Behringer Virtualizer Pro DSP2024P User manual

Technical Specifications

ENGLISH

VIRTUALIZER PRO DSP2024P

Version 1.1 January 2005

VIRTUALIZER PRO DSP2024P

DSP2024P

VIRTUALIZER PRO

High-Performance 24-Bit Mu ti-Engine Effects Processor

s71 reathtaking new algorithms, most in true stereo

sWave-adaptive VIRTUAL ROOM rever algorithms for ultra-natural rever and delay

sAwesome modulation, dynamic, psychoacoustic and EQ algorithms

sInnovative amp simulation, distortion and special effects

s11 effect com inations with selecta le serial/parallel configuration

sUp to 7 adjusta le parameters plus HI and LO EQ per effect

sHigh-resolution 24- it A/D and D/A converters with 64/128-times oversampling

sTrue stereo processing for realistic channel separation in stereo image

s24- it internal signal processing, professional 46 kHz sample rate

s100 factory presets plus 100 user memory locations

sExtensive MIDI implementation

sPrecise 8-segment LED level meters

sInternal power supply for professional applications

sServo- alanced XLR and 1/4" TRS inputs and outputs

sConceived and designed y BEHRINGER Germany

VIRTUALIZER PRO DSP2024P

8. SPECIFICATIONS

ANALOG INPUTS

Connectors XLR and 1/4" TRS

Type RF filtered, servo- alanced input stage

Impedance 80 kΩ alanced

Nominal Operating Level -10 dBV or +4 dBu (selecta le)

Max. Input Level +15 dBu at +4 dBu nominal level, +1 dBV at -10 dBV nominal level

ANALOG OUTPUTS

Connectors XLR and 1/4" TRS

Type Electronically servo- alanced output stage

Impedance 80 Ω alanced

Max. Output Level +15 dBu at +4 dBu nominal level, +1 dBV at -10 dBV nominal level

SYSTEM SPECIFICATIONS

Bandwidth 20 Hz to 20 kHz, +/- 3 dB

SNR 91 dB, unweighted, 20 Hz to 20 kHz

THD 0.018 % typ. @ +4 dBu, 1 kHz, 0 dBu input, gain 1

Crosstalk < -76 dB

MIDI INTERFACE

Type 5-pin DIN-socket IN / OUT / THRU

DIGITAL PROCESSING

Converters 24- it Sigma-Delta, 64/128-times oversampling

Sampling Rate 46.875 kHz

DISPLAY

Type 4-digit 14 segment alpha-numeric LED-Display

POWER SUPPLY

Voltage USA/Canada

120 V~, 60 Hz

Europe/U.K./Australia

230 V~, 50 Hz

Japan

100 V~, 50 - 60 Hz

General export model

120/230 V~, 50 - 60 Hz

Fuse 100 - 120 V~: T 200 mA H 250 V

200 - 240 V~: T 100 mA L 250 V

Power Consumption 15 Watts max.

Mains Connection Standard IEC receptacle

PHYSICAL

Dimensions (H x W x D) 1 3/4" x 19" x 8" (44 mm x 482,6 mm x 204,4 mm)

Net Weight approx. 4 1/2 l s (2 kg)

Shipping Weight approx. 6 2/3 l s (3 kg)

BEHRINGER is constantly striving to maintain the highest professional standards. As a result of these efforts, modifications may be made from time

to time to e isting products without prior notice. Specifications and appearance may differ from those listed or illustrated.

VIRTUALIZER PRO DSP2024P

Technical specifications and appearance subject to change without notice. The information contained herein is correct at the time of printing. The names

of companies, institutions or publications pictured or mentioned and their respective logos are registered trademarks of their respective owners. Their use

neither constitutes a claim of the trademarks by BEHRINGER® nor affiliation of the trademark owners with BEHRINGER®. BEHRINGER® accepts no

liability for any loss which may be suffered by any person who relies either wholly or in part upon any description, photograph or statement contained

herein. Colours and specification may vary slightly from product. Products are sold through our authorised dealers only. Distributors and dealers are not

agents of BEHRINGER® and have absolutely no authority to bind BEHRINGER® by any e press or implied undertaking or representation. No part of this

manual may be reproduced or transmitted in any form or by any means, electronic or mechanical, including photocopying and recording of any kind, for

any purpose, without the e press written permission of BEHRINGER Spezielle Studiotechnik GmbH. BEHRINGER® is a registered trademark.

Hanns-Martin-Schleyer-Str. 36-38, 47877 Willich-Münchheide II, Germany.

Tel. +49 2154 9206 0, Fa +49 2154 9206 4903
