Casio QV-4000 User manual
PLAYBACK
E-109
PLAYBACK
You can use the camera’s built in monitor screen to play
back recorded images.
Basic Playback Operation
Use the following procedure to scroll through recorded im-
ages stored in the camera’s memory.
1.
Align the power/function switch with .
: PLAY mode for playing back images
2.
Rock the control button to the left or right, or
rotate the selector dial to scroll through im-
ages on the monitor screen.
NOTES
•Keeping the control button pressed toward the left or
right scrolls through images at high speed.
•In order to allow for faster playback image scrolling,
the image that initially appears on the monitor screen
is a preview image, which is of somewhat lower quality
than the actual display image. The actual display im-
age appears about two seconds after the preview im-
age. Note that a fully detailed actual display image
may not be available in the case of some images cop-
ied from certain digital camera models.
If you want to do this:
Scroll forward
Scroll backward
Do this:
Rock the control button to the right.
Rock the control button to the left.
PLAYBACK
E-110
Playing a Movie
Use the following procedure to play back a movie recorded
in the Movie Mode.
1.
Align the power/function switch with .
2.
Rock the control button to the left or right, or
rotate the selector dial to scroll through the im-
ages on the monitor screen until the movie you
want to play is displayed.
3.
Click the control button to start movie play-
back.
•The following describes operations that are available
during movie playback.
Movie
Mode icon
If you want to do this:
Toggle the movie between
full screen and quarter
screen view
Playback forward
Playback in reverse
Pause playback
Skip to the next frame while
playback is paused
Skip to the previous frame
while playback is paused
Exit movie playback
Do this:
Press DISP.
Rock the control button to
the right.
Rock the control button to
the left.
Click the control button.
Rock the control button to
the right.
Rock the control button to
the left.
Press MENU.
PLAYBACK
E-111
Playing a Panorama
Use the following procedure to play back a panorama re-
corded in the Panorama Mode.
1.
Align the power/function switch with .
2.
Rock the control button to the left or right, or
rotate the selector dial to scroll through the
images on the monitor screen until the pan-
orama you want to play is displayed.
3.
Click the control button to start panorama
playback.
•The following describes operations that are available
during panorama playback.
Panorama
Mode icon
If you want to do this:
Toggle the panorama
between full screen and
compressed view
Scroll forward
Scroll backword
Pause playback
Skip to the next image while
playback is paused
Skip to the previous image
while playback is paused
Exit panorama playback
Do this:
Press DISP.
Rock the control button to
the right.
Rock the control button to
the left.
Click the control button.
Rock the control button to
the right.
Rock the control button to
the left.
Press MENU.
PLAYBACK
E-112
Enlarging the Playback Image
Use the following procedure to enlarge the playback image
on the screen. You can enlarge the image up to 3.2 times its
normal size.
1.
Align the power/function switch with .
2.
Rock the control button to the left or right, or
rotate the selector dial to display the image
you want to enlarge.
3.
Push the zoom controller upwards towards
(telephoto) to zoom in on the imge.
•Push the zoom controller downwards towards
(wide-angle) to zoom back out.
•The following describes operations that are available
while an enlarged image is on the playback screen.
2X
IMPORTANT!
•You cannot enlarge movie or panorama images.
NOTE
•Pushing the zoom controller downwards towards
(wide-angle) while a normal size (1X) image is on
the display switches to the 9-image view.
If you want to do this:
Shift the view right
Shift the view left
Shift the view upwards
Shift the view downwards
Exit the enlargement screen
Do this:
Rock the control button to
the right.
Rock the control button to
the left.
Rock the control button up.
Rock the control button down.
Press any button besides
the control button.
PLAYBACK
E-113
Displaying the 9-image View
The following procedure displays nine images on the monitor
screen at the same time.
1.
Align the power/function switch with .
2.
Push the zoom controller downwards towards
(wide-angle) .
•This displays the 9-image view, starting with the last
image you recorded.
3.
Rock the control button to the left or right to
scroll through images.
26 27
123
456
789
10 11 12
13 14 15
16 17 18
19 20 21
22 23 24
25
•The following describes operations that are available
while the 9-image view is on the monitor screen.
If you want to do this:
Scroll forward
Scroll backward
Display the selection pointer
(See following section. )
Exit the 9-image view
Do this:
Rock the control button to
the right.
Rock the control button to
the left.
Press DISP.
Press any button besides
the control button or DISP.
PLAYBACK
E-114
Selecting a Specific Image in the 9-image
View
1.
Display the 9-image view.
2.
Press DISP.
•This causes a pointer to appear in the upper left cor-
ner of the monitor screen.
3.
Rock the control button left, right, up, or down
to move the pointer to the image you want to
select, and then click the control button.
•This displays the single-image view of the selected
image.
PLAYBACK
E-115
Displaying the Histogram and
Other Image Information
The camera saves the histogram and other image informa-
tion along with the image itself. Use the following procedure
to view this other information.
1.
Align the power/function switch with .
2.
Press DISP to display the histogram and other
image information.
1
Histogram
7
Shutter
Speed
4
Light
Metering
3
Drive mode
2
Exposure
mode
5
Flash
8
White
balance
9
File size
6
Aperture
Use the histogram to check exposure when
recording.
• Exposure conditions indicated by the
histogram may not be accurate when
using the flash, when using multi-pattern
metering, or under certain other
conditions.
:Full Auto Mode
:Best Shot Mode
:Program AE Mode
:Aperture Priority AE Mode
:Shutter Speed Priority AE Mode
:Manual Mode
:1-Image Mode
:Continuous Shutter Mode
:AEB (Auto Exposure Bracketing) Mode
:Movie Mode
:Panorama Mode
:Multi-pattern metering
:Center-weighted metering
:Spot metering
:Flash on
:Flash off
1Histogram
2
Exposure mode
3Drive mode
4Light Metering
5Flash
6Aperture
7Shutter Speed
PLAYBACK
E-116
• Except for the histogram, “-----” is shown in place of
any item for which information is uncertain or other-
wise unavailable.
3.
Rock the control button to the left or right, or
rotate the selector dial to scroll through im-
ages on the monitor screen.
• It may take some time for the image data to appear
after you select an image.
4.
After you are finished, press DISP to clear dis-
play information.
8White balance
9File size
None:Auto
:Daylight
:Shade
:Tungsten
:Fluorescent
:Manual
IMPORTANT!
• The histogram does not appear during movie play-
back (page E-110).
• In the case of a panorama image (page E-111), the
histogram is displayed for the first image of the pan-
orama only.
PLAYBACK
E-117
IMPORTANT!
•Auto Power Off (page E-35) is disabled whenever
Slide Show is being used. This means you should not
leave Slide Show running when using batteries to
power the camera. Doing so can rundown batteries.
Be sure to stop Slide Show and turn off the camera
after you are finished.
•Note that all buttons are disabled while an image
change is in progress. Wait until an image is stopped
on the monitor screen before performing a button op-
eration, or hold down the button until the image stops.
•Images copied from another digital camera or a com-
puter may take longer time to appear than the Slide
Show interval time you select.
Using the Slide Show Feature
Slide Show automatically plays back images in sequence at
a fixed interval.
1.
Align the power/function switch with .
2.
Press MENU.
3.
Select “Slide Show”and then click the control
button to apply it.
•This starts the slide show.
•Pressing MENU at this point displays a screen for set-
ting the interval between image changes within the
range of five to 30 seconds.
4.
To stop Slide Show, press any button besides
MENU.
PLAYBACK
E-118
Resizing an Image
You can use the following procedure to change an image to
VGA size (640 x 480 pixels).
•VGA is the optimum image size for attachment to e-mail
messages or incorporation into Web pages.
1.
Align the power/function switch with .
2.
Rock the control button to the left or right, or
rotate the selector dial to display the image
you want to resize.
3.
Press MENU.
4.
Select “Resize”and then rock the control but-
ton to the right.
5.
Select “Yes”and then click the control button.
•Select “No”to exit the procedure without resizing the
image.
IMPORTANT!
•The resized version of the image is saved as a new
file.
•The original, pre-resized image is also retained in
memory.
•2256 x 1504 (3:2) size images are resized for 640 x
427 pixels.
•Images smaller than 640 x 480 pixels cannot be
resized.
•
MovieMode,PanoramaMode,andTIFF(uncompressed)
images cannot be resized.
•Resizing of an image cannot proceed if the message
“MEMORY FULL Delete unneeded images”appears.
