Behringer COMPRESSOR/LIMITER CL9 User manual

COMPRESSOR/LIMITER CL9

Classic Compressor/Limiter Eects Pedal

Thank you for showing your condence in us by purchasing the BEHRINGER COMPRESSOR/LIMITER CL9.

This ultimate eects pedal is specically designed to achieve super-smooth compression and

extended sustain. Thanks to its high-performance features you can compress loud and boost low

signals without degrading the original sound.

A compressor limits the dynamic range of a signal. This means that signal peaks will be attenuated

and the level dierences between loudest and softest playing are reduced. This results in a more

powerful tone.

1. Controls

(1) The ATTACK TIME control determines how fast the compressor responds to input signal peaks.

(2) The LEVEL control adjusts the output level.

(3) The SUSTAIN control determines the amount of compression.

(4) The ON/BATT LED illuminates when the eect is activated. It also serves as a

battery level indicator.

(5) Use the footswitch to activate/deactivate the eect.

(6) Use this ¼" TS IN connector to plug in the instrument cable.

(7) The ¼" TS OUT connector sends the signal to your amp.

Use the DC IN connection to plug in a 9 V power supply (not included).

The BATTERY COMPARTMENT is located underneath the pedal cover. To install or replace the 9 V battery

(not included), press the hinges with a ballpoint pen and remove the pedal cover. Be careful not to

scratch the unit.

(2)

(7)

(3)

(5)

(6)

(1) (4)

COMPRESSOR/LIMITER CL9

◊ The CL9 has no on/o switch. As soon as you insert the plug into the in connector,

the CL9 is on. When not in use, remove the plug from the in connector. This extends

the life of the battery.

The SERIAL NUMBER is located at the underside.

2. Safety Instructions

Do not use near water, or install near heat sources. Use only authorized attachments/accessories.

Do not service product yourself. Contact our qualied servicing personnel for servicing or repairs,

especially when power supply cord or plug is damaged.

3. Warranty

Please register your new BEHRINGER equipment right after your purchase by visiting

http://behringer.com and read the terms and conditions of our warranty carefully.

4. Specications

Connector ¼" TS

Impedance 500 kΩ

Out

Connector ¼" TS

Impedance 1 kΩ

Power Supply

9 V𝌂, 100 mA regulated

BEHRINGER PSU-SB

USA/Canada 120 V~, 60 Hz

Europe/U.K./ 230 V~, 50 Hz

Australia

China 220 V~, 50 Hz

Korea 220 V~, 60 Hz

Japan 100 V~, 50/60 Hz

Power connector 2 mm DC jack,

negative center

Battery 9 V type 6LR61

Power consumption 30 mA

Physical/Weight

Dimensions approx. 2 ⁄ x 2 ¾ x 4 ⁄"

(H x W x D) approx. 54 x 70 x 123 mm

Weight approx. 0.73 lbs / 0.33 kg

BEHRINGER is constantly striving to maintain the

highest professional standards. As a result of these efforts,

modifications may be made from time to time to existing

products without prior notice. Specifications and appearance

may therefore differ from those listed or shown.

MUSIC Tribe accepts no liability for any loss which may be suered by any person who relies either wholly or in part upon any description, photograph, or

statement contained herein. Technical specications, appearances and other information are subject to change without notice. All trademarks are the property of

their respective owners. MIDAS, KLARK TEKNIK, LAB GRUPPEN, LAKE,TANNOY,TURBOSOUND,TC ELECTRONIC, TC HELICON, BEHRINGER, BUGERA and COOLAUDIO
