Calflame Outdoor Kitchen User manual

GRILLS &

ACCESSORIES

GRILLS &

ACCESSORIES

Since the discovery of ﬁre, people have enjoyed outdoor cooking. Since then, outdoor enthusi-

asts have sought more convenient, powerful and professional barbecue grills and accessories.

Homeowners around the world all have one thing in common: The desire to cook outdoors.

Now you can do it with style and function! Cal Flame is the ﬁrst and only manufacturer to offer

you the commercial-grade equipment to build a true outdoor kitchen.

The very best in stainless steel grills and cooking peripherals can now be yours. Side burners,

food warmers and outdoor refrigerators eliminate the need to run inside and keep you where

you want to be the most: At the grill! Best of all, Cal Flame gives you the choice of grill ac-

cessories to personalize your barbecue island with your unique style of cooking. Add smoke

trays, sear zones and deep fryers with ease. Our grills provide every convenience of an indoor

kitchen…without the walls. Cal Flame: Gourmet grilling of the highest degree.

WWW.CALSPAS.COM

AN ASSORTMENT OF

GOURMET ACCESSORIES

FOR ANY OCCASION

177

10 11 12

13 14

All Cal Flame grills series are ETL and CE listed and constructed using 304 or 430 Commercial Grade stainless steel,

double-walled construction, and cast stainless steel or porcelain burners. Standard premium features include 3-5 burn-

ers; individual blowtorch igniters for each burner, infrared back burner, nighttime grill lights, full-length drip tray, and

ﬂavor bars. Cal Flame Grills are the hottest looking grills on the market, and the best performing. With designer knobs,

exclusive V-shaped grates and polished stainless steel construction, looks alone can sear your steak.

QUALITY YOU CAN TRUST

WWW.CALSPAS.COM

178

1 Sturdy Construction

Seamless 304-gauge stainless steel hood with built-in

temperature gauge for precision grilling.

2 Temperature Gauge

Precision cooking begins with just the

right temperature. Extended prong for

accurate cooking.

3 Durable Handle

Welded one-piece handle ﬁnished in high-polish.

4 Convenient Nighttime Grilling

Self-cleaning grill lights illuminate food for perfectly

grilled meals every time.

5 New Warmer Rack Hideaway Hook

The warming rack suspends from con-

venient hooks when you just need

more rotisserie space.

6 12V Rotisserie Roller

The built-in roller creates smooth, con-

tinuous turning of the rotisserie for

more even cooking.

7 Rotisserie Cooking

The infrared backburner produces an intense heat, even-

ly cooking up to 35 lbs. on the rotisserie spit.

8 Reversible Rotisserie Hook-Up

Rotisserie can be hooked directly to the grill,

on either side, for its power source. With

this unit attached to your Cal Flame grill you

can turn a roast perfectly and guarantee you

ﬂawlessly cooked dishes.

9 Convection Grill

Unique technology offered only on Cal Flame

grills features a powerful fan that circulates

heat throughout the cooking area, eliminating

cold zones and the need to shift food.

10 Smart Grilling

Cal Flame exclusive V-shaped grates

keep smaller food from falling through.

11 Largest Grilling Surface Areas

Cal Flame offers 25% more grilling capacity than the

competition.

12 Lifetime Guaranteed Cast Stainless Steel Burners

These commercial-grade burners emit

15000 BTUs each and features dedicat-

ed blowtorch ignition and control knobs.

13 Clean Knobs Every Time

Front panel controls are always pro-

tected by the one-piece splash guard.

14 One Hand Operation Knob

Cal Flame exclusive custom knobs

feature one-hand operation with blow-

torch ignition.

15 Easy Cleaning

The full-width drip tray catches all drippings and slides

out for easy cleaning.

16 Conversion Kit

All Cal Flame grills are built for liquid

propane, but come with natural gas

conversion kits as standard.

17 Lock in the Flavor

Substitute any grill burner with an op-

tional sear zone to seal ﬂavor and juices

with a tasty crust.

18 Enjoy Smoked Barbecue

Any grill burner can also be substituted

with a smoke tray to infuse food with

smoky ﬂavor.

OPTIONAL FEATURES

WWW.CALSPAS.COM 179

Grills

You don’t need to be a gourmet chef to prepare gourmet meals on these professional-grade drop-in grills.

Cal Flame has the grill for you: From the expanded “G” Series to the classic line of 2- to 5-burner models

(most with infrared backburners) to electric grills which are perfect for apartments to charcoal grills that

will satisfy any purist.

Grill Accessories

Add even more functionality to your grill with powerful 12V rotisseries. The rotisserie basket makes it

easy to prepare seafood and vegetables. Replace a burner with a sear zone or a smoke tray. Deep-fry

foods right on the grill with the Deep Fryer Helper—designed exclusively for Cal Flame.

Side Burners

Convenient side burners make it easy to prepare multiple meals while you grill. Cook soups, stews

and skillet dishes without having to run inside. Choose single and double side burners in the style that

complements your backyard design.

Drop-In Accessories

Drop-in accessories give you the functionality you need to handle any event in your backyard or garden.

Keep side dishes fresh with food warmers and make any drink with cocktail centers, blenders and ice

chests. Prepare rare meals with a vertical grill, hibachi grill and deep fryer. At Cal Flame, it’s all about

choice.

Doors & Drawers

Have everything you need to grill the perfect steak close at hand with deep drawers and spacious stor-

age. Cal Flame provides several options for storing spices, cooking utensils, propane, aprons and every-

thing else you may need.

Ovens

Enjoy the convenience of a food warmer that discreetly hides itself in a drawer. Kids will love the electric

pizza oven drawer that can also double as a dish warmer for keeping meals hot.

Refrigerators & Ice Makers

Keep food fresh and ready for cooking or chill drinks with stainless steel refrigerators. Host keg parties in

style with a built-in beer tap. Have sodas ready for the kids in the elegant beverage cooler. The Cal Flame

ice maker ensures you never have to run to the store for more ice!

Accessories

When you’re creating the perfect meal, the last thing you need are interruptions. That’s why Cal Flame

offers handy built-in tools like bottle openers, griddle trays and cutting boards.

WHAT MAKES A

PERFECT OUTDOOR KITCHEN

WWW.CALSPAS.COM

180

GRILLS

This is the ﬁnest cooking equipment in the

industry. Available in 2- to 5-burner, electric

and charcoal conﬁgurations.

SIDE BURNERS

Prepare side dishes while you grill the

main course!

DROP-IN ACCESSORIES

Add more functionality with food warmers,

sinks, blenders and ice chests.

OVENS

Enjoy the functionality of baking pizza or keeping

food warm.

DOORS & DRAWERS

Deep drawers and spacious cabinets for

discreet, convenient storage.

REFRIGERATORS & ICE MAKERS

Cooling units keep food fresh and beverages

crisp while the ice maker ensures you never

have to leave the party.

ACCESSORIES

Extra tools to make your cooking experience

easier, like bottle openers, griddles and cutting

boards.

WWW.CALSPAS.COM 181

Dimensions:

BTU Output:

Cooking Area:

Infrared Burner:

Rotisserie:

C/O Dimensions:

DIMENSIONS

CUTOUT

91/4”

221/4”313/8”

24”

311/2”

227/16”

Dimensions:

BTU Output:

Cooking Area:

Infrared Burner:

Rotisserie:

C/O Dimensions:

DIMENSIONS

CUTOUT

91/4”

221/4”387/8”

24”

39”

227/16”

Dimensions:

BTU Output:

Cooking Area:

Infrared Burner:

Rotisserie:

C/O Dimensions:

DIMENSIONS

CUTOUT

91/4”

221/4”387/8”

24”

39”

227/16”

4 Burner Grill

Part Number: BBQ08874P

5 Burner Convection Grill

Part Number: BBQ08875CP

5 Burner Grill

Part Number: BBQ08875P

4 Burner Convection Grill

Part Number: BBQ0874CP

Dimensions:

BTU Output:

Cooking Area:

Infrared Burner:

Rotisserie:

C/O Dimensions:

311/2”x 24”x 227/16” (80x 61x 57cm)

60,000

800 sq. in. (2032cm)

YES 15000 BTU

YES

91/4”x 313/8”x 221/4” (23.5x 79x 56.5cm)

39”x 24”x 227/16” (99x 61x 57cm)

75,000

1,000 sq. in. (2540cm)

YES 22000 BTU

YES

91/4”x 387/8”x 221/4” (23.5x 98.7x 56.5cm)

39”x 24”x 227/16” (99x 61x 57cm)

75,000

1,000 sq. in. (2540cm)

YES 22000 BTU

YES

91/4”x 387/8”x 221/4” (23.5x 98.7x 56.5cm)

311/2”x 24”x 227/16” (80x 61x 57cm)

60,000

800 sq. in. (2032cm)

YES 15000 BTU

YES

91/4”x 313/8”x 221/4” (23.5x 79x 56.5cm)

DIMENSIONS

CUTOUT

91/4”

221/4”

313/8”

24”

311/2”

227/16”

WWW.CALSPAS.COM

DROP-IN GRILLS

182

Dimensions:

BTU Output:

Cooking Area:

Infrared Burner:

Rotisserie:

C/O Dimensions:

DIMENSIONS

CUTOUT

91/4”

221/4”387/8”

24”

39”

227/16”

Dimensions:

BTU Output:

Cooking Area:

Infrared Burner:

Rotisserie:

C/O Dimensions:

DIMENSIONS

CUTOUT

91/4”

221/4”

313/8”

24”

311/2”

227/16”

Dimensions:

BTU Output:

Cooking Area:

Infrared Burner:

Rotisserie:

C/O Dimensions:

91/4”

221/4”233/4”

24”24”

227/16”

DIMENSIONS

CUTOUT

5 Burner G5 Grill

Part Number: BBQ09G05

4 Burner G4 Grill

Part Number: BBQ08G04

3 Burner G3 Grill

Part Number: BBQ09G03

3 Burner Grill

Part Number: BBQ08873P

Dimensions:

BTU Output:

Cooking Area:

Infrared Burner:

Rotisserie:

C/O Dimensions:

39”x 24”x 227/16” (99x 61x 57cm)

75,000

1,000 sq. in. (2540cm)

N/A

91/4”x 387/8”x 221/4” (23.5x 98.7x 56.5cm)

311/2”x 24”x 227/16” (80x 61x 57cm)

60,000

800 sq. in. (2032cm)

N/A

91/4”x 313/8”x 221/4” (23.5x 79x 56.5cm)

24”x 24”x 227⁄16” (61x 61x 57cm)

45,000

600 sq. in. (1524cm)

N/A

91/4”x 233/4”x 221/4” (23.5x 60.5x 56.5cm)

24”x 24”x 227⁄16” (61x 61x 57cm)

45,000

600 sq. in. (1524cm)

YES 11,000 BTU

YES

91/4”x 233/4”x 221/4” (23.5x 60.5x 56.5cm)

DIMENSIONS

CUTOUT

91/4”

221/4”233/4”

24”

227/16”

WWW.CALSPAS.COM

DROP-IN GRILLS

183

Charcoal Convection Grill (w/ Lights and Infrared)

Part Number: BBQ08880P

Charcoal Grill (No Lights)

Part Number: BBQ08870P

Dimensions:

Cooking Area:

Infrared Burner:

Rotisserie:

C/O Dimensions:

Dimensions:

Cooking Area:

Infrared Burner:

Rotisserie:

C/O Dimensions:

Electric Grill (110v)

Part Number: BBQ08882E

Dimensions:

Cooking Area:

Watts:

Amps:

39”x 24”x 227/16” (99x 61x 57 cm)

800 sq. in. (2,032 sq. cm)

N/A

91/4”x 387/8”x 221/4” (23.5x 98.7x 56.5 cm)

39”x 24”x 227/16” (99x 61x 57cm)

800 sq. in. (2,032cm)

YES 15000 BTU

YES

91/4”x 387/8”x 221/4” (23.5x 98.7x 56.5cm)

223/4”x 16”x 111/2”

277 sq. in.

1500

12.5

DIMENSIONS

CUTOUT

91/4”

221/4”387/8”

24”

39”

227/16”

DIMENSIONS

CUTOUT

91/4”

221/4”

387/8”

24”

39”

227/16”

223/4”

111/2”

16”

DIMENSIONS

WWW.CALSPAS.COM

DROP-IN GRILLS

184

This manual suits for next models

Table of contents

Other Calflame Grill manuals

Calflame

Calflame BBQ10900 User manual

Calflame

Calflame Barbeque Grill User manual

Calflame

Calflame MC800 User manual

Calflame

Calflame Barbecue Island User manual

Calflame

Calflame LTR50001038 User manual

Calflame

Calflame CONVECTION 3000 GRILL User manual

Calflame

Calflame LBK-710-SW User manual

Calflame

Calflame BBQ18G03 User manual

Calflame

Calflame Barbecue Electric Grill and Cart BBQCR07900E User manual

Calflame

Calflame G4 2008 User manual

Calflame

Calflame Kamado XXL User manual

Calflame

Calflame P4 User manual

Calflame

Calflame G3 User manual

Calflame

Calflame Chef C100 User manual

Calflame

Calflame BBQ11875CTG User manual

Calflame

Calflame KD6002 User manual

Calflame

Calflame G-3000 Sports Bar User manual

Calflame

Calflame BBQ08873P User manual

Calflame

Calflame Barbecue Grills Carts User manual

Calflame

Calflame BBQ11955P User manual

Calflame

Calflame G Series User manual

Calflame

Calflame BBQ13P04 User manual

Calflame

Calflame BBQ09G870 User manual

Calflame

Calflame 844 Professional User manual

Popular Grill manuals by other brands

Orbegozo

Orbegozo GR 2300 instruction manual

bora

bora PT11 Operating and installation instructions

Klarstein

Klarstein 10031664 manual

Garland

Garland MWE3W Installation and operation manual

Char-Broil

Char-Broil 463722714 Product guide

Nexgrill

Nexgrill 720-0830HK Operating instruction

Kenmore

Kenmore 415.16123800 Use and care guide

Camp Chef

Camp Chef PG24CLAU Warning & instruction booklet

Tucker Barbecues

Tucker Barbecues GTR Series Assembly, installation and operating instructions

Monogram

Monogram ZGG540NCP1SS owner's manual

Equipex

Equipex Sodir Savoy Operation manual

Gaggenau

Gaggenau VR 414 610 use and care manual

Miele

Miele KM 408-1 operating instructions

George Foreman

George Foreman GGR50B owner's manual

AOG

AOG T series quick start guide

Gorenje

Gorenje TG2000CB Instruction manua

Weber

Weber Genesis Silver-B Permamount NG 051701 owner's guide

Glen

Glen SA 3037 user guide
