Bissell SMARTCLEAN User manual

Movement

Key Pressed/

Control Key Action

FORWARD Vacuum will move forward until it encounters and obstacle and then it will

stop or it will move forward until another command is given.

LEFT Turn left. Pressing and holding the button makes it turn left continuously.

RIGHT Turn right. Pressing and holding the button makes it turn right continuously.

BACKWRD

Vacuum will move backward for 6 inches and then stop.

NOTE: Vacuum does NOT have cliff sensors on the back of the unit to prevent it

from falling down stairs when moving in reverse.

STOP Stop the unit.

Suction Power

Key Pressed/

Control Key Action

Adjust suction level: High

Adjust suction level: Low

Getting to Know the Remote Control

SMARTCLEAN® ROBOT

REMOTE INSTRUCTIONS

For How-To

videos, go to

www.BISSELL.com

Sections marked

with this video

icon have more

information online.

REMOTE CONTROL

FORWARD

TURN RIGHT

STOP

BACKWARDS

TURN

LEFT

AUTO

DOCKING

MAX

TIME

MODE SELECTION

SUCTION STRENGTH

SELECTION

TIME SELECTION

MINUTES

NOTE: Remote only

works when cleaner

is undocked and

unplugged.

Press and hold in tab on the battery tray

and pull outward with the tray to remove

Remove old battery from the tray and

replace with a new battery. (Uses one

CR2025 battery).

Replace the battery

tray in to the remote

Changing the Battery in the Remote Control

NOTE: Be sure to remove the

insulation sheet before using

your remote. It will be sticking

out of the back of the battery

door.

NOTE: For additional information, please refer to the SmartClean Robotic Vacuum User Guide.

Cleaning Mode

Key Pressed/

Control Key Action

AUTO Set the unit in auto clean mode. This mode will cycle through Spiral, Along

the Wall following, “Z” formation and Random modes.

SPIRAL Vacuum will work in circles until it encounters an obstacle. Once the unit

encounters an obstacle, it will transition to AUTO mode.

RANDOM Vacuum will move randomly around the room.

ALONG

THE WALL

Vacuum will clean along walls and edges.

Timer

Key Pressed/

Control Key Action

MAX Product continues to clean until the battery becomes low. Then returns to

its docking station.

60 Product cleans for 60 minutes then returns to its docking station.

45 Product cleans for 45 minutes then returns to its docking station.

30 Product cleans for 30 minutes then returns to its docking station.

DOCKING Sends the vacuum to begin looking for its docking station to recharge.

160-8475 rev 11/15 RevD

Troubleshooting

Remote

control

doesn’t work

Check the remote battery. Check if insulation sheet is still in the

remote. Remove by pulling the tab.

If not, replace with a new CR2025

battery per the instructions above.

The robot is off Turn the power switch on the robotic

vacuum to the ON position
