Caple WD140CLBK User manual
Contact Caple on 0117 938 7420 or for spare parts www.caple.co.uk
Classic warming drawer
Instruction manual
WD140CLSS / WD140CLBK
Instruction manual WD140CLSS / WD140CLBK
Please keep this instruction manual for future reference
2
CONTENTS
Warnings 3
Proper Use Of The Appliance 4
Safety Instructions And Warnings 5
Disposal Of Packaging 7
Electrical Connection 8
Before The First Use 10
Appliance Controls 10
Operation 10
Temperature Selection 11
Load Capacity 12
Care And Cleaning 13
Troubleshooting 14
Installation 15
Technical Data 18
Instruction manual WD140CLSS / WD140CLBK
Please keep this instruction manual for future reference
3
WARNINGS:
IMPORTANT INSTALLATION INFORMATION
-Please read this instruction manual carefully. This will
allow you to use your appliance in complete safety.
-Always keep the instruction manual handy.
-This appliance is exclusively for home use for heating
dishes.
-Caple shall not be held liable for damage to persons or
property due to incorrect installation, or incorrect use of
the appliance.
-Be sure to check the appliance once it has been
unpacked. If it has been damaged, do not use it and
contact your retailer straight away.
Instruction manual WD140CLSS / WD140CLBK
Please keep this instruction manual for future reference
4
PROPER USE OF THE APPLIANCE
-This appliance is compliant with current safety
regulations.
-Improper use may nonetheless cause damage to persons
and/or property.
-The inside of the appliance can reach a temperature of
up to 75˚C when the thermostat is set to the maximum
position. When taking out hot dishes, use appropriate
oven gloves as necessary.
-Remember that children have very delicate skin which is
more sensitive to heat.
-Therefore , do not allow children to play with the
appliance.
-If the on button is pressed , the drawer will start heating
and there is the danger of burns.
-This appliance is designed for domestic use only
Instruction manual WD140CLSS / WD140CLBK
Please keep this instruction manual for future reference
5
SAFETY INSTRUCTIONS AND WARNINGS
-This appliance is not intended for use by persons
(including children) with reduced physical, sensory or
mental capabilities, or lack of experience and knowledge,
unless they have been given supervision or instruction
concerning use of the appliance by a person responsible
for their safety.
-Children should be supervised to ensure that they do not
play with the appliance.
-Do not use the appliance to keep warm , re-heat or cook
foods and beverages.
-Humidity from foods or beverages may cause problems
for the appliance.
-Do not lean or sit on the open drawer. The telescopic
carriage may be damaged.
-The maximum load of the drawer is 25 kg.
-Make sure that the appliance is firmly secured to the
cabinet.
-Do not keep plastic or flammable objects in the
appliance. When the appliance it turned on, these kinds
of objects may melt or catch fire.
-Do not use the appliance to heat the room.
Instruction manual WD140CLSS / WD140CLBK
Please keep this instruction manual for future reference
6
-Never use steam cleaners. They may cause short circuits
and damage the appliance.
-Never under any circumstances insert objects (e.g.
screwdrivers, pointed objects, paper, etc.) through the
slots in the protection grille of the heating element and
fan.
-If the supply cord is damaged, it must be replaced by the
manufacturer or its service agent or a similarly qualified
person in order to avoid a hazard.
Instruction manual WD140CLSS / WD140CLBK
Please keep this instruction manual for future reference
7
DISPOSAL OF PACKAGING
The packaging materials protect the appliance during transport.
Recycling of the packaging makes it possible to save raw materials and reduce
waste volumes. If you dispose of the packaging yourself, ask local authorities for
the location of the nearest collection centre.
ENVIRONMENTAL PROTECTION
Waste electrical products should not be disposed of with household waste.
Please recycle where facilities exist. Check with your Local Authority or retailer for
recycling advice.
This appliance is marked according to the European directive on Waste Electrical
and Electronic Equipment (WEEE). By ensuring this product is disposed of correctly,
you will help prevent potential negative consequences for the environment and
human health, which could otherwise be caused by inappropriate waste handling
of this product. The symbol on the product indicates that this product may not
be treated as household waste. Instead it shall be handed over to the applicable
collection point for the recycling of electrical and electronic equipment. Disposal
must be carried out in accordance with local environmental regulations for waste
disposal.
For more detailed information about treatment, recovery and recycling of this
product, please contact your local council, your household waste disposal service or
the retailer where you purchased the product..
Instruction manual WD140CLSS / WD140CLBK
Please keep this instruction manual for future reference
8
ELECTRICAL CONNECTION
CONTACT A QUALIFIED ELECTRICIAN FOR THE ELECTRICAL CONNECTION OF
THIS PRODUCT
Before connecting the appliance to the electrical mains, ensure that the technical
data (voltage: V and frequency: Hz ) indicated on the rating plate concur with those
of the electrical mains.
This appliance has a 3amp fuse rating.
If in doubt, contact a qualified electrician.
If the plug is disconnected from the electrical power cord , a qualified electrician
will be required to insert and connect the appliance . Contact a qualified technician
who is knowledgeable of local standards and of any additional regulations issued by
the local electric company , and who ensures that work is carried out in compliance
with these standards.
IMPORTANT:
Check that the appliance is correctly connected to an approved earth wire to ensure
electrical safely. If necessary, have the system checked by a qualified electrician. If
the electrical outlet is no longer accessible after insertion, or if a fixed connection is
to be made, the installer must provide a separation device for each pole.
Valid separation devices include switches with a contact opening of at least 3mm.
Caple shall not be held liable for damage to individuals or property due to lack or
interruption of the earth wire.
ATTENTION: EARTH CONNECTION IS REQUIRED BY LAW.
If the appliance is connected to the mains with an extension cord. Make sure that
the extension cord and the connection are insulated against humidity.
Never open the covering of the appliance if you come into contact with wires
that carry voltage or if you modify the electrical and mechanical structure of the
appliance , it is possible that the appliance will malfunction during operation.
Instruction manual WD140CLSS / WD140CLBK
Please keep this instruction manual for future reference
9
If installation, maintenance and repair work is not carried out correctly, there may
be hazards for the user. Caple declines all liability for this type of personal injury
or property damage. During the warranty period , repairs may be carried out by
authorised service agents only. Otherwise, guarantee coverage will be void.
Installation, repair and cleaning work are to be carried out only with the machine
disconnected from the electrical mains. The appliance is disconnected from the
electrical mains in the following cases:
- The main switch of the electrical system is off.
- The safety switch is off.
- The appliance is unplugged.
USEFUL INFORMATION
The appliance is designed exclusively for the heating of dishes which are suited
for this purpose. The appliance is equipped with a hot air system. A fan creates
excellent distribution of warmth from the drawer heating element. Air circulation
heats the dishes evenly and quickly. A protection grille prevents contact with
the heating element and the fan. The base of the drawer is coverd with anti-slip
material to keep dishes from moving when it is opened or closed.
Instruction manual WD140CLSS / WD140CLBK
Please keep this instruction manual for future reference
10
BEFORE THE FIRST USE
- When using the appliance for the first time. Clean it as follows:
- Clean the surface with a soft cloth and then dry it.
- Pre-heat the empty drawer for at least two hours. Turn the temperature knob
to the maximum setting, in order to eliminate any residual grease, oil, or
manufacturing resins which may cause unpleasant odours during heating.
- Air out the room.
- Upon completion of this operation, the appliance is ready to be used for the
first time.
APPLIANCE CONTROLS
5
BEFORE THE FIRST USE
When using the appliance for the first time. Clean it as follows:
Clean the surface with a soft cloth and then dry it.
Pre-heat the empty drawer for at least two hours. Tum the temperature knob to the maximum
setting, in order to eliminate any residual grease, oil, or manufacturing resins which may cause
unpleasant odours during heating.
Air out the room.
Upon completion of this operation, the appliance is ready tobe used for the first time.
APPLIANCE CONTROLS
The control elements are the temperature knob and the luminous ON-OFF switch.
With the switch pressed (position 1) the drawer is on, whereas when the switch is released
(position 0) the drawer is off. These parts can be seen only when the drawer is open.
When the drawer is closed, a control light located on the front of the appliance lets you see
whether the drawer is on.
OPERAT ION
-Place the dishes in the drawer
-Select a temperature
- Turn on the appliance; the switch will light up
- Close the drwer gently
- Turn off the appliance before removing the heated dishes.
TEMPERATURE SELECTION
The temperature knob lets you select a temperature between approximately 30℃and 75℃.
Turn the temperature knob clockwise only, until it reaches it stop position (MAX).
Do not force it beyond the stop, otherwise thethermostat will be damaged.
The temperaturescale does not show absolute temperatures in ℃,but rather symbols that
represent the best temperature for respective groups of dishes, i.e cups - approx.40℃
The control elements are the temperature knob and the luminous ON-OFF switch.
With the switch pressed (position 1) the drawer is on, whereas when the switch
is released (position 0) the drawer is off. These parts can be seen only when the
drawer is open. When the drawer is closed, a control light located on the front of
the appliance lets you see whether the drawer is on.
OPERATION
- Place the dishes in the drawer
- Select a temperature
- Turn on the appliance; the switch will light up
- Close the drawer gently
- Turn off the appliance before removing the heated dishes.
