BLACKHAWK! PCI560 User manual
4 1
Installation Requirements
• Personal computer with at least one free PCI Slot.
• Windows® 2000/XP/Vista Operating Systems (32 or 64-bit versions).
• Texas Instruments Code Composer Studio version 2.2†or later.
• CD ROM Drive.
3 42 75 61 8 9
QUICK
START
GUIDE
Blackhawk™
PCI560
JTAG
Emulator (PCI560)
Inventory of Items Included
1. Blackhawk PCI560 PC Board.
2. XDS560 Rev D JTAG cable.
3. 20e_cTI-14t_TI Pin Converter
4. 20e_cTI-20t_ARM Pin Converter
5. 20e_cTI-60t_TI Pin Converter
6. Installation CD ROM.
7. Warranty and Product Registration
Card.
8. Quick Start Guide.
9. Low-Profile PCI Bracket
Other Items Required
1. Target Board System—a self-
powered board with a TI DSP and
compatible JTAG header connec-
tion conforming to IEEE 1149.1
Standard.
2. Copy of Code Composer
Studio Version 2.2†or later.
This equipment is designed to
be operated under the follow-
ing environmental conditions:
Temperature between 0°C –
55°C. Relative Humidity of
20% - 70% non-condensing.
Operation of the unit outside of
the above range may affect
structual and mechanical
integrity and cause permanent
damage.
Caution is necessasry to
minimize ESD (Electro-stactic
Discharge) which can damage
electronic components. Use in
a controlled environment
where ESD materials and
practices are employed is
highly recommended.
IMPORTANT
ENVIRONMENTAL
CONSIDERATIONS
4CCStudio Setup
B.) Using Create Board for CCStudio v3.1 and later
1. Run CCStudio Setup.
2. Select the “Create Board” tab and drag the “BH PCI560 Connection” to
My System on the left. This will prompt you for a connection name. You can
enter any string you want, but at a minimum, it typically includes the emulator
name and target DSP or board name (i.e. “Blackhawk PCI560—C5509”).
3. Now, highlight the new connection name you added under My System and add
the available processor(s) from the middle window to match your hardware.
4. Save your setup and start CCS.
C.) Changing an XDS560 PCI import for CCStudio v2.2-v3.0
1. Run CCStudio Setup and import a setup for the TI XDS560 PCI card that
matches your target (refer to section (A.) above for importing).
2. Highlight the board you added under My System, right click with the mouse and
choose properties.
3. Locate the Emulator Name field under board properties tab and change the
name from “XDS560 0” to “BH560PCI 0”. If you need to change other proper-
ties (GEL, DSP, etc.) , you can do that too.
4. Save CCSetup and start CCS.
A.) Importing a Pre-defined Import or Factory Board
These instructions apply to CCStudio v2.2 - v3.3, but the import dialog varies slightly be-
tween versions. Refer to the PCI560 Installation Guide if more information is needed.
1. Run CCStudio Setup. And for CCStudio v3.0 and earlier, start the “Import a
Configuration” dialog.
2. Find and select “bh-pci560 emulator” from the “Platform” pull down menu
located at the top of the middle CCSetup window or in the center of the import
dialog box (this will list the PCI560 imports).
3. You can narrow down the import options further by using the “Family” pull down
(i.e. select “C55xx“ to list all TMS320C55x device imports).
4. When you find your target, or an import close to it, highlight the entry and choose
the option to “add it to your system”.
5. If this import setup does not completely match your target, you can edit the prop-
erties manually (i.e. to add or change a GEL file).
6. When finished, save the setup and start CCStudio.
†For CCStudio v2.0 and v2.1 (only), download the XDS560 emulation driver subsystem from the TI web site:
https://www-a.ti.com/downloads/sds_support/XDS560Update.html. These files are included with CCS v2.2 and later.
A TI USCIF Update (v35.23.10.0) is necessary for CCStudio v3.2 orearlier, which is included with our
driver installations on CD ROM and Web Site.
Blackhawk
123 Gaither Drive, Mt. Laurel, NJ 08054-1701
www.blackhawk-dsp.com
Blackhawk is a registered trademark of EWA Technologies, Inc.
PCI560-QS-03
2 3
1Emulation Driver Installation
1. Power down your computer and open the case to gain access to an
available PCI slot.
2. Install the PCI560 board (see Figure 2) making sure to secure the PCI
end plate to the case. If your PC requires a low profile bracket, one has
been included to easily replace the standard (taller) bracket. Please refer
to the section in the Installation Guide for detailed instructions for replac-
ing the bracket.
3. Attach the JTAG cable assembly to the corresponding “D” connector of
the PCI560 (see Figure 1).
4. Close the computer case and boot the machine.
5. Follow the Plug-N-Play Found New Hardware Wizard to install device
drivers (see section 3 on PCI PnP Installation).
FIGURE 2 - PCI560 Installation
Standard
PCI
Bracket
The PCI560 JTAG Emulator shipped with its emulation drivers on CD ROM
media that are needed by Windows and CCStudio for operation.
1. Insert the Emulation Driver CDROM into your PC’s CDROM drive.
2. Follow the installation wizard, and when done, you are ready to install
the emulator hardware.
If the installation executable fails to start automatically, run X:\Setup\Setup.exe,
where [X] is the drive letter for your CD ROM drive.
2Hardware Installation
WARNING
Be careful to connect interface cables with the correct orientation. Pin 1 on the
interface cable should match Pin 1 on the DSP system connector. The JTAG
cable assembly features a "keyed" connector to minimize the chance of error.
Do not force cables into position. Forcing them may damage the cables or
the interconnected boards and systems.
PCI PnP Installation 3
Windows 2000/XP/Vista
1. Make sure the PCI560 Emulator is installed.
2. Boot the computer and log in.
3. Follow the Windows “Found New Hardware” wizard prompts.
4. You can select the “automatic” option for locating drivers.
5. If the automatic option did not locate them, you can manually specify the
location. These files were installed to your system during the Emulation
Driver Installation - section 1. The typical location for these files is
folder: C:\CCStudio_v3.3\blackhawk\drivers.1 , where
<C:\CCStudio_v3.3> is the location selected in section 1.
6. When completed, the Blackhawk Control Panel and Windows Device
Manager will show the device. The Blackhawk Control Panel can be
activated from its icon, located in the Windows Control Panel Dialog Box.
7. Now follow the Code Composer Studio Setup in section 4.
“D” connector
Low-profile PCI Bracket
FIGURE 1 - PCI560 with XDS560 JTAG Cable and Pod Assembly
