Bunn Tiger XL User manual

Features

Related Products

Item#

Project

Dat e

For current speciﬁcation sheets and other information, go to www.bunn.com.

Patents Apply 8/08 A8.3

BUNN Espress®Tiger XL Cool Froth Series

Simple solution for exceptional espresso beverages

from a sleek, compact super-automatic

• Upto180shotsperhourfromlessthan16” ofcounterspace.

• Yourchoiceoffourdrinkselections:espresso,cappuccino,latteandiced

cappuccino.

• Intelligentmodularbrewingchamberadjustsespresso.

• SimulatesBaristatampingandpolishingmotiontoprovideuniform

extraction.

• Two-grindermodelfortwovarietiesofespressobeans.

• Hoppershold1.75lbsoffreshbeans.

• Adjustsfor4.5to7.4inchcupclearance.

• Podbrewingoptionstandardonallmodels.

• Intuitiveoperationaldesign.Easytousecontrolpadguidesuserthrough

stepsformakingdrinks.

• Easydailycleaning.

• Innovativemilkdeliverysystemdoesnotinjectsteamorwatertodilutethe

foamsocustomersenjoyafull,richavorexperience.

•Availablewithaself-contained1gallonmilkdrawerorexternalmilk.

Model Agency Listing

TigerXL

TigerXL,EXT

Tiger XL Cool Froth™

Espresso Machine

Model Tiger XL Cool Froth EXT

external milk

Dimensions:19.3”Hx15.8”Wx18.1”D

(49 cm H x 40.1 cm W x 45.9 cm D)

Espresso Water Quality System

EQHP-ESP

ProductNo.:39000.0008

Replacement Cartridge

EQHP-ESPCRTG

ProductNo.:39000.1008

Caﬁza™Cleaning Tablets

ProductNo.:36000.1189(100count)

ProductNo.:36000.1188(12/case)

Rinza™

MilkFrotherCleaner

ProductNo.:39265.0000(each)

ProductNo.:39265.0001(6/case)

Complete Cafe™

Sanitizer

ProductNo.:39265.0010(each)

ProductNo.:39265.0011(6/case)

Model Tiger XL Cool Froth

with milk drawer

Dimensions:25.5”Hx15.8”Wx18.1”D

(64.8 cm H x 40.1 cm W x 45.9 cm D)

Cup Heater

ProductNo.:35800.0400

Steamer

ProductNo.:35800.0401

BUNN®practicescontinuousproductresearchandimprovement.Wereservetherighttochangespecicationsandproductdesignwithoutnotice.Such

revisionsdonotentitlethebuyertocorrespondingchanges,improvements,additionsorreplacementsforpreviouslypurchasedequipment.

Alldimensionsshownininches.

Dimensions & Speciﬁcations

Bunn-O-Matic®Corporation-1400StevensonDriveSpringeld,Illinois62703•800-637-8606•217-529-6601•Fax217-529-6644•www.bunn.com

Tank Heater Total Cubic Shipping Cord

Model Product # Volts Amps Watts Watts Capacity Measure Weight Attached

TigerXL 35800.0008 120 16 1700 1850 180shots/hr 12.5ft3 103lbs Yes/20APlug

 35800.0009 208 12 2000 2400 180shots/hr 12.5ft3 103lbs Yes/NoPlug

(.35 m3)(46.7 kg)

TigerXL,EXT 35800.0010 120 16 1700 1850 180shots/hr 10.5ft3 88lbs Yes/20APlug

 35800.0011 208 12 2000 2400 180shots/hr 10.5ft3 88lbs Yes/NoPlug

Capacity per Hour: Espresso:180      (.30 m3)(39.9 kg)

  Cappucino:120

  ColdCappucino:100

  CafeLatte:100

  PODProducts:60

  HotWater:7.9gallons(30 litres)

Model includes: Machine, water ﬁltration system, installation and 2-year preventative maintenance.

Electrical:Modelrequires2-wiregroundedservicerated120/208V,singlephase,50/60Hz.

Plumbing:20-100psi(138-690kPa).Machinesuppliedwith1/4”malearetting.Allmachinesaresuppliedwitha 

 wastewaterhoseandmustbeconnectedtoadrain.

Tiger XL, EXT

(front view)

8/08 © Bunn-O-Matic Corporation
