Brother BAS-326G PS Guide

RECOMMENDABLE SPARE PARTS BAS-311/326G PS 2009．01.08

NAME　OF　PARTS 品名 CODE

MOTOR　ASSY,CDD-430D モータクミCDD-430D J８０９９１－００１

PCB　ASSY,POWER　SUPPLY　MOTOR 電源モータ基板クミ SA３７５５－２０１

PANEL　PCB　ASSY パネル基板クミ SA３８３３－１０１

PCB　ASSY , PMD PMD基板クミ SA３７３９－３０１

PCB　ASSY , MAIN メイン基板クミ SA４５５６－１０１

PULSE　MOTOR　ASSY　PパルスモータPクミ SA４８２６－１０１

PULSE　MOTOR　ASSY　XパルスモータXクミ SA４８２０－１０１

PULSE　MOTOR　ASSY　YパルスモータYクミ SA４８２３－１０１

THREAD　TRIMMER　SOLENOID　ASSY イトキリソレノイド SA５１３５－００１

THREAD　WIPER　SOLENOID イトハライソレノイドクミ SA５２０８－００１

TENSION　RELEASE　HV　ASSY イトユルメクミHV SA４８３１－１０１

H-POSITION　SENSOR　ASSY ゲンテンセンサクミ SA４８３０－００１

NEEDLE　BAR　PハリボウPSB００１３－００１

NEEDLE　BAR　BUSH , D ハリボウメタルDSA３２２４－００１

THREAD　TAKE-UP　LEVER　P　SET ハリボウレンカンPクミ SB００１１－００１

SLIDE　BLOCK カクコマ１４２２１１－００１

Y-FEED　GEAR Yオクリギヤ SA４６５４－００１

X-FEED　GEAR Xオクリギヤ SA４６５３－００１

GEAR　１６クドウギヤ１６ SA３７０７－００１

WORK　CLAMP　RETAINER　ASSY オサエアシリテーナクミ SA４７０６－００１

NEEDLE　HOLE　PLATE ハリアナイタФ２．４ SA３３３６－１０１

BOBBIN　CASE　ASSY ボビンケースクミ SB００４６－００１

BOBBIN　ボビン SB００４９－００１

ROTARY　HOOK　ASSY , W/BOX　SB0038 カマハコクミ SB０３１８－００１

HOOK STOPPER カマトメ SB００３６－００１

HOOK STOPPER BRACKET カマトメアンナイ SB００３５－００１

MOVABLE　KNIFE　ASSY　イドウハクミ SB００７５－００１

M-KNIFE CONNECTING PLATE イドウハレンカン SB００７２－００１

FIXED　KNIFE　PコテイハPSB００７７－００１

THREAD HOLD SPRING イトホジバネ SB０３３１－００１

SPRING , TENSION イトチョウシバネ１０７６０６－００１

LOWER THREAD HOLD SPRING イトオサエバネ SB００８０－００１

NEEDLE PLATE SPACER ハリイタスペーサ SB００７８－００１

THREAD TRIMMER LINK イトキリリンク SB００８３－００１

SHOULDER SCREW7-3 ダンネジ７－３ SB００８４－００１

THREAD　TAKE-UP　SPRING イトトリバネ１４４５８８－4０１

NEEDLE　BAR　THREAD　GUIDE ハリボウイトアンナイASA３２５７－１０１

PRESSER　FOOT オサエアシAS４２８４３－００１

PRESSER　FOOT オサエアシBS４２８４４－００１

Q'TY

1

1

1

1

1

1

1

1

1

1

1

1

1

1

1

1

1

1

1

4

1

2

2

1

1

1

1

1

1

1

1

1

1

1

1

1

1

1

1
