Brother HL-5440D User manual

Version A

USA/CAN

Please read this guide before attempting to operate the product, or before attempting any

maintenance. Failure to follow these instructions may result in an increased risk of personal injury

or damage to property, including through fire, electrical shock, burns or suffocation. Brother shall

not be liable for damage caused where the product owner has failed to follow the instructions set

out in this guide.

Read all of the instructions. Save them for later reference.

Symbols and

conventions used in

the documentation A

The following symbols and conventions are

used throughout the documentation.

WARNING indicates a potentially hazardous

situation which, if not avoided, could result in

death or serious injuries.

CAUTION indicates a potentially hazardous

situation which, if not avoided, may result in

minor or moderate injuries.

Important indicates a potentially hazardous

situation which, if not avoided, may result in

damage to property or loss of product

functionality.

Follow all warnings and instructions marked

on the product.

Note

• Not all models are available in all

countries.

• The illustrations in this guide show the

HL-5470DW and MFC-8510DN.

(HL-6180DW(T) / DCP-8110DN / 8150DN /

8155DN) In USA:

Please go to the Brother Solutions Center at

http://solutions.brother.com/ and click

Manuals on your model page to download the

other manuals.

Product Safety Guide A

(HL-5440D / 5450DN / 5470DW(T) / 6180DW(T) / DCP-8110DN / 8150DN /

8155DN / MFC-8510DN / 8710DW / 8910DW / 8950DW(T))

Prohibition icons indicate actions

that must not be performed.

Electrical Hazard icons alert you to

possible electrical shock.

Fire Hazard icons alert you to the

possibility of fire.

Hot Surface icons warn you not to

touch product parts that are hot.

WARNING

CAUTION

Important

Notes tell you how you should

respond to a situation that may arise

or give tips about how the operation

works with other features.

Bold Bold typeface identifies specific

keys on the product’s control

panel or on the computer

screen.

Italics Italicized typeface emphasizes

an important point or refers you

to a related topic.

Courier

New

Text in Courier New font

identifies messages on the

LCD of the product.

Compilation and Publication A

Under the supervision of Brother Industries, Ltd., this manual has been compiled and published,

covering the latest product descriptions and specifications.

The contents of this manual and the specifications of this product are subject to change without

notice.

Brother reserves the right to make changes without notice in the specifications and materials

contained herein and shall not be responsible for any damages (including consequential) caused

by reliance on the materials presented, including but not limited to typographical and other errors

relating to the publication.

Choosing a location A

Put your product on a flat, level, stable surface that is free of vibration and shocks, such as a desk.

Put the product near a telephone wall jack (MFC only) and a standard grounded AC power outlet.

Choose a location where the temperature remains between 50°F and 90.5°F (10°C and 32.5°C)

and the humidity is between 20% to 80% (without condensation).

WARNING

DO NOT expose the product to direct sunlight, excessive heat, open flames, corrosive gasses,

moisture or dust. Doing so may create a risk of an electrical shock, electrical short or fire. It may

also damage the product and/or render it inoperable.

DO NOT place the product near heaters, air conditioners, electrical fans, refrigerators, or water.

Doing so may create the risk of a short circuit or fire, as water may come into contact with the

product (including condensation caused by heating/air conditioning/ventilation equipment).

DO NOT place the product near chemicals or in a place where chemicals could be spilled on it.

Should chemicals come into contact with the product, there may be a risk of fire or electric

shock. In particular, organic solvents or liquids such as benzene, paint thinner, polish remover,

or deodorizer may melt or dissolve the plastic cover and/or cables, resulting in a risk of fire or

electric shock. These or other chemicals may also cause the product to malfunction or become

discolored.

DO NOT put the product in a location that blocks or obstructs any slot or opening in the product.

These slots and openings are provided for ventilation. Blocking the product’s ventilation could

create a risk of overheating and/or fire.

Instead:

• Keep a gap of at least 6 in. (150 mm) between the ventilation hole and the wall.

• Place the product on a solid surface. DO NOT place the product on a bed, sofa, rug, or other

similar soft surface.

• DO NOT place this product near or over a radiator or heater.

• DO NOT place this product in a “built-in” installation unless adequate ventilation is provided.

DO install your product near an AC power outlet that is easily accessible. In the event of an

emergency, easy access to the plug and outlet will allow you to shut off power to the product

quickly and completely.

Plastic bags are used in the packing of your machine. Plastic bags are not toys. To avoid the

danger of suffocation, keep these bags away from babies and children and dispose of them

correctly.

CAUTION

Avoid placing your product in a high-traffic area. If you must place it in a high-traffic area, ensure

that the product is in a safe location where it cannot be accidentally knocked-over, which could

cause injury to you or others and serious damage to the product. Also ensure that cords are

secured so as not to pose a tripping hazard.

DO NOT eat the silica gel pack. Please throw away. If ingested seek medical attention

immediately.

DO NOT place heavy objects on the product. DO NOT place this product on an unstable cart,

stand, or table, particularly if children are expected to be near the product. The product is heavy

and may fall, causing injury to you or others, and serious damage to the product. For MFC and

DCP products, there is an added risk of injury if the scanner glass should break.

Important

• DO NOT put objects on top of the product. Doing so could increase the risk of overheating

should the product malfunction.

• DO NOT place your product next to devices that contain magnets or generate magnetic fields.

Doing so may interfere with the operation of the product, causing print quality problems.

• DO NOT place your product next to sources of interference, such as speakers or the base units

of non Brother cordless telephones. Doing so may interfere with the operation of the product's

electronic components.

• DO NOT connect your product to an AC power outlet controlled by wall switches or automatic

timers. Disruption of power can delete information from the product's memory.

• DO NOT connect your product to an AC power outlet on the same circuit as large appliances

or other equipment that requires a significant amount of electricity to operate. Operating this

product in conjunction with the other product(s) could create an overvoltage, tripping your

circuit breaker or blowing your fuse.

To use the product safely A

Please keep these instructions for later reference and read them before attempting any

maintenance. If you do not follow these safety instructions, there is a possibility of a fire, electrical

shock, burn or suffocation.

WARNING

ELECTRICAL HAZARDS

Failure to follow the warnings in this section may create the risk of an electrical shock. In

addition, you could create an electrical short, which may create the risk of a fire.

There are high voltage electrodes inside the product. Before you access the inside of the

product, including for routine maintenance such as cleaning, make sure you have unplugged the

telephone line cord first (MFC only) and then the power cord from the AC power outlet, as well

as any telephone (RJ-11) (MFC only) or Ethernet (RJ-45) cables (Network models only) from

the product. Never push objects of any kind into this product through cabinet slots, since they

may touch dangerous voltage points or short out parts.

DO NOT handle the plug with wet hands.

Always make sure the plug is fully inserted. DO NOT use the product or handle the cord if the

cord has become worn or frayed.

DO NOT use this product during an electrical storm.

DO NOT allow this product to come into contact with water. This product should not be used

around standing water, including a bath tub, sink, or swimming pool; around appliances

containing water, including a refrigerator; or in a wet basement.

This product should be connected to an AC power source within the range indicated on the

rating label. DO NOT connect it to a DC power source or inverter. If you are not sure what kind

of power source you have, contact a qualified electrician.

Power Cord Safety:

• This product is equipped with a 3-wire grounded plug. This plug will only fit into a grounded

power outlet. This is a safety feature. If you are unable to insert the plug into the outlet, call

your electrician to replace your obsolete outlet. DO NOT defeat the purpose of the grounded

plug.

• Use only the power cord supplied with this product.

• DO NOT allow anything to rest on the power cord. DO NOT place this product where people

can walk on the cord. DO NOT place this product in a position where the cord is stretched or

strain is otherwise put on the cord. Doing so may cause the cord to become worn or frayed.

• Brother strongly recommends that you DO NOT use any type of extension cord.

(MFC only)

Use caution when installing or modifying telephone lines. Never touch telephone wires or

terminals that are not insulated unless the telephone line has been unplugged at the wall jack.

Never install telephone wiring during a lightning storm. Never install a telephone wall jack in a

wet location.

• DO NOT put a toner cartridge or a toner cartridge and drum unit assembly into a fire. It could

explode, resulting in injuries.

• DO NOT use flammable substances, any type of spray, or an organic solvent/liquid

containing alcohol or ammonia to clean the inside or outside of the product. Doing so could

cause a fire or electrical shock. Instead, use only a dry, lint-free cloth. For instructions on how

to clean the product: uu User's Guide/Basic User's Guide: Routine Maintenance.

DO NOT attempt to operate this product with a paper jam or with stray pieces of paper inside

the product. Prolonged contact of the paper with the drum unit could cause a fire.

DO NOT use a vacuum cleaner to clean up scattered toner. Doing this might cause the toner

dust to ignite inside the vacuum cleaner, potentially starting a fire. Please carefully clean the

toner dust with a dry, lint-free soft cloth and dispose of it according to local regulations.

DO NOT inhale the toner powder. If toner powder is inhaled, please follow these steps

immediately:

• Move to an area with plenty of fresh air.

• Gargle and rinse your mouth out with plenty of water.

• If you develop a cough or any other symptoms soon after inhaling the toner, consult your

doctor immediately.

If toner powder is swallowed, rinse your mouth immediately and drink plenty of fresh water to

dilute the toner. Then consult your doctor immediately thereafter. For more safety information

regarding the toners used in your product, please visit the following web address to read the

Safety Data Sheets http://sds.brother.co.jp/sdsapp/index.html, which include important

information about the chemical composition of the toners and the precautions to take in case of

overexposure to toner.

HOT SURFACE

After you have just used the product, some internal parts of the product will be extremely hot.

Wait at least 10 minutes for the product to cool down before you touch the internal parts of the

product.

(MFC and DCP only)

When moving the product, grasp the side handholds firmly from the front of the product. The

side handholds are located under the scanner. DO NOT carry the product by holding it at the

bottom.

(DCP-8150DN/8155DN/MFC-8710DW/8910DW/8950DW(T) only)

This product is heavy and weighs more than 39.7 lb. (18.0 kg) including paper. To prevent

possible injuries at least two people should lift the product by holding it from the front and back.

If you use a Lower Tray, DO NOT carry the product with the Lower Tray as you may be injured

or cause damage to the product because it is not attached to the Lower Tray.

CAUTION

(MFC and DCP only)

To prevent injuries, be careful not to put your fingers in the areas shown in the illustrations.

Important

DO NOT remove or damage any of the caution or warning labels inside the product.

Note

Lightning and power surges can damage this product. We recommend that you use a quality

surge protection device on the AC power line and any telephone (RJ-11) (MFC only) or

Ethernet (RJ-45) cable (Network models only) plugged into the product.

190°C

374°F

Other manuals for HL-5440D

This manual suits for next models

Table of contents

Other Brother All In One Printer manuals

Brother

Brother DCP-8065DN User manual

Brother

Brother DCP-J125 User manual

Brother

Brother HL-L2395DW Technical manual

Brother

Brother DCP-130C User manual

Brother

Brother MFC-8510DN User manual

Brother

Brother MFC-J615W Operating and maintenance manual

Brother

Brother MFC 5890CN - Color Inkjet - All-in-One Quick start guide

Brother

Brother MFC 640CW - Color Inkjet - All-in-One User manual

Brother

Brother MFC-440CN User manual

Brother

Brother MFC-9420CN User manual

Brother

Brother MFC 3100C - Inkjet Multifunction User manual

Brother

Brother DCP-J140W Operating and maintenance manual

Brother

Brother MFC-250C User manual

Brother

Brother MFC-J200 Operating and maintenance manual

Brother

Brother DCP-9045CDN User manual

Brother

Brother MFC-9330CDW Manual

Brother

Brother MFC 6490CW - Color Inkjet - All-in-One User manual

Brother

Brother MFC 5890CN - Color Inkjet - All-in-One User manual

Brother

Brother MFC-J6920DW Assembly instructions

Brother

Brother MFC 795CW - Color Inkjet - All-in-One User manual

Brother

Brother DCP-7030 User manual

Brother

Brother MFC-9120 User manual

Brother

Brother DCP-J125 Assembly instructions

Brother

Brother MFC-J625DW Operating and maintenance manual

Popular All In One Printer manuals by other brands

Triumph Adler

Triumph Adler DC 2016 Instruction handbook

Epson

Epson WorkForce WF-2510 Basic guide

Epson

Epson Stylus Scan 2000 Product information guide

Epson

Epson PictureMate Snap PM 240 Start here

Konica Minolta

Konica Minolta bizhub C35 user guide

Konica Minolta

Konica Minolta BIZHUB 558 Quick reference guide

Lexmark

Lexmark MX710 Series setup sheet

Lexmark

Lexmark XC8155 user guide

Lexmark

Lexmark X642E Service manual

Sharp

Sharp MX-2310U Start guide

Aficio

Aficio 200 manual

Canon

Canon ImageCLASS 2300 setup sheet

Ricoh

Ricoh Pro C900 Brochure & specs

Lexmark

Lexmark X925 Installation

Epson

Epson Stylus CX8400 Series Brochure & specs

Oce

Oce VarioLink 5022 user guide

Copystar

Copystar CS 4551ci Specifications

Konica Minolta

Konica Minolta Magicolor 4650EN Service manual
