Cascade D Series Manual

倾翻架、倾翻式废纸叉

Hinged Forks & Hinged Broke Forks

官方微信号天猫旗舰店

操作指南 PERATER'S GUIDE

服务热线

Customer Service Hotline

40088 57315

目录 CONTENTS

介绍 Introduction 1

用户注意事项 End User Please Notice 2

操作 Operation 3

日常检查 Daily Inspection 4

安全规则 Safety Rules 5

安全操作和维护 Safe Operation and Maintenance(OSHA Regulations) 8

质量保证政策 Warranty 13

警告

:叉车属具综合承载能力是由叉车制造厂决定，其值可能比属具铭牌上的小，请参见叉车铭牌。

WARNING: Rated capacity of the truck/attachment combination is a responsibility of the original truck manufacturer and

may be less than shown on the attachment nameplate. Consult the truck nameplate.

注意

:操作者必须是经过培训且授权的人员。

CAUTION: Do not operate this attachment unless you are a trained and authorized lift truck driver.

注意

:本指南阐述对大多数货物工况的作业规则。特殊情况请向您的上级主管请教具体的正确操作规则。

CAUTION: This Guide shows recommended load handling procedures applicable to most products. Consult your

company or organization for any special procedures applicable to loads you.

卡斯卡特保留对本手册进行修改的权力。如有修改，恕不另行通知，请留意相应的版本号。

- 1 -

介绍 INTRODUCTION

本手册为 D,E,F 系列侧移叉的操作指南（以E系列侧移叉作图例），旨在帮助你

在操作中避免属具及货物的损伤，操作前请仔细阅读本手册，掌握所有的操作步骤及安

全规则，不详之处请向你的上级请教。

安全第一！大多数的事故都起因于操作或判断失误，请格外留心维护保养状况差和

工况恶劣的属具并及时加以解决。

This guide contains operating instructions for Cascade D,E,F-Series

Sideshifters(takes E-Series Sideshifter for example). It will help avoid common

errors which often cause damage to the equipment or product being handled.

Read this manual thoroughly before operating the attachment. Be sure you know

and understand all operating procedures and safety precautions. If you have any

questions, or don't understand a procedure, ask your supervisor.

Emphasize Safety! Most accident are caused by operator carelessness or

misjudgement. You must watch for hazardous situations and correct them.

倾翻式废纸叉

Hinged Broke Forks

倾翻架

Hinged Forks

压板

Press Plate

货叉

Forks

油缸

Cylinder

油缸

Cylinder

挡货架

Backrest

货叉架

Carriage

上钩

Upper Hooks

上钩

Upper Hooks

下钩

Lower Hooks

下钩

Lower Hooks

- 2 -

用户注意事项 END USER PLEASE NOTICE

日常的维护保养对于保证叉车属具产品的正常功能及使用寿命至关重要，

详细事项请参见卡斯卡特叉车属具

《操作手册》

或

《维修手册》，

或者请首先向售出该产品的叉车主机厂或其代理商咨询。

The daily inspection and periodic maintenance is very important for ensuring the normal performance and durable service life of the

forklift truck attachment. For details, please consult the Cascade Xiamen forklift truck attachment 《Operator's Guide》or 《Service

Manual》.

卡斯卡特（厦门）公司也非常乐意回答您在这方面任何感兴趣的问题。

You could also primarily consult the forklift truck OEM or its Dealer from whom you purchased this equipment. Of course, Cascade

Xiamen is willing to answer any questions of your interest, too.

请洽：

卡斯卡特（厦门）叉车属具有限公司

服务与配件处

电话：4008857315

传真：86-592-6512571

Please contact:

Customer Service Department,

Cascade Xiamen Forklift Truck Attachment Co. Ltd.

Tel: 4008857315

Fax: 86-592-6512571

- 3 -

操作 OPERATION

下降

Hoist Down

下降

Hoist Down

举升

Hoist Up

举升

Hoist Up

前倾

Tilt Forward

前倾

Tilt Forward

压板

Press Plate

前倾

Tilt Forward

前倾

Tilt Forward

后倾

Tilt Back

后倾

Tilt Back

后倾

Tilt Back

后倾

Tilt Back

压板张开

Open

张开

Open

压板夹紧

Clamp

夹紧

Clamp

货叉

Forks

货叉架

Carriage

货叉前倾

Carriage

Tilt Forward

货叉前倾

Carriage

Tilt Forward

货叉后倾

Carriage

Tilt Back

货叉后倾

Carriage Tilt Back

倾翻式废纸叉

Hinged Broke Forks

倾翻架

Hinged Forks

- 4 -

日常检查 DAILY INSPECTION

每天检查图示各项内容，发现问题及时汇报给上级。保养及维修事项请参见服务手册。

Check items shown each day. Inspect for problems and report to your supervisor in time. See Service Manual for matainenance and

repair procedures.

倾翻式废纸叉

Hinged Broke Forks

倾翻架

Hinged Forks

安全标签和铭牌

Safety Decals &

Nameplate

安全标签和铭牌

Safety Decals &

Nameplate

螺栓锁紧情况

Fasteners

油缸是否渗漏

Leaks

油缸是否渗漏

Leaks

螺栓锁紧情况

Fasteners

下钩嵌合情况

Lower Hooks

Engagement

上钩嵌合情况

Upper Hooks

Engagement

上钩嵌合情况

Upper Hooks

Engagement

下钩嵌合情况

Lower Hooks

Engagement

- 5 -

安全规则 SAFETY RULES

搬运货物 Handling Loads

附近有人禁止操作

Do not operate immediate

vicinity of other people

举升货物时叉车应限速行驶

Limit truck movement with

raised load

货物重量必须小于叉车 /属具组合承载能力（见叉车铭牌）

Load weight must not exceed combined truck/attachment

capacity(see truck namaplate)

左右货叉总承载能力必须大于货物重量

Total fork capacity(LH+RH fork)must be greater than load

weight. Check capacity stamp on forks.

行进前将货物居中

Center load prior to traveling

- 6 -

安全规则 SAFETY RULES

工业叉车 Industrial lift trucks

禁止载人行驶

No riders

空载行驶

Traveling Empty

禁止伸手穿越门架

No reach through mast

关闭发动机，制动，降下货叉

Motor off, Park, Lower load

禁止货叉下站人

No standing under load

3 in.

(76mm)

前后倾

Tilt

上下坡

RAMPS

空载时

No Loads

负载时

With Loads

提升

Raise

- 7 -

禁止坡上停车

No parking on ramp

禁止坡上转弯

No turning on ramp

注意行驶空间

Watch clearance

交通标志

TRAFFIC

STOP

湿地

Wet Floor

工作人员

Workers

双向行驶时必须慢行

Slow for two-way trafc

十字路口处鸣笛慢行

Sound horn, slow at

intersection

转弯时必须鸣笛慢行

Sound horn, slow at

corner

停止

Stop

凸起

Bumps

凹坑

Dips

安全规则 SAFETY RULES
