Borringia Rise III-130 Operator's manual

User’s Instruction Manual

Rise®IIIS-130 Hoisting Shower-, Commode- & Care Chair w. Tilting Seat

12C10S, English

January 2014

User’s Instruction Manual

Rise® IIIS-130 Hoisting Shower-, Commode- & Care Chair w. Tilting Seat

Table of Contents:

1. Marking ....................................................................................................................................................... 2

2. Introduction: .............................................................................................................................................. 3

3. Lifting & Tilting:........................................................................................................................................ 3

4. Battery & Charging: .................................................................................................................................. 4

5. Emergency-Stop: ....................................................................................................................................... 4

6. Interference: ............................................................................................................................................... 5

7. Safety:.......................................................................................................................................................... 5

8. Daily Inspection and Annual Service Inspection: ................................................................................ 5

9. Water Ingression:....................................................................................................................................... 5

10. Cleaning: ...................................................................................................................................................... 5

11. Recycling:..................................................................................................................................................... 6

12. Measurements & Weight:.......................................................................................................................... 6

13. Optional Equipment:................................................................................................................................. 7

14. Warranty: ..................................................................................................................................................... 7

15. Expected Product Life Span:.................................................................................................................... 7

16. Trouble Shooting: ...................................................................................................................................... 9

17. Appendix 1, Annual Serice Inspection.................................................................................................. 10

Dealer (Stamp):

Autho

rise

d Service (Stamp):

Manufacturer

Borringia A/S Hejreskovvej 18 B-C DK-3490 Kvistgård Phone: +45 49 13 88 55

1. Marking

Your Rise IIIS-130 chair carries marking, according to the applicable technical standards. For your

information each of the 2 labels on the Rise IIIS-130 are explained below:

Marking, Production, Frame- & Batch number for the Rise IIIS-130:

Explanation:

12C10S-130: Identifies the product, i.e. a Rise IIIS-130 Shower-, Commode- & Care Chair

12: Identifies the year of production, i.e. 2012

02: Identifies the month of production, i.e. February

200: Identifies the specific frame number of this one unit

Max. 130 kg Informs of the limit of the allowed weight of the user

Marking, Transport Packaging:

Rise III-130

Shower-, Commode-& Care Chair

Frame & Batch No. :

12C10S-130 12 02 200

Storage:

Keep Dry, 25-90% relative humidity,

0-50º Celcius, 250-1200 hPa

Explanation:

Borringia: The manufacturer

Rise III-130: Brand name of the product

Shower-, Commode- & Care Chair: Product description

Frame- & Batch No.: Identification of the specific product

Storage: Information about how to store the product

Keep dry: To be stored away from rain and water

25-90% Relative humidity: Indication of safe humidity-level

0-50º Celsius: Safe storage temperature

250-1200 hPa Safe air pressure

12C10S-130 12 02 200

Patented, EP 1286638

Max 130 kg

2. Introduction:

The Rise IIIS-130 Shower-, Commode- & Care Chair accommodates the needs of both the user and the helper.

The electrical elevation (Seat height 53,5 cm – 95 cm) makes it possible to avoid lifting the user with a traditional

sling. By elevating the seat to match the height of the bed or wheelchair, most users can transfer themselves

sideways to/from the Rise IIIS-130. For weak patients use of a transfer board may be advantageous.

The electrical elevating function enables the helper to obtain an ideal working position during toileting,

showering and personal hygiene routines. This allows the user to enjoy his/her daily shower, etc. without feeling

that they are a burden to the helper, thus contributing to less stressful care routines.

The elevating function combined with the seat, which can be tilted forward and backward, also enables the Rise

IIIS-130 to help the user to a standing position. This is possible because the chair not only lifts the seat up to

41,5 cm (16 in.) but, at the end of the elevating cycle, the user may be tilted forwards about 20 cm (8 in.). In this

way Rise IIIS-130, in the same way as typical catapult seats, may help the user to move their body’s centre of

gravity to a point directly above their feet. Getting to this vertical position is often one of the most difficult

problems for persons with limited walking or standing ability.

If you have any questions, comments or suggestions for improvements, please do not hesitate to call your local

dealer or contact Borringia directly by phone at TEL +45 49 13 88 55 or on the Internet: www.borringia.com.

Rise IIIS-130 Shower-, Commode & Care Chair is simple & logical to use. However, you must read the

following instructions carefully prior to using the chair:

3. Lifting & Tilting:

Both the lifting and the seat tilting functions are electrical. Power is supplied by a 24 volt battery (NiMh) with a

capacity of 1,4 Ah, sufficient for 25-30 full lifting cycles when fully charged.

Pressing the corresponding button on the hand control activates lifting/lowering and seat tilting. As soon as the

button is released, movement stops.

This button to

lift

This button to

lower

This button to

tilt the seat

forwards

This button to

tilt the seat

backwards

4. Battery & Charging:

1. Rise IIIS-130 is equipped with a 24 volt battery (NiMh) with a capacity of 1,5 Ah. When the battery is

fully charged, it has sufficient capacity for 25-30 full lifting cycles.

2. The battery and electronics box are equipped with a number of safety and signalling functions, which

help prevent that you run out of power during a job

a. When the battery has been discharged to a point, where there is sufficient power left for 5

lifting cycles, pressing the buttons on the hand control will result in a ”beep”. This is an

indication that charging is needed.

b. If the battery is still used without being charged, the electronics will at a certain point only allow

downwards movement. This is an indication that charging is needed.

c. If usage of the battery is continued, the electronics will at a given point prohibit all movement.

d. All batteries loose performance when they are cold, i.e. at 0° Celsius (32° F) or colder. If you

have left your Rise IIIS-130 or the battery in your car in cold weather, you may have to re-

charge the batteries, before using the Rise IIIS-130.

e. Normal operational temperature should be 0°- 40° Celsius (32° - 104° F)

To charge the battery follow the steps below.

Pull the battery out of the electronics box

2. Push the battery into the charging station and turn it clockwise until the magnets lock the battery in

place.

As long as the green lamp blinks, charging is ongoing. When the green lamp is lit permanently,

charging has been completed. The yellow lamp is lit, when the charging station is connected to the

mains supply.

5. Emergency-Stop:

The removable battery also functions as an ”Emergency-Stop” in the – unlikely – situation that movement

occurs without a button being pressed on the hand control. By pulling the battery out of the electronics box, all

movement is stopped. The “Emergency-Stop” is deactivated by pushing the battery into the electronics box and

turning it clockwise until the magnets lock the battery in place.

1 2

Contact your dealer IMMEDIATELY and DO NOT USE the Rise IIIS-130 chair until

service inspection and repair has been CARRIED OUT!

6. Interference:

7. Safety:

·Never leave person with insufficient body control alone, when lifted

·Make sure that the hands, legs and feet of the user are not squeezed between parts of the

Rise IIIS-130 and other aid products (e.g. wheelchair, bed, or the like)

·Never use the Rise IIIS-130 in hot surroundings, e.g. in Saunas or in steam baths

8. Daily Inspection and Annual Service Inspection:

Daily

Inspection: Before using the Rise IIIS-130, always check the following points:

·There should be no visual cracks, dents or deformation of any metal part on the Chair

·All retaining rings should be in place

·The actuator should not make jarring sounds when activated with load

Service: Rise IIIS-130 must undergo at least one service inspection annually by an authorized

technician. Service agreements can be made with your dealer. Borringia cannot be held

responsible for damage to persons caused by the failure to carry out annual service

inspections.

9. Water Ingression:

Humidity: Rise IIIS-130 is designed for use in the shower. However, neither the chair nor the

electronics should ever be submerged

The electronics box is ONLY splash proof if correctly mounted and the battery inserted. If

the battery is removed during showering / cleaning, water will enter into the box and the

electronics may be destroyed. Failure as a result of this is NOT covered by the warranty.

10. Cleaning:

The Rise IIIS-130 is designed to be easy to clean:

·For daily cleaning, we recommend using wet-wipes either based on ethanol or containing anti-bacterial

ingredients.

·For thorough cleaning, the Rise IIIS-130 may be cleaned in automated washing machines or with

saturated steam for up to 1 minute at 90° Celsius (194° Fahrenheit), for 5 minutes at 85° Celsius (185°

Fahrenheit) or 10 minutes at 80° Celsius (176° Fahrenheit).

Should the electronics on the Rise IIIS-130 interfere with other electrical equipment,

contact your dealer IMMEDIATELY and DO NOT USE the Rise IIIS-130 chair until

service inspection and repair has been CARRIED OUT!

Always follow the instructions below:

·Cleaning of the toilet seat and the frame underneath it is easily done. Just pull upwards at the front of

the seat and remove it.

·Depending on the hardness of the water in your region, we recommend that chalk stains be removed

every 2 – 4 weeks. For environmental reasons, we recommend that you refrain from using acids or the

like. Simply spray the chair with standard household vinegar and leave it to work for 2-3 hours, then

rinse with water. Dry the chair with a cloth. In extreme cases you may want to use a household chalk

stain remover. Dilute the product with 4 parts of water before applying to the areas to be cleaned.

Lubrication: Approx. once a month, apply a bit of Vaseline to the piston of the actuators.

11. Recycling:

When the Rise IIIS-130 is taken out of use, you should see to it that the chair is disposed off in an

environmentally friendly way. Follow the instructions below:

Metal parts: All metal parts are made of steel and can safely be recycled. The painting will

not result in any toxic components as a result of recycling.

Electronics: The electronics including the batteries should be delivered to a recycling plant

equipped to handle electronic waste safely. If in doubt as to whether such a

facility is available, please return the electronic components to your dealer, who

will then pass these on to the manufacturer for safe recycling.

12. Measurements & Weight:

Height: 108– 148 cm (43 – 59in.)

Width: 57 cm (22.5 in.)

Length: 88 – 105 cm (35 – 41in.)

Seat height: 53,5 – 95 cm (20 – 37in.)

Seat width: 45 cm (17.7 in.)

Seat depth: 43 cm (17.0 in.)

Armrest’s height over seat: 21 cm (8.3 in.)

Width between armrests: 47 cm (18.5in.)

Backrest, Height over seat: 56 cm (22.5in.)

Backrest upholstery, Height over seat: 43 cm (17.0 in.)

Backrest width: 43 cm (17.0 in.)

Height of carriage: 15 cm (5.9 in.)

Clearance, carriage: 7 cm (2.8 in.)

Turning circle: 98 cm (38.6 in.)

Weight: 32,0 kg (70.6 lbs.)

Lifting range: 40 cm (15.7 in.)

Lifting & Tilting mechanism: Electrical actuator

Never expose the battery to temperatures above 90° Celcius (194° Fahrenheit) for

more than 1 minute, 85° Celcius (185° Fahrenheit) for more than 5 minutes or at

80° Celcius (176° Fahrenheit) for more than 10 minutes as this can cause danger

of explosion

Always leave the battery in the control box during cleaning as the battery forms an

integral part of the system, which prevents ingression of water

Seat Tilt: From +6 to – 31 degrees

Battery: 24 V (NiMh)

Battery Capacity: 25 – 30 lifting cycles

Charging: Via external charging station

Charging time: 4-5 hours

Max user weight: 130 kg 286 lbs.

13. Optional Equipment:

·Bedpan w. lid - stainless steel

·Holders for bedpan

·Holders for low hanging bedpan (+50 mm / 2”)

·Headrest, with soft adjustable PU-padding

·Headrest, Small

·Headrest, Medium

·Headrest, Large

·Backrest with built-in positioning system

·Anti-pressure pillow with toilet cut-out

·Locking mechanism for armrests

·Armrest for hemiplegics, left or right

·Crossbar between armrests

·Set of armrest with front closure

·Elevating footrests

·Calf belt between footrests

·Amputation largest, left or right

·Lid for PU-Toilet Seat

·PU-Toilet seat with hygiene cut-away at the front.

·Torso-, Hip- & Thigh Belt

·Swing-away Torso-Support with PU-Padding

·Seat-tilt limitation (Blocks forward tilt at horizontal level)

·Bracket for wall-mounting of the charging station

·Direction lock on rear wheel (Factory mounted)

14. Warranty:

Two years warranty on failure in metal construction. Warranty does not cover damage as a result of faulty use of

the chair. Casters, and the battery, which are subject to normal tear, are warranted for one year. Failure as a result

of misuse is not covered by the warranty.

15. Expected Product Life Span:

If the annual service inspections are carried out, the Rise IIIS-130 is expected to have a life time of 8 – 10 years.

Actuators, castors and battery may have to be replaced during the life span, depending on the intensity of use.

Removing the Seat for cleaning:

1. Pull upwards at the front of the seat and the seat can be removed completely for thorough cleaning of

both the seat and the seat frame.

2. In order replace the seat; place the seat at an angle as seen in picture 2. Slide the seat backwards.

Push down on the front of the seat, until it clicks into position.

Footrests:

1. In order to remove the footrests, simply pull upwards

2. In order to put the footrests onto the chair, place the footrest over the holder as shown on the picture

and push downwards until the footrest clicks into place.

3. The height of the foot paltes may be adjusted by losening the thumb screw.

The angle opf the foot plates may be adjusted by using the Allen key supplied with the chair.

1 2

1 2 3

16. Trouble Shooting:

Is the plug of the

hand control inserted in Insert the plug

the electronics box?

Are the plugs of the

actuators inserted in Insert the plug

the electronics box?

Yes

Does the

lift & tilt movement

work?

the battery correctly' Push battery to the

incerted in the in bottom and turn until No

the electronics box?

magnets lock

Get in contact

with Borringia

Service representative

Does the Power Charge

Pack "beep" when the

activated?

battery

If MOVEMENT doesn't work

yes

3 4

Table of contents

Popular Mobility Aid manuals by other brands

Alber

Alber Scalamobil iQ operating instructions

Ferno

Ferno CCT-PX user manual

HEPRO

HEPRO Gripo user manual

Otto Bock

Otto Bock Pheon 3R62 Instructions for use

NRS Healthcare

NRS Healthcare M11090 User instructions

Medline

Medline MDS86835DSHEC User Instructions & Warranty

Guldmann

Guldmann Twin Turner II user manual

Drive

Drive ROOMBA Operation manual

Gate

Gate Balder operating instructions

Decon wheel

Decon wheel TNS Notos Assembly instructions

ExoAtlet

ExoAtlet ExoAtlet-II user manual

Invacare

Invacare Storm Series parts catalog

Rhythm Healthcare

Rhythm Healthcare B3800F manual

AMF-BRUNS

AMF-BRUNS PROTEKTOR installation manual

Drive DeVilbiss Healthcare

Drive DeVilbiss Healthcare OTTER Instructions for use

Rhythm Healthcare

Rhythm Healthcare C500U Assembly and Fitting Instructions

Lumex

Lumex RJ4200A manual

Rebotec

Rebotec Jumbo user manual
