548J***D

SINGLE PACKAGE ROOFTOP

HEAT PUMP UNITS

WITH FIELD--INSTALLED ELECTRIC HEAT

SIZES 08--14 WITH PURONR(R--410A) REFRIGERANT

Submittal Data

Certified to ISO

Use of the AHRI Certified

TM Mark indicates a

manufacturer’s

participation in the

program For verification

of certification for individual

products, go to

www.ahridirectory.org.

9001

DESCRIPTION

548J***D units are one--piece, two--stage heat pump units

that are low profile, prewired, tested and charged at the

factory. These units have field convertible supply and return

openings and are intended for installation on a roof curb

accessory (ordered separately), or for slab mounting (for

horizontal duct connections). Units are designed to accept

field--installed electric heaters. Units may be ordered with

various factory--installed options. Field--installed accessories

are also available.

STANDARD FEATURES

Base Unit

SPuron (R--410A) HFC refrigerant

SSEER’s up to 13.4, EER’s up to 11.2

SIEER’s:

— up to 12.2 with single speed indoor fan motor

— up to 12.5 with 2--speed/VFD indoor fan motor

SHSPF’s up to 7.7 and COP’s up to 3.3

SASHRAE 90.1 compliant

SRated in accordance with AHRI Standard 340

SDesigned in accordance with Underwriters’

Laboratories Std 1995 and listed by UL and UL, Canada

STwo--stage cooling capacity control

SNon--corrosive composite sloping design; side or center

drain condensate pan. Meets ASHRAE Standard 62

SCooling operating range from 25_Fupto115_F

(--4_Cupto46_C). Field installed accessory extends

the minimum down to --20_F(--29_C)

SConvertible from vertical to horizontal airflow for slab

mounting

STwo--inch disposable return air filters

SThru--the--bottom power entry capability

SSingle point electric connections on field--installed

electric heat units

S24--volt control circuit protected with resettable circuit

breaker and 75--VA transformer

SBelt drive, constant torque, permanently lubricated

evaporator--fan motor on all size units.

STotally enclosed condenser motors with permanently

lubricated bearings

SState--of--the--art defrost control board, easily configured

for defrost cycles of 30, 60, 90, or 120 minutes.

SCentral Terminal Board for component and unit wiring

connections.

SLoss of Charge, High--Pressure, and Freeze Protection

switches

SFull perimeter base rail with built--in rigging adapters

andforktruckslots.

Cabinet

SAccess panels with easy grip handles

SInnovative, easy starting, no strip screw features on unit

access panels.

SPre--painted exterior panels and primer--coated interior

panels tested to 500 hours salt spray protection

SFully insulated cabinet

STool--less filter access door

Refrigerant System

SAcutroltrefrigerant metering system

SLiquid line filter drier

SScroll compressors with internal line--break overload

protection

SIndoor and outdoor coils constructed of aluminum fins

mechanically bonded to seamless copper tubes.

SRemovable gauge line plugs for reading refrigerant

pressure with unit panels in place

SFour--way reversing valve operation

SSuction Line Accumulator standard -- prevents

excessive liquid flood back of refrigerant to the

compressor even during the start of the defrost cycle.

Standard Parts Warranty

S5--year electric heater (field--installed)

S5--year compressor

S1--year parts

SUBMITTAL DATA

Job Name

Architect

Engineer

Contractor

Unit Designation

PERFORMANCE DATA

Unit Operating Weight lb

Cooling

Net Total Capacity Btuh

Net Sensible Capacity Btuh

Compressor Power Input kW

at Outdoor Air Temperature _F

Indoor Entering Air db: _Fwb _F

Airflow CFM External Static Pressure in.wg

Curb Weight lb

Heating

Power Input to Unit kw

Integrated Capacity Btuh

Indoor Operating Air Temperature _F

Outdoor Air Temperature _F (Winter Design)

Rating at 70% R.H. Outdoors kW Heater Selected

Heat/Cool Ratio

Electrical Capacity Required Btuh

ELECTRICAL DATA

Power Supply to Unit Volts Phase Hz

Minimum Circuit Amps Maximum Overcurrent Protection (Fuse Only)

548J***D

FACTORY--INSTALLED OPTIONS (FIOPs)

jEconomizer with DRY BULB sensing and barometric

relief

Standard Air Leak Dampers —

fModels with W7212 controller provides standard

non--diagnostic control. EconoMi$er IV.

fModels with W7220 controller meets California

Title 24 (section 120.2) Fault Detection and

Diagnostic (FDD) requirements. EconoMi$er X.

fModels with RTU Open controller meets California

Title 24 (section 120.2) Fault Detection and

Diagnostic (FDD) requirements. EconoMi$er 2.

jEconomizer with ENTHALPY sensing and barometric

relief

Standard Air Leak Dampers —

fModels with W7212 controller provides standard

non--diagnostic control. EconoMi$er IV.

fModels with W7220 controller meets California

Title 24 (section 120.2) Fault Detection and

Diagnostic (FDD) requirements. EconoMi$er X.

fModels with RTU Open controller meets California

Title 24 (section 120.2) Fault Detection and

Diagnostic (FDD) requirements. EconoMi$er 2.

jEconomizer with DRY BULB sensing and barometric

relief

ULTRA LOW LEAK Air Dampers —

fModels with W7220 controller meets California

Title 24 (section 120.2) Fault Detection and

Diagnostic (FDD) requirements, has return, outside

air and relief damper leakage that meets Title 24

(section 140.4 and ASHRAE 90.1) requirements --

plus 5 year limited parts warranty. EconoMi$er X.

fModels with RTU Open controller meets California

Title 24 (section 120.2) Fault Detection and

Diagnostic (FDD) requirements, has return, outside

air and relief damper leakage that meets Title 24

(section 140.4 and ASHRAE 90.1) requirements --

plus 5 year limited parts warranty. EconoMi$er 2.

jEconomizer with ENTHALPY sensing and barometric

relief

ULTRA LOW LEAK Air Dampers —

fModels with W7220 controller meets California

Title 24 (section 120.2) Fault Detection and

Diagnostic (FDD) requirements, has return, outside

air and relief damper leakage that meets Title 24

(section 140.4 and ASHRAE 90.1) requirements --

plus 5 year limited parts warranty. EconoMi$er X.

fModels with RTU Open controller meets California

Title 24 (section 120.2) Fault Detection and

Diagnostic (FDD) requirements, has return, outside

air and relief damper leakage that meets Title 24

(section 140.4 and ASHRAE 90.1) requirements --

plus 5 year limited parts warranty. EconoMi$er 2.

j2--Speed Indoor Fan Motor system utilizes a Variable

Frequency Drive (VFD) to automatically adjust the indoor

fan motor for 2 speed indoor fan motor control. Conforms

to ASHRAE 90.1 2010 Standard – section 6.4.3.10.b.

jRTU Open multi--protocol controller communicates to

LON, MODBUS, BACNET and Johnson N2 protocols.

jThrough the base connectors electric conduit

jTwo--position motorized outdoor air damper

jNon--fused disconnect switch (80 A Max)

jPowered 115--volt convenience outlet

jNon--powered 115--volt convenience outlet

jHigh static indoor fan motor and drive

jReturn Air smoke detector

jSupply Air smoke detector

jPre--coated Al/Cu condenser coil

jE--coated Al/Cu condenser coil

jE--coated Al/Cu condenser and evaporator coil

jCu/Cu condenser coil

jCu/Cu condenser coil and evaporator coil

jCondenser hail guard — louvered style

jCO2sensor

OPTIONAL WARRANTIES

jComplete Unit Parts only up to 5 years

jComplete Unit Parts and Labor up to 5 years

Many other optional warranties are available.

See the Commercial Start--Up and Optional Extended

Warranty Price price pages for further information.

548J***D

FIELD INSTALLED ACCESSORIES

jEconomizer with DRY BULB sensing and barometric

relief

Standard Air Leak Dampers —

fModels with W7212 controller provides standard

non--diagnostic control. EconoMi$er IV.

fModels with W7220 controller meets California

Title 24 (section 120.2) Fault Detection and

Diagnostic (FDD) requirements. EconoMi$er X.

fModels with RTU Open controller meets California

Title 24 (section 120.2) Fault Detection and

Diagnostic (FDD) requirements. EconoMi$er 2.

jEconomizer with ENTHALPY sensing and barometric

relief

Standard Air Leak Dampers —

fModels with W7212 controller provides standard

non--diagnostic control. EconoMi$er IV.

fModels with W7220 controller meets California

Title 24 (section 120.2) Fault Detection and

Diagnostic (FDD) requirements. EconoMi$er X.

fModels with RTU Open controller meets California

Title 24 (section 120.2) Fault Detection and

Diagnostic (FDD) requirements. EconoMi$er 2.

jEconomizer with DRY BULB sensing and barometric

relief

ULTRA LOW LEAK Air Dampers —

fModels with W7220 controller meets California

Title 24 (section 120.2) Fault Detection and

Diagnostic (FDD) requirements, has return, outside

air and relief damper leakage that meets Title 24

(section 140.4 and ASHRAE 90.1) requirements.

EconoMi$er X.

fModels with RTU Open controller meets California

Title 24 (section 120.2) Fault Detection and

Diagnostic (FDD) requirements, has return, outside

air and relief damper leakage that meets Title 24

(section 140.4 and ASHRAE 90.1) requirements.

EconoMi$er 2.

jEconomizer with ENTHALPY sensing and barometric

relief

ULTRA LOW LEAK Air Dampers —

fModels with W7220 controller meets California

Title 24 (section 120.2) Fault Detection and

Diagnostic (FDD) requirements, has return, outside

air and relief damper leakage that meets Title 24

(section 140.4 and ASHRAE 90.1) requirements.

EconoMi$er X.

fModels with RTU Open controller meets California

Title 24 (section 120.2) Fault Detection and

Diagnostic (FDD) requirements, has return, outside

air and relief damper leakage that meets Title 24

(section 140.4 and ASHRAE 90.1) requirements.

EconoMi$er 2.

jDisplay Kit for Variable Frequency Drive (VFD),

2--Speed Indoor Fan Motor System. Allows additional

set up and diagnostics of the unit VFD controller. Can

be unit mounted or used with any other compatible

VFD model as a reusable device.

jPower Exhaust — vertical or horizontal

jElectric heat

jSingle point kit

jTwo--position motorized outdoor air damper

jManual outdoor air damper 25%

jManual outdoor air damper 50%

jRoofcurb — 14 inch (356mm) tall

jRoofcurb — 24 inch (610mm) tall

jThru--the--bottom utility connection kit

jTime Guard II compressor anti--cycle control

jOutdoor coil hail guard — louvered style

jLow ambient head pressure controller, down to --20_F

(--29_C)

jProgrammable setback thermostat

jElectrical/Mechanical thermostat and subbase

jPhase monitor

jHead pressure control

jDisconnect switch bracket (for size 14 units only)

jSupply Duct Cover (for size 14 units only)

Economizer Sensors

jSingle Dry bulb control

jDifferential Dry bulb control

jSingle enthalpy control

jDifferential enthalpy control

jCO2-- wall mounted

jCO2-- duct mounted

548J***D

CERTIFIED DIMENSION 548J*08 -- 09D

C12051

548J***D

CERTIFIED DIMENSION 548J*08 -- 09D

C12052

548J***D

CERTIFIED DIMENSION 548J*12D

C12053

548J***D

CERTIFIED DIMENSION 548J*12D

C12054

548J***D

CERTIFIED DIMENSION 548J*14D

C14194

548J***D

CERTIFIED DIMENSION 548J*14D

C14195

548J***D

This manual suits for next models

Table of contents

Other Bryant Heat Pump manuals

Bryant

Bryant LEGACY 213R Operation manual

Bryant

Bryant 663C Instructions and recipes

Bryant

Bryant 280ANV EVOLUTION User manual

Bryant

Bryant Evolutiont 286A User manual

Bryant

Bryant 575J Dimensions and installation guide

Bryant

Bryant 548J*D Series User manual

Bryant

Bryant 548J*14D Series User manual

Bryant

Bryant 549C User manual

Bryant

Bryant PREFERRED 607C--A Series User manual

Bryant

Bryant 548J*D Series Installation and user guide

Bryant

Bryant Legacy 213B User manual

Bryant

Bryant SPLIT-SYSTEM 697C User manual

Bryant

Bryant Evolution Extreme 186CNV User manual

Bryant

Bryant Legacy 215B Operation manual

Bryant

Bryant LEGACY 677C E Series User manual

Bryant

Bryant 698B Instructions and recipes

Bryant

Bryant CH17NA User manual

Bryant

Bryant 575Jx08G/H Series Dimensions and installation guide

Bryant

Bryant Evolution 284ANV Series User manual

Bryant

Bryant 677D--A User manual

Bryant

Bryant CNPHP User manual

Bryant

Bryant 569J 08G Series Dimensions and installation guide

Bryant

Bryant 657A Instructions and recipes

Bryant

Bryant 288BNV EVOLUTION V User manual

Popular Heat Pump manuals by other brands

MICROWELL

MICROWELL HP 1000 GREEN Installation and user manual

Sanyo

Sanyo SAP120FCH Service manual

Daikin

Daikin EHYHBH05AA Operation manual

Panasonic

Panasonic WH-SDF03E3E5 Design handbook

Airxcel

Airxcel 45000 Series Installation, operation and maintenance instructions

Mitsubishi Electric

Mitsubishi Electric PUZ-SWM60VAA Service manual

Dimplex

Dimplex LI 16I-TUR Installation and operating instruction

Carrier

Carrier WSHP Open v3 Integration guide

TGM

TGM CTV14CN018A Technical manual

Carrier

Carrier 38MGQ Series installation instructions

Kokido

Kokido K2O K880BX/EU Owner's manual & installation guide

Viessmann

Viessmann VITOCAL 300-G PRO Type BW 2150 Installation and service instructions

Carrier

Carrier 48EZN installation instructions

Viessmann

Viessmann KWT Vitocal 350-G Pro Series Installation and service instructions for contractors

Ariston

Ariston NIMBUS user manual

Weishaupt

Weishaupt WWP L 7 Installation and operating instruction

GE Zoneline AZ85H09EAC datasheet

Daikin

Daikin altherma EJHA04AAV3 installation manual
