Caple FGC610 User manual
Instruction manual for wall chimney hoods
Model codes: FGC610 / FGC710 / FGC910
Contact Caple on 0844 800 3830 or for spare parts www.4caple.co.uk
1 .
2.Use a cross point screwdriver to remove two
screws that fix the bottom light panel in position.
3.Pull the light panel to the back and remove.
It is located by two lugs.
4.With the light panel removed there is access into
the chimney to fit the carbon filter.
5.Locate the back edge of the filter in position and
push into position. The filter has two plastic
brackets that “snap” into two slots in the body.
6.Refit light panel.
7.Refit metal grease filter.
1. With the grease filter removed, from inside the hood press the light fixture out of its mounting bracket.
