CET PFP-11HPHND-FL Manual

C.E.T. Fire Pumps Mfg. This handbook is subject to change without notice,

Contact your local C.E.T. dealer or C.E.T. direct to ensure you have the latest version.

Instruction Handbook

(Version 1.0)

Model : PFP-11hpHND-FL

Your version of the pump, the engine and their accessories may vary from the one seen on the illustrations

Serial Number : ________________________________

his pump was built by :

C.E. . Fire Pumps Mfg.

Instruction Handbook PFP-11hpHND-FL - 2 -

C.E.T. Fire Pumps Mfg. This handbook is subject to change without notice,

Contact your local C.E.T. dealer or C.E.T. direct to ensure you have the latest version.

able of contents

FOREWORD............................................................................................................................................... - 3 -

SAFE Y INS RUC IONS.................................................................................................................... - 4 -

DESCRIP ION.......................................................................................................................................... - 7 -

GENERAL INS RUC IONS .............................................................................................................. - 10 -

RANSPOR AND S ORAGE ......................................................................................................... - 11 -

PERFORMANCE .................................................................................................................................... - 12 -

S AR ING PROCEDURE .................................................................................................................. - 13 -

OPERA ING AND S OPPING ......................................................................................................... - 15 -

S AR UP ................................................................................................................................................. - 16 -

10.

MAIN ENANCE ................................................................................................................................ - 17 -

11.

ROUBLESHOO ING GUIDE ..................................................................................................... - 18 -

12.

GENERAL WARRAN Y ................................................................................................................. - 20 -

13.

CON AC US .................................................................................................................................... - 21 -

Instruction Handbook PFP-11hpHND-FL - 3 -

C.E.T. Fire Pumps Mfg. This handbook is subject to change without notice,

Contact your local C.E.T. dealer or C.E.T. direct to ensure you have the latest version.

Foreword

Congratulations on your purchase of a new C.E.T. fire pump, a quality product

based on a century of experience in building fire-fighting equipment. If you follow

the directives given in this handbook, your pump will be a useful ally for many

years to come.

For your own safety and those around you, it is

important that you read and understand each part of

this handbook BEFORE you start the pump. Always

keep this manual accessible so you can refer to it

whenever the need arrives.

reproduced without the prior written permission of

C.E.T. Fire Pumps MFG.

Instruction Handbook PFP-11hpHND-FL - 4 -

C.E.T. Fire Pumps Mfg. This handbook is subject to change without notice,

Contact your local C.E.T. dealer or C.E.T. direct to ensure you have the latest version.

Safety instructions

It is very important that you read and understand this handbook and the

owner’s manual of the engine before you start the pump.

oNEVER run the engine in an enclosed area. Exhaust gases contain carbon

monoxide which is an odorless and potentially deadly gas.

oNEVER run the pump in a radius of 3 ft (1m) of a building or combustible

object.

oNEVER operate the engine if there is an accumulation of grass, leaves, or

other combustible material around, behind or under the muffler.

oNEVER run the engine without a muffler or proper exhaust system.

oNEVER operate the engine if the fuel tank cap is removed, do not fill the tank

while the engine is running. If fuel is spilled, move machine away from the

area of the spill and avoid creating any source of ignition until it has

completely evaporated.

oNEVER run the engine in an explosive environment.

oNEVER touch the spark plug or its components while running the engine; it

could give you an electric shock.

oNEVER put your foot or hand near moving parts.

oNEVER wear loose, bulky or torn clothing while operating the pump, it could

catch on moving parts and lead to serious injury.

oNEVER let your pump run unattended. It must always be operated by

trained personnel assuring the stability and direction of discharge hose.

oNEVER operate this machine while under the influence of drugs or alcohol.

oNEVER spray the pressurised flow of water at a person or animal.

DANGER

Instruction Handbook PFP-11hpHND-FL - 5 -

C.E.T. Fire Pumps Mfg. This handbook is subject to change without notice,

Contact your local C.E.T. dealer or C.E.T. direct to ensure you have the latest version.

oNot following the instruction handbook directives and operating procedure

can lead to serious injuries, or even death. The operator and all other

members or personnel handling the hoses connected to the pump must be

trained and familiar with this type of product, know its limitations and have

read and understood the Instruction Handbook and engine manual.

oRisk of injuries resulting from pressure hazard.

Before you disconnect a hose or take off a cap on the inlet or outlet,

make sure the engine is stopped and open the drain valve to relieve

pressure.

NEVER touch a pressurized flow of water, it is abrasive and could lead

to serious injury.

oRisk of injuries resulting from very hot water, scald and burn hazards.

NEVER let the pump run for more than one minute with discharge

valve(s) completely closed. When the pump is running make sure to

always leave the discharge valve slightly opened, to avoid overheating

of the pump. If the pump runs completely closed with water flowing for

a few minutes, the water inside may heat-up and scald or burn the

operator when he opens the valve. The mechanical seal and other

components could also be damaged.

oRisk of injuries resulting from high temperature components, burn hazard.

NEVER touch the exhaust system, the muffler or the engine while it is

running. All these components get very hot and touching them may

cause burns.

oRisk of injuries resulting from kickback from the recoil starter.

To prevent injuries from kickback from the recoil starter, pull slowly on

the rope until you feel a resistance, then pull quickly.

oRisk of injuries resulting from tipping hazard.

NEVER operate the engine if the pump is not stable. Always chose a flat,

stable surface to operate the pump. The maximal slope for operation is

15°.

WARNING

Instruction Handbook PFP-11hpHND-FL - 6 -

C.E.T. Fire Pumps Mfg. This handbook is subject to change without notice,

Contact your local C.E.T. dealer or C.E.T. direct to ensure you have the latest version.

oNEVER run the pump for more than one minute without water.

oNEVER run the engine without the proper amount of oil in the engine.

oNEVER alter the engine and/or the pump even partially.

Signs and Symbols

This warning symbol means that not following the attached note will put at risk

the security of the personnel operating near the pump. The words “danger”,

“warning” and “caution” are used for levels of risk.

This symbol means that it is mandatory to read and understand this handbook

as well as the operation manual from the engine manufacturer, BEFORE you

start the engine.

This symbol represents the risk of injury from high temperature surfaces.

This symbol represents the risk of intoxication from dangerous gases, such

as carbon monoxide.

This symbol represents the risk of injury caused by moving parts.

This symbol represents the hazards of handling dangerous material such as

gasoline or diesel.

CAUTION

Instruction Handbook PFP-11hpHND-FL - 7 -

C.E.T. Fire Pumps Mfg. This handbook is subject to change without notice,

Contact your local C.E.T. dealer or C.E.T. direct to ensure you have the latest version.

Description

This floating pump is directly driven by the very high quality GXV340 Honda

engine. It is equipped with a recoil starter. This gasoline engine has an integrated

fuel tank of 0.6 gallons (2.1L). The pump has a 2.5” (65mm) discharge and a 3”

(77mm) inlet.

Instruction Handbook PFP-11hpHND-FL - 8 -

C.E.T. Fire Pumps Mfg. This handbook is subject to change without notice,

Contact your local C.E.T. dealer or C.E.T. direct to ensure you have the latest version.

Dimensions:

Weight:

120lbs (54kg)

The pump has a bronze impeller and a high resistance aluminum alloy body. It

also has an axial mechanical seal. The pump can operate to a maximum pressure

of 75 PSI (5.1bar). It has been designed to work at a temperature between 5°F (-

15°C) and 104°F (40°C). The manufacturer does not guarantee the performances

outside of this temperature range. The pump is operated with the throttle control

knob on the top of the frame. The pump should not run on a slope of more than 15°

of incline or be tilted at more than 35° when stopped.

Instruction Handbook PFP-11hpHND-FL - 9 -

C.E.T. Fire Pumps Mfg. This handbook is subject to change without notice,

Contact your local C.E.T. dealer or C.E.T. direct to ensure you have the latest version.

The assembly includes

•High quality GXV340 Honda gasoline engine.

•Centrifugal pump with one (1) outlet.

•Handling frame.

•Throttle control system.

The pump requires

•Oil (See the engine operator manual)

•Fuel (See the engine operator manual)

•Install in a properly ventilated area.

Recommended individual protective equipments (not included)

•Firefighting grade protective gloves (conforms to EN65 or equivalent).

•Protective glasses.

•Hearing protection

Intended use for application

This pump has been designed to move water for fire-fighting purposes. It has been

engineered to run under the constant supervision of an operator properly trained.

The pump was assembled according to the intended use of the engine

manufacturer. Any use that doesn’t conform with the previously stated intended

use is not authorized unless C.E.T. Fire Pumps Mfg. gives such authorization in

writing. A violation of this agreement could compromise the safety of the

personnel working near the pump. The manufacturer’s responsibility would be

voided by C.E. Thibault Ladders Inc. and/or C.E.T. Fire Pumps Mfg. for damages

resulting from unauthorized use.

Instruction Handbook PFP-11hpHND-FL - 10 -

C.E.T. Fire Pumps Mfg. This handbook is subject to change without notice,

Contact your local C.E.T. dealer or C.E.T. direct to ensure you have the latest version.

General instructions

This pump must only be operated by trained personnel.

WARNING: The hydraulic power of the pump discharge can cause

severe damage, even death. Never, upper any circumstance, point the

discharge hose toward a person or an animal, handle with care.

Highly contaminated water containing sand or rocks of diameters larger than

0.200” (5mm) could damage and shorten the lifespan of your pump. Always use a

strainer at the end of the suction hose. If you are not sure of the quality of the

pumped water, use a floating strainer to prevent drawing the sand or stone from

bottom source.

The GXV340 engine runs on unleaded gasoline (with a octane rating of 86 or

higher) and requires a quantity of 1.2qt (1.1L) of oil (SAE10W-30) for a running

temperature range of -13°F (-25°C) to 5°F (35°C). (Refer to the engine manual)

WARNING: Always stop the engine before refilling the fuel tank.

WARNING: The exhaust system will get very hot. If the engine

manufacturer recommendations are not followed it could also emit

sparks, which could set the nearby environment on fire

CAUTION: Read and understand the engine owner’s manual and this

instruction handbook before you start the engine.

Table of contents

Popular Water Pump manuals by other brands

Neptun

Neptun NPHW 5500 operating instructions

Sensidyne

Sensidyne Gilian BDX-II Operation & service manual

Draper

Draper 47808 instructions

Trolla

Trolla 12820 manual

Sunfab

Sunfab SVH Series installation guide

WilTec

WilTec 50740 Operation manual

Fieldmann

Fieldmann FVC 5015 EK user manual

Everbilt

Everbilt EFSUB5-122HD Use and care guide

Graco

Graco Husky 3300e manual

esotec

esotec 101018 operating manual

moyno

moyno 2000 CC Service manual

Becker

Becker BASIC VASF 2.80/1-0.AC230 operating instructions

Sykes AmeriPumps

Sykes AmeriPumps GP100M Operation and maintenance instructions

DUROMAX

DUROMAX XP WX Series user manual

BRINKMANN PUMPS

BRINKMANN PUMPS SBF550 operating instructions

Franklin Electric

Franklin Electric IPS Installation & operation manual

Xylem

Xylem e-1532 Series instruction manual

Milton Roy

Milton Roy PRIMEROYAL instruction manual
