KEEP-NUT™
DRILLING MACHINE MANUAL
Ventilated Facades Under-mount
Sink Anchor
The KDM110 KEEP-NUT™ DRILLING MACHINE from
Chemical Concepts™, is a lightweight, precision tool for drilling
panels and countertops. This machine will enable any operator
to repeatedly and efficiently drill holes with the correct dimen-
sions for use with the Keep-nut anchoring system. This machine
can also be used to as a general-purpose, portable drill press for
many otherapplications.
Using an array of compatible bits, the machine can prepare holes
in a variety of hard surfaces including granite, marble, engineered
stone, UHPC, ceramics, glass, and composites. The vacuum-foot
allows secure attachment to rough surfaces including unpolished
granite and textured materials. This water-cooled, pneumatic
machine requires only a single airline and a water feed to operate.
Use with thin-wall core bits to drill faucet holes in record time
without a CNC.
KEEP-NUT™ DRILLING MACHINE works on:
PRODUCT INFORMATION:
• Vacuum-foot for secure attachment
to rough or even vertical surfaces
• Built in depth stop for precise,
repeatable results
• Fast, efficient drilling of anchor holes
for KEEP-NUT™ Anchoring System
• Lightweight and easy to operate
• Water cooled and air-operated
KEEP-NUT™ 5 x 8_Drill Manual AV.indd 3 9/17/19 2:01 PM
• 4 •
Chemical Concepts | 410 Pike Road, Huntingdon Valley, PA 19006 | Made in USA
www.chemical-concepts.com | 800.220.1966 | sales@chemical-concepts.com
KEEP-NUT™
DRILLING MACHINE MANUAL
KEEP-NUT™ is a press-in self-anchoring insert that provides a
permanent threaded fixing in panels or countertops made of
marble, granite, composites, carbon,
Corian®, HPL, glass and others
hard surface materials.
The KEEP-NUT™ insert is
specifically developed to
fasten ventilated façades,
wall-coverings, décor,
furniture, under-mount sinks,
as well as a variety of other applications.
The Keep-Nut is made of stainless steel
for durability and performance in exterior applications.
Available in different lengths to fit several different panel
thicknesses, KEEP-NUT™ can be installed quickly by drilling the
material to the correct hole diameter and pressing in the insert.
KEEP-NUT™ inserts have several advantages. The preparation
needed is just a cylindrical hole drilled by CNC or the KDM series
manual tools. In addition, assembly by pressure is quick and easy
and does not require use of adhesives.
PRODUCT USED WITH:
Two Crown
Four Crown
Panel and
Ceiling Hanging
Faucet Hole Drilling
KEEP-NUT™ DRILLING MACHINE works on:
KEEP-NUT™ 5 x 8_Drill Manual AV.indd 4 9/17/19 2:01 PM
• 5 •
Chemical Concepts | 410 Pike Road, Huntingdon Valley, PA 19006 | Made in USA
www.chemical-concepts.com | 800.220.1966 | sales@chemical-concepts.com
KEEP-NUT™
DRILLING MACHINE MANUAL
INDIVIDUAL PART PHOTOS
16
15
1
10
3
6
19
14
9
12
13
8
2
2
11
7
17
18
4
PART DRAWING
Use only with
11.8mm ⅝”x 11
diamond bit
5
Keep-Nut-Alpha-Air-Polisher
KEEP-NUT™ Machine
with accessories
Base with bottom view
(See chart on page 6)
KEEP-NUT™ 5 x 8_Drill Manual AV.indd 5 9/17/19 2:01 PM
• 6 •
Chemical Concepts | 410 Pike Road, Huntingdon Valley, PA 19006 | Made in USA
www.chemical-concepts.com | 800.220.1966 | sales@chemical-concepts.com
KEEP-NUT™
DRILLING MACHINE MANUAL
KEEP-NUT™ Machine
ITEM NO. DESCRIPTION QTY.
1 Cam Follower 2
2 Thread Insert 1/4” - 20 to 7/16” - 14 4
3 Thread Insert 5/16” - 18 to 1/2” - 13 3
4 FHCS #10-24 x 2” 4
5 FCHS 1/4” - 20 x 3/4” 2
6 BHCS 1/4” - 20 x 1 1/4” 1
7 Adjustment Screw 1
8 SHSS 5/16” - 18 x 3/8” 2
9 O Ring 1
10 Ceramic Shaft 2
11 Linear Bushing 2
12 Hex Union 1/4” to 1/4” NPT 1
13 Venturi Valve 1
14 Fixture Base 1
15 Clamping Block 1
16 Handle 1
17 Arm 1
18 Arm 1
19 Venturi Block 1
INDIVIDUAL PART PHOTOS
Full
side view
KEEP-NUT™
Machine
front with
11.8mm ⅝” x 11
diamond bit
KEEP-NUT™ 5 x 8_Drill Manual AV.indd 6 9/17/19 2:01 PM
• 7 •
Chemical Concepts | 410 Pike Road, Huntingdon Valley, PA 19006 | Made in USA
www.chemical-concepts.com | 800.220.1966 | sales@chemical-concepts.com
KEEP-NUT™
DRILLING MACHINE MANUAL
Specifications
Air Pressure..................................................85 PSI
Air Consumption.....................................16 CFM
Weight........................................................4.84 lbs
OVERVIEW:
Special Features
The KDM110 has a number of special features. The unit is
designed to power both the pneumatic drill/polisher and the
vacuum base using a single airline. The Venturi vacuum base
was designed to deliver powerful suction to hold the unit
securely in place even on rough and textured materials such
as the underside of granite and ceramic surfaces in wet or
dry conditions. The vacuum base allows the unit to be
operated in a vertical or horizontal positions, provided
sufficient air pressure and volume is available. The vacuum
base also has a convenient quick release system to allow the
user to quickly reposition the unit without shutting off the
air line. Simply cover the small circular opening located on
the front of the Venturi block (19) with your finger and the
suction will be temporarily disengaged. The front of the unit
has a slot to accept a wrench allowing the user to change
drill bits without removing the polisher from the base. Simply
slide the included wrench into the slide and engage the
spindle on the Alpha Air-680C. This will prevent the spindle
from rotating. You can then use the appropriate wrench to
attach/remove your drill bit. Lastly the KDM110 has an
integrated depth stop that allows a predetermined depth
to be set for repeatable, accurate drilling.
Equipment Included
Alpha Air680C........................................................................1 pc
Non-coring Drill Bit ( 11.8mm) (CCH-KNBITGRI-11.8MM)...…1 pc
Split Stop Collar (½”)...........................................................1 pc
KEEP-NUT™ 5 x 8_Drill Manual AV.indd 7 9/17/19 2:01 PM
• 8 •
Chemical Concepts | 410 Pike Road, Huntingdon Valley, PA 19006 | Made in USA
www.chemical-concepts.com | 800.220.1966 | sales@chemical-concepts.com
KEEP-NUT™
DRILLING MACHINE MANUAL
Air Pressure & Volume
The recommended air pressure for this tool is 85 PSI. The most
important factor in running this tool is the volume of air being
supplied to the tool. The volume is the air consumption needed
to run this tool at a constant speed under light downward hand
pressure. The volume is measured in CFM (cubic foot per
minute (ft3/min). You need a minimum of 16 CFM per tool to
power both the tool and the vacuum base effectively.
When choosing a compressor to run an KDM110 we recommend
a rotary screw type with a minimum of a 5 hp motor/15-20 CFM
and a 60-gallon tank, per tool. (I.E. if you want to run four tools,
you will need a compressor with a 20 hp motor capability of
80+ CFM and an 80 to 100-gallon storage tank.) It is also very
important to keep your air cool, dry, and clean, so look for a
compressor with a refrigerated dryer and high-efficiency filter
built in or purchase a separate air dryer and filter unit rated for
your compressors CFM. Also ensure that the hose feeding the
KDM110 is of sufficient diameter to provide the required volume.
½” Hose is recommended.
Tool Set-up Information
Unpack the tool carefully and study the manual. Set the tool on a
level surface and inspect for damage.
Before use, ensure that the Alpha AIR-680C is securely clamped
into the clamping block (15), using a ⁵/₃₂” Allen wrench. If the
drill is not clamped securely in the clamping block the drill
may come loose during use. Excessive force and/or insufficient
air pressure/volume may also force the polisher from the
clamping block.
OVERVIEW: (cont)
KEEP-NUT™ 5 x 8_Drill Manual AV.indd 8 9/17/19 2:01 PM
• 9 •
Chemical Concepts | 410 Pike Road, Huntingdon Valley, PA 19006 | Made in USA
www.chemical-concepts.com | 800.220.1966 | sales@chemical-concepts.com
KEEP-NUT™
DRILLING MACHINE MANUAL
Drill Bits
This machine is compatible with a variety of ⅝” x 11 threaded
drill bits. Specially designed drill compatible with the Keep-nut
anchoring system are available for this unit. The standard bit
included in the box is recommended for marble, granite, quartzite
and other natural stone surfaces. We recommend specialized bits
for drilling ceramic/porcelain and specialized drill bits for glass.
A variety of core bits are available for this machine as well for
drilling faucet holes and other applications where core-bits are
used. The max drilling depth on this unit is approximately 1¼” (3CM).
See below for a chart showing average drilling time to drill a ¼”
depth hole using the included drill bit.
For optimum drilling of porcelain, sintered and ceramic materials,
a higher RPM tool is recommended. The KDM110 can be used to
drill accurate holes in these surfaces when using a bit designed
for these materials, but drilling times will be considerably longer
compared to granite and marble.
OVERVIEW: (cont)
Marble (Carrara) 4.70
Soft Granite (Terra Bianc) 3.67
Hard Granite (Blue Pearl) 12.25
Quartzite (Taj Mahal) 13.00
Engineered Stone 5.67
Sintered/Porcelain
(Neolith) 53.50
Stone Average Drilling Time;
¼” Depth (seconds)
KEEP-NUT™ 5 x 8_Drill Manual AV.indd 9 9/17/19 2:01 PM
• 10 •
Chemical Concepts | 410 Pike Road, Huntingdon Valley, PA 19006 | Made in USA
www.chemical-concepts.com | 800.220.1966 | sales@chemical-concepts.com
KEEP-NUT™
DRILLING MACHINE MANUAL
If the unit looses suction and the vacuum is
unable to securely adhere to the surface the
most likely cause is a blockage in the venturi.
Debris can become lodged in the venturi
which prevents the unit from creating enough
suction. To correct this, the venturi needs to be
disassembled and the blockage removed.
Once the obstruction is removed the unit
should return to full functionality.
Follow the steps below:
1. Using a hex key loosen the screws (4) that
secure the venturi block (19), and remove
the venturi block from the base.
2. Using the appropriately sized wrench
remove the ¼” NPT fitting (12) on the
venturi block.
3. Remove the value (13) inside the
Venturi block.
4. Visually inspect for any debris
trapped in the Venturi block; Use a
blow gun to clear out any debris
lodged in the cavity.
5. Reassemble parts as shown in the
parts diagram on page 5 & 6; Check
for proper suction.
LOSS OF
SUCTION:
TROUBLE SHOOTING
Q
&
A
Use only with
11.8mm ⅝”x 1 1
diamond bit
SKU NUMBER
CCH-KN-KDM110
KEEP-NUT™ 5 x 8_Drill Manual AV.indd 10 9/17/19 2:01 PM
Table of contents
