Bunn TigerXL User manual

For current speciﬁcation sheets and other information, go to www.bunn.com.

Features

Related Products

Item#

Project

Dat e

Patents Apply 04/08 A8.3

BUNN Espress®Tiger XL Cool Froth Series

• Upto180shotsperhourfromlessthan16”ofcounterspace.

• Yourchoiceoffourdrinkselections:espresso,cappuccino,latteandiced

latte.

• Intelligentmodularbrewingchamberadjustsespresso.

• SimulatesBaristatampingandpolishingmotiontoprovideuniform

extraction.

• Two-grindermodelfortwovarietiesofespressobeans.

• Hoppershold1.75lbsoffreshbeans.

• Adjustsfor4.5to7.4inchcupclearance.

• Podbrewingoptionstandardonallmodels.

• Intuitiveoperationaldesign.Easytousecontrolpadguidesuserthrough

stepsformakingdrinks.

• Easydailycleaning.

• Innovativemilkdeliverysystemdoesnotinjectsteamorwatertodilutethe

foamsocustomersenjoyafull,richavorexperience.

•Availablewithaself-contained1gallonmilkdrawerorexternalmilk.

Model Agency Listing

TigerXL

TigerXL,EXT

Tiger XL Cool Froth™

Espresso Machine

Model Tiger XL Cool Froth

with external milk (EXT)

Dimensions:19.3”Hx15.8”Wx18.1”D

(49 cm H x 40.1 cm W x 45.9 cm D)

Espresso Water Quality System

EQHP-ESP

ProductNo.:39000.0008

Replacement Cartridge

EQHP-ESPCRTG

ProductNo.:39000.1008

Urnex®Caﬁza™Cleaning Tablets

ProductNo.:36000.1189(100count)

ProductNo.:36000.1188(12/case)

Urnex®Rinza™

MilkFrotherCleaner

ProductNo.:39265.0000(each)

ProductNo.:39265.0001(6/case)

Urnex®Complete Cafe™

Sanitizer

ProductNo.:39265.0010(each)

ProductNo.:39265.0011(6/case)

Model Tiger XL Cool Froth

with milk drawer

Dimensions:25.5”Hx15.8”Wx18.1”D

(64.8 cm H x 40.1 cm W x 45.9 cm D)

Cup Heater

ProductNo.:35800.6400

Steamer

ProductNo.:35800.6401

BUNN®practicescontinuousproductresearchandimprovement.Wereservetherighttochangespecicationsandproductdesignwithoutnotice.Such

revisionsdonotentitlethebuyertocorrespondingchanges,improvements,additionsorreplacementsforpreviouslypurchasedequipment.

Alldimensionsshownininches. Bunn Corporation owns all copyrights relating to materials in this publication. Please contact Bunn Corporation to request permission to reproduce any portion of this publication.

Dimensions & Speciﬁcations

Bunn-O-MaticCorporationofCanada-280IndustrialPkwy.S.Aurora,OntarioL4G3T9•905-841-2866•Fax905-841-2775•www.bunn.com

CANADA

Tank Htr Total Cubic Weight Cord

Model Product # Volts Amps Watts Watts Capacity Measure lbs / kg Attached

TigerXL 35800.6909 208 11.5 2000 2400 180shots/hr 12.5ft3/.35m3 103/46.7 Yes/NoPlug

TigerXL,EXT 35800.6911 208 11.5 2000 2400 180shots/hr 10.5ft3/.30m3 88/39.9 Yes/NoPlug

Capacity per Hour: Espresso:180

  Cappucino:120

  ColdCappucino:100

  CafeLatte:100

  PODProducts:60

  HotWater:7.9gallons(30 litres)

Model includes: Machine, water ﬁltration system and installation.

Electrical:Modelrequires2-wiregroundedservicerated208V,singlephase,50/60Hz.

Plumbing:20-100psi(138-690kPa).Machinesuppliedwith1/4"malearetting.Allmachinesaresuppliedwitha

 wastewaterhoseandmustbeconnectedtoadrain.

Tiger XL, EXT

(front view)
