Behringer STUDIO CONDENSER MICROPHONES C-2 User manual
User Manual
STUDIO CONDENSER
MICROPHONES C-2
2 Matched Studio Condenser Microphones
18 STUDIO CONDENSER MICROPHONES C-2 User Manual
Terminals marked with this symbol
carry electrical current of sucient
magnitude to constitute risk
of electric shock. Useonly high-quality
commercially-available speaker cables
with ¼"TS plugs pre-installed. Allother
installation or modication should be
performed only by qualiedpersonnel.
This symbol, wherever it appears,
alerts you to the presence of
uninsulated dangerous voltage
inside the enclosure -voltage that may be
sucient to constitute a risk ofshock.
This symbol, wherever it appears,
alertsyou to important operating
and maintenance instructions in the
accompanying literature. Please read themanual.
Condenser microphones are
extremely moisture-sensitive.
Never use your microphone in close
proximity to water (e.g. bath tubs, wash basins,
sinks, washing machines, pools, etc.). When doing
voice recordings, always use the enclosed
windscreen to safely protect the capsule
from moisture.
Always use the power
supply specied in the
operating instructions.
Take care not to drop
your microphone as this can
lead to severe damage.
BEHRINGER assumes no liability for any
damage caused by the user.
After each use, wipe the
microphone down with a soft
cloth and place it back into its
protective casing (included with the microphone).
Then, lay the small bag containing the
moisture-absorbing crystals on top of the
microphone head.
Important Safety
Instructions
19 STUDIO CONDENSER MICROPHONES C-2 User Manual
LIMITED WARRANTY
Please register your new BEHRINGER
equipment right after your purchase by visiting
behringer.com and read the terms and conditions
of our warranty carefully.
LEGAL DISCLAIMER
TECHNICAL SPECIFICATIONS AND APPEARANCES
ARE SUBJECT TO CHANGE WITHOUT NOTICE AND
ACCURACY IS NOT GUARANTEED. BEHRINGER IS
PART OF THE MUSIC GROUP (MUSIC-GROUP.COM).
ALL TRADEMARKS ARE THE PROPERTY OF THEIR
RESPECTIVE OWNERS. MUSICGROUP ACCEPTS
NO LIABILITY FOR ANY LOSSWHICH MAY BE
SUFFERED BY ANY PERSONWHO RELIES EITHER
WHOLLY OR IN PART UPON ANY DESCRIPTION,
PHOTOGRAPH OR STATEMENT CONTAINED HEREIN.
COLORS AND SPECIFICATIONS MAY VARY FROM
ACTUAL PRODUCT. MUSIC GROUP PRODUCTS
ARE SOLD THROUGH AUTHORIZED FULLFILLERS
AND RESELLERS ONLY. FULLFILLERSAND
RESELLERS ARE NOT AGENTS OF MUSICGROUP
AND HAVE ABSOLUTELY NO AUTHORITY TO BIND
MUSICGROUP BY ANY EXPRESS OR IMPLIED
UNDERTAKING OR REPRESENTATION.THIS MANUAL
IS COPYRIGHTED. NO PART OF THIS MANUAL
MAY BE REPRODUCED OR TRANSMITTED IN
ANY FORM OR BY ANY MEANS, ELECTRONIC OR
MECHANICAL, INCLUDING PHOTOCOPYING AND
RECORDING OF ANY KIND, FOR ANY PURPOSE,
WITHOUT THE EXPRESSWRITTEN PERMISSION OF
MUSICGROUPIPLTD.
ALL RIGHTS RESERVED.
© 2012 MUSICGroupIPLtd.
Trident Chambers, Wickhams Cay, P.O. Box 146,
Road Town, Tortola, British Virgin Islands
20 STUDIO CONDENSER MICROPHONES C-2 User Manual
1. Introduction
Congratulations! By purchasing the BEHRINGER C-2, you have obtained 2 condenser
microphones that oer the highest quality standards and the best audio characteristics.
Both microphones have been matched to one another (matched pair), and are
therefore particularly well-suited for stereo recordings. Of course, you can also use
the microphones individually.
Their outstanding characteristics make these microphones a valuable tool in the studio and
on the stage.
2. Power Supply
Phantom power (+48V) is required to operate your microphone. We assume no liability
for damage caused to your C-2 through deective phantom power. Before activating
phantom power, mute your playback system and connect the C-2 to the microphone input
of your mixing console. After activating phantom power, the C-2 requires several seconds to
stabilize itself.
3. Pickup Patterns
Both microphones feature a capsule with a cardioid pickup pattern. Microphones with this
polar pattern are most sensitive to sound coming from in front of the microphone, and also
to a lesser extent from the sides. Sound coming from behind the microphone will be greatly
attenuated. This makes the caqrdioid polar pattern most suitable for recording individual
instruments or vocals within a group.
The so-called proximity eect is typical for microphones with the cardioid pickup pattern.
Depending on the distance between the microphone and the sound source, a slight increase
in the lower frequency range occurs. The shorter the distance, the more pronounced
this eect. By cleverly selecting the position and the angle of your microphone, you can
eectively manipulate the proximity eect and thus aect how your recording sounds.
Experiment with various positions in order to gain more experience.
4. Possible Applications
Both microphones have been matched to one another (matched pair). Therefore, they are
particularly well-suited for stereo recordings. Regardless of whether you are miking an
entire ensemble or a single sound source (e.g. drums, piano or background vocals), this pair
of condenser microphones lets you achieve outstanding spatial impressions in every
recording session.
21 STUDIO CONDENSER MICROPHONES C-2 User Manual
Of course, you can use your microphones individually as well. A cardioid pattern capsule
is often used in recording situations in which several sound sources are present. Since this
capsule selectively tones down the pickup of sounds located to the side of the microphone,
this way you can achieve good separation of sound sources, thus easily avoiding feedback.
5. Low Cut-Filter and Signal Level
Attenuation (-10dB)
The C-2 studio microphones feature a switchable low-cut lter that lets you eliminate
low-frequency disturbances such as subsonic noise. Set the switch to its middle position to
activate the low-cut lter.
A switchable level attenuation is provided on your C-2s for applications in which the
microphones are exposed to extremely high sound pressures. When the switch is in its
“−10dB”position, the level attenuation is activated.
When the switch is in its top-most position, the signal is not inuenced in any way.
6. Microphone Installation
To attach the microphones to the microphone stands, two clamps are included with the
delivery. First screw a clamp onto the stand before attacting the microphone itself.
7. Audio Connection
Use a balanced XLR microphone cable with the following pin assignment: pin1=shielding;
pin2=+; pin3=-. Since your C-2 features gold-plated contact points throughout,
we recommend that you use only microphone cables with gold-plated connectors.
8. Level Setting/Adjusting the Basic Sound
Adjust the gain control in the microphone channel of your mixing console so that the peak
LED lights up only occasionally or never at all. The EQ controls in the microphone channel
should be set to mid-travel position to start with; low-cut lter and signal level attenunation
should be switched o. To get the sound you want, try changing the mic position relative to
the sound source or even move the microphone around in the recording room of your studio.
Adjusting the angle at which walls face the sound source can also be helpful. Only when
the desired basic sound has been achieved, should you start to use equalizers and signal
processors, if any at all. Remember: less is often more!
22 STUDIO CONDENSER MICROPHONES C-2 User Manual
0˚ 0˚
30˚30˚
60˚60˚
90˚90˚
120˚120˚
150˚150˚
180˚180˚
0
-10
-20
-30
dB
250 Hz
500 Hz
1 kHz
2 kHz
4 kHz
8 kHz
16 kHz
Polar pattern
-20
-10
10
20
20 50 100 200 500 1k 2k 5k 10k 20k
0
Frequency response
23 STUDIO CONDENSER MICROPHONES C-2 User Manual
9. Specications
Transducer type condenser, 16 mm (0.63'')
Operating principle pressure gradient
Polar pattern cardioid
Connector gold-plated balanced XLR connector
Open circuit sensitivity (@1kHz) −41dBV (0dBV = 1V/Pa)
Frequency response 20Hz to 20kHz
level attenuation −10dB, switchable
Low-cut lter 6dB/oct.@120Hz (switchable)
Max. SPL (≤1%THD@1kHz) 140dB (0dB), 150dB (−10dB)
Equivalent noise level (IEC651) 19dBA
Signal-to-noise ratio 75dB
Nominal impedance 75Ω
Load impedance > 1kΩ
Mains Voltage/Fuse
Supply voltage +48V
Supply current 3mA
Physical/Weight
Dimensions shaft:0.8" / 20mm
length:3.7" / length:94mm
Weight approx. 0.2lbs / 0.09kg
