Broan QTXE110S User manual

SPECIFICATION SHEET

REFERENCE QTY. REMARKS Project

Location

Architect

Engineer

Contractor

Submitted by Date

MODEL QTXE110S

VENTILATOR

21F 99044986A

A modern-styled, high performance fan, with

sensingcircuitry,that“knows”whentoventilate

the room.

FEATURES

BLOWER:

• Plug-in,permanentlylubricatedmotor-engineered

forcontinuousoperation

• Dynamicallybalancedcentrifugalblowerwheelfor

quiet,efcientperformance

• MaintainsahighpercentageofratedCFMinless

thanidealinstallations

• LowRPMforquietoperation

HOUSING:

• Rugged,26gauge,galvanizedsteelconstruction

• 6”roundductingforsuperiorperformance

• Polymericductconnectorwithtaperedsleeveandno

metallicclatter

• 7-5/8”heightallowsfor2”x8”(nominal)joist

installations

• Sturdy,easy,four-pointmountingdirectlytojoist

• Includesuniquespacer(patentpending)formounting

toengineered“I”joists

• Includeshangerbarstopositionhousinganywhere

between16”to24”-on-centerjoists

• Twosetsofmountingholesforhangerbarsallow

ushinstallationwithbottomortopofdrywall

GRILLE:

• Integratedhumiditysensor

• Polymericconstruction

• Innovativedesign-theresultofextensiveresearch

withdesignersandconsumers

Broan-NuToneLLCHartford,Wisconsinwww.broan.com800-558-1711

AUTOMATICCONTROL:

• HumiditycontrolautomaticallyturnsfanONwheneitherof

theseconditionsisdetected:

-arapidtomoderate(useradjustable)increaseofhumidity

-humidityaboveuser-adjustableset-point(50%-80%RH)

• Twowiremanualoperationforodorcontrol-TurnsfanON

whenpowerlinethroughwallswitchiscycledON,OFFand

backON

• RemainsONforauser-adjustable5to60minutesafter

humidityhasstabilizedandisbelowset-pointorafter

manuallyinitiatedthroughpowerlinecycling

• Savesenergybecauseunitrunsonlyforthetimerequired.

AunitcontrolledwithawalltimermaykeepfanONlonger

thanrequiredorturnitOFFbeforeroomissufciently

ventilated

ACCESSORYCONTROL(Purchaseseparately):

DesignedbyBroanforusewiththisproduct(purchase

separately)

• Model68V,P68V(Ivory)/68W(White)2-FunctionWall

Control

U.L.Listedforuseoverbathtubsandshowerswhenconnected

toaGFCIprotectedbranchcircuit(ceilingmountonly).

3-YearWarranty

Broan-NuToneLLCHartford,Wisconsinwww.broan.com800-558-1711

PERFORMANCE RATINGS

MODEL QTXE110S

VENTILATOR

AMPS

Model Amps*

 QTXE110S 0.3

WEIGHT

HVI-2100CERTIFIEDRATINGScomplywithnew

testingtechnologiesandproceduresprescribed

by the Home Ventilating Institute, for off-the-shelf

products,astheyareavailabletoconsumers.

Productperformanceisratedat0.1in.static

pressure,based ontests conductedin astate-of-

the-art test laboratory. Sones are a measure of

humanly-perceivedloudness,basedonlaboratory

measurements.

HVI PERFORMANCE

Model Shipping

Weight

 QTXE110S 12.2lbs.

*Total connected load

AIR FLOW PERFORMANCE

MODEL QTXE110S

TYPICAL SPECIFICATION

CeilingVentilatorshallbeBroanModelQTXE110S.

TheunitwillhaveacontrolthatwillautomaticallyturnfanON

whenhumidityincreaseisrapidtomoderate(useradjustable),or

whenhumidityishigherthanuser-adjustableset-point(50%-80%

RelativeHumidity),orwhensupplypoweriscycledfromON(for

morethanasecond)toOFF(forlessthanasecond)andback

ON.Itshallbeuser-adjustabletoturnOFF5to60minutesafter

humidityhasstabilizedandisbelowuser-adjustableset-point,

oraftermanuallyinitiatedbysupplypowercycling.

CeilingVentilatorshallhavecorrosionresistantgalvanizedsteel

housingwithfour-pointmountingcapability.Itshallbeductedto

arooforwallcapusing6”roundductwork.

Blowerassemblyshallberemovable,haveacentrifugal-typeblower

wheelandapermanentlylubricatedmotordesignedforcontinuous

operation.

Non-metallicdamper/ductconnectorshallbeincluded.

Airdeliveryshallbenolessthan110CFMandsoundlevelnogreater

than0.7Sones.AllairandsoundratingsshallbecertiedbyHVI.

CeilingVentilatorshallbeEnergyStar®qualiedandhaveanenergy

efcientpermanentsplitcapacitormotor.

CeilingVentilatorshallbeU.L.Listedforuseoverbathtubsand

showerswhenconnectedtoaGFCIprotectedbranchcircuit.

0.0

0.1

0.2

0.3

0.4

0.5

0.6

0.7

0 10 20 30 40 50 60 70 80 90 100 110 120 130

Airflow (cfm)

Ps (in. w.g.)

Static Fan

Model Pressure (Ps) CFM Sones Watts

QTXE110S 0.10 110 0.7 33.5

0.25 90
