Behringer Eurolive B212 User manual

EUROLIVE B212

Version 1.2 May 2006

Technical Specifications

EUROLIVE B212

B212

500-Watt 2-Way PA Speaker System with 12" Woofer and 1.75" Compression Driver

VHigh-power 2-Way PA sound reinforcement speaker system for live and playback applications (125 Watts

Continuous / 500 Watts Peak Power)

VUltra-compact and lightweight system delivers excellent sound even at extreme sound pressure levels

VExtremely powerful 12" long-excursion driver provides incredible deep bass and acoustic power

VState-of-the-art 1.75" diaphragm compression driver for exceptional high-frequency reproduction

VUltra-wide dispersion, large-format exponential/conical horn

VOverload-protection circuitry ensures optimal HF driver protection

VVersatile trapezoidal enclosure design allows different positioning:

- Stand mounting with 35-mm pole socket

- Tilts on its side for use as a floor monitor

VErgonomically shaped handles for easy carrying and setup

V2 professional speaker connectors (compatible to Neutrik®Speakon®) plus 1/4'' jack connectors*

VHigh-quality components and exceptionally rugged construction ensure long life

VConceived and designed by BEHRINGER Germany

* All trademarks mentioned belong to their respective owners and are not affiliated with BEHRINGER®.

EUROLIVE

EUROLIVE B212

SPECIFICATIONS

SYSTEM DATA

High-performance woofer

B212: 12" (305 mm)

Tweeter compression driver

B212 1.75" (44 mm)

Frequency range

B212: 65 Hz to 18 kHz

Power rating (Peak Program)

B212: 500 W

(125 Watts Continuous)

Impedance

B212 8 Ω

Sensitivity (1 W @ 1 m)

B212: 93 dB (Full Space)

Dispersion

B212: 90° x 60°

Crossover frequency

B212: 2.5 kHz

DIMENSIONS/WEIGHT

Dimensions (HxWxD)

B212: approx. 21 2/3" x

13 5/8" x 10 5/8"

(approx. 550 mm x

345 mm x 270 mmm)

Weight

B212: approx. 23.2 lbs.

(approx. 10.5 kg)

BEHRINGER is constantly striving to maintain the highest professional standards. As a result

of these efforts, modifications may be made from time to time to existing products without prior

notice. Specifications and appearance may differ from those listed or illustrated.

7. SPECIFICATIONS

EUROLIVE B212

Technical specifications and appearance subject to change without notice. The information contained herein is correct at the time of

printing. The names of companies, institutions or publications pictured or mentioned and their respective logos are registered trademarks

of their respective owners. Their use neither constitutes a claim of the trademarks by BEHRINGER nor affiliation of the trademark

owners with BEHRINGER. BEHRINGER accepts no liability for any loss which may be suffered by any person who relies either wholly

or in part upon any description, photograph or statement contained herein. Colours and specification may vary slightly from product.

Products are sold through our authorised dealers only. Distributors and dealers are not agents of BEHRINGER and have absolutely no

authority to bind BEHRINGER by any express or implied undertaking or representation. No part of this manual may be reproduced or

transmitted in any form or by any means, electronic or mechanical, including photocopying and recording of any kind, for any purpose,

without the express written permission of BEHRINGER Spezielle Studiotechnik GmbH. BEHRINGER®is a registered trademark.

Hanns-Martin-Schleyer-Str. 36-38, 47877 Willich-Münchheide II, Germany.

Tel. +49 2154 9206 0, Fax +49 2154 9206 4903

8. WARRANTY
