Blaupunkt TIF 4.0 User manual
Enjoy it.
Operating and Installation Instructions
12V 2-IN-1 TIRE INFLATOR
& VACUUM CLEANER
TIF 4.0
Safety Notes
This tire inator has been manufactured according to
established safety guidelines. However, dangers may still
occur if the safety notes in this manual is not observed.
This manual is intended to familiarize the user with the
tire inator’s important functions. Read this carefully,
prior to using the appliance. Keep this manual in an
easily accessible location. In addition, do observe the
instructions of the devices used in conjunction with this
appliance.
Attentions
•
•
•
•
•
•
•
•
•
•
•
•
This manual may be updated from time to time without
any notice.
This appliance is intended for installation and
operation in a vehicle with 12V vehicle system
voltage.
Do not operate the appliance for other purposes
other than inating car tires, motorbike or bicycle
tires, balls and other low pressure inatables.
Do not operate appliance on high pressure inatables
such as truck and heavy machine tires.
Use only the supplied accessories when operating
the appliance.
Do not leave the appliance unattended during
operation.
Do not over inate.
Do not operate the appliance for more than
30 minutes continously. Appliance or tire may be
damaged due to overheating.
Keep the appliance away from children.
Keep the appliance away from ammable areas
or liquids.
The appliance should be stored in dry and low
humidity place.
Do not operate the appliance during cleaning.
Dry all the components after cleaning.
CAUTIONS
Disclaimer
In no event shall Blaupunkt be liable for any direct,
indirect, punitive, incidental, special consequential
damages to property or life and whatsoever arising out
of or connected with the use or misuse of our products.
USA & CANADA: This product is not intended for sale in
the United States and Canada. If purchased in the U.S. or
Canada, this product is purchased on as-is basis. No
warranty, whether expressed or implied is provided in
the U.S. or Canada.
1
Pressure Gauge : Pressure Range (0~120 Psi)
Air Hose
Power Source : 12V Cig Charger
Button for Opening Dust Compartment
ON/ OFF Switch
Crevice Nozzle
Upholstery Brush
Soft Tube
Adaptor for Tire and Inatables
Adaptor for Ball
STRUCTURE & FUNCTIONS
TIRE INFLATOR & VACUUM CLEANER
Functions
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
910
2
2
4 5
6
7
8
ACCESSORIES
1
3
Problems
Inator does not start
Inator is started but
does not inate
Slow ination
Weak vacuum suction
Possible Causes
Car ignition is o.
Loose power plug connection.
Failure of power outlet fuse.
Incorrect or loose hose connections.
Air leaking from tire or hose.
Inator is overheating.
Insucient voltage supply.
Dust compartment is full.
Soft tube or Crevice Nozzle is
blocked.
Solutions
Turn on car ignition.
Ensure 12V cig charger is rmly attached to the
cig charger socket.
Ensure vehicle power outlet fuse is 15amp or
higher.
Ensure the hose connector is rmly screwed on
the valve stem.
Ensure the tire inator does not have leakage.
Ensure air hose or tire does not have puncture.
Do not operate inator for more than 30 minutes.
Allow approx. 15 minutes of cool down time in
case of overheating.
Ensure car battery is in good condition and not
in low voltage.
Empty the dust compartment.
Remove the blockage.
If any of the following problem occur, please resort to Troubleshooting for the possible solutions. Consult Blaupunkt
authorized dealer if problem persist.
TROUBLESHOOTING
3
SPECIFICATIONS
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
Easy to Clean Dust Compartment
Tire Inator Suitable for Car, Motorbike, Bicycle, Ball and Inatables
Ination Time : < 7min (Standard 195R65/15 Tire from 0 to 35Psi)
1L for Dust Compartment
Vacuum Power : 4200Pa
Air Flow : 24L
Hose Length : 50cm
Cable Length : 300cm
Working Temperature : -10°C ~ 60°C
Storage Temperature : -20°C ~ 70°C
Voltage : 12V
Max Current : 10A
Max Measuring Pressure:120 Psi
Max Continuous Working Pressure : 60 Psi
Power : 120W
Power Connection : 12V Car Cigarettes Lighter Socket
Weight : 1.5kg
Dimension : 470 x 133 x 150mm
Accessories : 12V Car Cigarette Charger, 2 Hose Adaptors (for ball and inatable),
Vacuum Cleaner with Crevice Nozzle, Upholstery Brush and Soft Tube
Plug the 12V cig charger into the car cig
charger socket.
Connect the inator hose to the tire
valve stem.
Press“II” to start the inator and keep and
eye on the pressure gauge.
Press“O” to stop operating the inator
when the desired pressure is achieved.
1.
2.
3.
4.
OPERATION INSTRUCTION (TIRE INFLATOR)
4
TIREINFLATORTIF4.0
TIREINFLATORTIF4.0
Plug the 12V power plug into the power
socket.
Press“I” to start operating vacuum cleaner.
Cleaning Vacuum Cleaner
•
•
•1.
2.
3.
Turn o the vacuum switch and
disconnect from the power source
before cleaning the vacuum.
Press the opening dust compartment
button, pull dust compartment gently to
remove the lter from appliance.
Clean the lter plate and make sure it is
dried before installing. Install the lter
plate back after cleaning.
OPERATION INSTRUCTION (VACUUM CLEANER)
5
TIREINFLATOR TIF 4.0
TIREINFLATORTIF4.0
Designed and engineered by Blaupunkt Competence Centre 1 571 19 002 34 01
