Breville Nespresso Vertuo Creatista User manual
Vertuo Creatista
BVE850
EN User Manual
FR Manuel d’instructions
ES Manual de usuario
2
EN
CONTENTS
PACKAGING CONTENT 2
SPECIFICATIONS 2
MACHINE OVERVIEW 3
CONNECTIVITY 4
MACHINE SET UP 5
SETTING THE WATER HARDNESS 6
FIRST USE / RINSE CYCLE 7
COFFEE PREPARATION 8
MILK COFFEE PREPARATION 10
MILK COFFEE RECIPES 13
DAILY CLEANING 14
CLEANING THE COFFEE SYSTEM 14
CLEANING THE STEAM WAND 16
DESCALING 17
RESET TO FACTORY SETTINGS 20
TURN THE BLUETOOTH® / 20
EMPTYING THE SYSTEM 21
TROUBLESHOOTING 23
ERRORS / BLINKING SUMMARY 26
ENERGY SAVING CONCEPT 27
CONTACT NESPRESSO 27
DISPOSAL AND
ENVIRONMENTAL PROTECTION 27
SPECIFICATIONS
USA / CA: 120 V 60 Hz 1500 W
MX: 127 V 60Hz 1 380 W
Frequency
2402 - 2480 GHz Max Transmit Power 4dBm
Standby
0.39 W/h
23 cm / 9.05 in
33 cm / 12.9 in
42 cm / 16.5 in
8.7 kg / 19.2 lbs
PACKAGING CONTENT
•
•
Tasting Box of Nespresso Vertuo Capsules
•
Vertuo Creatista Recipe Milk Jug
•
Nespresso Welcome Brochure
•
Quick Start Guide
•
Safety Booklet
•
Warranty Booklet
•
Water Hardness Test Strip
3
EN
MACHINE OVERVIEW
A. Waste Container
B. Drip Tray Grid
C. Milk Jug Recess
D. Drip Tray Separator
E. Drip Tray Float
F. Drip Tray
G.
H. Locking / Unlocking Lever
I.
J. Water Tank and Lid
K. Descaling Alert
L. Cleaning Alert
M. Milk Texture Button
(Flat White & Latte, Cappuccino, Latte Macchiato)
N. Milk Temperature Button
(Low, Medium, High)
O. Steam Button
P. Steam Wand
Q. Steam Wand Cleaning Tool
(located under the water tank)
R. Stainless Steel Milk Jug
S. Adjustable Cup Support
A
C
B
E
D
G
H
P
Q
R
S
O
N
M
F
I
J
L
K
4
EN
CONNECTIVITY
Benets of connecting your machine:
GET THE APP
* App Store is a trademark of Apple inc., registered in theU.S. and other countries.
** Google Play and the Google Play logo are trademarks of Google LLC.
Launch the Nespresso app. Select the machine icon. Follow the instructions via the app.
By default, the Bluetooth®/ Wi-Fi®is switched on. Factory reset will also switch the Bluetooth®/ Wi-Fi®on.
Smart Coee:
your machine up to date.
Expert advice: Receive real-time tips thanks to step-by-step features such as descaling,
rinsing and cleaning your machine.
Machine Care: Get support and tutorials for your machine care via your smartphone.
1
3
2
4
1x
5
EN
Rinse and dry all removable parts.
Plug in the power cord and turn on the machine.
Reassemble the machine. Fill the water tank with fresh potable water.
MACHINE SET UP
1 12 2
1 2 3
5 64
Properly attach water tank to the machine.
6
EN
Press and hold the Milk Temperature and
Milk Froth buttons for 5 seconds.
SETTING THE WATER HARDNESS
21
1s 5s
1 2
Press the Steam Button to save and exit.
4
Set the hardness according to the result of the testing strip. Use the
Milk Texture button and Milk Temperature button to change the level.
3
7
EN
Place the 1 L container on top of the drip tray.
Lift up the steam wand and insert in the milk jug.
This process will take up to 7 minutes but can be
Press and hold the Steam Button for 3 seconds.Fill the milk jug with potable water to the MAX line.
FIRST USE / RINSE CYCLE
WARNING:
Make sure no capsule is inserted into the machine during the rinsing process.
1 2
2s
3x
7m
1 2
3 4 5
3s
8
EN
Once the cycle is complete, remove the milk jug.
Wipe the steam wand with
a clean damp cloth.
Empty and rinse the milk jug,
drip tray and container.
1 2 3
FIRST USE / RINSE CYCLE
WARNING:
Make sure no capsule is inserted into the machine during the rinsing process.
WARNING:
HOT. Do not touch steam wand.
1
Fill the water tank with fresh
potable water.
Replace back on to
the machine.
1 2
67
COFFEE PREPARATION
321
NOTE:
Do not put any parts except the steam wand tip in the dishwasher.
9
EN
COFFEE PREPARATION
2 3 4 1
Adjust the height position of the cup support.
Remove the cup support and drip tray when using a carafe.
4
CAUTION:
1 2
5 6
10
EN
COFFEE PREPARATION
Fill the water tank with fresh
potable water.
Replace back on to
the machine.
Pour the milk of choice into the milk jug. Refer to the recipe
suggestions for the ideal amount. Do not exceed the MAX line.
Lift up steam wand and insert in the milk jug.
Positioning it in the drip tray recess.
1 2
MILK COFFEE PREPARATION
7
1 2
34
will be ejected.
1 2 3
NOTE:
For an ideal milk froth, we recommend the use of semi-skimmed pasteurized milk at fridge temperature.
