Chauvin Arnox C.A 1878 User manual

C.A 1877

C.A 1878

IR Thermography Camera

User Manual

ENGLISH

English

2 C.A 1877 – C.A 1878

You have just purchased an IR thermography camera and we thank you for your

confidence.

For best results from your device:

•read this user manual attentively,

•comply with the precautions for its use.

MEANING OF THE SYMBOLS USED

Selective sorting of wastes for the recycling of

electrical and electronic equipment within the

European Union.

In conformity with directive DEEE 2002/96/EC: this

equipment must not be treated as household waste.

Risk of danger. See explanations in this user manual:

Problems that may affect the operation of the I.R.

camera.

Notes completing the essential operating procedures.

Laser radiation, do not look directly into the LASER

beam.

This marking certifies compliance with the European

"Low Voltage" and "Electromagnetic Compatibility"

directives (2006/95/CE and 2004/108/CE).

English

C.A 1877 – C.A 1878 3

Specifications of the laser: Class 2, < 1 mW, wavelength 635 nm

WARNING

LASER RADIATION

DO NOT LOOK DIRECTLY INTO THE

BEAM

CLASS 2 LASER DEVICE

English

4 C.A 1877 – C.A 1878

CONTENTS

1. PRECAUTIONS FOR USE......................................................................................6

2. DESCRIPTION........................................................................................................7

2.1 FRONT PANEL....................................................................................................7

2.2 VIEW OF BACK AND BOTTOM.........................................................................8

2.3 CONTROLS.........................................................................................................9

2.4 BOTTOM/CONNECTORS...................................................................................9

3. PREPARING THE IR CAMERA..........................................................................10

3.1 CHARGING THE BATTERY.............................................................................10

3.2 INSTALLING THE BATTERY /SD CARD........................................................11

3.3 POWERING UP THE CAMERA.........................................................................12

3.4 CHECKING THE INFORMATION ON THE LCD SCREEN...............................13

3.5 SETTINGTHE DATE AND TIME......................................................................15

3.6 LOCALPARAMETERS.....................................................................................16

4. BASIC FUNCTIONS..............................................................................................18

4.1 USING THE LCD SCREEN................................................................................18

4.2 SELECTION OF THE MENUS AND PARAMETERS ........................................19

4.3 RESTORING THE DEFAULT PARAMETERS ..................................................21

5. TAKING SHOTS ...................................................................................................22

5.1 ADJUSTING THE CAMERA.............................................................................22

5.1.1 MANUAL FOCUSING...........................................................................22

5.2 ADHUSTING THE IR CAMERA .......................................................................23

5.2.1 ADJUSTING THE IMAGE.....................................................................23

5.2.2 ADJUSTMENT OF THE PALETTE........................................................23

5.2.3 FREEZE/ACTIVATE AN IMAGE ...........................................................23

5.3 PRESENTATION OF THE ANALYSIS FUNCTIONS ........................................24

5.3.1 ADJUSTMENT OF THE OBJECT/GLOBAL PARAMETERS ..................24

5.3.2 ADJUSTMENT OF THE ANALYSIS TOOLS ..........................................25

5.3.3 CURSOR ANALYSIS..............................................................................25

5.4 OPEN AND RECORDING THE IMAGE ............................................................26

6. READING AND ERASING ...................................................................................26

6.1 OPENING THE IMAGES ...................................................................................26

7. DOWNLOADING IMAGES..................................................................................29

7.1 DOWNLOADING IMAGES USING THE SD CARD..........................................29

English

C.A 1877 – C.A 1878 5

8. ACCESSORIES......................................................................................................30

8.1 USING THE SUN SHADE..................................................................................30

9. TROUBLESHOOTING .........................................................................................31

10. MAINTENANCE .................................................................................................32

10.1 SERVICING AND MAINTAINING THE CAMERA.........................................32

10.2METROLOGICALCHECK..............................................................................32

10.3 REPAIR ...........................................................................................................32

11. WARRANTY........................................................................................................33

12. APPENDIX...........................................................................................................34

12.1 TABLE OF EMISSIVITIES ..............................................................................34

13. TECHNICAL SPECIFICATIONS.......................................................................36

14. STATE AT DELIVERY.......................................................................................38

English

6 C.A 1877 – C.A 1878

1. PRECAUTIONS FOR USE

Before using the camera, make sure that you have read and understood the

safety precautions described below. Make sure that the camera is used correctly.

Please refer to this manual each time you encounter a hazard symbol. To avoid

exposure to laser radiation, injury, or damage to the device, and be sure that you

use the camera in a risk-free way, observe the safety recommendations given

below:

Do not look directly into the laser beam. Do not point the laser beam at

people.

Do not use the instrument other than for its intended purpose; keep it out

of reach of children and make sure that it is never treated as a toy.

Do not aim the device towards the sun or other source of intense heat.

Use only the recommended batteries and accessories. Do not leave the

device connected to mains when not necessary.

Avoid problems due to condensation.

Moving the I.R. camera rapidly from a cold to a warm place can cause

condensation (droplets of water) to form on its outside and inside surfaces.

You can avoid this problem by placing the camera in the plastic case and letting it

warm slowly to the ambient temperature before removing it from the case.

•When you switch on the camera, wait 10 to 15 minutes before recording

your first thermograms, to be certain that the camera's temperature has

stabilized and that your measurements are correct.

•Focus the lens correctly according to the distance to the target to be

inspected.

•In certain specific conditions only, this device may be sensitive to

electrostatic discharges (ESD).

English

C.A 1877 – C.A 1878 7

2. DESCRIPTION

2.1 FRONT PANEL

Focusing

ring

Laser pointer

Lens locking

ring

IR lens

Trigger

English

8 C.A 1877 – C.A 1878

2.2 VIEW OF BACK AND BOTTOM

Keypad

LCD screen

English

C.A 1877 – C.A 1878 9

2.3 CONTROLS

2.4 BOTTOM/CONNECTORS

Automatic adjustment key

Switch

Indicator

Freeze/Activate

Cancel key

Menu/Enter key

Cursor key

Battery latch

Multiple connector

Slot for SD card

Battery compartment

English

10 C.A 1877 – C.A 1878

3. PREPARING THE IR CAMERA

3.1 CHARGING THE BATTERY

Proceed as follows to charge the battery for the first time, and thereafter when the

"battery low" icon appears on the screen.

Align the edge of the battery pack

with the line marked on the

battery, then insert it in the

direction shown by the arrow.

Connect the mains cord to

the battery charger and the

plug at the other end to a

wall outlet.

The charging indicator lights up

red during charging of the battery

and turns green when the battery

is fully charged.

After recharging, disconnect the

battery charger and remove the

battery pack.

•The battery is a lithium ion battery, and so does not have to be

completely discharged before it is recharged. It can be recharged

at any time. However, since the life span of the battery is

approximately 300 charging cycles, we recommend charging the

battery only when it has been completely discharged, so that it will

last longer.

•The recharging time varies with the ambient relative humidity

and the battery charge condition.
