Beryl Smart BS65UK721UHD-V User manual
Please read these instructions before operating
your set and retain them for future reference.
LED COLOR TV
Model:
Operating Instruction
RWA700-H275
BS65UK721UHD-V
PRECAUTION
WARNING
Using cabinets orstands recommended bythe manufacturer ofthe television set.
Only using furniturethat can safelysupport the televisionset.
Ensuring the televisionset is notoverhanging the edgeof the supporting
furniture.
Not placing thetelevision set ontall furniture (forexample, cupboards or
bookcases)without anchoring both the furniture and the television setto a
suitable support.
Not placing thetelevisions set oncloth or othermaterials that maybe located
between the televisionset and supportingfurniture.
Educating children aboutthe dangers ofclimbing on furnitureto reach the
Televisionset or itscontrols.
Never place atelevision set inan unstable location.Atelevision set mayfall,
causing serious personalinjury or death.Many injuries,particularly tochildren,
can be avoidedby taking simpleprecautions such as:
If your existingtelevision set isbeing retained andrelocated,the same
considerations as aboveshould be applied.
IMPORTANT INFORMATION
Using cabinets orstands recommended bythe manufacturer ofthe television.
Only using furniturethat can safelysupport the television.
Ensuring the televisionis not overhangingthe edge ofthe supporting furniture.
Not placing thetelevision on tallfurniture (for example, cupboards or
Bookcases)without anchoring boththe furniture andthe television toa Suitable
Support.
Not standing thetelevisions on clothor other materialsplaced between the
television and supportingfurniture.
Educating children aboutthe dangers ofclimbing on furnitureto reach the
television or itscontrols.
If a televisionis not positionedin a sufficiently stable location,itcan be potentially
hazardous due tofalling.Many injuries,particularly to children, can beavoided
by taking simpleprecautions such as:
CAUTION
Danger of explosionif battery isincorrectly replaced.
Replace only withthe same orequivalent type.
Batteries shall notbe exposed toexcessive heat suchas sunshine, fireor the
like.
Used batteries shouldnot be throwninto the garbagecan, please leave them
at an appropriatedepot.
CAUTION
Where the MAINS plug or an appliance coupler is used as the disconnect
device, the disconnect device shall remain readily operable.
CAUTION
These servicing instructions are for use by qualified service personnel only.
To reduce the risk of electric shock, do not perform any servicing other than
that contained in the operating instructions unless you are qualified to do so.
Attention:
Motionless picture might cause permanent destruction to the display.
Be sure not to display motionless picture on the LED TV for more than
2 hours, because it would cause picture remnants to appear, which is
called "screen burns". To avoid suchpicture remnants, please decrease
the "contrast" and "brightness" of the display when displayingmotionless
picture.
While watching TV program in 4:3 size mode for a long time, there would .
be traces on the edge of the screen's left, right and center parts because
of different transmition of the light on the screen.Similar impact on the
screen will occurwhen playing DVDor connecting gamescontrol. Products
destroyed by these reasons can't be guaranteed for maintenance.
It might cause picture remnants to display electronic gamesand motionless .
picture of PC more than a period of time.To avoid sucheffect, please
decrease the "contrast" and "brightness" when displaying motionless
picture.
Place the TV on a firm and flat surface,leaving a space of at lease 10cm around
the set and30cm from thetop of theset to the wall or cabinet.Ensure the TV is
positioned close to the wall to avoid it falling when pushed.
10cm 30cm 10cm 10cm
When you turning the TV set,do not hold the top side of the TV set ,you should
hold the bottom side .
When you lifting the TV set,do not use one hand to handle it,you should lift the
TV set by two hands.
2.5 Main Menu
...................................................................................
.....................................................................................
1.3 Keys
1
CONTENTS
LED COLOR TV
1. Connection and Preparation of TV..................................................
1.1 Accessories ...........................................................................
1.2 Installation of Stand................................................................
and Interfaces................................................................
1.4 Remote Control.......................................................................
1.5 Installation of Batteries...........................................................
2. Basic Operation...........................................................................
2.2 Setting of Standby Mode..........................................................
2.4 Input
3. Technical Specification................................................................
4. Supported Signal Modes..............................................................
5. Simple Troubleshooting ...............................................................
2
2
2
3
4
5
5
5
6
18
19
20
2.1 Power ON/OFF(Optional)..........................................................5
2.6 Media ...................................................................................15
2.3 Home 6
............................................................................ 7
2 Insert thestand into thebottom socket ofthe TV.
1.Connection and Preparation of TV
1.1 Accessories
User Manual
Remote Control
Battery(UM-4/R03P/AAA)
Wall Mount Kit (Pre-assembled)(Optional)
1.2 Installation of Stand
1 Place theTV with the front panel facing downwards on the soft clothor soft
pads on adesk.
3 Insert the screws into the sockets and tighten them.
2
LED COLOR TV
(For the physical structure, please refer to the real object)
3
The design and specification takes actual
products as the standard
1.3 Keys and Interfaces
LED COLOR TV
or
or or
1. REMOTE SENSOR WINDOW
2. POWER INDICATOR
3. SPEAKER
4. MENU KEY
5. PROGRAM + KEY
6. PROGRAM - KEY
7. VOLUME + KEY
8. VOLUME - KEY
9. SOURCE KEY
10. STANDBYKEY
11. POWERPLUG INPUT
ok
or
(7keys) (1key) (5keys)
or
RJ45 VIDEO LR
AV I N
OPTICAL RF IN
(T2)
RF IN
(S2)
500mA
13V/18V---
HDMI2 HDMI1
(ARC)
USB1
5V---500mA
USB2
HDMI3 EARPHONE
LED COLOR TV
4
15. Mute: Mute sound.
3. 0~9 : Continue to press the keys to select.
2.INPUT:Chooseinput source.
MENU:Enter or exitmenu.
7.
Press one time to pause, press again to playback.
8.
4.GUIDE:
Enter GUIDE.
9.Direction/OK:Move up,down,left,right/Confiem.
10.Back:Return to theprevious interface or menu.
11.Exit:Exit currentinterface or menu.
12.Home:Enter home page.
13.Volume:Volumeup/down.
14.Channel:Change channel.
16. TXT: Enter or exit teletext.
17.SUBTITLE:USB convert videosubtitles.
18.INFO:Diaplay info inlive TV.
21.22.Contenarea:Seven button forCSP APPS.
19.BROWSER:Entering the website.
20.deezer:deezer.
2.1 Power ON/OFF(Optional)
5
1.5 Installation of Batteries
1 Open the back lid of the remote control.
2 Install two 7#(AAA)1.5V batteries.
Ensure the correct polarity of the batteries.
3 Cover the back lid.
Please take out of the batteries from the remote
control for long time of no use.
If the remote control doesn't work properly,
please carry out the following checks.
- Check the TV is turned on.
- Check the polarity of the batteries are correct.
- Check the batteries are not drained.
- Check the power supply is normal or the power cord
is correctly connected.
- Check there are no special fluorescent light or neon
light around.
LED COLOR TV
(Here is only the sketch, please in kind prevail)
2. Basic Operation
- Connect the power cord to the AC input. Insert the power cord into the
appropriate socket.
- Press the Power switch to switch on the TV, then pressPower button to
turn on the unit.
- Press thePower switch again to switch off the TV.
Note: After switch off the TV, please don t immediately re-open the power
switch ,should be delayed one minute more to re-open the power switch.
2.2 Setting of Standby Mode
- Press ( ) button to turn on the unit.
- Press ( ) button again to return the display to standby mode. The
power indicator turns red.
- Be sure not to set your TV in standby mode for a long period of time.
’
