Cateye COMMUTER CC-COM10W Instruction manual
CATEYE COMMUTER
CC-COM10W
Quick Start
Click the button and follow the in-
structions.
START
Thank you for purchasing our cyclocomputer CATEYE COMMUTER.
This Quick Start Manual explains how to set up the computer and how to install the unit on
your bicycle.
Please set up the unit according to the specified procedure, then it will be ready for use as a
cyclocomputer.
Before use, read the instruction manual that comes with the product thoroughly
to the end to understand the functions of this unit, and to use it safely in a
correct manner.
Next
This PDF contains a movie file.
When you click on the movie screen, a message regarding security appears. Click the
“Trust in the text” or “Play” button to close the message.
Click the screen again to play the movie.
Next
CATEYE COMMUTER
Quick Start Manual Contents
Click the item you wish to view.
Return to a Cover
Setting up the computer
How to install the speed sensor (movie)
How to install the bracket (movie)
Operation of buttons
Set up the computer by operating the buttons as follows.
Check the button position before you start setting up.
MODE
MENU
Back
Press the MODE button or MENU button
on the back of the computer.
Next
CATEYE COMMUTER
Quick Start Manual Setting up the computer
Setting the speed unit
Setting the date display
Setting the day
Setting the month
Measuring screen
(Setup completed)
Setting the temperature unit
Setting the year
Setting the clock display
Setting the AM/PM display
Setting the hour
Setting the minute
Entering the tire circumference
Entering the total distance
Formatting operation Formatting operation
Press the MENU button on the back of the computer
and the AC button simultaneously.
Press and hold the* MENU button for 3 seconds
after you release the AC button.
After full lighting of the screen, the computer switch-
es to the speed unit setting screen to start setup.
AC
MENU
Full lighting Setting the speed unit
Return to Contents
Next
Return
CATEYE COMMUTER
Quick Start Manual Setting up the computer
Setting the date display
Setting the day
Setting the month
Measuring screen
(Setup completed)
Setting the temperature unit
Setting the year
Setting the clock display
Setting the AM/PM display
Setting the hour
Setting the minute
Entering the tire circumference
Entering the total distance
Setting the speed unit
Formatting operation
Setting the
speed unit
Setting the speed unit
When the MODE button is pressed, either “km/h” or “mph”
is selected for the speed unit display. Select the display of
your choice.
After selecting, press and hold the MODE button to pro-
ceed to the next step “Setting the temperature unit”.
MODE
To the next step
MODE
(Press and hold)
km/h ↔mph
Return to Contents
Next
Return
CATEYE COMMUTER
Quick Start Manual Setting up the computer
Setting the date display
Setting the day
Setting the month
Measuring screen
(Setup completed)
Setting the year
Setting the clock display
Setting the AM/PM display
Setting the hour
Setting the minute
Entering the tire circumference
Entering the total distance
Setting the temperature unit
Setting the speed unit
Formatting operation Setting the temperature unit
When the MODE button is pressed, either “°C” (Celsius)
or “°F” (Fahrenheit) is selected for the temperature unit
display. Select the display of your choice.
After selecting, press the MENU button to proceed to the
next step “Setting the date display”.
Setting the
temperature unit To the next step
MODE
˚C ↔˚F
MENU
Return to Contents
Next
Return
CATEYE COMMUTER
Quick Start Manual Setting up the computer
Setting the day
Setting the month
Measuring screen
(Setup completed)
Setting the year
Setting the clock display
Setting the AM/PM display
Setting the hour
Setting the minute
Entering the tire circumference
Entering the total distance
Setting the date display
Setting the temperature unit
Setting the speed unit
Formatting operation Setting the date display
When the MODE button is pressed, either “D(Day) / M
(Month)” or “M(Month) / D(Day)” is selected for the date
display. Select the display of your choice.
After selecting, press and hold the MODE button to pro-
ceed to the next step “Setting the day”.
Be sure to enter the correct value for the date at the time of*
setup.
The following describes the case when “* M(Month) / D(Day)”
is selected.
Date display
MODE
To the next step
MODE
(Press and hold)
D/M ↔M/D
Return to Contents
Next
Return
CATEYE COMMUTER
Quick Start Manual Setting up the computer
Setting the month
Measuring screen
(Setup completed)
Setting the year
Setting the clock display
Setting the AM/PM display
Setting the hour
Setting the minute
Entering the tire circumference
Entering the total distance
Setting the day
Setting the date display
Setting the temperature unit
Setting the speed unit
Formatting operation Setting the day
Pressing the MODE button increases the value flashing
(“Day” of the date). Enter the correct value.
After entering, press and hold the MODE button to pro-
ceed to the next step “Setting the month”.
Day
MODE
To the next step
MODE
(Press and hold)
Increase the value
Return to Contents
Next
Return
