Brose F74738 User manual
Brose Battery 630
// Charger
F74738 // G01767 // F67261
ORIGINAL OPERATING INSTRUCTIONS
EN | 2 // Brose Battery 630 // Charger
P 3
Li-Ion Battery Charger
Model: BC222360040
Input: 100-240V~,2.5A(MAX.)
50/60Hz
Output: 42.0V 4.0A
• Red Light when charging
• Green Light when fully charged
Manufacurer Shenzhen Modiary Co.,Ltd.
MADE IN CHINA www.mdcharger.com
XXXXXXXXXXXXXXXXX
CAUTION/ATTENTION
Risk of re and electric shock, Indoor use only,
Other types of batteries may burst causing
personal injury and damage. See instruction
manual for use.
VORSICHT
Date Code: XXXX
RoHS
T4.0A
Brand- und Stromschlaggefahr. Nur für den Innenbereich.
Andere Batterietypen können platzen und Verletzungen und
Schäden verursachen. Bitte lesen Sie vor der Benutzung die
Bedienungsanleitung.
1“+“
2“-“
6“NTC“
8
4
597 3
(1)
(2)
(5)
(4)
(3)
(3)
(6)
(6)
A. Charger overview
3 | ENBrose Battery 630 // Charger //
ATTENTION
Charge at least every 3 months,even when the bicycle is not in use.
If internal materials leak from the battery, avoid any contact with such
materials, and immediately dispose of the battery and leaking contents
as industrial waste as required by law.
This battery is only compatible with Brose drive system.
Rechargeable Li-ion Battery Pack
Model : TP-BOS-01-35S
Voltage : 36V
Capacity : 17Ah/630Wh
10INR19/66-5 Made in China
Manufacturer : Trend Power Technology (Changshu) INC.
E41226-100
� Only use the approved charger to charge this battery.
� Do not store in direct sunlight or in places ( such as inside
cars) where the
heat can become excessive. Keep away from heat and open flames.
This battery need be stored in a cool, dry, well-ventilated place.
� Do not expose the battery to excessive physical shock or vibration.
If the battery becomes ruptured, do not allow the battery to
contact water.
� Only use the approved charger to charge this battery.
� Do not store in direct sunlight or in places ( such as inside
cars) where the
heat can become excessive. Keep away from heat and open flame
s.
This battery need be stored in a cool, dry, well-ventilated p
lace.
� Do not expose the battery to excessive physical shock or vibr
ation.
If the battery becomes ruptured, do not allow the battery to
contact water.
� Only use this battery with Brose system and compatible frame.
� Do not modify or disassemble the battery.
� Do not store the battery on a metal shelf. Do not connect and do not allow
a metal object, such as a wire, to contact both the (-) and (+) terminals.
� Do not store or carry the battery with metal parts like keys, screws, etc.
� Do not puncture, crush or otherwise damage the battery.
TEMPERATURE RANGE
Charging Temperature 32℉~104℉ / 0℃~40℃
Discharging Temperature -4℉~104℉ / -20℃~40℃
Storage Temperature -4℉~77℉ / -20℃~25℃
EU16750mAh
(14)
(13)
(7)
(8) (9)
(11)
(12)
(10)
(15)
B. Battery overview
EN | 4 // Brose Battery 630 // Charger
(5)
(1) / (2)
(3)
(3)
C. Charger start-up
(7)
(4)
(17)
(16)
D. Charging the battery
5 | ENBrose Battery 630 // Charger //
(14)
(13)
(4)
1
2
E. Charging battery on the e-bike
(9)
(9)
(7) (7)
1
2
F. Removing the battery
EN | 6 // Brose Battery 630 // Charger
(9)
(7)
(9)
(17)
(18)
(19)
(7)
1
3
4
2
(7)
KLICK
G. Inserting the battery
(20)
H. Vibration absorbers
7 | ENBrose Battery 630 // Charger // Table of contents
Table of contents
About these
original operating instructions 8
1 Additionally
applicable documents 8
2 Reading and storing
the user manual 8
3 Intended use 9
4 Foreseeable misuse 9
5 Residual risks 10
6 Explanation of illustrations 11
7 Explanation of
symbols and signs 12
For your safety 13
8 Information regarding
safety and warning notices 13
9 Warning notices on the product 14
10 Safety notices
for the battery 630 14
11 Safety notices
for the charger 16
Commissioning 19
12 Charging the battery 20
13 Displays and controls 22
14 Assembly 24
15 Switching on/off 26
16 Troubleshooting battery 26
17 Troubleshooting charger 27
Storage,
transport and dispatch 28
18 Service life 28
19 Storage 28
20 Transport 29
21 Dispatch 29
Maintenance and cleaning 30
22 Maintenance 30
23 Cleaning 30
Technical Data 32
24 Brose Battery 630 32
25 Brose Charger 32
Disposal 33
Service 35
26 Customer care and service 35
27 Copyright 35
EN | 8 About these original operating instructions // Brose Battery 630 // Charger
These original operating instructions – referred to as the user manual in the
following – is based on the standards and regulations applicable in the European
Union and contain important information on the use of Brose components.
About these original operating instructions
1 Additionally applicable documents
This user manual is part of the original
operating instructions for the Brose
Drive System.
The complete original operating
instructions consist of all documents
relating to the individual components of
the Brose Drive System installed in your
e-bike.
The component configuration for the
Brose Drive System installed in your
e-bike can be found in the included data
sheet of the e-bike manufacturer.
You absolutely must read and observe
the following:
· The operating instructions of the
e-bike manufacturer
· The user manuals of supplementary
components of the Brose Drive
System
· The user manuals for additional and
special equipment
2 Reading and storing the user manual
Read the user manual, especially the
safety advice in the following chapters,
carefully before using components of
the Brose Drive System.
This user manual contain information for
the safe and fault-free use of the battery
and corresponding charger for the Brose
Drive System.
This user manual does not contain any
instructions for operating the complete
Brose Drive System (information on this
topic can be found in the additionally
applicable documents).
· Keep the user manual at hand for
further use by all users.
· If you hand over your e-bike or
individual components of the Brose
Drive System to third parties, always
include the pertinent operating
instructions and all additionally
applicable documents.
9 | ENBrose Battery 630 // Charger // About these original operating instructions
3 Intended use
The Brose Drive System is designed as
an e-bike drive system. It consists of
several components.
The components of the Brose Drive
System installed in your e-bike are
especially designed for your e-bike
and may only be used in their original
configuration as intended.
The components described in this
manual – the battery and the charger
– are two such components.
The manufacturer‘s instructions
for the intended use of the e-bike
(e.g., use on certain terrain or similar
instructions) must also be followed (see
the manufacturer‘s instructions for the
e-bike).
Battery
The battery is intended for supplying
power to the Brose Drive System.
· The battery is designed and intended
only for use with a Brose Drive
System.
· Any other use is regarded as improper.
Charger
The charger is intended for charging the
battery belonging to the Brose Drive
System.
· The charger may only be used to
charge the battery belonging to the
Brose Drive System.
· Any other use is regarded as improper.
4 Foreseeable misuse
Foreseeable misuse, especially tuning,
will void the CE marking of your e-bike
(EPAC up to 25km/h) – with all legal
consequences.
Tuning consists of all non-approved
modifications to the Brose Drive System
or e-bike that manipulate performance.
Accidents that can be traced back to
technical manipulation are subject to
high personal liability costs and criminal
prosecution.
Furthermore, any kind of tampering with
the Brose Drive System will void the
warranty and guarantee claims on your
e-bike.
Refrain from the following misuse of
the battery and charger or the e-bike
equipped with them in order to prevent
hazards:
· Improperly performed repairs and/or
maintenance work;
· Improperly performed cleaning and
care;
· Structural modifications to the
delivery condition of the Brose Drive
System or the e-bike equipped with
it, especially tuning, and any other
manipulation of the Brose Drive
System and its components;
· The opening and modification of
all components of the Brose Drive
System.
EN | 10 About these original operating instructions // Brose Battery 630 // Charger
5 Residual risks
Certain residual risks unavoidably remain
when using the e-bike - despite a well-
calculated design by the manufacturer
and compliance with the specifications
for intended use by the user.
You can reduce these residual risks
yourself by observing all safety and
warning notices, but you cannot
completely exclude them. It is therefore
vital that you be aware of the existence
of residual risks when using the e-bike.
Unforeseeable residual risks associated
with the use of the e-bike described here
include:
Risk of injury
· Unforeseeable driving maneuvers
and/or misbehavior of other road
users;
· Surprising or sudden changes in the
road surface conditions, such as
freezing wetness or “black ice”;
· Incalculable material defects or signs
of wear that may cause components
of the e-bike to break or impair their
function.
Risk of fire
· Internal, invisible damage can cause
the battery to catch fire and ignite
objects in the vicinity.
Risk of damage
· When the battery is burning,
hydrofluoric acid escapes with the
flue gas. Hydrofluoric acid is highly
corrosive and permanently damages
surfaces.
