Vehicles Tracking Device

BI-530P TREK

Operating manual

Version 2020.06.1

www.bitrek.com.ua

[email protected].ua

+380 44 507 02 07

Introduction...................................................................................................... 3

Safety requirements within installation and maintenance of “BI-530P TREK”

tracking device .............................................................................................. 3

Transportation and storage ............................................................................. 3

Warranty ...................................................................................................... 3

Device ............................................................................................................. 3

Purpose ........................................................................................................ 3

Operation principles ....................................................................................... 4

Technical specifications................................................................................... 5

Supply package ............................................................................................. 6

Preparation for operation, commissioning ............................................................. 6

SIM-card installation ...................................................................................... 6

Connectors for power supply and peripherals..................................................... 7

Assembly, commissioning ................................................................................... 9

Assembly recommendations ............................................................................ 9

Electrical connections ..................................................................................... 9

Device to computer connection ........................................................................ 9

Description of indication ............................................................................... 10

Adjustment of “BI-530P TREK” device ................................................................ 11

Basic information ......................................................................................... 11

List of information commands to operate the device ......................................... 11

List of control commands to operate the device ............................................... 14

Basic configuration....................................................................................... 16

Security settings.......................................................................................... 16

Adjustment of I/O elements .......................................................................... 17

Notifications ................................................................................................ 20

Roaming options .......................................................................................... 21

Configuring the device to work with the RFID reader by RCS SOVA protocol on

RS-485 bus ................................................................................................. 21

Configuring the device for working with fuel level sensors by RS-485 ................. 22

Setting the device for temperature sensors ..................................................... 22

Setting the device for electronic keys ............................................................. 23

Configuring the device to work with CAN-LOG ................................................. 24

Configuring the device for working with fuel level sensors via RS-232 ................ 24

Setting the device to work with tires pressure sensors via RS-232 ..................... 25

Appendix 1 –Device parameters ....................................................................... 26

Appendix 2 –List of I/O elements...................................................................... 35

Appendix 3 –List of CAN-LOG I/O elements........................................................ 39

Appendix 4 –Selecting a discrete output control source ....................................... 43

Appendix 5 –List of TPMS I/O elements ............................................................. 44

www.bitrek.com.ua

[email protected].ua

+380 44 507 02 07

Introduction

Safety requirements within installation and maintenance

of “BI-530P TREK”tracking device

Technical staff involved in installation of tracking device is in charge

for compliance with security measures, as well as the staff responsible for

equipment at the work area.

To prevent damage, device shall be stored in a shock-proof

packaging. Before using, place the device so that you can see the

indication display elements. Before connecting/disconnecting the power

socket and inputs/outputs, turn off the power supply.

Transportation and storage

Transportation of tracking device in the transport packaging of the

manufacturer is allowed by all kinds of enclosed land and sea transport

(rail cars, containers, vehicles of closed type, bilges, etc.). Transportation

in pressurized heated compartments of the aircraft is allowed.

Transportation and storage shall comply with requirements

specified by the signs on the packages.

Warranty

Warranty period of operation of tracking device is 12 months from

the date of sale of the device.

The warranty obligations of the manufacturer are valid if the

consumer observes the requirements of this manual. In case of their

violation, or at any mechanical or electrical damages caused by factors

other than specified by this manual, the warranty shall be considered null

and void.

Device

Purpose

Tracking device “BI-530P TREK”shall be applied to solve issues of

navigation, remote control and monitoring of a vehicle or other remote

object.

The tracking device is designed to be installed on any mobile or

remote stationary object in order to:

determine the geographical coordinates, speed and direction

of movement;

ensure data collection from external devices;

control actuating mechanisms;

transmit data to the control dispatching center.

www.bitrek.com.ua

[email protected].ua

+380 44 507 02 07

Standart data communication channel is the network of mobile

communication operator with GSM standard 900/1800 or GSM

850/900/1800/1900. LBS, GPS or LBS, GPS/GLONASS are used to

determine the coordinates.

Device shall be installed out of reach of the driver.

The device is not designed to run on water transport.

Operation principles

In real time mode the tracking device:

determines location and movement parameters of the object

(time, geographical coordinates, speed, and direction).

collects and processes information from the analog, digital,

and discrete sensors

ensures control over actuating mechanisms upon command

from the control dispatching panel.

Received data are recorded and stored in an internal log, which is

implemented on microchip of nonvolatile memory. At specified intervals

or according to event entries from this log are sent to the server of the

dispatcher via the GSM network. Exchange of information is carried out

by means of GPRS and SMS channels.

Operation of the device in “on-line”mode is possible only at

presence of the network coverage. Outside GSM network coverage, the

tracking unit operates in the “black box”mode, i.e., it records all

information in the nonvolatile memory and sends it when the vehicle is

entering a GSM coverage area.

www.bitrek.com.ua

[email protected].ua

+380 44 507 02 07

Technical specifications

Table 1 –Technical specifications

No.

Name

Technical

specification

Data transmission standard

GSM 900/1800 or GSM

850/900/1800/1900

GSM network communication channel

GPRS, SMS

SIM-cards quantity

SIM-card format

Micro-SIM

GPRS class

Type of navigation system

LBS, GPS or LBS,

GPS/GLONASS

GSM and GPS antennas

Internal

Auxiliary digital interfaces

RS-485, RS-232, 1-Wire

Motion sensor

Accelerometer

Number of discrete inputs with active

“0”

Number of discrete outputs

Type of power supply

Direct current

Accumulator battery capacity

130 mAh

Supply voltage

From 6 V to 36 V

Average consumption current (12 V)

60 mA

Range of voltages of discrete inputs

From 0 V to 40 V

Type of discrete outputs

Open collector

Maximum current of discrete outputs

0.5 А

Number of analog inputs

Range of voltage of analog inputs

From 0 V to 27 V

Volume of nonvolatile memory

2 MB (or 50 000

records)

Operating temperature

From -30 °C to +80 °C

Relative humidity of air

(80±15) %

Dimensions (L x W x H)

(96 x 77 x 14) mm

Weight of the device

75 g

Housing protection class

IP54

Housing material

Plastic ABS UL94V0

Design of tracking device

Appearance and dimensions of the tracking device “BI-530P TREK”are

shown in Figure 1.

www.bitrek.com.ua

[email protected].ua

+380 44 507 02 07

Figure 1 –Appearance and design of the device.

Supply package

The tracking device “BI-530P TREK”is provided with the following set:

1. Tracking device “BI-530P TREK”–1 piece.

2. Connection cable –1 piece.

3. Technical data sheet –1 piece.

4. Warranty card –1 piece.

5. Package box –1 piece.

Preparation for operation, commissioning

SIM-card installation

To operate in GSM network device shall contain installed SIM-card of

Micro-SIM format. Phone book of SIM-card shall remain empty, PIN-code

shall be removed (use of SIM-card with PIN-code can be allowed subject

to entering the PIN-code to the device settings).

To install the SIM-card disconnect the power socket from the

device, remove the side cover and install the SIM-card into the slot (see

Figure 2).

www.bitrek.com.ua

[email protected].ua

+380 44 507 02 07

Figure 2 –Installation of SIM-card into the device.

Connectors for power supply and peripherals

The rear panel of the tracking device contains sockets for

connecting cables. Connecting cables in turn have outlets for power,

analog, digital, discrete sensors and actuating mechanisms. Location of

sockets and numbering of contacts are shown in Figure 3.

Marking of connector pins for power supply, sensors and

peripherals is shown in Table 2.

www.bitrek.com.ua

[email protected].ua

+380 44 507 02 07

Figure 3 –Location of sockets and numbering of contact elements.

Table 2 –Designation of contact elements

No.

Color

Contact

name

Signal type

Contact assignment

Black

GND

Power supply

Common cable (ground)

Brown

DAT_low 1

Input

Digital input with active

“0”No. 1

Black

GND

Power supply

Common cable (ground)

White

AN in 1

Input

Analogue input No. 1

Violet

Out 1

Output

Digital output No. 1

Orange

RS-485 A

Input/output

Signal “А” RS-485

Red/

Black

1-Wire

PWR

Power supply

1-Wire power

Red

+ V in

Power supply

“+”onboard power supply

(rated voltage 12 V or 24

Blue

DAT_low 2

Input

Digital input with active

“0”No. 2

Yellow

RS-232 TX

Input/output

Signal “TX” RS-232

Pink

RS-232 RX

Input/output

Signal “RX” RS-232

Grey

AN in 2

Input

Analogue input No. 2

Green

RS-485 B

Input/output

Signal “B”RS-485

Yellow/

Green

1-Wire

Input/output

1-Wire data

www.bitrek.com.ua

[email protected].ua

+380 44 507 02 07

Assembly, commissioning

Assembly recommendations

Zone of installation of tracking device shall enable the connecting of

the pin to it and disable the possibility of accidental damage to the

device, moisture, impact of high temperature. Recommended location for

installation in the vehicle is an empty space under the dashboard inside

the vehicle; in addition, the device shall be placed in a way ensuring the

upper side with LEDs to face up.

The body of the device contains grooves for easy fastening with

plastic ties.

Electrical connections

Power supply wires are laid through the maintenance holes in the

body of the vehicle from the regular battery location to the place of

installation of the tracking device. Power wires are connected to the

corresponding battery terminals.

Carrying out welding work during the repair of the vehicle

necessarily requires disabling of power socket and peripherals.

The active state for discrete input with active “0”is a connection of

this input with the negative of the power (ground). The passive state for

this input is the lack of connection (“in the air”input).

Analog input voltage can range from 0 V to 27 V.

The discrete output of the device are made according to the

scheme such as “Open collector”. The load shall be connected to the gap

between the discrete output and “+”power of the on-board network.

When activated, the output gets ground switching. Maximum current of

the discrete output load shall not exceed 0.5 A. If it is needed to switch

higher currents, connect digital outputs via additional relay.

The voltage on the discrete inputs shall not exceed 40 V.

The voltage on the analog inputs shall not exceed 27 V.

The power supply voltage of the device shall not exceed 36 V.

Otherwise, the device may be disabled.

Device to computer connection

The tracking device can be connected to a PC, in order to configure

the device, as well as to perform maintenance works. For this purpose,

the device is equipped with a service UART output. To connect to a

computer, use an additional USB-UART converter, which can be

purchased from a dealer for an additional fee.

UART service output socket is located on the board of the device

next to the SIM-card slot. To access the socket, remove the side cover of

www.bitrek.com.ua

[email protected].ua

+380 44 507 02 07

the device. Procedure of connection of USB-UART converter cable is

shown in Figure 4.

Connect the cable of USB-UART converter to the tracking device so

that the arrow on the cable socket to be located closer to the SIM-card

slot (see Figure 4).

To work with the USB-UART converter, install the appropriate

device drivers. They can be downloaded from the official website:

http://www.ftdichip.com

To exchange data with the device, use a terminal program. Settings

of the terminal: speed –115200 bit/second, data bit –8, stop bit –1, no

parity check, no flow control.

Figure 4 –Connection of the cable of USB-UART converter to the

device “BI-530P TREK”.

Once connected, the device will transmit data about its state to the

terminal. In addition, the user is able to use a terminal program to send

commands to a device and receive response to them. Send preliminary to

device the password to access the terminal in the following format:

TPASS: password;

, where password is a password for access to the device terminal (default

value is 11111).

Lifetime of access password after sending is 60 seconds.

After this time, re-send the password to exchange data with the device.

Description of indication

Top panel of the tracking device contains two LEDs that indicate the

current status of the device.

LED “STATUS”(red) is on for 0.5 seconds and is off for 0.5 seconds

when GPRS connection is inactive; is constantly on when GPRS

Table of contents

Other BITREK GPS manuals

BITREK

BITREK BI-868 TREK HW2 User manual

BITREK

BITREK BI-520L TREK User manual

BITREK

BITREK BI 810 TREK User manual

BITREK

BITREK BI 530R TREK User manual

BITREK

BITREK BI 868 TREK User manual

BITREK

BITREK BI-530C TREK User manual

BITREK

BITREK BI-820OBD TREK User manual

BITREK

BITREK BI-810 TREK User manual

BITREK

BITREK BI-910 TREK User manual

BITREK

BITREK BI 820 TREK OBD User manual

Popular GPS manuals by other brands

Raven

Raven Cruizer II Manual

Hama

Hama 53118 Operating instruction

Garmin

Garmin SOUNDER 125 Owner's manual & reference

Garmin

Garmin DEZL 580 owner's manual

Jigabot

Jigabot EX quick start guide

Pointer

Pointer Cellocator CelloTrack XT LTE overview

Queclink

Queclink GV55LITE user manual

Voxson

Voxson Voxtrack GPS500 Quick user guide

Garmin

Garmin ECHOMAP PLUS owner's manual

Starcom Systems

Starcom Systems Kylos Compact user guide

Garmin

Garmin 15 H Series Technical specifications

Cobra

Cobra Marine MC 600Ci owner's manual

Cellocator

Cellocator CelloTrack T installation guide

Enfora

Enfora Mini-MT GSM2228UG001 user guide

Magellan

Magellan eXplorist 100 Reference manual

LTE

LTE G50B user manual

Garmin

Garmin DEZL OTR500 owner's manual

SkyGolf

SkyGolf SkyCaddie SG1 user guide
