Start Here MFC-J200

Quick Setup Guide

ASA/SAF Version 0

Please read the Product Safety Guide first before you set up your machine. Then, please read this Quick Setup

Guide for the correct setup and installation.

User’s Guides for this model are available on the enclosed CD-ROM.

Unpack the machine

WARNING

• Plastic bags are used in the packing of your machine. To avoid the danger of suffocation, keep these

plastic bags away from babies and children. Plastic bags are not toys.

• To ensure safe operation the supplied plug must be inserted only into a standard power outlet that is

properly grounded through the standard electrical wiring. Non grounded equipment may cause an

electrical shock hazard, and may cause excessive electrical noise radiation.

aRemove the protective tape and film covering the machine, and also from the LCD.

WARNING WARNING indicates a potentially hazardous situation which, if not avoided, could result in death

or serious injuries.

CAUTION CAUTION indicates a potentially hazardous situation which, if not avoided, may result in minor

or moderate injuries.

IMPORTANT IMPORTANT indicates a potentially hazardous situation which, if not avoided, may result in

damage to property or loss of product functionality.

NOTE Notes tell you how to respond to a situation that may arise or give tips about how the operation

works with other features.

NOTE

If your computer does not have a CD-ROM drive, the supplied CD-ROM does not contain drivers for your

operating system, or if you want to download manuals and utilities, visit your model’s page at

http://solutions.brother.com/.

Connect the power cord

and telephone line

WARNING

• The machine must be fitted with an earthed

plug.

• Since the machine is grounded through the

power outlet, you can protect yourself from

potentially hazardous electrical conditions on

the telephone network by keeping the power

cord connected to your machine when you

connect it to a telephone line. Similarly, you

can protect yourself when you want to move

your machine by disconnecting the telephone

line first and then the power cord.

aConnect the power cord.

bLift the scanner cover until it locks securely into

the open position.

cConnect the telephone line cord.

Connect one end of the telephone line cord to

the socket marked LINE on the machine.

Carefully guide the telephone line cord into the

cable channel and out the back of the machine.

Connect the other end to a modular wall

socket.

dLift the scanner cover to release the lock a.

Gently push the scanner cover support

down band close the scanner cover cusing

both hands.

CAUTION

Be careful not to pinch your fingers when the

scanner cover closes.

NOTE

DO NOT connect the USB cable yet (if you are

using a USB cable).

NOTE

• If you do not plan to use the fax feature on this

machine, go to step 3on page 3.

• To prolong the life of the print head, provide the

best ink cartridge economy and maintain print

quality, we do not recommend unplugging the

machine frequently and/or leaving the machine

unplugged for extended periods of time. Each

time you plug the machine in, it automatically

cleans the print head, which uses some of your

ink.

We recommend using to power down the

machine. Using allows minimal power to

the machine, resulting in periodic, but less

frequent, cleaning of the print head.

IMPORTANT

The telephone line cord MUST be connected to

the socket marked LINE on the machine.

Install the ink cartridges

CAUTION

If ink gets in your eyes, wash it out with water at

once and call a doctor if you are concerned.

aMake sure that the power is turned on.

bOpen the ink cartridge cover a.

cRemove the orange protective part.

dUnpack the ink cartridge.

Turn the green release lever on the orange

protective packing acounterclockwise until it

clicks to release the vacuum seal. Then

remove the orange protective packing aas

shown.

eTake care to match the sticker colour with the

cartridge colour.

Install each ink cartridge in the direction of the

arrow on the label.

NOTE

Make sure you install the Starter Ink Cartridges

included with your machine first.

IMPORTANT

DO NOT shake the ink cartridges. If ink stains

your skin or clothing, wash with soap or detergent

at once.

fGently push the back of the ink cartridge

marked “PUSH” until the cartridge lever lifts.

After all the ink cartridges are installed, close

the ink cartridge cover.

Load plain A4 paper

aPull the paper tray completely out of the

machine.

bOpen the output paper tray cover.

cGently press and slide the paper width

guides aand then the paper length guide bto

fit the paper size.

Make sure that the triangular marks con the

paper width guides aand paper length

guide bline up with the mark for the paper size

you are using.

IMPORTANT

After initial installation of the ink cartridges, the

machine will start cleaning the ink tube system.

This cleaning process will last approximately four

minutes.

DO NOT unplug the machine from the power

outlet or attempt to stop the cleaning process.

Interruption of cleaning process may cause

undesired print quality problems.

IMPORTANT

• DO NOT take out ink cartridges if you do not

need to replace them. If you do so, it may

reduce the ink quantity and the machine will not

know the quantity of ink left in the cartridge.

• DO NOT repeatedly insert and remove the

cartridges. If you do so, ink may seep out of the

cartridge.

• Once you open an ink cartridge, install it in the

machine and use it up within six months of

installation. Use unopened ink cartridges by

the expiration date written on the cartridge

package.

• DO NOT dismantle or tamper with the ink

cartridge, this can cause the ink to leak out of

the cartridge.

• Brother multifunction machines are designed to

work with ink of a particular specification and

will work to a level of optimum performance

when used with genuine Brother branded ink

cartridges. Brother cannot guarantee this

optimum performance if ink or ink cartridges of

other specifications are used. Brother does not

therefore recommend the use of cartridges

other than genuine Brother branded cartridges

with this machine or the refilling of empty

cartridges with ink from other sources. If

damage is caused to the print head or other

parts of this machine as a result of using

incompatible products with this machine, any

repairs required as a result may not be covered

by the warranty.

dFan the stack of paper well to avoid paper jams

and misfeeds.

eGently put the paper into the paper tray print

side down and top edge first. Check that the

paper is flat in the tray.

fGently adjust the paper width guides to the

paper with both hands. Make sure that the

paper width guides touch the edges of the

paper.

gClose the output paper tray cover.

hSlowly push the paper tray completely into the

machine.

iWhile holding the paper tray in place, pull out

the paper support until it clicks, and then unfold

the paper support flap.

Check the print quality

aWhen the preparation process has finished, the

LCD shows this message

Set Paper and

Press Start

Press Colour Start.

bCheck the quality of the four colour blocks on

the sheet. (black/yellow/cyan/magenta)

cIf all lines are clear and visible, press 1(Yes) to

finish the quality check and go to the next step.

If lines are missing, press 2(No) and follow the

steps on the LCD.

NOTE

Always make sure that the paper is not curled or

wrinkled.

IMPORTANT

Be careful that you do not push the paper in too

far; it may lift at the back of the tray and cause

paper feed problems.

Set the date and time

The LCD displays the date and time. You can also

add the current date and time to each fax you send by

setting your Station ID (see step 10).

aWhen the LCD shows this message, press OK.

Date&Time

Enter & OK Key

bEnter the last two digits of the year on the dial

pad, and then press OK.

cEnter the two digits for the month on the dial

pad, and then press OK.

dEnter the two digits for the day on the dial pad,

and then press OK.

ePress aor bto choose 12h Clock or 24h

Clock, and then press OK.

fEnter the time on the dial pad, and then press

OK.

(12h Clock only)

Press aor bto choose AM or PM, and then

press OK.

Wireless setup

(if needed)

Setup Wi-Fi? message appears on the LCD.

For wireless setup using a mobile device, go to a.

For Windows®and Macintosh users, go to b.

aPress 1to choose 1.Yes.

Go to step 13 on page 15 to continue with the

wireless setup.

bPress 2to choose 2.No.

Wireless setup instructions for Windows®and

Macintosh users will be covered later, starting

on page 15.

NOTE

You can change date, time, or clock type (12h or

24h) at any time. For more information uuBasic

User’s Guide: Setting the date and time

NOTE

If you want to configure any of the options in

steps 8-11, you can choose 2.No in step a, and

then go to step 8.

You will be able to configure the wireless settings

later.

Choose your language

* Depending on your country

aPress Menu, 0, 0.

0.Local Language

bPress aor bto choose your language.

Press OK.

cPress Stop/Exit.

Choose a Receive Mode

There are four possible receive modes: Fax Only,

Fax/Tel, Manual and External TAD.

aPress Menu, 3, 1, 1.

1.Receive Mode

bPress aor bto choose your preferred receive

mode.

Press OK.

cPress Stop/Exit.

Yes

Do you want to use the telephone features of your

machine (if available), an external telephone or

external telephone answering device connected on the

same line as the machine?

Do you want the machine to

answer fax and telephone calls

automatically?

Are you using the voice message

function of an external telephone

answering device?

Manual

Fax Only

Fax/Tel

External TAD

You control the telephone

line and must answer every

call yourself.

Your external telephone

answering device (TAD)

automatically answers every

call. Voice messages are

stored on the external TAD.

Fax messages are printed.

Your machine controls the

line and automatically

answers every call. If the

call is not a fax, the

telephone will ring for you

to pick up the call.

Your machine automatically

answers every call as a fax.

Enter personal

information (Station ID)

You should store your name and fax number to be

printed on all fax pages that you send.

If you are not using this machine for faxing, go to the

next step.

aPress Menu, 0, 2.

2.Station ID

bEnter your fax number (up to 20 digits) on the

dial pad, and then press OK. To enter a “+” for

international codes, press l.

cEnter your name (up to 20 characters) using

the dial pad, and then press OK.

dPress Stop/Exit.

Set Tone or Pulse dialling

mode

Your machine comes set for a Tone dialling service. If

you have a Pulse dialling (rotary) service, you need to

change the dialling mode.

aPress Menu, 0, 3.

3.Tone/Pulse

bPress aor bto choose Pulse (or Tone).

Press OK.

cPress Stop/Exit.

NOTE

If you make a mistake and want to start again,

press Stop/Exit and go back to a.

Windows®Macintosh

USB Wireless Network

Choose your connection type

These installation instructions are for Windows®XP Home, XP Professional, XP Professional x64 Edition,

Windows Vista®, Windows®7, Windows®8, and Mac OS X v10.6.8, 10.7.x, 10.8.x.

NOTE

If your computer does not have a CD-ROM drive, the supplied CD-ROM does not contain drivers for your

operating system, or if you want to download manuals and utilities, visit your model’s page at

http://solutions.brother.com/. Some software applications included on the CD-ROM may not be available as a

download.

For USB interface cable

Windows

, go to page 10

Macintosh, go to page 13

For Wireless Network

Windows

and Macintosh,

go to page 15

Windows®

USB

For Windows

USB interface users

(Windows®XP Home/XP Professional/Windows Vista®/Windows®7/Windows®8)

Before you install

Make sure that your computer is ON and you are

logged on with Administrator rights.

Install MFL-Pro Suite

aPut the CD-ROM into your CD-ROM drive. If

the model name screen appears, choose your

machine. If the language screen appears,

choose your language.

bClick Install MFL-Pro Suite and click Yes if

you accept the license agreements.

cChoose Local Connection (USB), and then

click Next.

dFollow the on-screen instructions until the Plug

in the USB cable screen appears.

Connect the USB cable

NOTE

If the Brother screen does not appear

automatically, go to Computer (My Computer).

(For Windows®8: click the (File Explorer)

icon on the taskbar, and then go to Computer.)

Double-click the CD-ROM icon, and then

double-click start.exe.

IMPORTANT

Make sure that the cable does not restrict the

cover from closing, or an error may occur.

Other manuals for MFC-J200

Table of contents

Other Brother All In One Printer manuals

Brother

Brother MFC-8880DN User manual

Brother

Brother MFC-9*970CDW Operating and maintenance manual

Brother

Brother MFC-9160 User manual

Brother

Brother DCP-1400 User manual

Brother

Brother MFC MFC-465CN User manual

Brother

Brother DCP-1511 User manual

Brother

Brother DCP-8065DN User manual

Brother

Brother MFC-6800 User manual

Brother

Brother MFC-9180 User manual

Brother

Brother HL-P2500 User manual

Brother

Brother DCP-1510 User manual

Brother

Brother MFC9030 User manual

Brother

Brother MFC-8440 User manual

Brother

Brother MFC 7340 - B/W Laser - All-in-One Parts list manual

Brother

Brother MFC-L2732DW User manual

Brother

Brother DCP-8040 User manual

Brother

Brother MFC-8870DW Installation instructions

Brother

Brother DCP-115C User manual

Brother

Brother DCP-J140W Assembly instructions

Brother

Brother DCP-770W User manual

Brother

Brother MFC-J425W User manual

Brother

Brother DCP-1400 User manual

Brother

Brother MFC 7460DN User manual

Brother

Brother DCP-L8400CDN User manual

Popular All In One Printer manuals by other brands

Triumph Adler

Triumph Adler DC 2016 Instruction handbook

Epson

Epson WorkForce WF-2510 Basic guide

Epson

Epson Stylus Scan 2000 Product information guide

Epson

Epson PictureMate Snap PM 240 Start here

Konica Minolta

Konica Minolta bizhub C35 user guide

Konica Minolta

Konica Minolta BIZHUB 558 Quick reference guide

Lexmark

Lexmark MX710 Series setup sheet

Lexmark

Lexmark XC8155 user guide

Lexmark

Lexmark X642E Service manual

Sharp

Sharp MX-2310U Start guide

Aficio

Aficio 200 manual

Canon

Canon ImageCLASS 2300 setup sheet

Ricoh

Ricoh Pro C900 Brochure & specs

Lexmark

Lexmark X925 Installation

Epson

Epson Stylus CX8400 Series Brochure & specs

Oce

Oce VarioLink 5022 user guide

Copystar

Copystar CS 4551ci Specifications

Konica Minolta

Konica Minolta Magicolor 4650EN Service manual
