and become familiar

with the information being relayed to

you by the lights, gauges and indicators,

as well as what action can be taken to

ensure safety and to prevent damage

to your vehicle.

Getting to Know Your TrailBlazer

Reset fuel information

• Press the reset stem located on the

DIC cluster or the reset button on the

steering wheel.

Customize vehicle settings

• Press once and current-driver

preferences will be displayed. Any

changes made at this time affect only

the displayed driver.

• Press again to scroll through and

customize menu features.

Use Reset button

•When you find the choice you want,

press to select it and move on to

the next feature.

Reset all customization features to

their default settings

•Press and hold the Trip Information

button ( ) and the Customization

button ( ) for four seconds.

Recall driver preferences

•Press memory button #1 or #2

located on the driver’s door.

Driver Information Center (DIC)

(if equipped)

The DIC display is located above the

steering wheel on the instrument cluster,

and can be programmed in three lan-

guages. The controls are located on the

steering wheel:

Access trip information

• Press to access each of the

odometer, Trip A, Trip B and Timer

functions.

Reset trip odometers to zero

•Press the reset stem located on the

DIC cluster or use the reset button

( ) on the steering wheel.

Access fuel information

•Press to view range, average fuel

used and the GM Oil Life SystemTM

status.

Available Customization Features

Depending on the equipment ordered

on your vehicle, you could customize a

wide variety of preferences on the DIC.

Only the features included on your vehi-

cle will be displayed by the DIC.

Customization features can include:

• Alarm Warning Type

• Automatic Locking and Unlocking

• Perimeter Lighting

• Remote Lock and Unlock Feedback

• Headlamps On at Exit

• Mirror Curb View Assist

• Easy Exit Driver Seat

• Display Units (English/Metric)

• Display Language

See Section 3 of your Owner Manual.

Programmable Automatic

Door Locks

Your vehicle includes an automatic door

lock/unlock system with a choice of four

features, as well as automatic door lock-

out prevention to prevent locking the

keys in the vehicle. In the event the

power door lock switch is activated

when a door is open and the key is in

the ignition, the driver door will unlock.

Locking options: The default setting

for the programmable automatic door

locks is to lock automatically when the

transmission is shifted into gear. Locking

options include:

Mode 1: All doors lock when the trans-

mission is shifted into gear

Mode 2: All doors lock when vehicle

speed is over 8 mph (13 kph)

Unlocking options: Choose one of the

following options before personalizing

your unlocking preference:

Mode 1: Driver’s door unlocks when the

transmission is placed into Park

Mode 2: All doors unlock when the

transmission is shifted into Park

Mode 3: All doors unlock when the key

is removed from the ignition

Mode 4: No automatic door unlock

SAFETY & SECURITY

Getting to Know Your TrailBlazer

Remote Lock/Unlock Feedback

(if equipped)

Program Remote Keyless Entry

System lock/unlock feedback (horn,

parking lamps, both or neither)

• Press the Personalization button

( ) on your steering wheel until

LOCK FEEDBACK (or UNLOCK

FEEDBACK, as desired) appears on

the display.

• Press the Select button ( ) to scroll

through the menu of choices. To

program the lock/unlock feedback

feature, press when the desired

menu option is displayed.

See Section 3 of your Owner Manual.

Select and program functions

(if vehicle is equipped with a Driver

Information Center)

• Press the personalization button

( ) on the Driver Information Center

until LOCKS appears on the display.

Press the Select button ( ) until the

desired setting appears on the dis-

play and press to select it.

Select and program functions (if not

equipped with DIC)

1. With ignition off, pull the turn

signal/multifunction stalk toward you

and hold it there while performing the

next step.

2. Turn the ignition key to Run and Lock

twice, ending in the Lock position,

and release the turn signal stalk; the

lock switch locks/unlocks, the horn

chirps twice and a 30-second timer

begins.

3. To cycle through the locking/unlock-

ing choices, press the power door

lock switch to the Lock position to set

locking preference and the Unlock

position to set unlocking preference.

When the lock switch locks/unlocks

and the horn chirps twice, you have

left programming mode; if more time

is needed, repeat the process above.

4. To exit the program mode manually,

turn the ignition key to Run.

See Section 2 of your Owner Manual.

If your vehicle is OnStar-equipped, the

OnStar system provides in-vehicle safe-

ty, security, and phone services, avail-

able 24 hours a day, 7 days a week.

These services are easily accessed

through the three OnStar buttons in

your vehicle.

• Press the blue OnStar button to

connect to an OnStar Advisor for

services such as OnStar Vehicle

Diagnostics or driving directions

and location assistance.*

• Press the white Phone button to

make phone calls using OnStar

Hands-Free Calling.**

• Press the red Emergency button to

connect to an OnStar Advisor who

can contact a nearby emergency

services provider to request emer-

gency services be dispatched to

your location.

For more information about OnStar

features, refer to the OnStar Owner’s

Guide and enclosed audio CD located in

your glove box.

* Routing and location assistance may require service

upgrade

**Available in most markets

See Section 2 of your Owner Manual.

OnStar®(if equipped) Remote Keyless Entry System

(if equipped)

On equipped vehicles, the RKE system

locks and unlocks the doors and liftglass

from a range of three to 30 feet. At times

the range may be shorter than usual,

which is normal. If the transmitter does

not seem to be working properly:

• Ensure that you are within transmitter

range of the vehicle. Rainy and

snowy weather can reduce transmit-

ter range.

• Check to see whether other vehicles

or obstacles are blocking the trans-

mitter signal by stepping a few feet

to the left or right, and holding the

transmitter higher when pressing

the button(s).

• Consider the length of time that

the transmitter battery has been in

service and replace it if necessary

(the DIC will display RFA BAT # LOW

if the battery needs replacing). Use

CR 2032 battery or equivalent.

See Section 2 of your Owner Manual.

COMFORT

Getting to Know Your TrailBlazer

Manual Dual-Zone Climate

Controls (if equipped)

Content Theft-Deterrent System

(if equipped)

This feature has a Security light ( )

located in the instrument panel cluster.

After closing all vehicle doors, the

system can be activated in two ways:

• Press the Lock button on the Remote

Keyless Entry key fob, or

• Press the power door Lock switch

with the door open.

The alarm is not armed until the

security light turns off (after a delay of

approximately 30 seconds).

If the alarm is tripped, the horn sounds

for 30 seconds, and the headlamps and

parking lamps also flash for two minutes

to get visual attention. The alarm sounds

whenever a locked door is opened

without the key or Remote Keyless

Entry transmitter.

See Section 2 of your Owner Manual.

( ) Instrument panel vents

( ) Instrument panel vents and

floor vents

( ) Floor vents

( ) Floor, windshield and side

window vents

( ) Windshield and side window

vents

Raise or lower fan speed

• Turn the fan control knob ( ) on the

left of the climate control panel.

Adjust the dual temperature controls

• Use the lever on the left-hand side of

the climate control panel to adjust the

temperature on the driver’s side of

the vehicle.

• Use the right-hand lever to adjust the

temperature on the front passenger’s

side of the vehicle and the tempera-

ture for the second row.

Cool the vehicle interior more quickly

on very hot days

• Open the windows just long enough

to let the hot air escape.

• Choose the coolest temperature

setting.

• Activate the Recirculate ( ) and

A/C ( ) buttons.

• Place the A/C mode knob in the ( )

Vent mode.

Recirculate interior air and prevent

outside air from entering your vehicle

• Press the Recirculate ( ) button.

This feature can be activated while in

the Vent or Bi-Level mode, but not in

Defog, Defrost or Floor mode.

Select airflow source

• Turn the Mode knob on the right of

the climate control panel to the

desired setting:

Automatic Dual-Zone Climate

Controls (if equipped)

Turn on the rear window defogger

• Press the rear window defogger

(REAR) button.

• The indicator light on the button will

come on to let you know the rear

window defogger is active.

See Section 3 of your Owner Manual.

Manually select desired airflow source

• Press and release the Mode ( )

button until the desired source is

indicated on the display. Mode selec-

tions include Vent, Bi-Level, Floor

and Defog.

Manually raise or lower fan speed

• Press the upper or lower portion of

the fan control ( ) button.

Manually adjust the dual temperature

controls

•Use the knob on the left-hand side of

the climate control panel to adjust the

temperature on the driver’s side of

the vehicle. Use the right-hand knob

to adjust the temperature on the pas-

senger’s side of the vehicle as well

as the second row.

• To match and link the passenger-side

temperature to the driver’s, press and

hold the AUTO button for three seconds.

Recirculate interior air and prevent

outside air from entering your vehicle

• Press the Recirculate ( ) button.

This feature can be activated while in

the Vent or Bi-Level mode, but not in

Defog, Defrost or Floor mode.

Clear the windshield and front side

windows of fog or frost more quickly

• Press the button and adjust the

fan speed.

Clear the rear glass of fog or frost

more quickly, and activate the heated

outside rearview mirrors (if equipped)

• Press the Rear button.

• The indicator light on the button will

come on to let you know the rear

window defogger is active.

Automatic Operation

In the automatic mode, the system

will automatically control the inside

temperature, air delivery mode and

the fan speed to achieve your set

temperature as quickly as possible.

1. Press the AUTO button.

2. Set the driver’s and passenger’s

temperatures.

Rear Seat Controls (if equipped)

Rear seat comfort controls are located

on the rear seat audio system display.

When the front climate control MODE

button is set to Defrost, the rear controls

do not function.

See Section 3 of your Owner Manual.

Getting to Know Your TrailBlazer

Heated Seats (if equipped)

Activate heat for the seatback only

•Press the vertical switch located on

the front door armrest until the switch

light indicates the desired setting.

Memory Seats (if equipped)

The memory seat controls are located

on the driver door. They program and

recall driver seat position and outside

mirror settings for up to two drivers.

Store the driver seat and mirror

settings

1. Adjust the seat and outside mirrors to

the desired position.

2. Press and hold memory button #1 for

three seconds until a chime sounds

to indicate that the seat position is

now stored.

Repeat the sequence using memory

button #2 for a second driver.

See Section 2 of your Owner Manual.

Electric Adjustable Pedals

(if equipped)

Adjust brake and accelerator pedals

to a comfortable setting

• Operate the pedal adjustment switch

located on the steering column.

See Section 2 of your Owner Manual.

Note: The pedals cannot be positioned

farther away from the driver than they

are in their standard position. This fea-

ture can be programmed to work with

the memory function (if equipped) on

your vehicle. Adjustment of the powered

pedals requires that the vehicle be in

Park and the key be out of the ignition.

Activate heat for seatback and seat

cushion

• Press the horizontal switch located on

the front door armrest until the switch

light indicates the desired setting.

See Section 1 of your Owner Manual.

Note: The engine must be running for

the heated seat feature to work.

Other manuals for 2007 TrailBlazer

Table of contents

Other Chevrolet Automobile manuals

Chevrolet

Chevrolet Pontiac Pursuit 2005 User manual

Chevrolet

Chevrolet 2009 Aveo User manual

Chevrolet

Chevrolet AVEO - S User manual

Chevrolet

Chevrolet 2014 CORVETTE User manual

Chevrolet

Chevrolet 2005 Tahoe Assembly instructions

Chevrolet

Chevrolet 2006 TrailBlazer Assembly instructions

Chevrolet

Chevrolet 2010 HHR User manual

Chevrolet

Chevrolet VOLT 2012 User manual

Chevrolet

Chevrolet 2004 Express Van User manual

Chevrolet

Chevrolet 2002 tracker User manual

Chevrolet

Chevrolet Impala 1969 User manual

Chevrolet

Chevrolet MATIZ User manual

Chevrolet

Chevrolet kodiak 2004 User manual

Chevrolet

Chevrolet Tahoe 2014 User manual

Chevrolet

Chevrolet CAPTIVA - S User manual

Chevrolet

Chevrolet 1999 Silverado 1500 Pickup User manual

Chevrolet

Chevrolet Colorado 2018 User manual

Chevrolet

Chevrolet 2003 TraiIBIazer EXT User manual

Chevrolet

Chevrolet 1998 Prizm User manual

Chevrolet

Chevrolet 2006 SSR Pickup User manual

Chevrolet

Chevrolet CAPTIVA - S User manual

Chevrolet

Chevrolet 1999 Blazer Installation and operation manual

Chevrolet

Chevrolet 2011 Aveo User manual

Chevrolet

Chevrolet 2007 Equinox User manual

Popular Automobile manuals by other brands

Toyota

Toyota 2000 Tundra owner's manual

CITROËN

CITROËN DS4 DSign Handbook

Lexus

Lexus 2015 CT 200h owner's manual

Cadillac

Cadillac CTS 2008 owner's manual

Mercedes-Benz

Mercedes-Benz M-class ML 55 AMG Operator's manual

Porsche

Porsche Boxster S Technical manual

GMC

GMC 2010 Savana 1500 Cargo owner's manual

KIAM

KIAM SPORTAGE 2014 Features & functions guide

GMC

GMC 2013 Terrain Getting to know

GMC

GMC T-Series 1999 owner's manual

Mercury

Mercury 1998 Mystique owner's manual

Mercury

Mercury 2007 Mariner Quick reference guide

Mazda

Mazda 2007 Mazdaspeed 3 Smart start guide

Mazda

Mazda 2014 CX-5 owner's manual

GMC

GMC Chevrolet Express 2022 owner's manual

GMC

GMC 1997 Jimmy owner's manual

Cadillac

Cadillac 2010 Escalade manual

Skoda

Skoda FABIA RS - ANNEXE 118 brochure
