tellus surface hpq
RGBWquad
USER MANUAL
BEDIENUNGSANLEITUNG
www.biontechnologies.com
tellus surface hpq
RGBWquad
USER MANUAL
Safety Instructions
Devices must be installed by qualified personnel in compliance
with all pertaining regulations.
Always refer to the technical parameters in the data sheet. All items are subject to technical modification.
Refer to the attached User Manual as a basis for correct use.
Consult circuit diagram for correct wiring.
Note! Before attempting any work, make sure device is separated from main power. Protect device from moisture.
Make sure protection against line voltage shock is provided during installation.
We recommend securing the installation by RCD circuit breakers.
Note that adjacent parts or devices must be temperature proof up to 90°C.
Do not operate the fixture with inductive consumers (fluorescent lamps, gas discharge lamps, ventilators etc.) in the same
electric circuit. Activation of inductive consumers can cause damage to the operating device.
Do not place heat insulation material on the fixture.
Mind the operating temperatures of the fixture according to the technical data sheet.
Before drilling the mounting holes, take precautions not to harm or damage any power lines.
Do not solder cable strands. Use cable strand sleeves instead.
Note and mind voltage label on the device.
Make sure flawless electrical connectivity is provided.
Connecting the lamp to the powered-up device can cause damage to the lamp! (voids product warranty!)
No modification allowed. No liability will be assumed in case of damage incurred by alteration, improper use or faulty installation.
2 | www.biontechnologies.com
Scope of delivery
Check completeness of supplied device immediately after receipt.
In delivery included:
1x User manual
1x Luminaire Bion Technologies tellus surface m
6x Lighting connector
If you detect any transportation damage or differencies between specified packing contents and your unpacked delivery, please contact
your dealer immediately.
www.biontechnologies.com | 3
Technical Data
Dimensions 115 mm x 100 mm [W x H]
4.53 in x 3.94 in [W x H]
Standard Unit Lengths 352 mm, 657 mm, 962 mm, 1267 mm
13.86 in, 25.87 in, 37.88 in, 49.89 in
Fixture Typ
RGBWquad
Color Temperatures W-Channel 4000 K, 6500 K
Beam Angles 10°, 22°, 34°, 60°, 8° x 31°
10° x 40°, 12° x 60°, 12° x 90°, 30° x 60°, 30° x 58° (Tilt in C0-plane: -14°), 30°
x 11° (Tilt in C0-plane: -14°)
Luminous Flux 352 mm (13.86 in): 1244 lm
657 mm (25.87 in): 2488 lm
962 mm (37.88 in): 3732 lm
1267 mm (49.89 in): 4976 lm
Light Source 352 mm (13.86 in): 4 LEDs
657 mm (25.87 in): 8 LEDs
962 mm (37.88 in): 12 LEDs
1267 mm (49.89 in): 16 LEDs
Color Rendering Index Ra >= 80
Antiglare Honeycomb
LED-Binning
Control DMX, IOT
Input Voltage Power supply: internal | 100 - 240, 277 VAC (50 - 60 Hz) | 127 - 431 VDC
Power Consumption 352 mm (13.86 in): Max. 30 W
657 mm (25.87 in): Max. 60 W
962 mm (37.88 in): Max. 90 W
1267 mm (49.89 in): Max. 120 W
Power Factor Correction > 0,98 -> 115 VAC @ max. Output
> 0,95 -> 230 VAC @ max. Output
> 0,91 -> 277 VAC @ max. Output
Protection Class II
Storage Temperatur -40 °C / +80 °C | -40 °F / +176 °F
Operating Temperature -40 °C / +40 °C | -40 °F / +104 °F
Start-up Temperature -25 °C / +40 °C | -13 °F / +104 °F
Lumen Maintenance [L70] 65’000 h @ 25 °C (77 °F) | 40‘000 h @ 40 °C (104 °F)
LED-Class Class 2 LED product
Housing Extruded aluminium profile
4 | www.biontechnologies.com
Housing Color(s)
DB703 pow
dercoated
White powd
ercoated
Black powd
ercoated
Custom
Color RAL
Lens Tempered safety glass
Frame Aluminium
Weight 352 mm (13.86 in): 6 kg (13.23 lbs)
657 mm (25.87 in): 9 kg (19.84 lbs)
962 mm (37.88 in): 12 kg (26.46 lbs)
1267 mm (49.89 in): 15 kg (33.07 lbs)
Ingress Protection IP67
Environment
indoor outdoor
Impact Protection IK09
Certification
Engineering Drawing
www.biontechnologies.com | 5
Commissioning
1. Wiring DMX / CE
The luminaire connection must be made outside of the housing via junction box supplied by others.
Please remove the any warning label on light emitting surface of the luminaire before operating the fixture.
2. Wiring DMX / cETLus
The luminaire connection must be made outside of the housing via junction box supplied by others.
Please remove the any warning label on light emitting surface of the luminaire before operating the fixture.
6 | www.biontechnologies.com
3. Wiring 0 - 10 V / CE
The luminaire connection must be made outside of the housing via junction box supplied by others.
Please remove the any warning label on light emitting surface of the luminaire before operating the fixture.
4. Wiring 0 - 10 V / cETLus
The luminaire connection must be made outside of the housing via junction box supplied by others.
Please remove the any warning label on light emitting surface of the luminaire before operating the fixture.
www.biontechnologies.com | 7
5. Wiring IoT / CE
The luminaire connection must be made outside of the housing via junction box supplied by others.
Please remove the any warning label on light emitting surface of the luminaire before operating the fixture.
6. Wiring IoT / cETLus
The luminaire connection must be made outside of the housing via junction box supplied by others.
Please remove the any warning label on light emitting surface of the luminaire before operating the fixture.
8 | www.biontechnologies.com
Operation
1. IoT - App and Password
Password in the delivery condition: 00000000
The BIONcontrol app is available from the Apple App Store or Google Play.
Maintenance
Clean device from dirt and residue regularly. Use solvent-free cleaning agents only and do not employ aggressive chemicals or high
pressure cleaner. Operate device only after complete drying.
Conformity
Our devices are certified according to the following European and American Standards:
NOTE
This equipment has been tested and found to comply with the limits for a class a digital device, pursuant to part 15 of the FCC rules.
These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a
commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in
accordance with the instruction manual, may cause harmful interference to radio communications. Operation of these equipment in a
residental area is likely to cause harmful interference in which case the user will be required to correct the interference at his own
expense.
„This Class (B) digital apparatus complies with Canadian ICES-003”
www.biontechnologies.com | 9
Manufacturer
Bion Technologies GmbH
Lindberghstrasse 15
86343 Koenigsbrunn
Tel: +49 (0)8231/95787-0
Fax: +49 (0)8231/95787-29
www.biontechnologies.com
YouTube: http://www.youtube.com/BIONTECHNOLOGIES
All rights reserved / Subject to change / Specifications may change without notice
