Broil King SSG36LP Instruction Manual

2007

SUGGESTED RETAIL

PRICE LIST

Effective October 23, 2006

Grill Heads, Mountings,

Shelving and Accessories

P3 on PC2 Cart, with

Side Burner, and

Stainless Steel Shelves

Superb by Broilmaster Stainless Steel Grills

SSG 36 – The Ultimate Grill 1

SBG 2500 – 36,000 Btu 2

SBG-2501 – 36,000 Btu, plus 12,000 Btu Infrared Rotisserie 2

SBG-2801 – 48,000 Btu, plus 12,000 Btu Infrared Rotisserie 2

Broilmaster Premium Gas Grills

P3S and P3SN (Nat) – Top of the Line 3

P3FBL and P3FBLN (Nat) – Stainless Steel Flavor Screen 3

P4FBL and P4FBLN (Nat) – Stainless Steel Flavor Screen 3

P3BL and P3BLN (Nat) – Charmaster Briquets 4

P4BL and P4BLN (Nat) – Charmaster Briquets 4

T3 and T3N (Nat)– New for 2007! 5

Broilmaster Carts and Posts 6

Broilmaster Shelves & Side Burner 7

Grill Tools 8

Broilmaster Accessories 9

Contents Page

MODEL SSG36LP SSG36NAT

Suggested Retail Price $4,500.00 $4,500.00

Type of Gas LP Nat

Specifications

Total Cooking Area 691 Sq. In.

Direct Broiling Area 576 Sq. In.

Warming Rack Area 115 Sq. In

Housing Width, Left to Right 55-1/4 In.

Housing Height,Top to Bottom 26-3/4 In.

Housing Depth, Front to Back 25”

Overall Width with Shelves and 1 Sideburner 83-1/4”

Overall Height (with optional Cart) 56-3/4”

Shipping Weight, lbs. 326

Standard Features

Stainless Steel Burners 5 at 12,000 Btu ea.

2 Independently Controlled C e ramic Rotisserie Burn e rs 24,000 total Btu

Cast Stainless Steel Side Burner 30,000 Btu

Stainless Steel Side Shelf with Cup Tray Optional

Flat/Raised Two-Sided Stainless Steel Cooking Grids Included

Rotary Ignitors Included

2 Heat Indicators (Main and Grill Warming Area) Included

User's Guide Included

OPTIONS Model Weight Price

Stainless Steel Doors SGD-36 28 $402.00

Stainless Steel Cart SCG-36 109 $1,400.00

Insulation Jacket GIJ-36 39 $470.00

Large Cover (Cart) VCC-36 13 $338.00

Small Cover (Island) VCB-36 7 $180.00

Stainless Steel Side Shelf GSS-36 10.5 $191.00

Steamer Pan Set SSP-1 4 $46.00

SUPERB BY BROILMASTER SSG SERIES STAINLESS STEEL GRILL

SSG36 on Optional Stainless

Steel Cabinet Cart with

optional side shelf

114,000 total Btu

SSG36 with GIJ Insulation

Jacket built into

Custom Island

114,000 total Btu

MODEL

Suggested Retail Price $799.00 $999.00 $1,249.00

Type of Gas (Ships as LP, includes Conversion Kit) LP LP LP

Specifications

Total Cooking Area 580 580 660

Direct Broiling Area 440 440 500

Warming Rack Area (Chromed Wire) 140 140 160

Housing Depth, Front to Back 24 24 26

Overall Width with Standard Shelves 57 57 60

Overall Height (with Cart) 48 3/4 48 3/4 48 3/4

Shipping Weight, lbs. 165 170 180

Standard Features

Stainless Steel Burners 3 at 12,000 Btu 3 at 12,000 Btu 4 at 12,000 Btu

Rear Infrared Rotisserie Burner NA 8,000 Btu 12,000 Btu

Motorized Rotisserie NA Included Included

Porcelain-Coated Flame Tamers Included Included Included

Side Shelves 2 Painted 2 Stainless Steel 2 Stainless Steel

Porcelain Cast Iron Cooking Grids Included Included Included

Push-Button Electronic Ignitor Included Included Included

Heat Indicator Included Included Included

Cart Painted Stainless Steel Stainless Steel

Casters 4 4 4

Cutting Board 2 Included 2 Included 2 Included

User’s Guide Included Included Included

OPTIONS Model Weight Price

Black Grill Cover SBA005 4 $68.00

Side Burner DPASBC 10 $149.00

SUPERB BY BROILMASTER STAINLESS STEEL GRILLS

SBG 2501

SBG 2500 SBG 2801

SBG2801

4 Main Burners - 48,000 Btu

12,000 Btu IR Burner

Stainless Shelves

and Cart

SBG2501

3 Main Burners - 36,000 Btu

8,000 Btu IR Burner

Stainless Shelves

and Cart

SBG2500

36,000 Btu

Painted Shelves

and Cart

PREMIUM GAS GRILL HEADS

P3S P3SN P3FBL P3FBLN P4FBL P4FBLN

Suggested Retail Price $1,162.00 $1,143.00 $932.00 $913.00 $809.00 $790.00

Type of Gas Propane Propane Propane

Includes Includes Includes

Natural Natural Natural Natural Natural Natural

Conversion Kit Conversion Kit Conversion Kit

Total Cooking Area 695 Sq. In. 695 Sq. In. 695 Sq. In. 695 Sq. In. 473 Sq. In. 473 Sq. In.

Direct Broiling Area 442 Sq. In. 442 Sq. In. 442 Sq. In. 442 Sq. In. 360 Sq. In. 360 Sq. In.

Warming Rack Area 253 Sq. In 253 Sq. In 253 Sq. In. 253 Sq. In. 113 Sq. In. 113 Sq. In.

Housing Width, 26-3/4" 26-3/4" 26-3/4" 26-3/4" 24" 24"

Left to Right

Housing Height, 19" 19" 19" 19" 19" 19"

Top to Bottom

Housing Depth, 18-3/4" 18-3/4" 18-3/4" 18-3/4" 16-1/4" 16-1/4"

Front to Back

Approximate . 99 99 90 90 76 76

Shipping Weight, lbs

User's Guide & Cookbook Included Included Included Included Included Included

Porcelain/Cast Iron Not Available Not Available Included Included Included Included

Cooking Grids (3 piece)

Cast Stainless Steel Included Included Accessory Accessory Accessory Accessory

Cooking Grids (3 piece) DPA101 DPA101 DPA102 DPA102

Warming Rack - Stainless Steel Included Included Included Included Included Included

Twin Stainless Steel 40,000 40,000 40,000 40,000 40,000 40,000

Bow-Tie Burners-BTU

Electronic Igniter Included Included Included Included Included Included

Drop-Down Side Shelf See Shelving See Shelving See Shelving See Shelving See Shelving See Shelving

Heat Indicator Included Included Included Included Included Included

Drip Shield - Stainless Steel Included Included Included Included Included Included

Adjustable Lid Stop - Included Included Included Included Included Included

Stainless Steel

Propane Hose & Regulator Included Not Available Included Not Available Included Not Available

Grill Cover See Grill Covers See Grill Covers See Grill Covers See Grill Cove rs See Grill Covers See Grill Cove rs

Charmaster™ Briquets Not Required Not Required Not Required Not Required Not Required Not Required

Flavor Screen - Included Included Included Included Included Included

Stainless Steel

Smoker Shutter - Included Included Accessory Accessory Not Not

Stainless Steel Stainless Steel Stainless Steel DPA100 DPA100 Available Available

All prices subject to change.

All dimensions and measurements are approximate.

Prices for Broilmaster propane models do not include 20 lb. propane tanks.

Super

Premium

SUPER PREMIUM & PREMIUMGASGRILLHEAD

PREMIUM GAS GRILL HEADS

P3BL P3BLN P4BL P4BLN

Suggested Retail Price $879.00 $861.00 $769.00 $743.00

Type of Gas Propane Propane

Includes Includes

Natural Natural Natural Natural

Conversion Kit Conversion Kit

Total Cooking Area 695 Sq. In. 695 Sq. In. 473 Sq. In. 473 Sq. In.

Direct Broiling Area 442 Sq. In. 442 Sq. In. 360 Sq. In. 360 Sq. In.

Warming Rack Area 253 Sq. In. 253 Sq. In. 113 Sq. In. 113 Sq. In.

Housing Width, 26-3/4" 26-3/4" 24" 24"

Left to Right

Housing Height, 19" 19" 19" 19"

Top to Bottom

Housing Depth, 18-3/4" 18-3/4" 16-1/4" 16-1/4"

Front to Back

Approximate 105 105 91 91

Shipping Weight, lbs.

User's Guide & Cookbook Included Included Included Included

Porcelain/Cast Iron Included Included Included Included

Cooking Grids (3 piece)

Cast Stainless Steel Accessory Accessory Accessory Accessory

Cooking Grids (3 piece) DPA101 DPA101 DPA102 DPA102

Warming Rack - Stainless Steel Included Included Included Included

Twin Stainless Steel 40,000 40,000 40,000 40,000

Bow-Tie Burners-BTU

Electronic Igniter Included Included Included Included

Drop-Down Side Shelf See Shelving See Shelving See Shelving See Shelving

Heat Indicator Included Included Included Included

Drip Shield - Stainless Steel Included Included Included Included

Adjustable Lid Stop - Included Included Included Included

Stainless Steel

Propane Hose and Regulator Included Not Available Included Not Available

Grill Cover See Grill Covers See Grill Covers See Grill Covers See Grill Covers

Charmaster™ Briquets Included Included Included Included

Flavor Screen - Accessory Accessory Accessory Accessory

Stainless Steel DPA103 DPA103 DPA104 DPA104

Smoker Shutter - Accessory Accessory Not Not

Stainless Steel DPA100 DPA100 Available Available

All prices subject to change.

All dimensions and measurements are approximate.

Prices for Broilmaster propane models do not include 20 lb. propane tanks.

PREMIUMGASGRILLHEAD

Suggested Retail Price $699.00 $679.00 $739.00 $719.00 $799.00 $779.00

Type of Gas Propane

Includes

Natural

Conversion Kit

Natural

Propane

Includes

Natural

Conversion Kit

Natural

Propane

Includes

Natural

Conversion Kit

Natural

Total Cooking Area 601 Sq. In. 601 Sq. In. 695 Sq. In. 695 Sq. In. 695 Sq. In. 695 Sq. In.

Direct Broiling Area 442 Sq. In. 442 Sq. In. 442 Sq. In. 442 Sq. In. 442 Sq. In. 442 Sq. In.

Warming Rack Area 159 Sq. In. 159 Sq. In. 253 Sq. In. 253 Sq. In. 253 Sq. In. 253 Sq. In.

Housing Width,

Left to Right

26-3/4” 26-3/4” 26-3/4” 26-3/4” 26-3/4” 26-3/4”

Housing Height,

Top to Bottom

19” 19” 19” 19” 19” 19”

Housing Depth,

Front to Back

18-3/4” 18-3/4” 18-3/4” 18-3/4” 18-3/4” 18-3/4”

Approximate

Shipping Weight, lbs.

105 105 105 105 105 105

User’s Guide & Cookbook Included Included Included Included Included Included

Porcelain/Cast Iron

Cooking Grids (2 piece)

Included Included Included Included Included Included

Cast Stainless Steel

Cooking Grids (3 piece)

Accessory

DPA101

Accessory

DPA101

Accessory

DPA101

Accessory

DPA101

Accessory

DPA101

Accessory

DPA101

Control Panel Black Black Stainless Steel Stainless Steel Stainless Steel Stainless Steel

Warming Rack Chrome Chrome Stainless Steel Stainless Steel Stainless Steel Stainless Steel

Twin Stainless Steel

Burners - Btu

36,000 40,000 36,000 40,000 36,000 40,000

Electronic Igniter Included Included Included Included Included Included

Drop-Down Side Shelf See Shelving See Shelving See Shelving See Shelving See Shelving See Shelving

Heat Indicator Included Included Included Included Included Included

Drip Shield - Stainless Steel Included Included Included Included Included Included

Adjustable Lid Stop -

Stainless Steel

Accessory

DPA106

Accessory

DPA106 Included Included Included Included

Propane Hose & Regulator Included NA Included NA Included NA

Grill Cover See Grill Covers See Grill Covers See Grill Covers See Grill Covers See Grill Covers See Grill Covers

Charmaster™ Briquets Included Included Included Included NA NA

Flavor Screen -

Stainless Steel

Accessory

DPA103

Accessory

DPA 103

Accessory

DPA103

Accessory

DPA103 Included Included

Smoker Shutter -

Stainless Steel

Accessory

DPA100

Accessory

DPA100

Accessory

DPA100

Accessory

DPA100

Accessory

DPA100

Accessory

DPA100

DELUXEGASGRILLS

T3GasGrillshown

withPC2CartT3 T3C T3CF

T3N T3CN T3CFN

PC2CART DC2CART

Suggested Retail Price $336.00 $225.00

Material Stainless Steel Painted Steel

ShippingWeight,lbs. 34 34

Fits P Series P Series

T Series T Series

SideShelves See Shelving - Page 8 See Shelving - Page 8

12'Hose/QuickDisconnect Not Included Not Included

SSP48 SSPB26 BPB26 BP48

Suggested Retail Price $158.00 $204.00 $188.00 $115.00

Material Stainless Steel Stainless Steel Post Painted Steel Post Painted Steel

w/Cast Iron Base w/Cast Iron Base

ShippingWeight,lbs. 13 33 33 13

Fits P Series P Series P Series P Series

T Series T Series T Series T Series

SideShelves See Shelving Page 8 See Shelving Page 8 See Shelving Page 8 See Shelving Page 8

12'Hose/QuickDisconnect Not Included Not Included Not Included Not Included

GardenCart GC3 GC4

Suggested Retail Price $245.00 $245.00

Material Painted Steel Painted Steel

ShippingWeight,lbs. 25 24

Fits P3 Series P4 Series

SideShelfIncludes 1 SKFPBLACK Includes 1 SKFPBLACK

LOWER MOUNTINGS

Seepage 9 forPostandCartconversionkitstofitT3tooldstylepostsandcarts.

FKBLACK FKCHAR FKTAU FKSS FKWOOD

(Black) (Charcoal) (Taupe) (Stainless Steel) (Wood)

Front Shelf Front Shelf Front Shelf Front Shelf Front Shelf

Suggested Retail Price $62.00 $62.00 $62.00 $110.00 $56.00

Material Drop-Down Drop-Down Drop-Down Drop-Down Drop-Down

(Bracket) Stainless Steel Stainless Steel Stainless Steel Stainless Steel Stainless Steel

(Shelf) Composite Composite Composite Stainless Steel Wood

Width 27-1/2" 27-1/2" 27-1/2" 24" 24"

Depth 10-1/2" 10-1/2" 10-1/2" 9" 9"

Shipping77 7 77

Weight,lbs.

SKCHAR SKTAU SKSS SKWOOD

(Charcoal) (Taupe) (Stainless Steel) (Wood)

Side Shelf Side Shelf Side Shelf Side Shelf

Suggested Retail Price $77.00 $65.00 $122.00 $53.00

Material (Bracket) Stationary Stainless Steel Stationary Stainless Steel Stationary Stainless Steel Stationary Stainless Steel

(Shelf) Composite Composite Stainless Steel Wood

Width 12" 12" 13" 9-1/2"

Depth 14" 14" 12" 11-1/4"

Shipping55 5 5

Weight,lbs.

SKBLACK SKFPBLACK SKFBLACK

replaces SKGRAY replaces SKFPGRAY replaces SKFGRAY DPSBSS

(Black) (Black) (Black) (Stainless Steel)

Side Shelf Side Shelf Side Shelf Side Burner

Suggested Retail Price $85.00 $90.00 $115.00 $299.00

Material (Bracket) Stationary Stainless Steel Drop-Down Painted Drop-Down Stainless Steel Stainless Steel

(Shelf) Solid Surface Solid Surface Solid Surface

Width 16" 16" 16" 12-1/2"

Depth 21" 21" 21" 17"

Shipping88 815

Weight,lbs.

SHELVING(FITSALLCURRENTBROILMASTERMODELS)

GRILL TOOLS SUGGESTED

RETAIL PRICE

DPA20 Professional Quality 4-pc. BBQ Set with Spatula,Tong, Fork, and Brush $55.00

with Broilmaster Logo Burned into Rosewood Handles

DPA21 Deluxe Brass Bristle Brush — a must for Porcelain. $12.00

DPA27 Cast Iron Smoking Box. Use with all Smoking Chips. $20.00

STTP-1 Digital Remote Temperature Probe and Timer $49.00

ROTISSERIEUNITS/BASKETS/GRIDDLES

DPA11 Hugga-Rack Rotisserie with Flat Basket for P3/P4 and T3 (B070425) $189.00

DPA51 Heavy Duty Standard Rotisserie for P3/P4 and T3 (B070425) $102.00

GR3 Griddle for size 3 grill head $73.00

GR4 Griddle for size 4 grill head $56.00

GRILLCOVERS

DPA110 Full Length Broilmaster Premium Grill Cover for P and T Series grill $52.00

with Two Cup-Holder Side Shelves. Available in Black only.

DPA109 Full Length Broilmaster Premium Grill Cover for P and T Series grill $47.00

with One Cup-Holder Side Shelf. Available in Black only.

DPA8 Full Length Broilmaster Premium Grill Cover for P and T Series grill $42.00

without Side Shelves. Available in Black only.

DPA45 Built-In Kit Premium Grill Cover for P3 Head Built into Broilmaster $47.00

BIK Surround Covers Head and Control Panel. Available in Black only.

This manual suits for next models

Other Broil King Grill manuals

Broil King

Broil King Smoke 500 945050 CH User manual

Broil King

Broil King P3XN-4 User manual

Broil King

Broil King REGAL 690 User manual

Broil King

Broil King DPA151P-1 User manual

Broil King

Broil King Superb SBG2500-1 User manual

Broil King

Broil King 9235-84 User manual

Broil King

Broil King 9986-44 User manual

Broil King

Broil King 10107997 User manual

Broil King

Broil King PREMIUM BCP-400S User manual

Broil King

Broil King SOVEREIGN 20 User manual

Broil King

Broil King CROWN 20 POST User manual

Broil King

Broil King S18428 REV H 1004 User manual

Broil King

Broil King SIGNET 20B User manual

Broil King

Broil King P3PK5(N)-1 User manual

Broil King

Broil King 9211-64 User manual

Broil King

Broil King OPTIONS Premium P P3S-1 User manual

Broil King

Broil King Imperial XLS 9578-84 User manual

Broil King

Broil King 911050 Series User manual

Broil King

Broil King PORTA-CHEF 100 User manual

Broil King

Broil King REGAL XL90 User manual

Broil King

Broil King 9159-64 User manual

Broil King

Broil King Baron S490 User manual

Broil King

Broil King 9896-84 User manual

Broil King

Broil King 911470 User manual

Popular Grill manuals by other brands

Orbegozo

Orbegozo GR 2300 instruction manual

bora

bora PT11 Operating and installation instructions

Klarstein

Klarstein 10031664 manual

Garland

Garland MWE3W Installation and operation manual

Char-Broil

Char-Broil 463722714 Product guide

Nexgrill

Nexgrill 720-0830HK Operating instruction

Kenmore

Kenmore 415.16123800 Use and care guide

Camp Chef

Camp Chef PG24CLAU Warning & instruction booklet

Tucker Barbecues

Tucker Barbecues GTR Series Assembly, installation and operating instructions

Monogram

Monogram ZGG540NCP1SS owner's manual

Equipex

Equipex Sodir Savoy Operation manual

Gaggenau

Gaggenau VR 414 610 use and care manual

Miele

Miele KM 408-1 operating instructions

George Foreman

George Foreman GGR50B owner's manual

AOG

AOG T series quick start guide

Gorenje

Gorenje TG2000CB Instruction manua

Weber

Weber Genesis Silver-B Permamount NG 051701 owner's guide

Glen

Glen SA 3037 user guide
