SERVICE MANUAL

ELECTRONIC CASH REGISTER

(without price)

QT-2100(EX-590)

FEB. 2002

CONTENTS

QT-2100 PAGE

1. SPECIFICATIONS........................................................................................ 1

2. CONNECTOR LOCATIONS ........................................................................ 3

3. INITIALIZE (MAC) OPERATION.................................................................. 4

4. DISASSEMBLY............................................................................................ 9

5. CIRCUIT EXPLANATIONS ........................................................................ 14

6. OPTION INSTALLATION........................................................................... 27

7. IN LINE ....................................................................................................... 33

8. ON LINE ..................................................................................................... 36

9. DIAGNOSTIC OPERATION....................................................................... 39

10. ERROR CODE LIST................................................................................... 55

11. IC DATA ..................................................................................................... 62

12. PCB LAYOUT ............................................................................................ 68

13. CIRCUIT DIAGRAMS................................................................................. 70

14. PARTS LIST............................................................................................... 90

— 1 —

1. SPECIFICATIONS

1-1. Electrical specifications

1-2. Environmental specifications

1-3. Main components

• Operating temperature 0 °C ~ 40 °C

• Operating humidity 10 % ~ 90 %

• Storage temperature -20 °C ~ 60 °C

• Storage humidity 10 % ~ 90 %

• Vibration strength 1.5 G (The machine must be in the carton box)

• CPU Name HD6417709AF133B

Number of control bit32 bits

Internal RAM 16 KBytes

• RAM1, 2, 3 and 4 Name MSM51V18165DSL-6TKFB

Capacity2 Mbits x 2pcs(Standard RAM1,2)

• Video RAM Name LC35256FT-70U

Capacity 256 Kbytes

• Flash ROM Name MBM24DL324BE90PFTN

Capacity4 Mbits

120V 220V 230V 240V

•Power consumption In operation Max. 0.6 A 0.4A 0.4A 0.4A

stand-by Max. 0.15 A 0.09A 0.09A 0.08A

•Memory protection Back-up battery VL3032/SGA

Back-up period 30 days (25 °C)

Battery life Replace the battery every 5 years.

Recharge time 48 hours

•Clock & Calendar Accuracy Within ±30 sec. per month (25 °C)

Auto calendar Effective until 2099 A.D.

1-4. Drawer List

DRAWER NAME Type Specification NOTE

•DL-2780 M D-18BC-B84M-13* Europe, other countries

•DL-2916 M D-18BC-B87M-13* Europe

•DL-2781 M D-18BC-B84SM-13* Europe, UK, Germany

•DL-2917 M D-18BC-B87SM-13* Europe, UK, Germany

•DL-3618 L D-17BT-B65SM-9* USA, Canada

•DL-3619 L D-17BT-B65M-9* Europe

— 2 —

1-5. Option List

DEVICE NAME MODEL NOTE

•Dallas key (Clerk key) CLK-K22 for 6 clerk

•MCR (Magnetic card reader) QT-2046MC

•Rear display QT-2160D

•Sheet holder SH-KIT8 1 holders (1st - 4th)

•Sheet holder SH-KIT9 2 holders (1st - 4th, 5th - 8th)

•RAM CHIP QT-2130RAM Capacity 4 Mbytes, Backup battery

•Multi drawer kit MDL-11 additional 1 drawer

•Remote display QT-2163D

•Option pole QT-2061S For Remote display

•Remote display cable QT-2162S

•PC cable PRL-CB-2

•Sheet cover WT-81

•Slip printer SP-1300

•Slip printer cable PRT-CB-8C Length 1.5m

•Remote printer UP-250

•Remote printer UP-350

•Remote printer SA-3015

•Printer cable PRT-CB-8B Length 5m

•Printer cable PRT-CB-8A Length 3m

•Printer power supply PS-170 Power supply unit

•Printer AC AC-170 AC cord

•Handy scnner HHS-15

•CF Memory Card SDCFB-xx-505

•Modem

56k External Faxmodem

“US Robotics”

•Modem 56k External Voice

Faxmodem

“US Robotics”

•ISDN TA ELSA MICROLINK Only in Germany

TL-Pro (ISDN)

CAUTION

Danger of explosion if battery is incorrectly replaced.

Replace only with the same or equivalent type

recommended by the manufacturer.

Dispose of used batteries according

to the manufacture’s instructions.

VORSICHT !

Explosionsgefahr bei unsachgemäßem Austausch der

Batterie.

Ersatz nur durch denselben oder einen vom

Hersteller empfohlenen gleichwertigen Typ.

Entsorgung gebrauchter Batterien nach

Angaben des Herstellers.

ADVARSEL !

Lithiumbatteri - Eksplosionsfare ved fejlagtig hándtering.

Udskiftning má kun ske med batteri

af samme fabrikat og type.

Levér det brugte batteri tilbage til leverandØren.

— 3 —

2. CONNECTOR LOCATIONS

COM1 Port (PC/MODEM)

COM4 Port

COM5 Port

COM6 Port

COM3 Port (REMOTE DISP)

IN LINE SELECTOR

IN LINE2 TERMINATOR

IN LINE2 IN

IN LINE2 OUT

POWER SWITCH

SLIP POWER

COM2 Port (SCANNER)

IN LINE1

— 4 —

3. INITIALIZE (MAC) OPERATION

3-1.How to initialize QT-2100 terminal

Preparation: 1. All peripheral devices and QT-2100 terminals of this cluster

should be turned off.

2. Connect all of the peripheral devices (such as printer, display

etc.) to QT-2100 terminal.

3. Connect all QT-2100 terminals by in-line.

Operation: 4. Turn on all peripheral devices of a QT-2100 terminal.

5. TurnonthisQT-2100terminalwithpressingtheleft-mostkeyof

the top row and release the key after buzzer sounds.

6. After releasing the key, enter “other = 1000, USA = 2000” and

press the right part of the <ST> key.

7. Data:

Enterthecurrentdate(YY/MM/DDorder)andpressthe<YES>

key.

8. Time:

Enterthecurrentdate(HH/MM/SSorder)andpressthe<YES>

key.

9. ID Character:

In ID character field, the auto-defined ID No. is shown.

We recommend that you should not change the value.

Date 01-10-10

Time 12:34 00

Check System Master

Check Cluster ID 0

ID Character MC #01

R/J/Order Printer(1) No

R/J/Order Printer(2) No

R/J/Order Printer(3) No

Slip Printer No

OK? YES

Time 12:34 00

Check System Master

Check Cluster ID 0

ID Character MC #01

R/J/Order Printer(1) No

R/J/Order Printer(2) No

R/J/Order Printer(3) No

Slip Printer No

OK? YES

Date 01-10-10

Check System Master

Check Cluster ID 0

ID Character MC #01

R/J/Order Printer(1) No

R/J/Order Printer(2) No

R/J/Order Printer(3) No

Slip Printer No

OK? YES

Date 01-10-10

Time 12:34 00

Check System Master

Check Cluster ID 0

ID Character MC #01

R/J/Order Printer(1) No

R/J/Order Printer(2) No

R/J/Order Printer(3) No

Slip Printer No

OK? YES

Date 01-10-10

Time 12:34 00

— 5 —

10.Check System:

Align the cursor as shown to the left.

The following is displayed by pressing <YES> key.

Selectone fromthe itemsinthe abovefigure andpress <YES>

key.

11.Check System:

Align the cursor as shown to the left.

The following is displayed by pressing <YES> key.

Selectone fromthe itemsinthe abovefigure andpress <YES>

key.

12.Check System:

Align the cursor as shown to the left.

The following is displayed by pressing <YES> key.

Selectone fromthe itemsinthe abovefigure andpress <YES>

key.

13.Please confirm all of the field and if they are all right, press the

<YES> key to proceed the next step.

Check System Master

Check Cluster ID 0

ID Character MC #01

R/J/Order Printer(1) No

R/J/Order Printer(2) No

R/J/Order Printer(3) No

Slip Printer No

OK? YES

Date 01-10-10

Time 12:34 00

Check System

1. Master

2. Backup Master

3. Satellite

4. Selfmaster

R/J/Order Printer2

1. No

2. UP-350

3. SA-3015

4. UP-250

Check System Master

Check Cluster ID 0

ID Character MC #01

R/J/Order Printer(1) No

R/J/Order Printer(2) No

R/J/Order Printer(3) No

Slip Printer No

OK? YES

Date 01-10-10

Time 12:34 00

Check System Master

Check Cluster ID 0

ID Character MC #01

R/J/Order Printer(1) No

R/J/Order Printer(2) No

R/J/Order Printer(3) No

Slip Printer No

OK? YES

Date 01-10-10

Time 12:34 00

Slip Printer

1. No

2. SA-3015

3. SP-1300

Check System Master

Check Cluster ID 0

ID Character MC #01

R/J/Order Printer(1) No

R/J/Order Printer(2) No

R/J/Order Printer(3) No

Slip Printer No

OK? YES

Date 01-10-10

Time 12:34 00

— 6 —

14.If you want to download program data from other terminal,

Please select one of “2” or “3” and Press <YES> key.

If you don’t need to download any program data, select “1. No

Restore / Receive” and Press <YES> key. The initialization of

this terminal is completed.

1. No Restore / Receive

2. PGM Restore (CF Card)

3. PGM Restore (Inline)

AUTO PGM

■When “2. PGM Restore (CF card)” is selected

1The file name list of the AUTO PGM data inside the CF CARD

is displayed.

Note: The files are displayed in the order they are found.

They may not be listed in chronological order.

2Selecting a file name displays the confirmation as shown in the

left figure.

Press <ESC> to return to the previous screen.

3When <YES> is pressed: the file is restored from the CF card,

followed by “End” display.

Press<NO>or<ESC>toendandreturntothepreviousdisplay.

4Press <ESC> to end CF Card and change to waiting mode.

CF Card

Data Restor

*1. PLUPGM1 .004****

2. PLUPGM2 .004

3. PLUPGM3 .004

4. STORE-AA.090

5. STORE-BB.090

6. STORE-CC.090

7. STORE-DD.090

8. SETMENU .028

0. 00

* * *

Are you sure to restore?

STORE-AA.090

CF Card

0. 00

* * *

CF Card 20

Data Restore 090

Normal End

CF Card

0. 00

— 7 —

■When “3. PGM Restore (IN LINE)” is selected

1Select one of the following for the Receive PGM.

1. All Data: Eincluding totalizer, CHK, Index&Detail

2. All PGM

2Select receive terminal.

3Align the cursor and press <YES> key.

When INLINE AUTO PGM normally ended. When INLINE AUTO PGM abnormally ended.

Notes: There is no retry even when abnormally ended.

Ineither(normalorabnormal)ending,press<ESC>to

end INLINE AUTO PGM and change to waiting mode.

Receive Data *All*Data**** 1

PGM Receive from *MC*#1******* 2

OK? *Yes* 3

Normal End

31-12-96 11:59PM

Receive Data All Data

PGM Receive from MC #01

Normal End

31-12-96 11:59PM

Receive Data All Data

PGM Receive from MC #01

OK? YES

Normal End

31-12-96 11:59PM

— 8 —

3-2. How to initialize QT-2100 terminal (add/replace one QT-2100)

1. All peripheral devices and QT-2100 terminals of this cluster should be turned off.

2. Connect all of the peripheral devices (such as printer, display etc.) to this QT-2100 terminal.

3. Connect this QT-2100 terminal to in-line.

4. Turn on all peripheral devices of this QT-2100 terminal.

And turn on all QT-2100 except this terminal of the cluster.

5. Turn on this QT-2100 terminal with pressing the left-most key of the top row and release the key after

buzzer sounds.

6. After releasing the key, enter “other = 1000, USA = 2000” and press the right part of the <ST> key.

7. Refer to “2-1 How to initialize QT-2100 terminal” on page 3.

2-3. How to flag clear QT-2100 terminal (or INIT2)

Preparation: 1. This QT-2100 terminal should be turned off.

2. Checkthe connectionof allperipheral devices(suchasprinter,

display etc.) of this QT-2100 terminal.

3. Check the connection of this QT-2100 terminal to in-line.

Operation: 4. Turn on this QT-2100 terminal with pressing the right-most key

of the top row and release the key after buzzer sounds.

5. After releasing the key, press the <ST> key.

6. Select “1.Flag Clear” and press the <YES> kye.

The flag clear operation is finished.

Note:

Performing “Init 2” requires password “8888888888”.

0.00

10-10-01 12:34

INIT

1.Flag Clear

2.Init2

Other manuals for QT-2100

This manual suits for next models

Table of contents

Other Casio Cash Register manuals

Casio

Casio QT-7300 Series User manual

Casio

Casio TE-4000 User manual

Casio

Casio PCR-T2000 User manual

Casio

Casio PCR 262 - Personal Cash Reg 10DEPT/100 Price Look UPS/8CLERK Impact... User manual

Casio

Casio TE-8000F Series User manual

Casio

Casio SR-C4500 User manual

Casio

Casio PCR-T2500 User manual

Casio

Casio PCR-365A Assembly instructions

Casio

Casio PCR 272 - Cabinet Design Cash Register User manual

Casio

Casio PCR 272 - Cabinet Design Cash Register User manual

Casio

Casio PCR-T2000 User manual

Casio

Casio TK-1550 User manual

Casio

Casio TE-1500 User manual

Casio

Casio SR-C550 User manual

Casio

Casio QT-6000 User manual

Casio

Casio SE-S10 Operating instructions

Casio

Casio PCR-T285 User manual

Casio

Casio PCR-T465 User manual

Casio

Casio TE-7000S Owner's manual

Casio

Casio TE-2000 User manual

Casio

Casio SE-S300 User manual

Casio

Casio SE-G1 User manual

Casio

Casio CE-T300 User manual

Casio

Casio PCR 272 - Cabinet Design Cash Register User manual

Popular Cash Register manuals by other brands

Royal

Royal 480nt operating manual

Olivetti

Olivetti ECR 8200 S user guide

TEC

TEC TEC FS-3600 owner's manual

Integrated System Laboratory

Integrated System Laboratory ISL 4006 user manual

Sam4s

Sam4s ER-380 Operation and program manual

Sharp

Sharp XE-A206 Guía de inicio Rápido

Samsung

Samsung ER 5215 Operator's manual

Toast

Toast Toast Quick setup guide

Sharp

Sharp XE-A130 Bedienungsanleitung

TEC

TEC MA-600-1 series owner's manual

QUORION

QUORION CR 1200 user manual

Olivetti

Olivetti ECR 7700 LD eco Plus user guide

Sharp

Sharp XE-A137-WH Operation Basic user manual

Sharp

Sharp XE-A203 - Cash Register Thermal Printing Graphic Logo... instruction manual

TEC

TEC TEC MA-1060 owner's manual

ELCOM

ELCOM Euro-2100TE user manual

American Changer

American Changer CLASSIC Series Operation manual

Sam4s

Sam4s ER-180 Operation manual
