BluMill SL-9827H User manual
EN - Manual...................................... 2
NL - Gebruiksaanwijzing................ 9
FR - Mode d’emploi ......................16
DE - Anleitung ...............................23
IT - Istruzioni per l’uso ................. 30
ES - Instrucciones de uso ............37
SW - Instruktioner ........................44
PL - Instrukcje................................51
Stand mixer
SL-9827H
2021-01-05 OCG BluMill Stand Mixer manual V02.indd 12021-01-05 OCG BluMill Stand Mixer manual V02.indd 1 21-01-2021 15:4921-01-2021 15:49
2
Important safety precautions
When using any kind of electrical appliance, some basic safety precautions must
always be followed, including the following:
•
Read all instructions.
•
To protect against risk of electrical shock do not put the appliance, unit cord
or plug in water or any other liquid.
•
Close supervision is necessary when a appliance is used by or near children.
•
Unplug the appliance when it is not in use, changing accessories and before
cleaning.
•
Avoid contacting moving parts.
•
If the supply cord is damaged, it must be replaced by the manufacturer or its
service agent or a similarly quali ed person in order to avoid a hazard.
•
The use of attachments not recommended or sold by the manufacturer may
cause re, electrical shock or injury.
EN
1 Swivel arm 6 Lid
2 Release button 7 Whisk
3 Speed control knob 8 Flat beater
4 Main house 9 Splashguard
5 Mixing bowl 10 Kneading hook
2021-01-05 OCG BluMill Stand Mixer manual V02.indd 22021-01-05 OCG BluMill Stand Mixer manual V02.indd 2 21-01-2021 15:4921-01-2021 15:49
3
•
Do not use outdoors.
•
Do not let the cord hang over the edge of the table or counter.
•
Keep hands and utensils away from moving parts while processing food to
reduce risk of severe injury to a person or damage to the food mixer.
•
Some parts may be sharp, handle them carefully.
•
To reduce the risk of injury, never place sharp objects on the base.
•
Be certain the appliance is securely locked in place before operating the
appliance.
•
Do not attempt to defeat the lid interlock mechanism.
•
Turn off the machine before replacing an attachment.
•
Use the product and assemble the accessories as mentioned in the user
manual only.
•
Switch off the appliance before changing accessories or approaching parts
which move in use.
•
This appliance shall not be used by children. Keep the appliance and its cord
out of reach of children.
•
Appliances can be used by persons with reduced physical, sensory or
mental capabilities or lack of experience and knowledge if they have been
given supervision or instruction concerning use of the appliance in a safe
way and if they understand the hazards involved. Children shall not play with
the appliance.
•
Always disconnect the appliance from the supply if it is left unattended and
before assembling, disassembling or cleaning.
Save these instructions
EN
2021-01-05 OCG BluMill Stand Mixer manual V02.indd 32021-01-05 OCG BluMill Stand Mixer manual V02.indd 3 21-01-2021 15:4921-01-2021 15:49
4
Control panel
Operating positions
Setting speed
EN
0 Stop
Setting 1-6 Operating speed
Setting 1 Minimum
Setting 6 Maximum
Accessories Picture Speed
setting
Time Capacity
Kneading
Hook
1, 4 1 min at speed 1
4 min at speed 4
700 g our and
350ml water
(Temperature
40+/-5°C)
Flat beater 4-5 10 min
Whisk 6 10 min
Warning!
Operate the appliance only when the accessory/tool is attached according to this
table and always use the correct operating position.
2021-01-05 OCG BluMill Stand Mixer manual V02.indd 42021-01-05 OCG BluMill Stand Mixer manual V02.indd 4 21-01-2021 15:4921-01-2021 15:49
5
Item Position Accessory
1
2 Set up Kneading Hook, Flat beater, Wisk, accor-
ding to your desire.
EN
Risk of injury from the rotating tools!
While the appliance is operating, keep ngers clear of the mixing bowl.
Do not change tools until the appliance is at a standstill and has been unplugged.
When switching off, the drive continues to run briey.
How to use Kneading hook, Flat beater, Whisk
1. Place the appliance on a at surface, e.g. a
kitchen counter, and make sure it is standing
rmly.
2. Turn the arm release button (2) clockwise.
At the same time lift the swivel arm (1) with a
hand so that it locks into place with a click. The
swivel arm tilts up.
1
2021-01-05 OCG BluMill Stand Mixer manual V02.indd 52021-01-05 OCG BluMill Stand Mixer manual V02.indd 5 21-01-2021 15:4921-01-2021 15:49
6
1. Put the splashguard (9) onto the kneading
hook (10) as shown in the picture. Turn and x
the hook. The splashguard (9) can prevent the
dough from climbing to the top of the hook.
2. Fit the required accessory (10 with 9, 7 or 8)
onto the motor spindle on the underside of the
swivel arm (1).
3. A. The kneading hook (10) is used for heavy
dough, minced meat or other demanding
kneading jobs.
B. The at beater (8) is used to mix lighter types
of dough.
C. The whisk (7) is used for whisking cream,
egg whites, etc.
4. Turn the accessory, so the pins on the
spindle are aligned with the depressions on
the accessory top edge. Press the accessory
against the swivel arm and turn it anti-clockwise
at the same time until the pins engage and the
accessory locks into position securely. The
accessory must not be loose nor should you be
able to pull it free.
EN Fit the lid (6) onto the swivel arm and turn it
slightly clockwise, so that it locks into position
securely.
1. Place the food in the mixing bowl (5).
2. Fit the mixing bowl in the recess on the main
house (4).
3. Turn the mixing bowl slightly clockwise, so it
locks into position.
4
4.1
4.2
2
2
2021-01-05 OCG BluMill Stand Mixer manual V02.indd 62021-01-05 OCG BluMill Stand Mixer manual V02.indd 6 21-01-2021 15:4921-01-2021 15:49
7
1. Switch off the appliance by turning the speed
control knob to 0 when you have nished
mixing. Switch off the appliance and unplug it
before you change the accessories, or before
you take the appliance apart or when it is not
in use.
2. Turn the swivel arm release button clockwise.
At the same time lift the swivel arm with hand
so that it locks into place with a click. The
swivel arm tilts up.
1. Lower the swivel arm so that it locks into
place with a click. The lid must t tightly with
the mixing bowl, otherwise it is tted incorrectly.
The appliance is now ready for use.
2. Plug the power cord into the main power
outlet.
3. Select the setting you want by using the
recommended speed, time and capacity which
are shown in the table above.
4. If you need to scrape inside the mixing
bowl, wait until the accessory has stopped
completely. Use the spatula, never your ngers.
EN
5
6
1. Detach the accessory by turning it clockwise.
2. Remove the mixing bowl with prepared food
anti-clockwise.
7
2021-01-05 OCG BluMill Stand Mixer manual V02.indd 72021-01-05 OCG BluMill Stand Mixer manual V02.indd 7 21-01-2021 15:4921-01-2021 15:49
8
EN Important!
The temperature of water should be added into the dough at 40 +/-5°C when
preparing the dough is in progress.
Capability of bowl
5000 mL
Cleaning
When cleaning the appliance, you should pay attention to the following points:
• Remove the plug from the main socket, and allow the appliance to cool down
before cleaning it.
• Do not immerse the motor section of the appliance in water and make sure
no water enters the appliance.
• Clean the motor section by wiping it with a damp cloth. A little detergent can
be added if the appliance is heavily soiled.
• Do not use scouring pads, steel wool or any form of strong solvents or abra-
sive cleaning agents to clean the appliance, as they may damage the outside
surfaces of the appliance.
• Take the appliance apart and clean all of the accessories separately. They can
be cleaned in warm soapy water or in the dishwasher. Make sure the parts are
not xed rmly in the dishwasher as this may change their shape.
• Be careful not to touch any sharp parts during use and cleaning.
• IMPORTANT! Allow to dry fully after cleaning before using it again. Do not use
the appliance if it’s damp.
• After washing and drying, immediately place the attachment into the protec-
tive sleeve for storage.
Correct Disposal of this product
This marking indicates that this product should not be disposed with other
household wastes throughout the EU. To prevent possible harm to the environ-
ment or human health from uncontrolled waste disposal, recycle it responsibly
to promote the sustainable reuse of material resources. To return your used
device, please use the return and collection systems or contact the retailer
where the product was purchased. They can take this product for environmen-
tal safe recycling.
SL-9827H
AC 220-240V 50Hz 1300W
2021-01-05 OCG BluMill Stand Mixer manual V02.indd 82021-01-05 OCG BluMill Stand Mixer manual V02.indd 8 21-01-2021 15:4921-01-2021 15:49
9
Belangrijke voorzorgsmaatregelen
Houd u bij het gebruik van elektrische apparatuur altijd aan de standaard
veiligheidsvoorschriften, waaronder de volgende:
•
Lees alle instructies door.
•
Laat het apparaat, het snoer en de stekker niet in aanraking komen met
water of andere vloeistoffen, om het risico van een elektrische schok te
vermijden.
•
Houd altijd toezicht als een apparaat wordt gebruikt door of in de nabijheid
van kinderen.
•
Haal altijd de stekker uit het stopcontact wanneer het apparaat niet wordt
gebruikt, wanneer u accessoires verwisselt en voordat u het apparaat
schoonmaakt.
•
Raak bewegende delen niet aan.
1 Draaiarm 6 Deksel
2 Ontgrendelknop 7 Garde
3 Snelheidsregeling 8 Menghaak
4 Onderstel 9 Spatdeksel
5 Mengkom 10 Kneedhaak
NL
2021-01-05 OCG BluMill Stand Mixer manual V02.indd 92021-01-05 OCG BluMill Stand Mixer manual V02.indd 9 21-01-2021 15:4921-01-2021 15:49
10
•
Wanneer het snoer beschadigd is, moet het worden vervangen door de
fabrikant of een erkend onderhoudsbedrijf om gevaarlijke situaties te
voorkomen.
•
Het gebruik van opzetstukken die niet worden aanbevolen of verkocht door
de fabrikant kan brand, elektrische schokken of persoonlijk letsel tot gevolg
hebben.
•
Gebruik het apparaat niet buitenshuis.
•
Laat het snoer niet over de rand van de tafel of het aanrecht hangen.
•
Houd handen en keukengerei uit de buurt van bewegende delen
wanneer u het apparaat gebruikt, om persoonlijk letsel en schade aan de
keukenmachine te voorkomen.
•
Let op: sommige onderdelen kunnen scherp zijn.
•
Plaats geen scherpe objecten op het onderstel om letsel te voorkomen.
•
Zorg dat het apparaat stevig staat voordat u het gebruikt.
•
Probeer niet de dekselvergrendeling te forceren.
•
Zet het apparaat uit voordat u accessoires verwisselt.
•
Gebruik het apparaat en de accessoires uitsluitend zoals beschreven in de
gebruiksaanwijzing.
•
Schakel het apparaat uit voordat u accessoires verwisselt of met uw vingers
in de buurt komt van bewegende onderdelen.
•
Dit apparaat mag niet worden gebruikt door kinderen. Houd het apparaat en
het snoer altijd buiten bereik van kinderen.
•
Dit apparaat mag worden gebruikt door personen met lichamelijke,
zintuiglijke of geestelijke beperkingen of met gebrek aan ervaring en kennis,
op voorwaarde dat zij worden begeleid of geïnstrueerd over het veilige
gebruik van het apparaat en op de hoogte zijn van de risico’s ervan. Dit
apparaat is geen speelgoed.
•
Haal de stekker altijd uit het stopcontact als het apparaat onbeheerd wordt
achtergelaten en voordat u het in elkaar zet, uit elkaar haalt of schoonmaakt.
Bewaar deze voorschriften goed
