Beyerdynamic TG-X 60 Installation and operation manual

APPLICATIONS

The TG-X 60/61 is designed for close miking vocals especially

in Pop, Soul and Jazz. Due to the proximity effect and the

strong bass accentuation the TG-X 60/61 features a powerful

yet soft and transparent sound in the highs. The hypercardioid

polar pattern ensures a very high gain before feedback.

The TG-X 60/61 can be used as handheld or on a stand

with the supplied microphone clamp.

FEATURES

• Hypercardioid polar pattern

• High volume before feedback

• Vocal tailored frequency response

• Rugged construction to withstand touring damage

• Shock absorbing rubber ring

• Structure borne noise attenuation

• TG-X 61 switched version

SUPPLIED ACCESSORIES

MKV 8 Microphone clamp with 3/8" internal thread,

for shaft diameters of 22 - 32 mm. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Order # 407.216

OPTIONAL ACCESSORIES

BMC 05 FM BK Standard XLR-XLR microphone cable, length 5 m . . . . . . . . . . . . . . . . . . . . . . . . Order # 434.787

BMC 10 FM BK Standard XLR-XLR microphone cable, length 10 m . . . . . . . . . . . . . . . . . . . . . . . Order # 434.795

GST 500 Microphone stand, 3/8", height 0.85 - 1.60 m, with telescopic G 500 boom . . . Order # 406.252

PS 60/80 Popscreen, charcoal-grey . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Order # 437.980

VERSIONS

TGX 60 Dynamic microphone, hypercardioid . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Order # 436.283

TGX 61 same as above, but with ON/OFF switch. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Order # 436.321

TG-X 60

Dynamic Microphone

Germany

Theresienstr. 8

D-74072 Heilbronn

Tel. +49 (0 )71 31 / 6 17-0

Fax +49 (0 )71 31 / 617-224

E-mail: [email protected]

Internet: www.beyerdynamic.de

United States

56 Central Ave.

Farmingdale, NY 11735

Tel. +1 (631) 293-3200

Fax +1 (631) 293-3288

E-mail: [email protected]

Internet: www.beyerdynamic.com

Great Britain

17 Albert Drive

Burgess Hill RH15 9TN

Tel. +44 (0)1444 / 258 258

Fax +44 (0)1444 / 258 444

E-mail: [email protected]

Internet: www.beyerdynamic.co.uk

FREQUENCY RESPONSE & POLAR PATTERN

This polar pattern and frequency response curve (measuring distance ± 2.5 dB) correspond to a typical production

sample for this microphone.

WIRING DIAGRAMS

Positive pressure produces positive voltage on

red lead (+).

Photos are non-contractual. Contents subject to change without notice.

Frequency response ± 2.5 dB 0 dB 3 mV/Pa TG-X 60

TECHNICAL SPECIFICATIONS

Transducer type . . . . . . . . . . . . . . . . . . . . . . Dynamic

Operating principle . . . . . . . . . . . . . . . . . . . Pressure gradient

Frequency response

Close miking . . . . . . . . . . . . . . . . . . . . . . 25 - 18,000 Hz

Distant miking . . . . . . . . . . . . . . . . . . . . 90 - 16,000 Hz (measured at 1 metre)

Polar pattern . . . . . . . . . . . . . . . . . . . . . . . . Hypercardioid

Rear attenuation at 1 kHz . . . . . . . . . . . . . > 25 dB at 110°

Open circuit voltage

at 1 kHz (0 dB = 1V/Pa) . . . . . . . . . . . . . . . . 3.0 mV/Pa ± 1.5 dB = -50 dBV

Magnetic field suppression. . . . . . . . . . . . . > 20 dB at 50 Hz

Nominal output impedance . . . . . . . . . . . . 280 Ω

Load impedance . . . . . . . . . . . . . . . . . . . . . ≥1000 Ω

Diaphragm . . . . . . . . . . . . . . . . . . . . . . . . . . Macrolon®

Case/finish. . . . . . . . . . . . . . . . . . . . . . . . . . . Die casting, non-glare black mat

Connection . . . . . . . . . . . . . . . . . . . . . . . . . . 3-pin XLR male

Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . Length: 205 mm

Head diameter: 50 mm

Weight without cable . . . . . . . . . . . . . . . . . 345 g

TG-X 60

TG-X 61

E2/beyerdynamic))))) TG-X 60/61 (01.06)
