BenQ PD Series User manual

PD Series
LCD Monitor
User Manual

2
Copyright
Copyright © 2017 by BenQ Corporation. All rights reserved. No part of this publication may
be reproduced, transmitted, transcribed, stored in a retrieval system or translated into any
language or computer language, in any form or by any means, electronic, mechanical, magnetic,
optical, chemical, manual or otherwise, without the prior written permission of BenQ
Corporation.
Disclaimer
BenQ Corporation makes no representations or warranties, either expressed or implied, with
respect to the contents hereof and specifically disclaims any warranties, merchantability or
fitness for any particular purpose. Further, BenQ Corporation reserves the right to revise this
publication and to make changes from time to time in the contents hereof without obligation of
BenQ Corporation to notify any person of such revision or changes.
The performance of flicker-free may be affected by external factors such as poor cable quality,
unstable power supply, signal interference, or poor grounding, and not limited to the above
mentioned external factors. (Applicable for flicker-free models only.)
Power Safety
• The AC plug isolates this equipment from the AC supply.
• The power supply cord serves as a power disconnect device for pluggable equipment. The
socket outlet should be installed near the equipment and be easily accessible.
• This product should be operated from the type of power indicated on the marked label. If you
are not sure of the type of power available, consult your dealer or local power company.
• An approved power cord greater or equal to H03VV-F or H05VV-F, 2G or 3G, 0.75mm2must
be used.
• For PD2710QC monitor base, the power adapter is manufactured by TPV Technology Ltd.
(ADPC20120).
• Use only the power adapter supplied with your LCD Monitor. Use of another type of power
adapter will result in malfunction and/or danger.
• Allow adequate ventilation around the adapter when using it to operate the device or charge
the battery. Do not cover the power adapter with paper or other objects that will reduce
cooling. Do not use the power adapter while it is inside a carrying case.
• Connect the power adapter to a proper power source.
• Do not attempt to service the power adapter. There are no service parts inside. Replace the
unit if it is damaged or exposed to excess moisture.
Please follow these safety instructions for best performance, and long life for your monitor.

3
Care And Cleaning
• Cleaning. Always unplug your monitor from the wall outlet before cleaning. Clean the LCD
monitor surface with a lint-free, non-abrasive cloth. Avoid using any liquid, aerosol or glass
cleaners.
• Slots and openings on the back or top of the cabinet are for ventilation. They must not be
blocked or covered. Your monitor should never be placed near or over a radiator or heat
source, or in a built-in installation unless proper ventilation is provided.
• Never push objects or spill liquid of any kind into this product.
Servicing
Do not attempt to service this product yourself, as opening or removing covers may expose
you to dangerous voltages or other risks. If any of the above mentioned misuse or other
accident such as dropping or mishandling occurs, contact qualified service personnel for
servicing.
BenQ ecoFACTS
BenQ has been dedicated to the design and development of greener product as part of its
aspiration to realize the ideal of the "Bringing Enjoyment 'N Quality to Life" corporate vision
with the ultimate goal to achieve a low-carbon society. Besides meeting international regulatory
requirement and standards pertaining to environmental management, BenQ has spared no
efforts in pushing our initiatives further to incorporate life cycle design in the aspects of
material selection, manufacturing, packaging, transportation, using and disposal of the products.
BenQ ecoFACTS label lists key eco-friendly design highlights of each product, hoping to ensure
that consumers make informed green choices at purchase. Check out BenQ's CSR Website at
http://csr.BenQ.com/ for more details on BenQ's environmental commitments and
achievements.

4
Table of Contents
Copyright ......................................................................................................................................2
Getting started .............................................................................................................................5
Getting to know your monitor ................................................................................................7
Front view.................................................................................................................................................... 7
Back view ..................................................................................................................................................... 7
Connections .................................................................................................................................................9
How to assemble your monitor hardware when working with a desktop ................ 11
How to detach the stand ....................................................................................................................... 16
Adjusting the monitor height ................................................................................................................ 17
Rotating the monitor .............................................................................................................................. 18
Viewing angle adjustment ....................................................................................................................... 19
Using the monitor wall mounting kit ................................................................................................... 20
How to assemble your monitor hardware when working with a laptop ................... 21
Getting the most from your BenQ monitor ...................................................................... 25
How to install the monitor on a new computer .............................................................................. 26
How to upgrade the monitor on an existing computer ................................................................. 27
How to install on Windows 10 system .............................................................................................. 28
How to install on Windows 8 (8.1) system .......................................................................................29
How to install on Windows 7 system ................................................................................................ 30
How to adjust your monitor ................................................................................................. 31
The control panel..................................................................................................................................... 31
Basic menu operation ............................................................................................................................. 32
Customizing the hot keys....................................................................................................................... 33
Adjusting display mode ........................................................................................................................... 34
Choosing an appropriate picture mode.............................................................................................. 34
Connecting the monitor to your MacBook series product ........................................................... 34
Connecting multiple monitors via MST (Multi-Stream Transport) .............................................. 34
Navigating the main menu ...................................................................................................... 36
Display menu ............................................................................................................................................. 37
Picture menu ............................................................................................................................................. 38
Picture Advanced menu ......................................................................................................................... 40
Audio menu ............................................................................................................................................... 42
System menu ............................................................................................................................................. 43
Troubleshooting ....................................................................................................................... 47
Frequently asked questions (FAQ) ...................................................................................................... 47
Need more help?...................................................................................................................................... 49

5Getting started
Getting started
When unpacking please check you have the following items. If any are missing or damaged,
please contact the place of purchase for a replacement.
BenQ LCD Monitor
Monitor Stand
Monitor Base
Quick Start Guide
CD-ROM
Power Cord
(Picture may differ from product supplied
for your region.)
Video Cable: DP to mini DP

6 Getting started
USB Cable: Type-C
Power Adapter (for monitor base)
Power Cord (for monitor base)
(Picture may differ from product supplied
for your region.)
• Available accessories and the pictures shown here may differ from the actual contents and the product supplied
for your region. And the package contents may subject to change without prior notice. For cables that are not
supplied with your product, you can purchase them separately.
• Consider keeping the box and packaging in storage for use in the future when you may need to transport the
monitor. The fitted foam packing is ideal for protecting the monitor during transport.
Always keep the product and accessories out of reach of small children.

7Getting to know your monitor
Getting to know your monitor
Front view
Back view
1. Power LED indicator
1
2. Control buttons
3. Power button
4. AC power switch (for monitor)
5. AC power input jack (for
monitor)
6. Cable management hole
7. HDMI socket
8. DisplayPort socket
9. Mini DisplayPort socket
10. DisplayPort output socket (for
Multi-Stream Transport, MST)
11. Headphone jack
12. Kensington lock slot
LAN
5129
2
67
8
11
10
3
4

8 Getting to know your monitor
13. Quick release button
14. Headphone jack
15. USB 3.0 ports (downstream;
connecting to USB devices)
16. LAN (Local Area Network) port
(RJ-45 connector)
17. USB Type-C port
18. DisplayPort socket
19. Kensington lock slot
20. DC power input jack (for
monitor base)
21. DC power switch (for monitor
base)
• Above diagram may vary depending on the model.
• Picture may differ from product supplied for your region.
LAN
14
15
16 15 17 18 19 21
13
20

9Getting to know your monitor
Connections
Your monitor can work with a desktop as any other monitors do. Apart from that, its base is a
powerful docking that allows a quick and easy connection with a laptop.
The following connection illustrations are for your reference only. For cables that are not
supplied with your product, you can purchase them separately.
Working with a desktop
For detailed connection methods, see page 13.
LAN
PC
Headphone/
Speakers

10 Getting to know your monitor
Connection with a laptop
For detailed connection methods, see page 13. For more information, see How to assemble
your monitor hardware when working with a laptop on page 21.
LAN
LAN
Headphone/
Speakers
LAN switch
or hub Laptop
USB
peripherals
USB
peripherals
Monitor
base
adapter
