Cecotec CONGA POPSTAR 7000 MATTRESS User manual

CONGA POPSTAR 7000 MATTRESS

Mattress vacuum cleaner with UV light and motorised brush

Instruction manual

INDEX

1. Parts and components

2. Before use

3. Operation

4. Cleaning and maintenance

5. Troubleshooting

6. Technical specications

7. Disposal of old electrical appliances

8. Technical support and warranty

SAFETY INSTRUCTIONS

Read these instructions thoroughly before using the appliance.

Keep this instruction manual for future reference or new users.

All safety instructions should be closely followed when using

the appliance.

-Make sure that the mains voltage matches the voltage

stated on the rating labelofthe appliance and thatthe outlet

is grounded.

- Do not allow the machine to run unattended.

-Do not immerse the cord, plug or other non-removable part

of the product in water or other liquids. Do not expose the

electrical connections to water. Make sure your hands are

dry before handling the plug or switching on the appliance.

-If the product falls accidentally in water, unplug it

immediately. Do not reach into the water!

-Do not use the device to vacuum hot objects such as carbon

or cigarette butts, sharp objects such as broken glass,

corrosive liquids, or ammable and explosive materials

such as gasoline and alcohol.

-Do not use this product to vacuum water or wet dust

and avoid using it next to water or in wet places such as

bathrooms, toilettes and laundry rooms.

-Do not look at the UV lamp on the bottom part of the device,

it could cause eye and skin damage.

-Do not irradiate the plants or persons with ultraviolet rays,

otherwise it may damage them. Do not use ultraviolet rays

in one place continuously, otherwise it may damage the

cleaning object.

- Do not disassemble de UV lamp.

- Do not sit on the product.

-Do not remove the rolling brush cover or force the cover

outward when the machine is powered on or running, so as

not to damage the product.

-Do not use this product forthe purposes ratherthan cleaning

textiles such as mattresses, blankets, pillows and sofas and

removing mite.

-Keep the device awayfrom heat sources and direct sun light.

-Check the power cord regularly for visible damage. If the

cord is damaged, it must be replaced by the ofcial Technical

Support Service of Cecotec, in order to avoid any type of

danger.

-Do not move the product or pull from it from its cord. Do

not use the cable as handle. Do not force the cable against

corners or sharp edges. Do not run appliance over the cord.

Keep the power cord away from hot surfaces.

-Do not use the appliance if its cord, plug, or housing is

damaged, nor after it malfunctions or has been dropped or

damaged in any way.

-Do not tryto disassemble the device byyourself. Contact the

ofcial Technical Support Service of Cecotec.

-Cleaning and maintenance must be carried out according to

this instruction manualto make surethe appliancefunctions

properly. Turn off and unplug the appliance before moving

and cleaning it.

-Store the appliance and its instruction manual in a safe and

dry place when not in use.

-This appliance is not intended to be operated by means of an

external timer or separate remote-control system.

-Turn off and unplug the device from the mains supply when

not in use and before cleaning. Unplug it when it is not going

to be used for a long time. Pull from the plug, not the cord, to

disconnect it from the outlet.

-This appliance is intended for domestic use only. It is not

suitable for commercial or industrial use. Do not use it

outdoors.

-No liability is accepted for any eventual damage or personal

injuries derived from misuse or non-compliance with this

instruction manual.

-The appliance is not intended to be used by children under

the age of 8. It can be used by children over the age of 8, as

long as they are given continuous supervision.

-This appliance is not intended to be used by persons

with reduced physical, sensory, or mental capabilities, or

lack of experience or knowledge, unless they have been

given supervision or instruction concerning the use of the

appliance in a safe way by a person responsible for their

safety, and understand the hazards involved.

-Supervise young children to make sure that they do not play

with the appliance. Close supervision is necessary when the

appliance is being used by or near children.

-Keep this product out of the reach of children under 8 years

old.

-The cleaning and maintenance of the appliance should not

be carried out by children.

1. PARTS AND COMPONENTS

Fig. 1

1. Cleaning mode button

2. On/Off button

3. Dust tank assembly

4. Cleaning mode indicator

5. Power cord

Fig. 2

1. Rolling brush

2. Hot air outlet

3. UV lamp

4. Power cord

2. BEFORE USE

- Remove all packaging materials.

-Inspect all parts of the appliance for visual damage. Unwind the power cord completely

and inspect it for damage. Do not use the appliance if the device or its cord have been

damaged or are not working properly. In case of damage, contact the ofcial Technical

Support Service of Cecotec for advice, repairs, or returns.

- Make sure all components are included in the package.

-Make sure you have read and understood all instructions and warnings in this instruction

manual. Pay particular attention to the safety instructions on previous pages.

- Keep the original box and the instructions manual.

3. OPERATION

Fig. 3.

1. Cleaning mode button

2. On/Off button

3. Mite removal mode indicator

4. Brush rotation mode indicator

5. Full cleaning mode indicator

Full cleaning mode: Vacuuming, Brush rotation & Mite removal

-Turn the device on. Itwillrun underFull cleaning mode (Vacuuming, Patting & Mite removal

with UV-C light) by default. The corresponding light indicator will turn on.

- Press the On/Off button once to turn the device off.

Vacuuming & Brush rotation mode

-Once the device is turned on in the Full cleaning mode, press the Mode button to switch to

Vacuuming & Patting mode. The corresponding light indicator will turn on.

- Press the On/Off button once to turn the device off.

Vacuuming & Mire removal mode

-Once the device is turned on in the Vacuuming & Patting mode, press the Mode button to

switch to Dust & Mite removal mode. The corresponding light indicator will turn on.

- Press the Mode button once to return to the Full cleaning mode.

- Press the On/Off button once to turn the device off.

Note

The 3 operating modes are set in a cycle. Press the Cleaning mode button once to switch from

one to another following the before order.

Warning

In order to avoid accidental injury, the UV lamp must be placed within 5 cm of the object to be

irradiated and the machine inclination must not exceed 30º. Outside this range, the UV lamp

will turn automatically off. Under this premise, the Mite removal mode indicator turns on,

indicating that the UV lamp is working normally.

After the mite eliminator starts to work, the hot air outlet continues to emit hot air and the

hot air temperature is high. Do not touch the hot air outlet with your hand while the machine

is working.

4. CLEANING AND MAINTENANCE

-It is recommended to clean the dust tank after each use; when the lter dust is blocked due

to excessive dust, it needs to be cleaned and replaced if necessary.

-If the dust tank is lled with dust during the process of use, clean it immediately.

-When the device has reached 30 hrs.- 50 hrs. use, (depending on the use of lter cotton), it

is suggested to buy a new lter cotton and change the air inlet lter cotton so as to ensure

good performance of the machine.

-UV penetration ability is weak. Any paper, glass and plastic will greatly reduce the intensity

of ultraviolet radiation. Therefore, dust and oil stains on the lamp tube will directly

affect its penetrating ability. UV lamps shall be cleaned regularly to avoid affecting UV

transmittance and intensity.

-Do not touch the UV lamp with your ngers, since stains can affect the penetration of UV

light.

-If the device is not going to be used for a long time, keep the machine in a cool and dry

place. Do not put it in direct sunlight or in humid environments.

Dust tank cleaning

1. Turn the device off and remove the power plug.

2. Place the machine in an upright position.

3. Press the dust tank release button.

4. Lift the dust tank assembly upwards.

5. Rotate the dust tank counterclockwise and lift the dust tank cover.

Fig. 4.

6. Take out the cotton lter and the dust tank lter.

7. Clean the dust tank.

Fig. 5.

Rolling brush cleaning

1. Take out the Rolling brush and clean it.

Fig. 6.

Fig. 7.

2. After cleaning, rst place the hexagonal rolling brush head gear into the belt, snap the

hexagonal rolling brush head into the base, and then press the four corner rolling brush

head on the other end into the base to assemble the rolling brush.

3. Finally, install the rolling brush cover in the reverse order.

Fig. 8.

Note

When cleaning the rolling brush, be sure to disconnect the power supply to avoid accidental

start of the roller brush and to avoid damage and injuries.

UV lamp cleaning and installation

1. Turn the device off and unplug it from the power supply.

2. Gently wipe the surface of the UV lamp with a dry cloth.

Note

When cleaning the UV lamp, be sure to disconnect the power supply to avoid electric shock

and injury to humans.

5. TROUBLESHOOTING

Problem Possible causes Solutions

The machine does not work.

The power plug is not inserted

tightly.

Check if the power plug is

inserted tightly.

The power socket has no

electricity.

Check the socket.

The on/off button is not pressed. Press the on/off button.

The absorbing force

becomes weaker.

Intake air lter cotton is too

dusty, causing protector

turn on

Clean the suction inlet.

Too many foreign objects are

attached on the lter cotton and

dust tank.

Clean the dust tank and

lter cotton.

There is too many foreign objects

in the second-level cyclone cover.

Clean the foreign objects

on the second-level

cyclone cover.

Intake air lter cotton is too

dusty, as a result, it may turn on

protector

Clean the dust from the

intake lter.

The ultraviolet light does

not work.

The ultraviolet light is badly

reected on the surface of

cleaned object, or it is far away

from the cleaned object.

In normal condition, the

ultraviolet light will be

started automatically when

the machine is 5cm away

from the object.

The machine stops on the

blanket.

Move the machine forwards

and backwards on the

blanket.

The machine is placed upright.

The machine inclination

shall not exceed 30º.

The transparent lm on the

infrared detector at the bottom of

the machine is covered with dirt

or too much dust.

Wash the transparent lm

on the detector with half

dry cotton cloth.

The ultraviolet tube is damaged.

Contact after-sale staff to

change ultraviolet tube.

The machine stops working

suddenly.

The dust tank is lled with the

dust.

To avoid overheating of

this product motor, the

overheating protection

mechanism has been

outtted on the machine. If

the product is overheated,

turn off the power supply,

clean up the blockage, and

then use it after two hours.

The suction inlet is blocked.

The lter cotton is blocked by

foreign objects.

The roller brush stops

working suddenly.

The foreign objects are wound on

the roller brush.

Open the cove of roller

brush as required, and then

clean the roller brush and

use it.

The belt falls off or has broken

off.

Open the cove of roller

brush as required, and

check if the belt falls off or

has broken off.

6. TECHNICAL SPECIFICATIONS

Product: Conga PopStar 7000 Mattress

Product reference: 05568

Rated voltage: 220-240 V~

Rated frequency: 50 Hz

Rated power: 700 W

Dust tank capacity: 0.35L

Made in China | Designed in Spain

7. DISPOSAL OF OLD ELECTRICAL APPLIANCES

The European directive 2012/19/EU on Waste Electrical and Electronic

Equipment (WEEE), species that old household electrical appliances must

not be disposed ofwith the normalunsorted municipalwaste. Old appliances

must be collected separately, in order to optimize the recovery and recycling

of the materials they contain and reduce the impact on human health and

the environment.

The crossed out “wheeled bin” symbol on the product reminds you of your

obligation to dispose of the appliance correctly.

Consumers must contact their local authorities or retailer for information concerning the

correct disposal of old appliances and/or their batteries.

Other manuals for CONGA POPSTAR 7000 MATTRESS

This manual suits for next models

Table of contents

Other cecotec Vacuum Cleaner manuals

cecotec

cecotec CONGA ROCKSTAR 2000 WET&DRY LIBERTY User manual

cecotec

cecotec Conga Quick&Clean Titanium User manual

cecotec

cecotec CONGA ROCKSTAR 1700 X-TREME ERGOWET User manual

cecotec

cecotec Conga 7490 Ultimate Home X-Treme User manual

cecotec

cecotec Conga PopStar 10180 Ash User manual

cecotec

cecotec CONGA ROCKSTAR MULTICYCLONIC XL User manual

cecotec

cecotec CONGA THUNDERBRUSH 750 User manual

cecotec

cecotec Conga Powerash 1200 Steel User manual

cecotec

cecotec Conga 5490 User manual

cecotec

cecotec CONGA User manual

cecotec

cecotec Conga Powerash 1200 Steel User manual

cecotec

cecotec CONGA ROCKSTAR 7500 ASTRAL JALISCAZO ANIMAL User manual

cecotec

cecotec Conga Rockstar 900 ULTIMATE ERGOWET User manual

cecotec

cecotec CONGA ROCKSTAR 1500 ULTIMATE ERGOFLEX User manual

cecotec

cecotec CONGA 4000 CARPET&SPOT CLEAN User manual

cecotec

cecotec Conga Rockstar NonStop Flex User manual

cecotec

cecotec CONGA ROCKSTAR 1500 ULTIMATE ERGOWET User manual

cecotec

cecotec CONGA 1290 Series User manual

cecotec

cecotec Conga 2290 Ultra User manual

cecotec

cecotec CONGA 5090 User manual

cecotec

cecotec HCONGA POPSTAR User manual

cecotec

cecotec POWERBAG 2000 COMPACT User manual

cecotec

cecotec Conga 11090 Spin Revolution Home&Wash User manual

cecotec

cecotec CONGA ROCKSTAR 3700 GLASS User manual

Popular Vacuum Cleaner manuals by other brands

Bissell

Bissell LittleGreen Proheat 1425 Series user guide

Panasonic

Panasonic MC-YL637S147-AE Service manual

NEFF

NEFF N17XH10 0 Series instruction manual

LG A9 Series owner's manual

Oreck

Oreck Cordless Captura BK51700 Series user guide

Kogan

Kogan KAVACROBVWA user manual

Kränzle

Kränzle VENTOS 50 ID Use and maintenance

EVVO

EVVO Ai35 instruction manual

DeWalt

DeWalt DWH200D instruction manual

Pontec

Pontec Pondomatic Vacuum Cleaner operating instructions

Cleanmaxx

Cleanmaxx PC-P007E instruction manual

Exido

Exido 240-114 manual

RIDGID

RIDGID WD1685AU0 owner's manual

Ezviz

Ezviz RE4P manual

STG global

STG global TANVAC HDV3000 Operator's manual

Shark

Shark ROTATOR PRO COMPLETE NV550 Series manual

Factory

Factory M3340 operating manual

Shop-Vac

Shop-Vac VN92 SERIES user manual

cecotec CONGA POPSTAR 7000 MATTRESS User manual

Popular Vacuum Cleaner manuals by other brands
