CANON

HFR21

Instruction Manual for Beginning Users

Inventory

Make sure all contents are included in bag before using.

1. Canon Vixia HFR21

Camera

2. BP-110 Battery Pack

3. USB cable

4. Compact Power Adapter

Battery Pack should be found underneath the Camera (as seen below)

First, turn on

the camera.

If camera is not fully charged, or you would

like to record while camera is plugged in,

insert compact power adapter to DC IN slot

located on the right panel of the camera.

Using the Canon HFR21 When you are ready to capture video, note that the red button

is to record(1),W-T is to zoom-in and out(2), and the button

behind the W-T is to capture a photo while you are lming(3).

Note: If you have an SD Card that you would like to use, instead of the built-in memory,

insert it into one of the slots located on the left inside panel of the camera.

To change settings manually, select [FUNCTION] on the LCD display,

and select [MENU]. (If you would also like to change overall video quality

settings like white balance, focus, exposure, added decorations, and more,

feel free to adjust to your desired quality.)

After selecting [MENU],

click the second tab and

scroll down to where it

says (Built-In Memory),

and press it.You will now

be able to select which

SD slot you would like

the video to write onto.

Adjusting the Settings

You can view what you just lmed on the camera by

pressing the [Camera]<---->[Play] Button(4). If you would

like to view what you did on a television, you can use

either the component(5)or HDMI slot(6)

External Microphone can be plugged into MIC.

56

Using A/V Peripherals

Finally, to Import Footage to computer, insert USB cord into slot and computer.Then, press the

[Camera]<---->[Play] Button(4) and wait for computer and camera to sync.

If you are a PC user: Install the supplied software before you connect the camcorder to the computer

for the rst time. Ask Information Services to provide you with an installation CD.

If you are a MAC user:There is no need for an installation CD. Instead, follow the steps above, and then

open iMovie. In iMovie, select the [CAMCORDER] icon on the left and it should display thumbnails of the

footage you recorded. Select all and import to capture footage to computer.

Importing Footage to Computer
