Brother MFC-9160 User manual

MFC-9160

OWNER’S MANUAL

Using This Manual

Thank you for purchasing a Brother machine.

This machine has been designed to be simple to use, with LCD screen prompts to guide you through

functions. However, you can use the machine to its fullest potential by taking a few minutes to read

this manual.

Finding Information

All chapter headings and subheadings are listed in the Table of Contents. You will also be able to

findinformationaboutaspecificfeatureorfunctionbycheckingtheIndexatthebackofthismanual.

Also, throughout this manual, you will see special symbols alerting you to important information,

cross-references, and warnings. Illustrations of some screen displays also help you choose the

correct key-presses.

Symbols Used In This Manual

User-Friendly Programming

We have designed the machine with on-screen programming. User-friendly programming helps you

take full advantage of all the functions the machine has to offer.

Since your programming is done on the LCD, we have created step-by-step on-screen prompts to

help you program the machine. All you need to do is follow the prompts as they guide you through

the function menu selections, programming options and settings. Additionally, you can program

settings more quickly by pressing

Menu/Set

and the menu number using the numeric keys.

A complete list of the function selections, options, and settings that are available is provided in the

appendix of this manual. (See

Menu Mode & Menu Selection Table

, page 8.)

Note or additional information.

The machine may be damaged or may not work correctly if this is not

observed.

Warnings detail precautions you must take to avoid possible personal

injury.

iii

Table of Contents

Using This Manual

User-Friendly Programming

Table of Contents ...............................................................................iii

PREPARATION AND SIMPLE USE

Preparation and Simple Use Guide

Advice for Preparation and Simple Use Guide ...................................4

Control Panel Overview......................................................................6

Menu Mode & Menu Selection Table.................................................8

CUSTOM SETUP

Chapter 1

Custom Settings

Custom Settings.................................................................................10

Using the Reports Key.......................................................................11

COPIER

Chapter 2

Making Copies

Basic Copy Operations......................................................................12

Temporary Copy Setting ...................................................................14

Changing Default Settings.................................................................19

PRINTER/SCANNER

Chapter 3

Using the machine as a Printer

Special Printing Features...................................................................21

Printing From Your PC .....................................................................21

Simultaneous Printing .......................................................................23

Printer Menu Functions.....................................................................23

Acceptable Paper...............................................................................24

Chapter 4

Printer Driver Settings (For Windows

Only)

Using the Brother MFC-9160 Printer Driver ....................................25

Basic Tab...........................................................................................25

Advanced Tab....................................................................................27

Support ..............................................................................................34

Chapter 5

Using the Windows

-Based Brother Control Centre

(For Windows

Only)

Brother Control Centre ......................................................................35

Using the Scan Key with Windows PC .............................................36

Using the Control Panel Keys............................................................37

Brother Control Centre Features........................................................38

Scan to File ........................................................................................41

Scan to E-mail....................................................................................42

Scan to Word Processor.....................................................................44

User Defined Button..........................................................................45

Copy...................................................................................................46

Chapter 6

Using ScanSoft

™

PaperPort

for Brother and

ScanSoft

™

TextBridge

Chapter 7

Using the Brother MFC with a New Power

Macintosh

G3, G4 or iMac

™

/ iBook

™

Set up Your USB Equipped Apple

Macintosh

G3,G4 or iMac

™

with Mac OS 8.5/8.5.1/8.6/9.0/9.0.4/9.1............................................53

Using Brother Printer Driver with your Apple

Macintosh

...........53

Using Brother TWAIN Scanner Driver with

Your Apple

Macintosh

..................................................................55

Chapter 8

For DOS User

MAINTENANCE

Chapter 9

Troubleshooting and Maintenance

Error Messages...................................................................................62

Document Jams and Paper Jams........................................................64

Packing and Shipping the Machine....................................................69

Regular Maintenance.........................................................................71

IMPORTANT INFORMATION

Chapter 10

Important Safety Information

Important Safety Instructions.............................................................81

APPENDIX

Chapter 11

Specifications

General Specifications.......................................................................84

Printer Specifications.........................................................................84

Computer Requirement ....................................................................85

Electrical and Environment...............................................................86

Compilation and Publication Notice .................................................86

Trademarks........................................................................................87

Index..................................................................................................88

Preparation and Simple Use Guide

PREPARATION

AND SIMPLE USE

Preparation and Simple Use Guide

Steps to prepare and use the machine simply

Follow the steps below to prepare and use the machine simply.

However, before you perform these steps, see Important Safety Information (page 81), and

Advice for Preparation and Simple Use Guide (page 4).

1 Read the Quick Setup Guide

Follow the instructions on the Brother Quick Setup Guide to set up the machine.

2 Setting the Document

You can scan the document for copying from either the ADF (Automatic Document Feeder) or

from the glass platen.

Using the ADF (Automatic Document Feeder)

The automatic document feeder (ADF) can hold up to 30 pages, feeding each one individually

through the machine. Use standard (75 g/m

) paper when using the ADF. Always fan the pages

well before placing them in the ADF.

Recommended Environment

Temperature: 20-30˚C (68-86˚F)

Humidity: 50%-70%

DO NOT use curled, wrinkled, folded, or ripped paper, or paper with

staples, paper clips, paste or tape attached. DO NOT use cardboard,

newspaper, or fabric. (To copy or scan this kind of document, see

Using

the Glass Platen

, page 3.)

■

Make sure documents written with ink are completely dry.

■

Documents must be from 14.8 to 21.6 cm wide, and from 14.8 to 35.6 cm long.

Fan the pages and stagger them at a 30 degree angle. Insert the pages

face up

top edge first

in the ADF until you feel them touch the feed roller.

Adjust the paper guides to fit the width of your pages.

Pull up the document stopper.

Multiple pages should be fanned first as shown in the diagram below.

Setting the Special Media Lever

You can use the special media lever to select the Regular Position ( ) or Special Position ( ).

To feed regular types of originals, move the special media lever to the Regular Position ( ). You

can feed multiple pages.

To feed special types of originals (such as coated paper or glossy paper), move the special media

lever to the Special Position ( ). Feed the original one by one. It will allow the original to feed

through the ADF without slipping or jamming.

If the original “double-feeds” try again by inserting a simple sheet of original in

the ADF or use glass platen.

Document Stopper

30˚

Documents are

Face Up

in the ADF

Regular Position

Special Position

Special Media Lever

Preparation and Simple Use Guide

PREPARATION

AND SIMPLE USE

Using the Glass Platen

To use the glass platen, the ADF must be empty.

Lift the document cover.

Using the document guidelines on the left, centre the document FACE DOWN on the glass

platen.

Close the document cover.

If the document is a book or is thick, do not slam the cover or press on

it, as damage to the glass platen may result.

3 Making a Single copy

Insert the document

face up

in the ADF, or

face down

on the glass platen.

Press

Copy

To stop the copy process and release the original, press Stop/Exit. (See

Making Copies, page 12.)

4 Multiple Copies (Using the ADF)

Insert the document face up in the ADF.

Using the numeric keys, enter the number of copies you want (up to 99).

For example, press 3, 8for 38 copies.

Press Copy.

Documents are

Face Down

on the Glass

Platen

Advice for Preparation and Simple Use Guide

Choosing a Location

Place the machine on a flat, stable surface, such as a desk. Select a place that is free of vibration and

shocks. Locate the machine near a standard earthed electrical socket.

Avoid placing the machine where it may be knocked. Do not place near

heaters, air conditioners, water, chemicals or refrigerators. Do not expose

the machine to direct sunlight, excessive heat, moisture or dust. Do not

connect the machine to electrical outlets controlled by wall switches or

automatic timers as disruption of power can wipe out information in the

unit’s memory. Do not connect the machine to electrical outlets on the same

circuit as large appliances or other equipment that might disrupt the power

supply. Avoid interference sources, such as speakers or the base units of

cordless phones. Ensure the airflow from the fan on the right hand side of

the machine is not impeded.

We recommend that this product be used with a surge protection device to

protect the product against damage caused by a lightning strike.
