Canon EOS REBEL T6i Installation guide

Camera

Wi-Fi/NFC Function

This manual is the Basic Instruction Manual.

For more detailed instructions, refer to the Instruction Manuals

included in the Camera Instruction Manual CD-ROM.

Basic Instruction Manual

EOS REBEL T6i (W)

EOS 750D (W)

The Camera Basic Instruction Manual covers the most basic operations.

Camera Basic Instruction Manual

EOS REBEL T6i (W)

EOS 750D (W)

The EOS REBEL T6i or EOS 750D is a digital single-lens reflex camera

featuring a fine-detail CMOS sensor with approx. 24.2 effective

megapixels, DIGIC 6, high-precision and high-speed 19-point AF

(cross-type AF point: max. 19 points), approx. 5.0 fps continuous

shooting, Live View shooting, Full High-Definition (Full HD) movie

shooting, and Wi-Fi/NFC function.

Before Starting to Shoot, Be Sure to Read the Following

To avoid botched pictures and accidents, first read the “Safety

Precautions” (p.16-18) and “Handling Precautions” (p.19-21).

Refer to This Manual while Using the Camera to Further

Familiarize Yourself with the Camera

While reading this manual, take a few test shots and see how they

come out. You can then better understand the camera.

Testing the Camera Before Use and Liability

After shooting, play images back and check whether they have been

properly recorded. If the camera or memory card is faulty and the

images cannot be recorded or downloaded to a computer, Canon

cannot be held liable for any loss or inconvenience caused.

Copyrights

images or copyrighted music and images with music in the memory

card for anything other than private enjoyment. Also be aware that

certain public performances, exhibitions, etc., may prohibit photography

even for private enjoyment.

Introduction

Before starting, check that all the following items are included with your

camera. If anything is missing, contact your dealer.

* Battery Charger LC-E17 or LC-E17E is provided. (The LC-E17E comes with a

power cord.)

The Instruction Manuals and CD-ROMs provided are listed on the next page.

If you purchased a Lens Kit, check that the lenses are included.

Depending on the Lens Kit type, lens instruction manuals may also be

included.

Be careful not to lose any of the above items.

Item Check List

Battery Pack

LP-E17

(with protective cover)

Battery Charger

LC-E17/LC-E17E*

Wide Strap

Camera

(with eyecup and body cap)

Interface Cable

The instruction manual consists of a booklet and electronic manuals

(PDF files on the CD-ROM). The booklet is the Basic Instruction

Manual. For more detailed instructions, see the Camera Instruction

Manual on the CD-ROM.

Camera Instruction Manual CD-ROM

Contains the following manuals (PDF files):

• Camera Instruction Manual

• Wi-Fi/NFC Function Instruction Manual

• Quick Reference Guide

Instructions for viewing the Camera Instruction Manual

CD-ROM are on pages 152-153.

EOS DIGITAL Solution Disk (Software CD-ROM)

Contains software such as image-editing software and

Software Instruction Manuals (PDF files).

For more information and installation procedures of the

software, see pages 156-157.

Instructions for viewing the Software Instruction Manual

are on page 158.

Instruction Manual and CD-ROMs

Camera and Wi-Fi/NFC Function

Basic Instruction Manual

(This Manual)

The camera can use the following cards regardless of capacity: If the

card is new or was previously formatted by another camera or

computer, format the card with this camera (p.55).

• SD memory cards

• SDHC memory cards*

• SDXC memory cards*

* UHS-I cards supported.

When shooting movies, use a large-capacity SD card rated SD

Speed Class 6 “ ” or higher.

If you use a slow-writing card when shooting movies, the movie may

not be recorded properly. Also, if you play back a movie on a card

with a slow reading speed, the movie may not play back properly.

If you want to shoot still photos while shooting a movie, you will need

an even faster card.

To check the card’s reading/writing speed, refer to the card

manufacturer’s Web site.

Compatible Cards

Cards that Can Record Movies

In this manual, “card” refers to SD memory cards, SDHC memory

cards, and SDXC memory cards.

*The camera does not come with a card for recording images/

movies. Please purchase it separately.

Quick Start Guide

1Insert the battery (p.32).

To charge the battery, see page 30.

2Insert the card (p.33).

With the card’s label facing

toward the back of the

camera, insert it into the

card slot.

3Attach the lens (p.41).

Align the lens’s white or red mount

index with the camera’s mount

index of the same color.

4Set the lens focus mode switch

to <f> (p.41).

5Set the power switch to <1>,

then set the Mode Dial to <A>

(Scene Intelligent Auto) (p.62).

All the necessary camera settings

will be set automatically.

White index Red index

Quick Start Guide

6Flip out the LCD monitor (p.35).

When the LCD monitor displays the

date/time/zone setting screens, see

page 38.

7Focus on the subject (p.46).

Look through the viewfinder and

aim the viewfinder center over the

subject.

Press the shutter button halfway,

and the camera will focus on the

subject.

If necessary, the built-in flash will be

raised.

8Take the picture (p.46).

Press the shutter button completely

to take the picture.

9Review the picture.

The captured image will be

displayed for 2 sec. on the LCD

monitor.

To display the image again, press

the <x> button (p.86).

To shoot while looking at the LCD monitor, see “Live View

Shooting” (p.123).

To view the images captured so far, see “Image Playback” (p.86).

To delete an image, see “Erasing Images” (p.150).

Icons in this Manual

<6> : Indicates the Main Dial.

<W><X><Y><Z> : Indicates the <S> cross keys on the top,

bottom, left, and right.

<0> : Indicates the Setting button.

0, 9, 7, 8: Indicates that each function remains active

for 4 sec., 6 sec., 10 sec., or 16 sec. after

you let go of the button.

* In this manual, the icons and markings indicating the camera’s buttons, dials,

and settings correspond to the icons and markings on the camera and on the

LCD monitor.

3: Indicates a function that can be changed by pressing the

<M> button to change its settings.

When shown on the upper right of a page, it indicates that the

function is available only in the Creative Zone modes (p.26).

(p.**) : Reference page numbers for more information.

: Warning to prevent shooting problems.

: Supplemental information.

: Tips or advice for better shooting.

: Troubleshooting advice.

Basic Assumptions

All operations explained in this manual assume that the power switch

is set to <1> (p.36).

It is assumed that all the menu settings, Custom Functions, etc. are

set to their defaults.

The illustrations in this manual show the camera attached with the

EF-S18-55mm f/3.5-5.6 IS STM lens as an example.

Conventions Used in this Manual
