Bissell CLEANVIEW User manual

CLEANVIEW® CONNECT

ROBOTIC VACUUM

MODEL 2908N

Product View....................2

Setup .........................3-4

Operations ....................4-5

Maintenance & Care ...........5-8

Troubleshooting .................8

2BISSELL.eu

What’s in the Box?

Additional

Pleated and

Foam Filters

Additional

Edge Cleaning

Brushes

B I S S E L L®

CleanView®

Connect

Docking

Station

Power

Adapter

(charger)

Cleaning

Tool

Product View

WARNING

Do not plug in your robot until you are familiar with all instructions and operating procedures.

1. Power Switch

2. Start/Pause Button

3. Contact Points

(for automatic charging)

4. Cliff Sensors

5. Bumper

6. Edge Cleaning Brushes

7. Front Wheel

8. Rear Wheels

9. Dirt Bin Release Button

10. Dirt Bin (filters inside)

11. Brush Roll

12. DC Port

13. Removable Battery

14. LED Light Ring

3 3

8 8

BISSELL.eu

Setting Up Your Robot

Place the back of Docking Station

firmly against a wall. Ensure there is at

least 1 meter to one side, 1 meter to the

opposing side and no obstructions in

front of the Docking Station.

Insert the Docking Station Power Adapter

plug into the port on the side of the Docking

Station, then plug the other end into the wall

outlet. Turn the robot’s Power Switch ON

and put on the Docking Station. The first

charge will take 4-5 hours.

4 5

Connecting to the App

In the App or Google

Play Store search

“BISSELL Connect” and

download.

From the app, select “Add Product”. Then choose

your product from the menu.

Note: Be sure the device is near your WiFi router

and the robot is fully charged or in the dock

during the pairing process.

Once downloaded, open

the app and sign in or

create a new login.

Make sure you’re near

your WiFi router before

turning the robot ON (I).

Downloading the BISSELL Connect App means you can change your robot’s cleaning

mode, start, pause, or stop your robot, schedule cleanings, view notifications, track your

cleaning history, and troubleshoot all from the palm of your hand.

To put the robot in pairing mode,

press and hold the Start/Pause

Button for 5 seconds until you

hear a single beep.

80 inches

(2m)

40 inches

(1m)

40 inches

(1m)

40 inches

(1m)

40 inches

(1m)

40 inches

(1m)

4BISSELL.eu

1 32

Manual Cleaning

Automatic Cleaning

Press the Power Switch

to the ON (I) position.

To return the robot to

the dock, press the

Start/Pause Button

twice. The button will

flash white as it finds its

way back to the dock.

Press the Start/Pause

Button on the top of the

robot to start cleaning.

When finished, press the

Start/Pause Button again

to stop the robot.

You can designate a day and time for your robot to run automatically using the BISSELL

Connect App. Once the robot is connected to the app, go to the Schedule tab and follow

the on-screen prompts.

Connecting to the App (cont.)

6 7

The QR code needed for setup can be

found by removing the Dirt Bin and

turning the robot over.

Once you locate and scan the QR

code, follow the instructions in the app

to pair.

Scan

Code

BISSELL.eu

4 6

Cleaning the Dirt Bin

Press the button on top

of the Dirt Bin and pull

to remove.

Use the Cleaning Tool

to brush the filter cover

and filters. Do not wash

the filters.

Open the filter door by

pulling both sides apart.

Empty debris from the

Dirt Bin.

With filters removed,

rinse the Dirt Bin with

tap water. Ensure Dirt

Bin is completely dry

before reinstalling. It is

not necessary to wash

every time.

Do not machine wash

the Dirt Bin.

Once clean, reinstall the

filters and filter cover,

close and push back

into the machine.

Remove the filter cover,

then the Foam and

Pleated Filters.

Activating Low Power Mode

Press and hold the Start/Pause Button for

15 seconds until you hear 2 beeps. Release

the button to activate low power mode.

Send the robot back to the dock.

15s

6BISSELL.eu

A Phillips-head screwdriver is required for this task.

1 2

Use a Phillips-head screwdriver to

remove the screw. Pull up on the base

of the brush.

Push the brush directly onto the

holder. Replace the screws with a

Phillips-head screwdriver.

Replacing the Edge Cleaning Brushes

NOTE: After being used for a period of time, the Edge Cleaning Brushes need to be cleaned

to work more eectively. Once removed, the Edge Cleaning Brushes can be rinsed or soaked

in water. Be sure they are completely dry before returning to the machine.

Clean the Brush Roll

with the Cleaning Tool.

Replace the Brush Roll and

brush guard.

NOTE: The Brush Roll has

two different end pieces.

Ensure the square-shaped

end piece is inserted into the

square-shaped port.

Pinch the tabs on the

brush guard inward and

pull to remove.

Lift to remove the

Brush Roll.

Cleaning the Brush Roll

WARNING

To reduce the risk of electric shock, turn Power Switch OFF and disconnect plug from electrical outlet

before performing maintenance or troubleshooting checks.

BISSELL.eu

3 4

Replacing the Battery

DO NOT REMOVE THE PLASTIC SHRINK

SLEEVE FROM THE BATTERY PACK.

Install the

new battery

into battery

compartment.

Use a

Phillips-head

screwdriver

to replace

the battery

cover and two

screws.

A Phillips-head screwdriver is

required for this task.

Turn the

Power Switch

OFF (0). Use

a Phillips-head

screwdriver

to remove the

two screws

and battery

cover.

Remove the old battery from battery

compartment. Note the tape location

that covers over the connectors.

Remove the tape by unwrapping, then

separate the connectors.

Connect the new battery. Wrap

the tape to the original location to

completely cover the connectors and

terminals.

After repeated use, debris can accumulate on the

sensors of the robot and the robot’s performance

could be affected.

To ensure the best efficiency, the sensors should

be cleaned off periodically by brushing any debris

from them.

Before cleaning the sensors, ensure the Power

Switch on the robot is in the OFF (0) position.

Cleaning the Sensors

WARNING

To reduce the risk of electric shock, turn Power Switch OFF and disconnect plug from electrical outlet

before performing maintenance or troubleshooting checks.

Storing Your Robot

Status and Error Notiﬁcations

Status Button Light State Light Ring Sound

Power ON Pulse Once > Blink > On Pulse Once Activation Sound

Cleaning Blink > Fade In > On Pulse Once > Fade In > 30 seconds > Fade Out Activation Sound

Charging Breathing Pulse Once > Breathing for 30 seconds > Off 1 Beep

Pairing Mode Blink Off 1 Beep

Paired On Solid for 5 Seconds > Fade Out 3 Beeps

Low Battery Blinking White Off 2 Beeps

Error Button Light State Sound Remedies

Robot is Trapped, Lifted, or

Cli Sensors are Dirty

Flashing Red 1 Beep Place robot on floor away from objects and

resume cleaning. If error persists, use a dry cloth

to clean the 3 cliff sensors on the bottom of the

robot.

Front Caster Wheel Sensor is Blocked Flashing Red 3 Beeps Remove Front Caster Wheel assembly, clear

debris from assembly housing, reinstall wheel.

Left or Right Wheel is Stuck Flashing Red > Solid Red 1 Beep Turn robot OFF and remove hair and debris from

wheels.

Edge Cleaning Brushes are Stuck Flashing Red > Solid Red 2 Beeps Turn OFF the robot and remove hair and debris

from Edge Cleaning Brushes.

Brush Roll is Stuck Flashing Red > Solid Red 3 Beeps Turn OFF the robot and remove hair and debris

from Brush Roll.

Bumper is Stuck or Robot is Trapped

Flashing White 2 Beeps Turn OFF the robot and tap the Bumper several

times to release any debris that may have

accumulated.

Error Notifications

Status Notifications

Store your robotic vacuum cleaner safely indoors where it is unlikely to be damaged.

Part Number 1625231 07/20
