Blendtec Brawn User manual
MANUAL
ABC SMOOTHER SPACESAVER
Table Of Contents
Section Page
Section 1.....Important Safeguards 5
Section 2.....Component Overview 7
Section 3.....Unpacking 9
Section 4.....Installation 10
Section 5.....Operating Instructions 12
Section 6.....Warranty and Service 16
Appendix A.....ABC Operation 18
Appendix B.....Product Diagrams 21
5
SECTION 1 – IMPORTANT SAFEGUARDS
READ ALL INSTRUCTIONS CAREFULLY BEFORE USING YOUR
BLENDTEC MACHINE.
1.1 SAFETY CERTIFICATION
The ABC, Smoother, and SpaceSaver
blenders and accessories are certied by ETL
to UL standard 763, and to CSA standard C22.2 No.
195-m1987, and to CE Standards.
1.2 HEALTH CERTIFICATION
The ABC, Smoother, and SpaceSaver
blenders and accessories are certied by
NSF International.
1.3 AVOID CONTACT WITH MOVING PARTS
● Keep ngers, hands, hair and clothing away from all moving parts.
● Keep all utensils away from the drive socket and blender blades during
operation. Metal utensils will damage blades.
·NEVER put hands into blender jar or add substances by hand when
blender is operating.
·NEVER place jar into drive socket if blender motor is operating.
·Do not rock the blender when it is operating. Keep the blender jar
straight up until the operation is complete.
● These precautions will prevent personal injury and/or damage to the
blender.
1.4 POWER CORD PRECAUTIONS
·Do not operate with a damaged cord or plug.
·If the supply cord is damaged, it must be replaced by the manufacturer
or its service agent in order to avoid a hazard.
·Do not let the cord hang over the edge of the work surface.
·Never use an extension cord with the unit.
·Unplug the blender motor before removing from sound enclosure,
changing blender locations, or cleaning.
1.5 NEVER ATTEMPT TO REPAIR THE POWER UNIT
Never remove the blender base cover. The blender base does not
contain self-adjustable or serviceable parts. All service and adjustments
must be made by a qualied service agent. Removing the cover or
attempting to service the blender will void the warranty.
1.6 TURN THE UNIT OFF WHEN NOT IN USE
R
6
1.7 THE 110/120 VOLT RECEPTACLE FOR EACH POWER UNIT MUST
BE PROTECTED BY A SEPARATE 20 AMP CIRCUIT BREAKER OR FUSE.
THE 220/240 VOLT RECEPTACLE FOR EACH POWER UNIT MUST BE
PROTECTED BY A SEPARATE 13 AMP CIRCUIT BREAKER OR FUSE.
Do not use any other electrical equipment on the same circuit as
the blender or you risk overloading the circuit and either damaging
the blender electronics or blowing the circuit protection.
1.8 NEVER OPERATE IF THE UNIT APPEARS DAMAGED
If the blender malfunctions call the service agent rst. If it is dropped
or damaged in any way, return the blender to a Blendtec service agent
immediately for examination, repair, electrical or mechanical adjustment,
or possible replacement.
1.9 NEVER OPERATE IN LIQUID
Do not operate the blender motor in water or any other liquid. Avoid
any contact between the motor and water. Deliberate use of machine
outdoors in conditions where precipitation is present will void the
warranty.
1.10 NEVER PUT ITEMS SUCH AS METAL, ROCKS, OR OTHER
HARD MATERIALS INTO BLENDER JAR
Metal utensils and other hard materials are dangerous. They can cause
injury or damage. Damage caused by such foreign objects will void the
warranty.
1.11 NEVER OPERATE USING ATTACHMENTS NOT SOLD BY
BLENDTEC
The use of unauthorized attachments voids the warranty and may cause
re, electric shock, or injury.
1.12 ALWAYS SECURE THE BLENDER LID BEFORE STARTING THE
MACHINE
Even if you have a sound enclosure, make sure you place a lid on the
blender jar before you close the cover.
1.13 AVOID TOUCHING THE METAL BASE AFTER EXTENSIVE USE
The metal base of the blender may become hot after numerous cycles.
1.14 BLADES ARE SHARP! HANDLE CAREFULLY
1.15 When blending HOT LIQUIDS, remove center plug of lid.
7
1.16 NEVER CLEAN THIS UNIT WITH A WATER JET.
1.17 THE POWER CORD RECEPTACLE WHICH POWERS THE
BLENDER MUST ALWAYS BE ACCESSIBLE.
SAVE THESE INSTRUCTIONS
SECTION 2: COMPONENT OVERVIEW
2.1 BLENDER MOTOR
The blender motor consists of the blender base shell, touch pad control,
Liquid Crystal Display (LCD) information center, and the power unit.
(See Figures 1.1 and 1.2)
●
·Motor housing: Houses the power unit in a general stainless steel casing.
Never remove the motor cover. Removal of the motor cover will void the
warranty.
●
·Touch Pad: Consists of six buttons which contain pre-programmed
settings as well as a pulse for selective blender control.
●
·LCD Information Center: When a cycle is completed, the display
increments the cumulative cycle for warranty purposes. It also indicates
overload or over-temperature conditions.
●
·Blender Motor: This unit is located within the motor housing and
contains the machinery which runs the blender, including the electric
motor, drive train, and computerized control board.
2.2 BLENDER JAR ASSEMBLY
The blender jar assembly consists of the blender jar, blade assembly,
and lid. The blender jar assembly integrates these components to
ensure consistently blended drinks and greater operator safety.
●
Jar: Made from polycarbonate to provide maximum performance as
well as clear visibility of blender performance.
●
Blade Assembly: Stainless steel, designed to ensure fast, consistent
blending.
●
Lid: Designed to provide ease of handling and quick removal for high
speed operations.
8
2.3 OPTIONAL SOUND ENCLOSURE
The sound enclosure reduces noise created during blender operation.
2.4 OPTIONAL SOUND ENCLOSURE BOTTOM
A “top-of-the-counter” version of the blender is created by combining the
sound enclosure described above with a sound enclosure bottom into
which the blender motor is inserted. This allows for portable operation of
the blender.
2.5 POWER SPECIFICATIONS
Blendtec Blenders are made with power specications listed below
according to your specic model.
110/120 VOLT BLENDTEC BLENDERS ARE REQUIRED
TO BE PROTECTED BY A DEDICATED 20 AMP
CIRCUIT BREAKER OR FUSE.
MODEL (110/120 VOLT) AMPS WATTS
ICB7 (Smoother20) 20 2400
ICB5 (Smoother18) 18 2000
ICB4 (Smoother15, SpaceSaver15) 15 1800
ICB3 (Smoother13, SpaceSaver13) 13 1500
ABC5 (ABC18) 18 2000
ABC4 (ABC15) 15 1800
ABC3 (ABC13) 13 1500
220/240 VOLT BLENDTEC BLENDERS ARE REQUIRED
TO BE PROTECTED BY A DEDICATED 13 AMP
CIRCUIT BREAKER OR FUSE.
MODEL (220/240 VOLT) AMPS WATTS
ICB5 (Smoother18) 9 2000
ICB3 (Smoother13, SpaceSaver13) 6.5 1500
ABC5 (ABC18) 9 2000
ABC3 (ABC13) 6.5 1500
9
SECTION 3: UNPACKING
SAVE THE TWO FOAM INSERTS AND ALL PACKAGING FOR FUTURE
STORAGE OR SHIPPING. SAVE THESE INSTRUCTIONS FOR
FUTURE REFERENCE.
3.1 UNPACKING YOUR BLENDER
1. You should have received the following items:
·Model ICB or ABC Blender Base
·Blender Jars (2), Lids (2)
·Sound Enclosure (optional)
●
·Additional Blender Jars (optional)
2. Remove blender motor, sound enclosure components, blender jars
and lids from carton.
3. Unwind the power cord.
4. Check for and remove any packing material which may have blocked
ventilation holes in either the power unit or the black motor stand.
5. Inspect all items to ensure no damage occurred in shipment.
6. If any damage has occurred contact your Blendtec service agent
immediately.
3.2 RECORDING YOUR SERIAL NUMBER AND DATE OF SHIPMENT
Record your blender base serial number and date of purchase in the
space below. You will need these when contacting Blendtec for service.
Blender Serial No. ____________________________________
Date of Purchase ___________________________________
Refer to these whenever contacting your Blendtec service agent.
10
SECTION 4: INSTALLATION
4.1 Above Counter Installation
(For SpaceSaver model, disregard mention of sound enclosure)
1. Insure that an electrical receptacle is readily accessible when you
locate the equipment.
2. Be sure the unit is switched off and unplugged. Remove the lid (top)
of the sound enclosure by either sliding the piano hinge pin out of the
hinges. (For the Q Series model, lift the top straight off the bottom to
remove.) Lay the sound enclosure top and the hinge pin aside.
3. Route the power cord from the top through the bottom of the clear
sound enclosure bottom and insert the motor carefully into the opening
in the bottom of the sound enclosure base. Be sure the rubber gasket ts
smoothly and tightly into the plastic base.
4. Slide the power cord and the motor into the black plastic sound
enclosure base with the touch pad facing the front, tting the motor and
clear sound enclosure bottom snugly into the black base. Extend the
cord out the bottom of the base to its full length.
5. Set the equipment on the counter and re-install the clear sound
enclosure top.
6. Insure clearance above the counter around the installation to allow for
unhampered operation of the sound enclosure.
4.2 Preparation for In-Counter Installations
1. Identify desired blender location. Consider preferences such as
proximity to ingredients, how close you want to be to customers, and
available counter space.
2. Ensure potential site meets all dimensional requirements. (See
Figures 3.1-3.3.)
● ·Counter top can be no thicker than 3/4 in (19 mm). A counter top
thicker than 3/4 in. (19 mm) will obstruct ventilation louvers on the upper
sides of the motor.
● ·If installing more than one blender, allow 14 to 16 in. (356 - 406 mm)
center-to-center blender spacing.
