Brookstone iDesign Power Speaker User manual
FALL ASLEEP AND WAKE TO
YOUR FAVORITE MUSIC
Cube Clock Radio
IDESIGN®
TABLE OF CONTENTS
Cautions,Warnings&FCCInformation................................................2
Location of Controls, Icons, Accessories & Compatible iPod®Models................... 6
Compatible iPod/iPhone®Models....................................................9
Back-upBattery...................................................................10
ButtonBacklightOperation........................................................10
SettingtheClock..................................................................10
AdjustingtheDisplayBacklight.....................................................11
SettingandActivatingAlarm1.....................................................11
SettingandActivatingAlarm2.....................................................12
DeactivatingtheAlarms............................................................13
UsingSnooze.....................................................................13
UsingtheSleepFunction..........................................................14
Power............................................................................14
ListeningtotheRadio.............................................................14
ConnectingyouriPod/iPhone......................................................15
PlayingandPausingiPod/iPhoneMusic............................................17
Fast-ForwardingandRewindingSongs .............................................17
SkippingForwardandBackwardtoaSong..........................................17
AdjustingtheVolume..............................................................17
ListeningtoanExternalSource....................................................17
UsingAUXOut ...................................................................17
Specifications.....................................................................18
Troubleshooting...................................................................19
Warranty .........................................................................21
1
2
CAUTION
TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER.
THERE ARE NO SERVICEABLE PARTS INSIDE.
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE
THIS UNIT TO RAIN OR MOISTURE.
The lightning flash with arrow-head symbol within an equilateral triangle
is intended to alert the user to the presence of uninsulated “dangerous
voltage” within the unit’s enclosure that may be of sufficient magnitude
to constitute a risk of electric shock.
The exclamation point within an equilateral triangle is intended to alert
the user to the presence of important operating and maintenance
(servicing) instructions in the literature accompanying the unit.
IMPORTANT SAFETY INSTRUCTIONS
All of the safety and operating instructions should be read, adhered to and followed
before the unit is operated.
SAVE THESE INSTRUCTIONS
•
•
3
DANGER
To reduce the risk of electric shock, burns, fire or injury:
Do not use while bathing or in a shower.
Do not place or store unit where it can fall or be pulled into a tub or sink.
Do not place in or drop into water or other liquid.
Do not reach for unit that has fallen into water. Unplug it immediately.
Care should be taken so that objects do not fall and liquids are not
spilled onto the unit.
WARNING
Close supervision is necessary when this unit is used by or near children.
Use this unit only for its intended use as described in this manual.
Unplug this unit during lightning storms or when unused for long periods
of time.
Never drop or insert an object into any opening.
Protect the power cord from being walked on or pinched, particularly at plug
outlets, convenience receptacles and the point where it exits the unit.
Do not allow the cord to touch hot surfaces. Wrap the cord loosely around
the unit when storing.
The unit should be situated away from direct sunlight or heat sources such
as radiators, electric heaters, heat registers, stoves or other units (including
amplifiers) that produce heat. Avoid placing on top of stereo equipment that
radiates heat.
1.
2.
3.
4.
5.
1.
2.
3.
4.
5.
6.
7.
4
Never block the air openings of the unit with materials such as clothing,
plastic bags or papers, or place it on a soft surface such as a bed or couch,
where the air openings may be blocked.
Do not overload electrical outlet. Use only the power source as indicated.
Do not carry this unit by its cord or use the cord as a handle.
Never operate this unit if it has a damaged cord or plug, if it is not working
properly, or if it has been dropped or damaged, or dropped into water. If the
unit’s power supply cord or plug is damaged, do not attempt to fix it yourself.
To avoid the risk of electric shock, do not disassemble or attempt to repair
the unit. Incorrect repair can cause risk of electric shock or injury to persons
when the unit is used.
Do not operate in the presence of explosive and/or flammable fumes.
FCC INFORMATION
This equipment has been tested and found to comply with the limits for a Class B
Digital Device, pursuant to part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following measures:
8.
9.
10.
11.
12.
13.
5
Reorient or relocate the receiving antenna.
Increase the distance between the equipment and receiver.
Connect the equipment to an outlet on a circuit different from that
to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
This equipment complies with part 15 of the FCC Rules. Operation is subject
to the following two conditions:
This equipment may not cause harmful interference.
This equipment must accept any interference received, including interference
that may cause undesired operation.
Modifications not authorized by the manufacturer may void the user’s authority
to operate this device.
BATTERY PRECAUTIONS
Dispose of the old battery properly. Do not dispose of the old battery in a fire.
Do not leave the battery where a child or pet could play with or swallow it.
If the battery is swallowed, contact a physician immediately.
The battery may explode if mistreated. Do not attempt to recharge
or disassemble the battery.
Use only a fresh battery of the required size and type. Do not mix old and
new batteries, different types of batteries, or rechargeable batteries of
different capacities.
•
•
•
•
1.
2.
•
•
•
•
6
LOCATION OF PARTS AND CONTROLS
Power Button
AUX Mode Button
Alarm 2 On/Off Button
Clock Set Button
Sleep Button
Alarm 2 Set Button
Volume/Set Dial
Snooze Button
Alarm 1 Set Button
Alarm 1 On/Off Button
3 Radio Preset Buttons
Back Button
iPod/iPhone
Play/Pause Button
Forward Button
iPod/iPhone Dock
iPod/iPhone Mode Button
Radio Mode
AM/FM Button
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
12.
13.
14.
15.
16.
17. 11 10 9 78 6
1
235 4
171615141312
7
3
4
7 6 5
8
LOCATION OF ICONS ON LCD SCREEN
Clock
AM/PM Icons
Radio Band
Radio Presets
Alarm 2 Time
Alarm 2 Wake-to Icons
1.
2.
3.
4.
5.
6.
Alarm 1 Wake-to Icons
Alarm 1 Time
Radio Mode Icon
iPod/iPhone Auto Play Icon
iPod/iPhone Mode Icon
7.
8.
9.
10.
11.
1 2
9
10
11
8
6
5
LOCATION OF PARTS AND CONTROLS
Auxiliary Output
Auxiliary Input
FM Antenna Connection
AM Antenna Connection
DC Input
Back-up Battery Compartment (on bottom)
1.
2.
3.
4.
5.
6.
34
2
1
9
3.5mm to
3.5mm Cable
iPod/iPhone
Dock Adapters
(7 Included)
INCLUDED ACCESSORIES
AM Antenna FM Pigtail
Antenna
DC Adapter
iPod touch (2nd generation)*
iPod touch (1st generation)*
iPod classic*
iPod nano (5th generation)*
iPod nano (4th generation)*
iPhone 3GS*
iPhone 3G*
iPhone*
*Dock adapter included
COMPATIBLE iPod/iPhone MODELS
