Beko CHE 30000 User manual
Instruction Manual
Bedienungsanleitung
Prietaiso eksploatavimo vadovas
Manuale di istruzioni
GB
D
LT
IT
CHE 30000
Sicurezza iniziale /28
Requisiti elettrici /29
Istruzioni per il trasporto /29
Installation instructions /29
Conoscere l'elettrodomestico /30
Suggerimenti sulla disposizione del cibo
nell'elettrodomestico /30
Controllo e regolazione della
temperatura /31
Prima della messa in funzione /31
Prima della messa in funzione /31
Conservazione di cibo congelato /32
Congelamento di cibo fresco /32
Preparazione dei cubetti di
ghiaccio /32
Sbrinamento /33
Sostituzione della lampadina interna
/33
Pulizia e manutenzione /33
Cosa fare e cosa non fare /34
Risoluzione dei problemi /35
Riposizionamento dello sportello /36
Safety first/1
Electrical requirements/2
Transportation instructions/2
Installation instructions/2-3
Getting to know your appliance/3
Suggested arrangement of
food in the appliance/3-4
Temperature control and adjustment/4
Before operating/4
Storing frozen food/5
Freezing fresh food/5
Making ice cubes/5
Defrosting/6
Replacing the interior light bulb/6
Cleaning and care/6-7
Do’s and don’ts/7-8
Trouble - shooting/8
Repositioning the door/9
1-9
GB Index
Wichtige Sicherheitshinweise/10
Technische Merkmale/10
Elektrische Voraussetzungen/11
Transporthinweise/11
Aufstellen des Geräts/11
Lernen Sie Ihr neues Gerät kennen/12
Empfohlene Lagerung der Lebensmittel
in Ihrem Gerät/12
Temperaturkontrolle und -
einstellung/13
Vor der Inbetriebnahme/13
Lagerung von Tiefkühlkost/14
Frische Lebensmittel tiefkühlen/14
Herstellung von Eiswürfeln/14
Einschub-Staufächer/14
Abtauen/15
Austausch der Glühlampe der
Innenbeleuchtung/15
Reinigung und Pflege/15
Wichtige Hinweise – Bitte
beachten/16
Störungssuche und - behebung/17
Änderung des Türanschlages/18
10-18
DInhalt
19-27
LT
28-36
IT Indice
1
1
3
5
4
7
13
14
10
11
12
9
12
17
15
16
4
8
6
2
16
18
3
5
2
4
6
25
24
1
6
3
17
18
7
9
10
23
22
22
2
45
4
26
19 16
180°
20
19
12
13
11
27
11
14
15
27
45 °
8
21
Instruction ManualGB
1
Congratulations on your choice of a Quality
Appliance, designed to give you many years of service.
Safety first!
Do not connect your appliance to the electricity supply
until all packing and transit protectors have been removed.
• Leave to stand for at least 4 hours before switching
on, to allow compressor oil to settle, if transported
horizontally.
• If you are discarding an old appliance with a lock or
latch fitted to the door, ensure that it is left in a safe
condition to prevent the entrapment of children.
• This appliance must only be used for its intended
purpose i.e. the storing and freezing of edible foodstuff.
• Do not dispose of the appliance on a fire. Your
appliance contains non CFC substances in the insulation
which are flammable. We suggest you contact your local
authority for information on disposal and available
facilities.
• We do not recommend use of this appliance in an
unheated, cold room. (e.g. garage, conservatory, annex,
shed, out-house etc.)
To obtain the best possible performance and trouble free
operation from your appliance it is very important to
read these instructions carefully. Failure to observe these
instructions may invalidate your right to free service
during the guarantee period.
Please keep these instructions in a safe place for easy
reference.
Instruction ManualGB
2
Electrical requirements
Before inserting the plug into the wall socket
make sure that the voltage and the frequency
shown in the rating plate inside the appliance
corresponds to your electricity supply.
Ensure that the plug remains readily accessible.
Do not use multiple adapter bar or extension
cable.
Warning! This appliance must be
earthed.
Repairs to electrical equipment should only be
performed by a qualified technician. Incorrect
repairs carried out by an unqualified person
carry risks that may have critical consequences
for the user of the appliance.
• Do not dispose of the appliance on a fire.
At , the care and protection of our
environment is an ongoing commitment. This
appliance which is among the latest range
introduced is particularly environment friendly.
Your appliance contains non CFC/HFC natural
substances in the cooling system (called R600a)
and the insulation (called cyclopentane) which
are potentially flammable if exposed to fire.
Therefore, take care not to damage, the cooling
circuit/ pipes of the appliance in transportation
and in use. In case of a damage do not expose
the appliance to fire, potential ignition source
and immediately ventilate the room where the
appliance is situated.
• We suggest you contact your local authority
for disposal information and facilities available.
WARNING- Keep ventilation openings, in the
appliance enclosure or in the built-in structure,
clear of obstruction.
WARNING- Do not use mechanical devices
or other means to accelerate the defrosting
process, other than those recommended by the
manufacturer.
WARNING- Do not damage the refrigerant
circuit.
WARNING- Do not use electrical appliances
inside the food storage compartments of the
appliance, unless they are of the type
recommended by the manufacturer.
Transportation
instructions
1. The appliance should be transported only
in upright position. The packing as supplied
must be intact during transportation.
2. If during the course of transport the appliance,
has been positioned horizontally, it must not
be operated for at least 4 hours, to allow the
system to settle.
3. Failure to comply with the above instructions
could result in damage to the appliance, for
which the manufacturer will not be liable for.
4. The appliance must be protected against
rain, moisture and other atmospheric influences.
Important!
• Care must be taken while cleaning/carrying
the appliance not to touch the bottom of the
condenser metal wires at the back of the
appliance, as this could cause injury to fingers
and hands.
• Do not attempt to sit or stand on top of your
appliance as it is not designed for such use.
You could injure yourself or damage the
appliance.
• Make sure that the mains cable is not caught
under the appliance during and after moving,
as this could damage the cable.
• Do not allow children to play with the
appliance or tamper with the controls.
Installation instructions
1. Do not keep your appliance in a room where
the temperature is likely to fall below 10 º C
(50 º F) at night and/or especially in winter,
as it is designed to operate in ambient
temperatures between +10 and +32 º C (50
and 90 º F). At lower temperatures the appliance
may not operate, resulting in a reduction in the
storage life of the food.
2. Do not place the appliance near cookers
Instruction ManualGB
3
Suggested arrangement
of food in the appliance
Guidelines for obtaining optimum storage and
hygiene:
1. The fridge compartment is for the short-term
storage of fresh food and drinks.
2. The freezer compartment is rated
and suitable for the freezing and storage of
pre-frozen food. The recommendation for
storage as stated on the food packaging
should be observed at all times.
3. Dairy products should be stored in the special
compartment provided in the door liner.
4. Cooked dishes should be stored in airtight
containers.
5. Fresh wrapped products can be kept on the
shelf. Fresh fruit and vegetables should be
cleaned and stored in the crisper bins.
6. Bottles can be kept in the door section.
7. To store raw meat, wrap in polythene bags
and place on the lowest shelf. Do not allow to
come into contact with cooked food, to avoid
contamination. For safety, only store raw meat
for two to three days.
8. Do not keep vegetable oil on door shelves.
Keep the food packed, wrapped or covered.
Allow hot food and beverages to cool before
refrigerating. Leftover canned food should not
be stored in the can.
9. Fizzy drinks should not be frozen and
products such as flavoured water ices should
not be consumed too cold.
10. Some fruit and vegetables suffer damage
if kept at temperatures near 0°C. Therefore
wrap pineapples, melons, cucumbers, tomatoes
and similar produce in polythene bags.
11. High-proof alcohol must be stored upright
in tightly closed containers. Never store products
that contain an inflammable propellant gas
(e.g. cream dispensers, spray cans, etc.) or
explosive substances. These are an explosion
hazard.
Front panel
Interior light
Thermostat knob
Movable shelves
Wine rack
Defrost water collection channel - Drain
tube
Crisper cover
Salad crisper
Ice bank
Fast freeze compartment
Freezer fan
Freezer compartment
Air grille
Adjustable front feet
Dairy compartment
Adjustable door shelves
Egg tray
Sliding storage boxes
Getting to know your
appliance
(Fig. 1)
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
12.
13.
14.
15.
16.
17.
18.
or radiators or in direct sunlight, as this will
cause extra strain on the appliance's functions.
If installed next to a source of heat or freezer,
maintain the following minimum side clearances:
From Cookers 30 mm
From Radiators 300 mm
From Freezers 25 mm
3. Make sure that sufficient room is provided
around the appliance to ensure free air
circulation.
• Put the back airing lid to the back of your
refrigerator to set the distance between the
refrigerator and the wall.
4. The appliance should be positioned on a
smooth surface. The two front feet can be
adjusted as required. To ensure that your
appliance is standing upright adjust the two
front feet by turning clockwise or anti-clockwise,
until firm contact is secured with the floor.
Correct adjustment of feet prevents excessive
vibration and noise.
5. Refer to "Cleaning and Care" section to
prepare your appliance for use.
Instruction ManualGB
4
Temperature control and
adjustment
Operating temperatures are controlled by the
thermostat knob (Fig. 2) and may be set at
any position between 1 and 5 (the coldest
position).
The average temperature inside the fridge
should be around +5°C (+41°F).
Therefore adjust the thermostat to obtain the
desired temperature. Some sections of the
fridge may be cooler or warmer (such as salad
crisper and top part of the cabinet) which is
quite normal. We recommend that you check
the temperature periodically with a thermometer
to ensure that the cabinet is kept to this
temperature. Frequent door openings cause
internal temperatures to rise, so it is advisable
to close the door as soon as possible after use.
Before operating
Final Check
Before you start using the appliance check that:
1. The feet have been adjusted for perfect
levelling.
2. The interior is dry and air can circulate freely
at the rear.
3. The interior is clean as recommended under
"Cleaning and care.”
4. The plug has been inserted into the wall
socket and the electricity is switched on. When
the door is open the interior light will come on.
And note that:
5. You will hear a noise as the compressor
starts up. The liquid and gases sealed within
the refrigeration system may also make some
(noise), whether the compressor is running or
not. This is quite normal.
6. Slight undulation of the top of the cabinet
is quite normal due to the manufacturing process
used; it is not a defect.
7. We recommend setting the thermostat knob
midway and monitor the temperature to ensure
the appliance maintains desired storage
temperatures (See section Temperature Control
and Adjustment).
8. Do not load the appliance immediately it is
switched on. Wait until the correct storage
temperature has been reached. We recommend
checking the temperature with an accurate
thermometer (see; Temperature Control and
Adjustment).
Table of contents
Languages:
Other Beko Refrigerator manuals
Beko
Beko CSA300M20X User manual
Beko
Beko RCNA365E40XP User manual
Beko
Beko RSSE265K20W User manual
Beko
Beko CNA365E20P Instruction Manual
Beko
Beko FN 121920 User manual
Beko
Beko DN156220DE User manual
Beko
Beko FSE1175N User manual
Beko
Beko RDSA310M20X Instruction Manual
Beko
Beko CSG4571W User manual
Beko
Beko RCHE300K30WN User manual
Beko
Beko CSA270K30XP Instruction Manual
Beko
Beko BU 1200 HCA User manual
Beko
Beko B1RCHE363W User manual
Beko
Beko RCNA400E31ZW Instruction Manual
Beko
Beko RSSE445K31XBN User manual
Beko
Beko RDSE535MSX User manual
Beko
Beko GNE V422 X User manual
Beko
Beko RFNE 270 L23 W User manual
Beko
Beko CSA30010 User manual
Beko
Beko CDA 648 F User manual
