Bose L1 Model I Operating instructions

Troubleshooting – Preset Update Process for L1™ model I systems

Symptom Cause Resolution

I'm playing an

upgrade disc from the

DVD player, but the

power LED on the

power stand does not

blink.

The DVD player is not actually

playing the disc.

Ensure that the DVD

player is playing the disc

by viewing the

incrementing playback

time on the DVD display.

Make sure PAUSE is not

on.

Data is not yet streaming into the

power stand.

Wait at least 10 seconds

of playback to witness

the LED blinking on the

power stand after the

disc begins to play.

The DVD player is not connected to

the power stand.

Connect a RCA patch

cable from the DVD

player's coaxial digital

audio output to the

power stand Data IN

jack.

The digital audio output setting on

the DVD player is set to the wrong

output format.

With a TV connected,

check the menu options

of the digital audio

output connection.

Sometimes an option for

Bitstream or PCM is

available. Bitstream

should be selected on

most players. If

Bitstream does not

work, then try PCM or

other available options.

The digital audio output is altered by

other "sound-enhancing" settings on

the DVD player.

With a TV connected,

check the menu options

for audio output. Some

players offer 3D,

normalization, and

compression settings.

All of these should be

turned off.

The RCA patch cable is damaged. Try another good-quality

RCA cable.

Red LED The power stand was sent Reboot the power stand

Red LED information which locked it from

receiving further input.

(turn OFF the power

switch, wait 5 seconds,

and then turn the power

switch back ON). Try the

upgrade procedure

again.

My DVD player does

not play the upgrade

disc at all.

The DVD player is not compatible

with CD-R. Many DVD players are

listed on

http://www.dvdrhelp.com/dvdplayers

. Find compatibility details on your

DVD player here.

Use another, compatible

DVD player to perform

the upgrade.

Reference

DVD Player Database – See if your DVD player is equipped with a digital audio output

http://www.dvdrhelp.com/dvdplayers

Optical to Coax Digital Audio Adapter (tested $16.75):

For DVD players with optical only outputs (also check to ensure player is compatible with

CD-Rs) http://www.minidisc.org/part_Dayton_Audio_Optical_to_Coax_converter.html

Known Compatible DVD Players

Toshiba

DVD

(Portable) SD-P2500 Bitstream/PCM YES

Works on Track 2,

Must use mono mini

plug to RCA adapter

APEX DVD AD-1225 Coaxial YES

As is, insert CD and

press play

Toshiba DVD SD-3960 Coaxial YES

As is, insert CD and

press play

Panasonic DVD DVD-547

Digital audio out

(PCM/bitstream) YES

As is, insert CD and

press play

Phillips DVD DVD750VR

Digital audio out

coaxial YES

As is, insert CD and

press play

Onkyo DVD DV-SP301

Digital audio out

coaxial YES

As is, insert CD and

press play

Bose DVD

Lifestyle

Digital audio out

coaxial YES

As is, insert CD and

press play

Bose DVD

Lifestyle

Digital audio out

coaxial YES

As is, insert CD and

press play

Samsung DVD

DVD P-

231

Digital audio out

coaxial YES

As is, insert CD and

press play

Panasonic DVD DVD F-87

Digital audio out

coaxial YES

As is, insert CD and

press play

Tascam CD-RW CD-RW700 Coax Output YES
