Casio EX-S3 - 2 User manual
70
PLAYBACK
PLAYBACK
3.
Use [왘] (forward) or [왗] (back) to scroll
through files on the monitor screen.
NOTES
•Holding down [왗] or [왘] scrolls images at high
speed.
•Note that the images produced on the monitor
screen of this camera are simplified versions of the
actual image stored in memory.
You can use the camera’s built-in monitor screen to view
images after you record them.
Basic Playback Operation
Use the following procedure to scroll through files stored in
the camera’s memory.
1.
Press the power
button to turn on the
camera.
•This causes an image
or a message to appear
on the monitor screen.
2.
Align the mode
selector with “PLAY”.
•This enters the PLAY
mode.
Power button
RECPLAY
MENU
Mode selector
ON/OFF
71
PLAYBACK
RECPLAY
MENU
DISP
REC
PLAY
MENU
DISP
Flipping the Display
The following procedure flips the image 180 degrees. This
comes in handy when you want to show someone standing
in front of you an image on the monitor screen.
1.
In the PLAY mode, use [왗] and [왘] to scroll
through images on the monitor screen and
display the one you want.
2.
Press the shutter release button and [SET] at
the same time.
•This flips the image 180 degrees. The histogram or
any other display information you had displayed is
cleared automatically whenever you flip the image.
•While an image is flipped, you can use [왗] and [왘] to
scroll to another image, if you want.
3.
To return the image to its normal orientation,
press any button other than [왖], [왔], [왗], or
[왘].
IMPORTANT!
•Note that you cannot play a movie on the monitor
screen while a flipped image is displayed.
•You cannot use the above procedure to flip an image
while a zoomed image, or calendar screen is on the
display, or while a movie is playing.
[SET]
Shutter release
button
72
PLAYBACK
3.
To scroll the image
on the display, press
[SET] and then press
[왖], [왔], [왗], or [왘].
•To display the indicator
for further zooming,
press [SET] again.
4.
Press [MENU] to return the image to its
original size.
IMPORTANT!
•You cannot enlarge a movie image.
•Depending on the original size of the recorded
image, you may not be able to zoom a display image
the full four times its normal size.
Zooming the Display Image
Perform the following procedure to zoom the image
currently on the monitor screen up to four times its normal
size.
1.
In the PLAY mode, use [왗] and [왘] to display
the image you want.
2.
Press [왖] ( ) to
enlarge the image.
•This displays an
indicator that shows the
current zoom factor.
Current zoom factor
73
PLAYBACK
Resizing an Image
You can use the following procedure to change a snapshot
image to either SXGA size (1280 x 960 pixels) or VGA size
(640 x 480 pixels).
•VGA is the optimum image size for attachment to e-mail
messages or incorporation into Web pages.
1.
In the PLAY mode, press [MENU].
2.
Select the “PLAY”
tab, select “Resize”,
and then press [왘].
3.
Use [왗] and [왘] to scroll through images and
display the one you want to resize.
IMPORTANT!
•Resizing an image creates a new file that contains
the image in the size you select. The file with the
original image also remains in memory.
•Images smaller than 640 x 480 pixels cannot be
resized.
•Note that you can resize snapshots recorded with
this camera only.
•If the message “The function is not supported for this
file.”appears, it means that the current image cannot
be resized.
•The resize operation cannot be performed if there is
not enough memory to store the resized image.
4.
Use [왖] and [왔] to select the setting you
want, and then press [SET].
To do this:
Resize to 1280 x 960 pixels (SXGA)
Resize to 640 x 480 pixels (VGA)
Cancel the resizing operation
Select this:
1280 x 960
640 x 480
Cancel
74
PLAYBACK
Cropping an Image
Use the following procedure when you want to crop a
portion of an enlarged image and use the remaining part of
the image as an e-mail attachment, Web page image, etc.
1.
In the PLAY mode, use [왗] and [왘] to scroll
through images and display the one you want
to crop.
2.
Press [MENU].
3.
Select the “PLAY”
tab, select
“Trimming”, and then
press [왘].
•This causes a cropping
boundary to appear.
4.
Use [왖] and [왔] to make the cropping
boundary smaller or larger.
•The size of the cropping boundary depends on the
size of the image on the display.
5.
When the cropping
boundary is the size
you want, press [DISP]
to lock it.
•After pressing [DISP] to
lock the size of the
cropping boundary, you
can press [DISP] again to
unlock it. After that, you
can repeat steps 4 and 5
to change the cropping
boundary size.
6.
Use [왖], [왔], [왗], and [왘] to move the
cropping boundary up, down, left, or right
until the area of the image you want to extract
is within the boundary.
7.
Press [SET] to extract the part of the image
enclosed in the cropping boundary.
•If you want to cancel the procedure at any point,
press [MENU].
75
PLAYBACK
Playing a Movie
Use the following procedure to play back a movie that was
recorded in the movie mode.
1.
In the PLAY mode,
press [왗] and [왘] to
scroll through images
until the movie you
want to play is
displayed.
2.
Press [SET].
•This start playback of the movie.
Movie icon
IMPORTANT!
•Cropping an image creates a new file that contains
the cropped image. The file with the original image
also remains in memory.
•A Movie mode image cannot be cropped.
•An image recorded using another camera model
cannot be cropped.
•If the message “The function is not supported for this
file.”appears, it means that the current image cannot
be cropped.
•The cropping operation cannot be performed if there
is not enough memory to store the cropped image.
76
PLAYBACK
IMPORTANT!
•You cannot repeat play a movie. To play a movie
more than once, repeat the steps of the above
procedure.
•Note that this camera cannot play back a movie’s
audio. You need to transfer the movie file to a
computer (page 112) to hear the audio.
•You can perform the following operations while a
movie is playing.
To do this:
Fast forward or fast reverse
the movie
Pause and unpause movie
playback
Skip forward or back one
frame while paused
Cancel playback
Do this:
Hold down [왗] or
[왘].
Press [SET].
Press [왗] or [왘].
Press [MENU].
Displaying the Calendar Screen
Use the following procedure to display a 1-month calendar.
While the calendar is on the display, you can select a date,
which displays the first image recorded on that date. This
helps to make it easy to find the images you want.
1.
In the PLAY mode, press [MENU].
2.
Select the “PLAY”tab, select “Calendar”, and
then press [왘].
3.
Use [왖], [왔], [왗], and
[왘] to move the date
selection cursor.
•Use the procedure
under “Changing the
Date Format”on page
102 to specify the date
format.
•The image displayed on
the calendar for each
date is the first image
that was recorded on
that date.
Year/Month
Date selection cursor
77
PLAYBACK
•Pressing [왖] while the date selection cursor is
located anywhere in the top line of the calendar
causes the previous month to appear.
•Pressing [왔] while the date selection cursor is
located anywhere in the bottom line of the calendar
causes the next month to appear.
•To exit the calendar screen, press [MENU].
•appears in place of the image when the date
contains data that cannot be displayed by this
camera.
4.
To view the large version of a date’s image,
move the date selection cursor to the date
and then press [SET].
•This displays the first image that was recorded on
the selected date.
Playing a Slide Show
Slide Show automatically plays back images in sequence
at a fixed interval.
1.
In the PLAY mode, press [MENU].
2.
Select the “PLAY”tab, select “Slideshow”,
and then press [왘].
78
PLAYBACK
4.
Use [왖] and [왔] to select “Start”, and then
press [SET].
•This starts the slide show.
5.
To stop Slide Show, press any button.
•The slideshow will also stop automatically after the
amount of time you specified for “Time”elapses.
3.
Configure the slideshow settings.
•See the pages indicated below for more information.
For information about
configuring this setting:
Images
Time
Interval
Go here:
“To specify the slideshow
images”on page 79
“To specify the slideshow
time”on page 80
“To set the slideshow
interval”on page 80
IMPORTANT!
•Note that all buttons are disabled while an image
change is in progress. Wait until an image is stopped
on the monitor screen before performing a button
operation, or hold down the button until the image
stops.
•Images copied from another digital camera or a
computer may take longer time to appear than the
slideshow interval time you specify.
79
PLAYBACK
To specify the slideshow images
1.
Use [왖] and [왔] to select “Images”, and then
press [왘].
2.
Use [왖] and [왔] to select the setting you
want, and then press [SET].
3.
Use [왖] and [왔] to select “Start”, and then
press [SET].
•This starts the slideshow.
To do this:
Include all images in file memory in the
slideshow
Display a single image
Include all images in the FAVORITE
folder (page 93) in the slideshow
Select this setting:
All images
One Image
Favorites
■Selecting a Particular Image for a Slideshow
When you select “One image”as the slideshow type, the
slide show displays only one image, without changing it.
Use this setting when you want a particular image to
remain on the display while the camera is on the USB
cradle (Photo Stand feature). Perform the following steps to
specify which image you want displayed.
1.
Select “One image”, and then press [왘].
2.
Use [왗] and [왘] to scroll through the images
until the one you want to use is on the
monitor screen.
3.
Press [SET] to
register your
selection and return
to the menu screen.
•Pressing [MENU]
instead of [SET] returns
to the menu screen
without registering the
setting.
This manual suits for next models
1
Table of contents
Other Casio Digital Camera manuals
Casio
Casio Exilim EX-M20U Instruction and safety manual
Casio
Casio EX-TR80 User manual
Casio
Casio EXILIM EX-TR150 User manual
Casio
Casio QV-R40 Troubleshooting guide
Casio
Casio EX-M20 - 3 User manual
Casio
Casio EXILIM EXS3DBA User manual
Casio
Casio Exilim EX-N5 User manual
Casio
Casio QV-2400UX User manual
Casio
Casio EX-G1 - Exilim 12.1 MP Endurance Digital... User manual
Casio
Casio Exilim EX-S8 User manual
Casio
Casio QV-5500SX User manual
Casio
Casio EX-FC100BK User manual
Casio
Casio EX-Z330 - EXILIM Digital Camera User manual
Casio
Casio E MULTI PJ CAMERA Multifunctional Camera... User manual
Casio
Casio QV-3000EX/Ir User manual
Casio
Casio QV-5000SX User manual
Casio
Casio EX-M2 - EXILIM Digital Camera User manual
Casio
Casio Exilim EX-P700 User manual
Casio
Casio EX-Z550BE Owner's manual
Casio
Casio EX-V8 - EXILIM Hi-Zoom Digital Camera User manual
