Bryant CK5A User manual

Form No. PDS CK5A.18.1

FURNACE N-COILS

CK5A, CK5B

Sizes A018 thru A060

This vertical design N-coil is a furnace coil designed to provide

the highest standards of reliability and durability. The product is

offered in a painted cased (CK5A) or an embossed cased

(CK5B) version. The cased coils are offered in standard, over-

hang, and wide configurations for use in multiple installation ap-

plications.Additionally,thecasedcoilsareofferedinaTransition

configuration, which is designed to fit two furnace widths without

field modification.

Easy maintenance is provided as the coil slides out of the cabi-

net after removing the access door and service panel.

The coils are available in sizes 018 through 060 (1-1/2-5 tons).

COMMON FEATURES

Water Management

—The CK coil design does an excellent job

of water management. The coils are designed to avoid water

blow-off into the ducts by directing condensate away from the

fins and into the drain pan. The coils drain pan design provides

improved condensate removal into the drain. This improves in-

door air quality.

Durable Condensate Pan

—Each coil is equipped with a corro-

sion resistant condensate drain pan. The condensate drain pan

is designed with a slope to help ensure proper drainage, im-

proved moisture removal, and home comfort.

Compact Design

—Unique design offers as much as 2 in. less

in height to aid in tight installations.

Brass Inserts

— Every condensate pan features two 3/4 in. fe-

male threaded brass insert connections. The Bryant unique

brass inserts provide for a leak-free condensate line connection

to prevent water damage.

Refrigerant Connections

—The coils are provided with proven

sweat-connections for leak-free operation maintaining system

reliability.

Burst Pressures

—These coils meet or exceed burst pressure

of 2100 psi which is at least three to five times the pressure they

will see in actual application.

External Piston Location

—Provides easy access to the piston

metering device, for quick installations and standard service pro-

cedures.

Liquid Line Bracket

—Holds the piston body in place for quick,

safe piston access without needing a back-up wrench.

Neoprene Ring

—The ring, installed inside the liquid line con-

nection, is the best option for preventing refrigerant leaks and fu-

ture service calls. Neoprene works with both Puron® and R-22

Refrigerant.

Protective Tube Sheets

—Protect the durable copper tubing

from being damaged during the manufacturing and installation

process.

Warranty

—All Bryant coils feature a 1-year limited warranty on

parts, with additional extended warranties available for the

system.

—2—

MODEL NUMBER NOMENCLATURE

CK5

C—Coil

K—Cased, N-Coil

5—Upflow/Downflow

CERTIFICATION APPLIES ONLY WHEN

USED WITH PROPER COMPONENTS

AS LISTED WITH ARI

AXA018

018—1-1/2 Ton

024—2 Ton

030—2-1/2 Ton

Etc.

014—14-3/16 in.

017—17-1/2 in.

021—21 in.

024—24 1/2 in.

A — Standard

N — Narrow

T — Transition

W — Wide

X — Max Cap

Position

A—Painted

B—Embossed

014

—3—

A97606

DIMENSIONS (In.)

* In these models the coil can be removed from the casing and installed as an uncased coil without needing to field fabricate the coil enclosure to prevent air bypass.

UNIT SERIES A B C D E F G SHIPPING

WEIGHT (LB)

CK5(A,B)XA018014* A 14-3/16 13-1/4 12-9/16 5 5/8 2-1/8 1-3/8 28-1/2

CK5(A,B)XA024014* A 14-3/16 13-1/4 12-9/16 7-1/16 5/8 2-1/8 1-3/8 32

CK5(A,B)XW024017 A 17-1/2 13-1/4 15-7/8 6-11/16 5/8 2-1/8 1-3/8 33

CK5(A,B)XA030014* A 14-3/16 15-1/4 12-9/16 9-1/16 3/4 2-1/8 1-3/8 35-1/2

CK5(A,B)XW030017 A 17-1/2 15-1/4 15-7/8 8-13/16 3/4 2-1/8 1-3/8 37-1/2

CK5(A,B)XA036017* B 17-1/2 17-5/8 15-7/8 10-13/16 3/4 2-1/8 1-3/8 43

CK5(A,B)XN036014 B 14-3/16 17-5/8 12-9/16 11-3/16 3/4 2-1/8 1-3/8 40

CK5(A,B)XT036017* A 17-1/2 19-7/16 15-7/8 13-1/16 3/4 4-3/8 3-5/8 49

CK5(A,B)XW036021 B 21 17-5/8 19-3/8 10-1/2 3/4 2-1/8 1-3/8 44

CK5(A,B)XA042021* B 21 17-5/8 19-3/8 10-1/2 7/8 2-1/8 1-3/8 44

CK5(A,B)XN042017 B 17-1/2 17-5/8 15-7/8 10-7/8 7/8 2-1/8 1-3/8 43

CK5(A,B)XT042021* A 21 19-7/16 19-3/8 12-3/4 7/8 4-3/8 3-5/8 52

CK5(A,B)XA048021* B 21 19-5/8 19-3/8 12-11/16 7/8 2-1/8 1-3/8 47-1/2

CK5(A,B)XN048017 B 17-1/2 19-5/8 15-7/8 12-15/16 7/8 2-1/8 1-3/8 45-1/2

CK5(A,B)XT048021* A 21 21-3/8 19-3/8 14-15/16 7/8 4-3/8 3-5/8 56

CK5(A,B)XW048024 B 24-1/2 19-5/8 22-7/8 12-3/16 7/8 2-1/8 1-3/8 49-1/2

CK5(A,B)XA060024* A 24-1/2 22-5/8 22-7/8 16-1/2 7/8 2-1/8 1-3/8 62

CK5(A,B)XN060021 A 21 26-15/16 19-3/8 14-3/8 7/8 2-1/8 1-3/8 67

CK5(A,B)XT060024* A 24-1/2 24-7/8 22-7/8 18-3/4 7/8 4-3/8 3-5/8 69

CK5(A,B)XX060024 A 24-1/2 26-15/16 22-7/8 14-1/4 7/8 2-1/8 1-3/8 70

C1 1⁄8″

21⁄8″

19″

21″

1 9⁄16″

2 5⁄8″

2″

1 7⁄8″

13⁄16″

5⁄8″

E SUCTION LINE

3⁄4–IN.

PLUGGED

DRAIN

3⁄4–IN. NPT DRAIN

FRONT RIGHT SIDE

NOTE: 1.Series designation is the 14th position of

unit model number.

3 1⁄16″

—4—

GROSS COOLING CAPACITIES (MBH)

CFM

— Cubic Ft per Minute

EWB

— Entering Wet Bulb (°F)

— Gross Cooling Capacity 1000 Btuh

SHC

— Gross Sensible Capacity 1000 Btuh

— Bypass Factor

MBH

— 1000 Btuh

UNIT

SIZE

INDOOR COIL

AIR SATURATED TEMPERATURE LEAVING EVAPORATOR (°F)

30 35 40 45 50

CFM EWB TC SHC BF TC SHC BF TC SHC BF TC SHC BF TC SHC BF

A018

450 72 31.9 14.8 0.00 28.9 13.4 0.00 26.0 12.1 0.00 22.6 10.7 0.07 18.5 9.04 0.06

26.8 15.8 0.07 23.7 14.3 0.06 20.5 12.8 0.05 16.7 11.2 0.04 12.5 9.40 0.05

21.8 16.6 0.04 18.6 14.9 0.04 15.4 13.3 0.05 12.3 11.7 0.08 9.95 9.95 0.18

600 72 37.5 17.3 0.00 34.0 15.8 0.00 30.5 14.2 0.16 26.5 12.6 0.11 22.1 10.9 0.09

31.3 18.7 0.10 27.8 17.1 0.09 24.3 15.5 0.08 20.1 13.7 0.07 15.2 11.7 0.09

25.8 20.1 0.08 22.2 18.4 0.08 18.6 16.6 0.08 15.2 14.7 0.11 12.5 12.5 0.22

750 72 41.7 19.2 0.00 37.9 17.6 0.00 34.0 16.0 0.17 29.6 14.2 0.14 24.7 12.4 0.12

35.1 21.2 0.13 31.0 19.5 0.12 26.9 17.7 0.11 22.6 15.9 0.11 17.4 13.7 0.12

28.4 22.9 0.10 24.9 21.3 0.10 21.4 19.6 0.11 17.7 17.5 0.14 14.8 14.8 0.26

A024

W024

600 72 38.7 17.9 0.00 35.4 16.4 0.00 32.0 15.0 0.13 28.1 13.3 0.08 23.7 11.6 0.07

32.6 19.5 0.07 29.1 17.9 0.06 25.6 16.3 0.06 21.5 14.5 0.05 16.6 12.5 0.06

27.0 20.9 0.05 23.4 19.2 0.05 19.8 17.4 0.05 16.2 15.5 0.08 13.3 13.3 0.18

800 72 44.0 20.4 0.21 40.4 18.9 0.17 36.8 17.3 0.13 32.4 15.6 0.11 27.2 13.7 0.10

37.4 22.8 0.10 33.5 21.1 0.10 29.5 19.4 0.09 25.0 17.5 0.08 19.7 15.4 0.09

30.6 25.0 0.07 27.0 23.2 0.08 23.4 21.4 0.09 19.7 19.3 0.12 16.6 16.6 0.23

1000 72 47.9 22.3 0.18 44.0 20.7 0.17 40.1 19.2 0.16 35.5 17.4 0.14 30.0 15.4 0.13

40.7 25.5 0.13 36.6 23.8 0.13 32.4 22.0 0.12 27.3 20.0 0.11 21.9 17.9 0.12

33.7 28.6 0.10 30.0 26.7 0.11 26.2 24.9 0.12 22.7 22.5 0.17 19.4 19.4 0.28

A030

W030

750 72 54.4 25.3 0.00 48.7 22.7 0.00 43.1 20.1 0.00 36.6 17.3 0.07 29.3 14.5 0.06

45.1 26.5 0.07 39.1 23.7 0.07 33.2 20.9 0.06 26.7 18.1 0.05 20.0 15.2 0.08

36.0 27.3 0.05 30.5 24.5 0.06 25.0 21.8 0.07 19.7 19.0 0.09 16.1 16.1 0.21

1000 72 64.1 29.5 0.00 57.7 26.7 0.00 51.2 23.9 0.19 43.9 20.9 0.12 35.2 17.6 0.10

53.6 31.8 0.11 46.8 28.7 0.10 40.1 25.6 0.10 32.3 22.3 0.09 24.1 18.8 0.11

43.4 33.4 0.10 36.9 30.3 0.10 30.4 27.2 0.10 24.3 24.0 0.12 20.1 20.1 0.26

1250 72 72.1 33.0 0.00 64.7 29.9 0.00 57.3 26.8 0.20 49.4 23.7 0.15 40.1 20.3 0.14

59.6 35.8 0.14 52.4 32.7 0.14 45.3 29.5 0.13 36.8 25.9 0.13 27.5 22.0 0.15

49.0 38.4 0.14 42.0 35.2 0.13 35.0 32.1 0.13 28.6 28.4 0.16 23.7 23.7 0.30

A036

N036

T036

W036

900 72 63.4 29.6 0.00 57.2 26.8 0.00 50.9 23.9 0.00 44.3 21.0 0.00 36.3 17.9 0.00

52.1 31.0 0.00 46.0 28.1 0.00 39.8 25.1 0.00 32.8 22.1 0.00 24.9 18.8 0.01

42.8 32.7 0.00 36.7 29.6 0.00 30.5 26.6 0.01 23.9 23.0 0.04 19.2 19.2 0.18

1200 72 75.1 34.7 0.00 67.8 31.6 0.00 60.5 28.5 0.05 52.1 25.1 0.03 43.4 21.8 0.02

61.6 37.2 0.02 54.5 34.0 0.02 47.5 30.8 0.02 39.3 27.3 0.02 30.2 23.4 0.04

51.1 40.2 0.02 44.0 36.7 0.03 36.9 33.2 0.03 29.3 28.9 0.08 24.2 24.2 0.22

1500 72 83.3 38.5 0.17 75.5 35.3 0.13 67.6 32.1 0.09 58.5 28.5 0.06 48.4 24.8 0.06

69.4 42.5 0.06 61.3 38.9 0.06 53.1 35.4 0.05 44.4 31.7 0.05 34.5 27.5 0.07

56.6 46.2 0.04 49.3 42.5 0.06 42.0 38.8 0.07 34.3 34.3 0.11 28.8 28.8 0.25

A042

N042

T042

1050 72 75.4 35.0 0.00 68.0 31.8 0.00 60.7 28.6 0.02 52.7 25.3 0.00 43.6 21.7 0.00

62.1 37.3 0.00 55.0 34.0 0.00 47.8 30.7 0.00 39.3 26.9 0.01 30.2 23.1 0.03

51.5 39.8 0.01 44.2 36.2 0.01 36.9 32.7 0.02 29.1 28.3 0.06 23.7 23.7 0.20

1400 72 87.8 40.6 0.18 79.4 37.1 0.13 71.0 33.6 0.07 61.3 29.8 0.05 51.0 25.9 0.05

72.9 44.4 0.05 64.4 40.7 0.04 55.9 36.9 0.04 46.7 33.0 0.04 36.1 28.5 0.06

60.0 48.3 0.03 52.0 44.3 0.05 44.0 40.3 0.06 35.5 35.5 0.10 29.7 29.7 0.24

1750 72 96.3 44.6 0.16 87.4 41.1 0.13 78.5 37.5 0.11 67.9 33.5 0.09 55.9 29.1 0.09

80.8 50.1 0.08 71.5 46.1 0.08 62.2 42.2 0.08 51.9 37.9 0.08 40.9 33.4 0.10

65.7 55.1 0.07 57.6 50.9 0.08 49.5 46.6 0.10 41.7 41.7 0.15 35.0 35.0 0.28

A048

N048

T048

W048

1200 72 79.8 36.9 0.00 72.6 33.7 0.00 65.4 30.6 0.12 57.0 27.1 0.08 47.5 23.4 0.07

66.6 39.8 0.07 59.1 36.4 0.06 51.7 33.0 0.06 43.2 29.3 0.05 33.3 25.2 0.07

55.2 42.8 0.06 47.6 39.1 0.06 40.0 35.4 0.06 32.2 31.3 0.08 26.7 26.7 0.20

1600 72 91.0 42.1 0.22 83.0 38.7 0.18 75.0 35.4 0.13 65.4 31.7 0.11 54.5 27.6 0.10

76.7 46.9 0.10 68.1 43.1 0.10 59.5 39.4 0.09 50.1 35.4 0.09 39.4 31.0 0.11

62.7 51.0 0.08 54.9 47.2 0.09 47.1 43.4 0.10 39.3 39.0 0.13 33.1 33.1 0.25

2000 72 99.2 46.1 0.19 90.7 42.7 0.17 82.2 39.4 0.15 72.0 35.5 0.14 60.0 31.2 0.13

84.0 52.6 0.13 74.8 48.8 0.13 65.7 44.9 0.12 55.1 40.5 0.12 44.0 36.0 0.13

69.0 58.5 0.11 60.8 54.3 0.12 52.6 50.2 0.14 45.4 45.4 0.18 38.5 38.5 0.30

—5—

GROSS COOLING CAPACITIES (MBH) Continued

CFM

— Cubic Ft per Minute

EWB

— Entering Wet Bulb (°F)

LWB

— Leaving Wet Bulb (°F)

— Total Cooling Capacity 1000 Btuh

SHC

— Total Sensible Capacity 1000 Btuh

— Bypass Factor

MBH

—1000 Btuh

NOTES:

1. Contact manufacturer for cooling capacities at conditions other than

shown in table.

2. Formulas:

Leaving db = entering db —

Leaving wb = wb corresponding to enthalpy of air leaving coil (h

LWB

)

LWB

= h

EWB

—

where h

EWB

= enthalpy of air entering coil.

UNIT

SIZE

INDOOR COIL

AIR SATURATED TEMPERATURE LEAVING EVAPORATOR (°F)

30 35 40 45 50

CFM EWB TC SHC BF TC SHC BF TC SHC BF TC SHC BF TC SHC BF

A060

N060

T060

1600 72 101.0 46.7 0.00 90.8 42.2 0.00 80.4 37.6 0.12 69.1 33.0 0.08 56.0 28.0 0.07

67 83.8 49.9 0.07 73.5 45.2 0.07 63.1 40.5 0.06 51.1 35.3 0.06 38.0 29.8 0.08

62 68.7 53.0 0.07 58.2 48.0 0.07 47.7 43.0 0.07 38.2 37.6 0.11 31.6 31.6 0.24

2000 72 113.0 52.2 0.00 102.0 47.4 0.00 90.4 42.6 0.14 77.5 37.5 0.11 63.5 32.3 0.10

67 94.0 56.8 0.10 82.6 51.8 0.10 71.2 46.8 0.09 58.5 41.3 0.10 43.7 35.2 0.11

62 77.0 61.2 0.09 66.0 56.0 0.10 55.1 50.7 0.10 45.0 44.7 0.15 37.3 37.3 0.28

2400 72 123.0 56.6 0.26 111.0 51.6 0.21 98.4 46.7 0.16 84.2 41.2 0.13 69.4 35.8 0.13

67 103.0 62.8 0.13 89.9 57.4 0.13 77.3 52.0 0.12 64.3 46.5 0.12 48.3 40.0 0.14

62 83.0 68.4 0.11 72.2 63.0 0.12 61.4 57.5 0.13 51.1 51.1 0.18 42.5 42.5 0.32

X060

1600 72 106.0 49.0 0.00 94.4 44.0 0.00 83.1 39.0 0.07 71.6 34.3 0.05 58.4 29.1 0.06

67 85.7 51.3 0.05 75.4 46.5 0.05 65.1 41.7 0.05 52.9 36.4 0.05 39.8 30.9 0.07

62 70.8 54.8 0.04 59.6 49.2 0.05 48.4 43.7 0.06 38.0 37.2 0.13 31.1 31.1 0.26

2000 72 116.0 53.7 0.18 105.0 49.2 0.14 94.7 44.7 0.10 81.6 39.5 0.08 67.3 34.0 0.08

67 97.6 59.1 0.07 86.1 54.0 0.07 74.5 48.8 0.07 61.4 43.1 0.07 46.4 36.9 0.09

62 80.0 64.0 0.05 68.4 58.1 0.07 56.8 52.1 0.09 45.0 44.7 0.16 37.4 37.4 0.29

2400 72 128.0 59.4 0.17 116.0 54.4 0.15 104.0 49.4 0.12 89.9 43.9 0.10 74.1 38.0 0.10

67 108.0 66.0 0.09 94.7 60.4 0.09 81.8 54.7 0.10 67.9 48.8 0.10 51.9 42.3 0.11

62 86.4 71.3 0.08 75.0 65.4 0.10 63.6 59.5 0.12 52.1 52.1 0.17 43.3 43.3 0.31

sensible heat cap.

1.09 x CFM

total capacity (Btuh)

4.5 x CFM

3. Direct interpolation is permissible.Do not extrapolate.

4. SHC is based on 80°F db temperature of air entering coil.

Below 80°F db, subtract (Correction Factor x CFM) from SHC.

Above 80°F db, add (Correction Factor x CFM) to SHC.

5. All data points are based on 10°F superheat leaving coil.

6. Bypass Factor = 0 indicates no psychometric solution. Use bypass

factor of next lower EWB for approximation.

Interpolation is permissible.

Correction Factor = 1.09 x (1 – BF) x (db – 80)

BYPASS

FACTOR

ENTERING AIR DRY BULB TEMPERATURE (°F)

79 78 77 76 75 Under 75

81 82 83 84 84 Over 85

Correction Factor

0.10 0.98 1.96 2.94 3.92 4.91 Use formula

shown below

0.20 0.87 1.74 2.62 3.49 4.36

0.30 0.76 1.53 2.29 3.05 3.82

—6—

COIL STATIC PRESSURE DROP (In. WC)

INDOOR COIL PISTONS

UNIT SIZE BULB AIR QUANTITY (CFM)

A018

400 500 600 700 800 —

WET 0.08 0.12 0.16 0.22 0.29 —

DRY 0.07 0.11 0.15 0.20 0.27 —

A024

600 700 800 900 — —

WET 0.16 0.21 0.26 0.31 — —

DRY 0.14 0.19 0.24 0.29 — —

W024

600 700 800 900 — —

WET 0.15 0.20 0.24 0.30 — —

DRY 0.13 0.18 0.23 0.29 — —

A030

700 800 900 1000 1100 —

WET 0.17 0.22 0.28 0.33 0.41 —

DRY 0.16 0.21 0.27 0.32 0.40 —

W030

700 800 900 1000 1100 —

WET 0.13 0.16 0.20 0.24 0.27 —

DRY 0.10 0.14 0.17 0.20 0.24 —

A036

T036

900 1000 1100 1200 1300 —

WET 0.18 0.22 0.26 0.30 0.35 —

DRY 0.15 0.18 0.22 0.26 0.30 —

W036

900 1000 1100 1200 1300 —

WET 0.15 0.18 0.21 0.25 0.28 —

DRY 0.12 0.14 0.16 0.19 0.23 —

N036

800 900 1000 1100 — —

WET 0.24 0.29 0.36 0.44 — —

DRY 0.23 0.28 0.34 0.43 — —

A042

T042

1000 1100 1200 1300 1400 —

WET 0.18 0.21 0.25 0.28 0.32 —

DRY 0.14 0.16 0.19 0.23 0.24 —

N042

1000 1100 1200 1300 1400 —

WET 0.22 0.26 0.30 0.35 0.41 —

DRY 0.18 0.22 0.26 0.30 0.34 —

A048

T048

1300 1400 1500 1600 — —

WET 0.21 0.24 0.28 0.31 — —

DRY 0.19 0.22 0.25 0.28 — —

W048

1300 1400 1500 1600 1700 —

WET 0.16 0.17 0.19 0.21 0.23 —

DRY 0.14 0.16 0.18 0.20 0.22 —

N048

1200 1300 1400 1500 — —

WET 0.25 0.30 0.34 0.40 — —

DRY 0.23 0.27 0.31 0.35 — —

N060

1600 1700 1800 — — —

WET 0.27 0.30 0.33 — — —

DRY 0.25 0.28 0.31 — — —

A060

T060

1600 1700 1800 1900 2000 2100

WET 0.19 0.21 0.23 0.26 0.29 0.33

DRY 0.17 0.19 0.21 0.23 0.25 0.28

X060

1600 1700 1800 1900 2000 2100

WET 0.21 0.23 0.25 0.27 0.29 0.31

DRY 0.16 0.18 0.20 0.22 0.25 0.27

UNIT FACTORY-INSTALLED

INDOOR PISTON SIZE

CK5A/CK5BA018 52

CK5A/CK5BA024, W024 59

CK5A/CK5BA030, W030 67

CK5A/CK5BA036, N036, T036, W036 70

CK5A/CK5BA042, N042, T042 78

CK5A/CK5BA048, N048, T048, W048 84

CK5A/CK5BA060, N060, T060, X060 90

—7—

SPECIFICATIONS SUBJECT TO CHANGE WITHOUT NOTICE

UNIT MUST BE INSTALLED IN ACCORDANCE

WITH INSTALLATION INSTRUCTIONS

Cancels: PDS CJ5A.18.3

—8—

PRINTED IN U.S.A. Catalog No. 12CK-5A1 4-99

SERVICE TRAINING

Packaged Service Training programs are an excellent way to increase your

knowledge of the equipment discussed in this manual, including:

 • Unit Familiarization • Maintenance

 • Installation Overview • Operating Sequence

A large selection of product, theory, and skills programs is available, using popular

video-based formats and materials. All include video and/or slides, plus companion

book.

Classroom Service Training plus "hands-on" the products in our labs can mean

increased confidence that really pays dividends in faster troubleshooting, fewer

callbacks. Course descriptions and schedules are in our catalog.

CALL FOR FREE CATALOG 1-800-962-9212

[ ] Packaged Service Training [ ] Classroom Service Training

A94328

This manual suits for next models

Table of contents

Other Bryant Furnace Accessories manuals

Bryant

Bryant CK3B User manual

Bryant

Bryant 394GAD User manual

Popular Furnace Accessories manuals by other brands

Honeywell

Honeywell CQ8000A installation instructions

Carrier

Carrier KGATW0601HSI installation instructions

Carrier

Carrier 337938 -782 -CBP installation instructions

Thermo Pride

Thermo Pride AOPS7488 instructions

Trane

Trane 4TXCA002DS3HCA Installer's guide

Central Boiler

Central Boiler ECL 1400 installation instructions

Lennox

Lennox Twinning Kit 16W72 installation instructions

Dungs

Dungs GasMultiBloc MB-D B01 instructions

Carrier

Carrier AGAGC9NPS01D installation instructions

Carrier

Carrier AGAGC9NPS01C installation instructions

ICP

ICP NAHA00601WK installation instructions

Dungs

Dungs GasMultiBloc MB-ZR B01 Series Operation and assembly instructions

Dungs

Dungs GasMultiBloc MB-ZR B01 Series Operation and assembly instructions

Carrier

Carrier KGBPN42011SP installation instructions

Carrier

Carrier KGBPN42011SP installation instructions

Carrier

Carrier 337938-791-CBP installation instructions

Empire Comfort Systems

Empire Comfort Systems ROK-1 installation instructions

Carrier

Carrier 337938-782-CBP owner's manual
