Beko CHE 46260 User manual
en en
1
Congratulations on your choice of our product which will certainly provide you with many years
of good service.
Safety comes first!
Please read this Instruction Manual carefully. It contains important information on how to use
your new appliance. If instructions are not adhered to, you may lose your right to service at
no charge during the warranty period. Please keep this manual in a safe place and pass it on
to later users if applicable.
• Do not connect your appliance to the power supply until all packing and transit protectors
have been removed.
• if transported horizontally, leave to stand upright for at least 4 hours before switching on to
allow the system to settle.
• This appliance must only be used for its intended purpose, i.e. the storing and freezing of
edible foodstuff.
• We do not recommend use of this appliance in an unheated, cold room e.g. garage,
conservatory, annex, shed, outdoors etc., see ‘Location’.
• On delivery, check to make sure that the product is not damaged and that all the parts and
accessories are in perfect condition.
• Do not operate a damaged appliance. If in doubt, check with your dealer.
• Do not allow children to play with the appliance.
• Do not allow anyone especially childiren to sit or stand on the appliance or on the pull-out
parts.
• Do not hang on the appliance door.
• Do not dispose of the appliance by setting it on fire. Your appliance contains non CFC
substances in the insulation which are flammable.
• Please contact your local authority in your region for information on disposal methods and
facilities available.
Warning - Keep well ventilated and clear of obstructions.
Warning - Do not use mechanical devices or other means to accelerate defrosting, other
than those recommended by the manufacturer.
Warning - Do not damage the refrigerant circuit.
Warning - Do not use electrical devices inside the food storage compartments of the
appliance, unless they are of the type recommended by the manufacturer.
• Avoid touching the metal condenser wiring on the rear of the appliance because there is risk
of injury.
• In the event of a possible malfunction, disconnect the appliance from the power supply first.
• Prior to cleaning the appliance always unplug the appliance or switch off the circuit breaker.
To disconnect the power, pull the plug from the socket. Do not pull the power cable.
• Repairs to the electrical equipment may only be made by qualified experts. If the power
cable is damaged, the manufacturer or customer service must replace it in order to avoid
danger.
en en
Transport instructions
The appliance should be transported only in
an upright position.
The packing as supplied must be intact during
transportation.
After transportation in a horizontal position,
the appliance may only be operated after
standing upright for 4 hours.
The appliance must be protected against rain,
moisture and other atmospheric influences.
The manufacturer assumes no liability if safety
instructions are disregarded.
Disposal
Make the appliance unusable immediately.
Pull out the mains plug and cut the power
cable. Remove or destroy snap or latch locks
before disposing of the appliance. In this
manner you prevent children from locking
themselves in and endangering their lives.
Appliance setup
• Do not operate your appliance in a room
where the temperature is likely to fall below
10 °C at night and/or especially in winter. At
lower temperatures the appliance may not
operate, resulting in a reduction in the storage
life of the food.
• The climate class rate of your appliance is
given on the rating label located inside the
appliance. It specifies the appropriate operating
ambient temperatures as explained below.
Climatic class Ambient temperatures
SN.......................+10 °C to 32 °C
N .........................+16 °C to 32 °C
ST .......................+18 °C to 38 °C
T..........................+18 °C to 43 °C
SN-ST.................+10 °C to 38 °C
SN-T ...................+10 °C to 43 °C
Location
Only install the appliance in a dry room which
Is well ventilated.
Avoid direct sunlight or direct heat sources
such as a stove or a heater.
If this cannot be avoided, the following
minimum distances should be maintained:
Electric stoves: 3,00 cm
Heater: 3,00 cm
Cooling devices: 2,50 cm
• Ensure sufficient air circulation for your
appliance.
• Make sure that sufficient room is provided
around the appliance to ensure free air
circulation.
Fit the two plastic wall spacers supplied with
the appliance rotating 1/4 turn to the condenser
at the back of the appliance (Fig. 4).
• The appliance should be located on a smooth
surface. The two front feet can be adjusted as
required. To ensure that your appliance is
standing upright adjust the two front feet by
turning clockwise or counter-clockwise, until
the product is in firm contact with the floor.
Correct adjustment of feet avoids excessive
vibration and noise.
Electrical connections
Warning
This appliance must be grounded.
• Check whether the power type and voltage
in your region corresponds to the one stated
on the rating platel inside the appliance.
• The electrical safety of the appliance is only
assured when the grounding system in the
house is installed in accordance with
regulations.
• When installing the appliance, do not allow
it to stand on the power cable otherwise the
cable will be damaged.
• Ensure that the plug remains readily
accessible. Do not use a multiple adapter or
an extension cable.
• The electrical specifications of your appliance
is given on the rating label located inside the
appliance.
• Route power cable to allow easy connection
and disconnection after installation.
• A contact separator should be used if the
power cable is not accessible. (for built-in
models)
2
en en
3
Get to know your appliance
Warning
Below information about accessories are
supplied only for reference. Below accessories
may not be exactly same as the accessories
of your appliance.
A)
B) Fridge compartment
Freezer compartment
Fig. 1
3
Interior light
Thermostat knob
Fan
Adjustable shelves
Defrost water collection channel - Drain
tube
Crisper cover
Salad crisper
Ice bank
Ice box
Freezer compartment
Air grille
Adjustable front feet
Adjustable door shelves
Egg tray
Bottle shelf
Water dispenser
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
12.
13.
14.
15.
16.
How to use the accessories
Water dispenser
Water dispenser is a very useful feature to
obtain chilled water without opening the door
of your fridge. Since you do not have to open
the door of your fridge frequently, you also
save on electricitiy.
Using the water dispenser (Fig. 6)
Push in the lever of the water dispenser with
your glass. By releasing the lever, you cut off
the dispensing.
When operating the water dispenser,
maximum flow is achieved by fully depressing
the lever. Please note, the rate of water flow
from the dispenser depends on how far you
depress the lever. As the level of water in your
cup / glass rises, gently reduce the amount of
pressure on the lever to avoid overflow. If you
depress the lever a small amount, then water
will trickle; this is perfectly normal and is not a
fault.
Filling the tank of the water dispenser
(Fig. 7)
Open the cap of the water tank as illustrated
in the figure. Fill with pure and clean drinking
water. Close the cap.
To avoid accidental water dispensing, we
recommend you lock the water dispenser.
Caution!
• Do not fill the water tank with liquid other than
drinking water. Beverages such as fruit juice,
carbonated fizzy soda drinks and alcoholic
drinks are not suitable for use with water
dispenser. If such liquids are used, the water
dispenser will malfunction and may be damaged
beyond repair. The guarantee does not cover
such uses. Some chemical ingredients and
additives in such drinks / beverages may also
attack and damage water tank material.
• Only use clean pure drinking water.
• Capacity of water dispenser tank is 2.2 litres
[3.8 pints], do not overfill.
• Push the water dispenser lever with a rigid
cup. If you are using a plastic disposable cup,
then push the lever with your fingers from
behind the cup.
• A Safety Lock is supplied for your convenience
and also to prevent small children tampering
with - the water dispenser.
Cleaning the water tank (Fig. 8-9)
Remove the water tank, open the latches on
both sides and detach the top cover
mechanism. Clean with warm clean water,
reinstall the top cover mechanism and fasten
the latches.
When installing the water tank, make sure that
hooks behind it fit securely into the hangers
on the door. Make sure that parts removed
during cleaning (if any) are installed correctly
into their original locations, otherwise, water
may leak.
Important:
Water tank and components of water
dispenser are not dishwasher-proof.
en en
4
4
To avoid accidental water dispensing, we
recommend you lock the water dispenser.
Water tray (Fig. 10)
Water that drips while using the water
dispenser accumulates in the drip tray.
Remove the drip tray by pulling it towards
yourself and empty it from time to time.
Remove the plastic drainer part as shown in
the diagram by pressing down on the edge.
(Fig. 11)
Remove the water valve from the water tank
as shown in the diagram. When re-fitting, make
sure the O-shaped seal is in place. (Fig. 12)
Ice-matic (Fig. 13-14)
Fill the ice-matics with water and put them in
place. Your ice will be ready in about two hours.
It is not necessary to remove the ice-matic In
order to obtain ice; just turn it 90° to the right,
and the ice will drop into the ice-bowl below.
Then take out the ice-bowl to serve the ice. If
you wish, you can leave the ice in the bowl for
a while.
Attention!
The ice-bowl is only meant for collecting ice.
If you put water in, it will break.
1 = Lowest cooling setting (Warmest setting)
5 = Highest cooling setting (Coldest setting)
(Or)
Min. = Lowest cooling setting
(Warmest setting)
Max. = Highest cooling setting
(Coldest setting)
The average temperature inside the fridge
should be around +5°C.
Please choose the setting according to the
desired temperature.
You can stop operation of your device by
adjusting the thermostat knob to “0” position.
Please note that there will be different
temperatures in the cooling area.
The coldest region is immediately above the
vegetable compartment.
The interior temperature also depends on
ambient temperature, the frequency with which
the door is opened and the amount of foods
kept inside.
Frequently opening the door causes the interior
temperature to rise.
For this reason, it is recommended the door
is closed as soon as possible after use.
Setting the operating
temperature
(Fig. 2)
The operating temperature is regulated by the
temperature control.
Prior to startup
Before you begin operating your device, the
following points should be re-checked for
safety:
• Is the device standing properly on the floor?
•Is there sufficient space for good air
circulation?
•Is the interior clean? (Also see the section
“Cleaning and care”)
• Set the thermostat knob half way between
1 and 5 or Min. and Max.
• Now connect the device to the mains.
Warm Cold
1 2 3 4 5
(Or) Min. Max.
The compressor is turned on; the interior light
comes on when the door is opened.
Do not place foodstuff into the refrigerator until
the temperature has reached the desired level.
This manual suits for next models
1
Table of contents
Languages:
Other Beko Refrigerator manuals
Beko
Beko CFP1675W Instruction Manual
Beko
Beko RDSA310K30WN Instruction Manual
Beko
Beko CH234020 User manual
Beko
Beko RFNE320L23S User manual
Beko
Beko CNE63721 DE User manual
Beko
Beko RCSA366K40XBN Instruction Manual
Beko
Beko RCSA366K40DSN Instruction Manual
Beko
Beko CSA24020 User manual
Beko
Beko CNE366E30ZXP User manual
Beko
Beko CHE 42200 User manual
Beko
Beko RDNE420K42X User manual
Beko
Beko DN152240PT User manual
Beko
Beko CNE47520GB User manual
Beko
Beko GN163130ZGB User manual
Beko
Beko RDSE510M21S User manual
Beko
Beko GN163231XB User manual
Beko
Beko CN320E30PI User manual
Beko
Beko GN162341XBN User manual
Beko
Beko HSA 32550 User manual
Beko
Beko CNK321EC0A User manual
